Trusted Transportation Solutions PocketPass™ Installation Instructions 16-0042-001 Rev A2 PocketPass is designed for mounting to a vehicle's interior windshield surface using 3M™ Dual Lock™ strips. This mounting method provide for easy mounting and removal when portability is needed. General Installation Information Metallized Windshields Some vehicle windshields contain a metallic treatment that could prevent an interior windshield-mounted device from working correctly. If you have a vehicle with a metalized windshield, contact your local customer service center for more information. If your vehicle’s metalized windshield has a metal-free zone, it is typically located near the rearview mirror. Required Supplies • PocketPass • Commercial glass cleaner and paper towels PocketPass Installation and Removal Procedures Installing the PocketPass with Dual Lock Strips 1. Choose the location for your PocketPass (Figure 1). It should be mounted as close to the bottom center of the windshield as possible; at least 3 inches away from the windshield frame or dashboard, and not behind the windshield wipers. Figure 1 – Page 2 Installation Instructions 2. Clean and dry the interior windshield surface completely before affixing the Dual Lock strips. The windshield temperature must be at least 68ºF (20ºC) for optimum bonding. 3. Peel the backing off the Dual Lock strips (Figure 2). Leave both sides of the Dual Lock strips pressed together to ensure the strips will align between the tag and windshield. Apply the PocketPass to the windshield using moderate pressure. Figure 2 – Note: When installing the PocketPass using Dual Lock strips for the first time, leave it in place for at least 24 hours to allow the adhesive to cure. 4. To remove a PocketPass mounted with Dual Lock strips from the windshield, grip the case at the top and bottom sides. Gently lift the PocketPass away from the windshield on one end until the tag is free from the windshield. User Replaceable Batteries Two AAA batteries are pre-installed in your PocketPass. TransCore recommends Energizer® Advanced Lithium AAA batteries for use in the PocketPass. To replace the batteries, remove the tag from the windshield as described in Step 4 on page 2. 1. Hold the tag with the LED side facing down. Locate the battery door. Press the indentation located under the arrow and slide the door in the direction of the arrow to open the door. Page 3 PocketPass Figure 3 – 2. Remove the old batteries and replace them with AAA batteries according to the diagram on the inside of the battery compartment. Figure 4 – 3. Close the cover and slide it back into place. You should hear a soft snap when the cover is in the correct position. 4. You will see a brief audio/visual sequence display as the tag powers up. If there is an ASTM V6 AV code stored, the sequence will take up to 15 minutes to complete. 5. Reinstall the tag on the windshield. Installation Instructions Page 4 NO UNAUTHORIZED MODIFICATIONS STATEMENT Caution: This equipment may not be modified, altered, or changed in any way without permission from TransCore, LP. Unauthorized modification may void the equipment authorization from the FCC and will void the TransCore warranty. RADIO FREQUENCY INTERFERENCE STATEMENTS Note: This device complies with Part 15 of the FCC Rules and the Industry Canada Licence-Exempt RSS Standards. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device. Note: Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur del’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Page 5 PocketPass For more information: Sales Support 800.923.4824 Technical Support 505.856.8007 transcore.com Trusted Transportation Solutions © 2015 TransCore L.P. All rights reserved. TRANSCORE and TRANSSUITE are registered trademarks, and are used under license. All other trademarks listed are the property of their respective owners. Contents subject to change. Printed in the U.S.A.

Amtech Technology Center 8600 Jefferson Street NE Albuquerque, New Mexico 87113 October 06, 2015 TIMCO Engineering Inc. 849 NW State Road 45 P.O. Box 370 Newberry, FL 32669 Re: FIH05946 Additional Information Applicant: Transcore Amtech Technology Center 8600 Jefferson Street, NE Albuquerque, NM 87113 USA Equipment: FCC: FIH05946 To whom it may concern: Item 1. Label: Subpart 1. With regard to feedback indicating that the placement of the label is not clear, the following image is offered. The marking is actually etched into the plastic case with a laser; there is not a label as such. Figure 1 - FIH05946 Marking Diagram Item 1. Label: Subpart 2. To conform to our particular manufacturing process we have chosen to mark the equipment using a laser. The amount of process time at the laser station is directly proportional to the amount of text being applied so we wish to minimize the amount of text as Amtech Technology Center 8600 Jefferson Street NE Albuquerque, New Mexico 87113 much as possible to maintain our throughput efficiency. In addition, although the overall size of the equipment is indeed larger than the palm of a hand, the amount of space available for marking is in fact limited by the necessary placement of hook and loop tape, a battery door, and discontinuities, all of which reduce the amount of contiguous surface area. The full warning statement is included in the installation instructions for this tag so we respectfully request approval for the marking illustrated in this document. Thank you for your consideration in this matter. Sincerely, Chris Wilson Transcore - Amtech Technology Center

