FKGE14ANotebook Computer W/802.11 b/g WLAN Built-In

U U s s e e r r ’ ’ s s M M a a n n u u a a l l Table Of Contents CHAPTER 1 GETTING STARTED 1 Getting Started...................................................................................2 Inventory .............................................................................................3 Safety and Maintenance....................................................................4 Checklists ...........................................................................................5 Features..............................................................................................6 Where to Look For Information.........................................................7 Quick Start..........................................................................................8 Loading Windows ..............................................................................9 Adjusting the Volume......................................................................10 Adjusting the Brightness................................................................10 Turning off Your Computer.............................................................11 Making a Startup Disk......................................................................11 Tips for New Owners.......................................................................11 CHAPTER 2 GETTING STARTED 13 Hardware and Software...................................................................14 Front View .........................................................................................15 Left View............................................................................................16 Right View .........................................................................................17 Bottom View......................................................................................18 LED Status Indicators......................................................................19 Power Indicators..............................................................................20 Function Keys ..................................................................................20 Numeric Keypad...............................................................................21 Touchpad..........................................................................................21 Connecting the Floppy Disk Drive .................................................23 Disk Drives........................................................................................23 The CD-ROM, DVD-ROM, Combo Drive, or DVD±RW...................24 Connecting the Printer ....................................................................26 The PCMCIA Card Slot.....................................................................26 ii Memory..............................................................................................27 The Graphics System......................................................................28 Communication Components .........................................................32 Information about the Wireless LAN button..................................33 CHAPTER 3 MAKING CONNECTIONS 35 Making Connections........................................................................36 Left Side Connectors .......................................................................36 Right Side Connectors ....................................................................37 Front Side Connectors ....................................................................38 CHAPTER 4 SYSTEM SOFTWARE 39 System Software..............................................................................40 System Recovery .............................................................................41 CHAPTER 5 POWER MANAGEMENT 45 Power Management.........................................................................46 Power Saving Modes.......................................................................48 Power Saving Tips...........................................................................50 When to Replace the Battery ..........................................................50 Heat Considerations........................................................................51 CHAPTER 6 USING THE BIOS SETUP UTILITY 53 Using the BIOS Setup Utility ...........................................................54 Navigating and Entering Information in BIOS...............................55 The Main Menu.................................................................................56 Advanced Menu ...............................................................................57 Boot Menu.........................................................................................58 Security Menu...................................................................................59 Change Supervisor Password: .......................................................60 Change User Password...................................................................60 Exit Menu..........................................................................................62 APPENDIX A iii FREQUENTLY ASKED QUESTIONS 63 Frequently Asked Questions..........................................................64 APPENDIX B STATEMENTS 67 Statements........................................................................................68 European Notice...............................................................................71 UL CAUTION.....................................................................................71 Canadian Department of Communications...................................72 Battery Disposal...............................................................................73 CAUTION FOR ADAPTER................................................................73 BATTERY CAUTION.........................................................................73 CLASS 1 LASER PRODUCT..............…

Text truncated - open the document above for the full version.

Chris Harvey From: [email protected] Sent: Friday, June 04, 2004 2:30 PM To: Chris Harvey Cc: '[email protected]'; Mike Kuo; [email protected]; [email protected] Subject: ??: Additional Information Needed AN04T3925 FCC ID: FKGE14A Page 1 of 2 6/5/2004 Hi Chris, Here are our replies to your questions. 1. The schematics appear only to be for the computer and do not cover the RF MiniPCI card. Please provide schematic diagrams for the RF transmitter. Reply: The RF transmitter is attached. 2. The Operational Description provided is just a drawing. Please provide an operational description that meets the following FCC requirements: 2.1033(b)(4) A brief description of the circuit functions of the device along with a statement describing how the device operates. This statement should contain a description of the ground system and antenna, if any, used with the device. Reply: A revised operational description is provided. 3. The Users Manual exhibit did not include any RF Exposure information for the user. Please see your previous FCC Certification documentation for FCC ID: FKGR15B for an example of an acceptable statement for this device. Reply: The user manual is updated. Please refer to the attached. I hope the above would conclude your review and receive your grant soon. Thank you. Best Rgds, WK Dear CCS: I have reviewed the application for the device listed above. The following items must be corrected before the Chris Harvey <charvey- [email protected]> 2004/06/04 05:20 PM ¦¬¥ó¤H¡G "'[email protected]'" <[email protected]>, "'[email protected]'" <[email protected]> °Æ¥»§Û°e¡G Mike Kuo <[email protected]> ¥D¦®¡G Additional Information Needed AN04T3925 FCC ID: FKGE14A review can continue: 1. The schematics appear only to be for the computer and do not cover the RF MiniPCI card. Please provide schematic diagrams for the RF transmitter. 2. The Operational Description provided is just a drawing. Please provide an operational description that meets the following FCC requirements: 2.1033(b)(4) A brief description of the circuit functions of the device along with a statement describing how the device operates. This statement should contain a description of the ground system and antenna, if any, used with the device. 3. The Users Manual exhibit did not include any RF Exposure information for the user. Please see your previous FCC Certification documentation for FCC ID: FKGR15B for an example of an acceptable statement for this device. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Chris Harvey [email protected] Page 2 of 2 6/5/2004

Compliance Certification Services Inc. Report No: B40405001 Date of Issue: May 10, 2004 Page 1 of 8 EXTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: B40405001 Date of Issue: May 10, 2004 Page 2 Compliance Certification Services Inc. Report No: B40405001 Date of Issue: May 10, 2004 Page 3 Compliance Certification Services Inc. Report No: B40405001 Date of Issue: May 10, 2004 Page 4

Color Requirement: P Corporation Design E14A-FCC LABEL FOR SYSTEM NoteBackground(N222sample) Font R2*3 116.5 0.25 0 9 9 . 5 9 9 . 5 0 . 2 5 0 . 2 5 00 L Wen Fu Chieng R

Compliance Certification Services Inc. Report No: B40405001 Date of Issue: May 10, 2004 Page 5 INTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: B40405001 Date of Issue: May 10, 2004 Page 6 Compliance Certification Services Inc. Report No: B40405001 Date of Issue: May 10, 2004 Page 7 Compliance Certification Services Inc. Report No: B40405001 Date of Issue: May 10, 2004 Page 8

Well Green Technology Co., Ltd 2004/4/13 1 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt RD Manager Supervisor RD en gineer Sales engineer David Johnson Tim Jerry TWINHEAD E14A Antenna Test Report Well Green Technology Co., Ltd 2004/4/13 2 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt Antenna Testing Conditions: 