September 30, 2015 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Transcore - Amtech Technology Center 8600 Jefferson Street NE Albuquerque, New Mexico 87113 Equipment: FCC ID: FIH05946 FCC Rules: Part 2 and 90 Dear Sirs: Transcore - Amtech Technology Center requests that the following information be withheld from public disclosure pursuant to CFR47 paragraphs 0.457 and 0.459, and KDB 726920 until 180 days after the Grant of Equipment Authorization. Disclosure of information would offer competitors additional unwarranted insight into the state of the product development. Short-term confidential files Exhibit File External Photos 05946 Short Term Conf ExtPho.pdf Internal Photos 05946 Short Term Conf IntPho.pdf Test Setup Photos 05946 Short Term Conf TSup.pdf User Manual 05946 Short Term Conf UserMan.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 +1 913 837-3214

September 30, 2015 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Transcore - Amtech Technology Center 8600 Jefferson Street NE Albuquerque, New Mexico 87113 Re: Confidentiality for submittal information regarding FCC ID number FIH05946 Product: Low Power Transmitter operating under parts 2 and 90 Dear Sirs: Transcore Amtech Technology Center requests that the material in the Parts List, Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Transcore Amtech Technology Center submits the following information. CONFIDENTIAL FILES Block Diagram 05946 Conf BlkDia.pdf Parts List 05946 Conf PartsList.pdf Operational Description 05946 Conf OpDes.pdf Schematics 05946 Conf Schem.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, Parts List, block diagram, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: FIH05946 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, Parts List, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Transcore Amtech Technology Center engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Transcore Amtech Technology Center. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Transcore Amtech Technology Center and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. This equipment is designed for commercial, industrial, and governmental applications. As such, unlike most consumer equipment, this equipment could be used for more than a decade in some cases. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

Rogers Labs, Inc. Transcore Amtech Technology Center S/N: ENG1 4405 W. 259th Terrace Models: 05946 FCC ID#: FIH05946 Louisburg, KS 66053 Test #: 150915a IC: 1584A-05946 Phone/Fax: (913) 837-3214 Test to: 47CFR Parts 2, 90 and RSS-137 Date: September 30, 2015 Revision 1 File: 05946 short Term Conf ExtPho Page 1 of 3 Equipment photographs Rogers Labs, Inc. Transcore Amtech Technology Center S/N: ENG1 4405 W. 259th Terrace Models: 05946 FCC ID#: FIH05946 Louisburg, KS 66053 Test #: 150915a IC: 1584A-05946 Phone/Fax: (913) 837-3214 Test to: 47CFR Parts 2, 90 and RSS-137 Date: September 30, 2015 Revision 1 File: 05946 short Term Conf ExtPho Page 2 of 3 Rogers Labs, Inc. Transcore Amtech Technology Center S/N: ENG1 4405 W. 259th Terrace Models: 05946 FCC ID#: FIH05946 Louisburg, KS 66053 Test #: 150915a IC: 1584A-05946 Phone/Fax: (913) 837-3214 Test to: 47CFR Parts 2, 90 and RSS-137 Date: September 30, 2015 Revision 1 File: 05946 short Term Conf ExtPho Page 3 of 3

11 22 33 44 55 66 77 88 A A B B C C D D DRAWING TITLE DO NOT SCALE DRAWING DRAWING NO. SHEET OF SIZE SCALE AMTECH PROPRIETARY INFORMATION INITIAL DATE Amtech Technology Center 8600 Jefferson Street NE Albuquerque, NM 87113 (505) 856-8000 TOLERANCE UNLESS OTHERWISE SPECIFIED.XX  .XXX  ANGLES (  ) SURFACE DFTRDSGNRCHKRPROJENGRG MFG MATRL QA 05946-00 ASSY, POCKETPASS DUAL POWER N/A 11 JDC 9/3/15 D 7 PACKAGING, POCKETPASS 67142-01 EA .05 .05 .05 6 LABEL, GOANYWHERE PASS, PREPASS 03670-03 EA - - 1 5 LABEL, GOANYWHERE PASS 03670-02 EA - 1 - 4 LABEL, GOANYWHERE PASS, BLANK 03670-01 EA 1 - - 3 FSTNR, DUAL LOCK, 1.25 X 0.50 87031-02 EA 4 4 4 2 ASSY, RADOME, POCKETPASS DUAL POWER 05947-01 EA 1 1 1 1 ASSY, BASE, POCKETPASS 03723-01 EA 1 1 1 Parts List ITEM DESCRIPTION PART NUMBER U/M -01 -02 -03 -04 -05 NOTES: UNLESS OTHERWISE SPECIFIED LASER ETCH AS SHOWN . PACKAGING NOT SHOWN AT THIS LEVEL. REFERENCE 67142-01FOR PACKING DETAIL. REVISIONS REV ECO DESCRIPTION E. DATE I. DATE CHKR. ENGR. DFTR. X1 - PROTOTYPE - JDC - 1 2 456 1 2 3 3 -01 -02 -03 1 2

Rogers Labs, Inc. Transcore Amtech Technology Center S/N: ENG1 4405 W. 259th Terrace Models: 05946 FCC ID#: FIH05946 Louisburg, KS 66053 Test #: 150915a IC: 1584A-05946 Phone/Fax: (913) 837-3214 Test to: 47CFR Parts 2, 90 and RSS-137 Date: October 7, 2015 Revision 1 File: 05946 short Term Conf IntPho Page 1 of 3 Internal photographs Rogers Labs, Inc. Transcore Amtech Technology Center S/N: ENG1 4405 W. 259th Terrace Models: 05946 FCC ID#: FIH05946 Louisburg, KS 66053 Test #: 150915a IC: 1584A-05946 Phone/Fax: (913) 837-3214 Test to: 47CFR Parts 2, 90 and RSS-137 Date: October 7, 2015 Revision 1 File: 05946 short Term Conf IntPho Page 2 of 3 Rogers Labs, Inc. Transcore Amtech Technology Center S/N: ENG1 4405 W. 259th Terrace Models: 05946 FCC ID#: FIH05946 Louisburg, KS 66053 Test #: 150915a IC: 1584A-05946 Phone/Fax: (913) 837-3214 Test to: 47CFR Parts 2, 90 and RSS-137 Date: October 7, 2015 Revision 1 File: 05946 short Term Conf IntPho Page 3 of 3

1 Introduction The 05946 transmitter referred to herein is part of a multi-protocol Radio-Frequency Identification (RFID) transponder. The transmitter is battery-powered, microprocessor- controlled and communicates in the Inter-Agency Group (IAG) and ASTM V6 TDMA protocols. 2 Tune-Up Instructions The 05946 transmitter is manufactured with fixed components and no means for tuning are provided. Transmitters are 100% tested to ensure compliance.

Rogers Labs, Inc. Transcore Amtech Technology Center S/N: ENG1 4405 W. 259th Terrace Model: 05946 FCC ID#: FIH05946 Louisburg, KS 66053 Test #: 150915a IC: 1584A-05946 Phone/Fax: (913) 837-3214 Test to: 47CFR Parts 2, 90 and RSS-137 Date: September 30, 2015 Revision 1 File: 05946 RFExp Page 1 of 1 Transcore 5946Test Number:150915a MPE CalculatorMPE uses EIRP for calculation. EIRP is based on TX power added to the antenna gain in dBi. dBi = dB gain compared to an isotropic radiator. S = power density in mW/cm^2 Antenna Gain (dBi)1 Output PowerdBd + 2.17 = dBidBi to dBd2.2 Tx Frequency (MHz)914.89Maximum (Watts)0.006873Antenna Gain (dBd)-1.17 Cable Loss (dB)0.0(dBm)8.37Antenna minus cable (dBi)1.00 Calculated ERP (mw)5.250EIRP = Po(dBM) + Gain (dB) Calculated EIRP (mw)8.652Radiated (EIRP) dBm9.371 ERP = EIRP - 2.17 dB Occupational Limit Radiated (ERP) dBm7.201 0.6455ƒ0.5 W/m 2 0.90775 W/m 2 General Public Limit 0.02619ƒ0.6834 W/m 2 2.76653 W/m 2 Frequency (MHz)Occupational LimitPublic Limit 300-1,500f/300f/1500 1,500-10,00051 Frequency (MHz) Occupational Limit (W/m 2 )Public Limit (W/m 2 ) 100-6,000 0.6455ƒ 0.5 6,000-15,00050 300-6,000 0.02619ƒ 0.6834 6,000-15,0005010 EIRPSSDistanceDistanceDistanceDistance milliwatts mW/cm 2 W/m 2 cmmeterinchesFeet 8.6520.000090.0008590.000.9035.432.95 8.6520.000110.0010880.000.8031.502.62 8.6520.000140.0014170.000.7027.562.30 8.6520.000190.0019160.000.6023.621.97 8.6520.000280.0027550.000.5019.691.64 8.6520.000430.0043040.000.4015.751.31 8.6520.000770.0076530.000.3011.810.98 8.6520.001720.0172120.000.207.870.66 8.6520.006890.0688510.000.103.940.33 8.6520.008500.085009.000.093.540.30 8.6520.010760.107588.000.0803.150.26 8.6520.014050.140517.000.0702.760.23 8.6520.019130.191256.000.0602.360.20 8.6520.027540.275405.000.0501.970.16 8.6520.043030.430324.000.0401.570.13 8.6520.076500.765013.000.0301.180.10 8.6520.172131.721282.000.0200.790.07 Frequency (MHz) Occupational Limit minimum Distance (meters) Occupational Limit minimum Distance (cm / inches) Public Limit minimum distance (meters) Public Limit minimum distance (cm / inches) 300-1,500N/AN/AN/AN/A 1,500-10,000 FCC radio frequency radiation exposure limits per 1.1310 IC radio frequency radiation exposure limits per RSS-102 Power density (S) EIRP -------= mW/cm^2 4 pr^2 r (cm) EIRP (mW)
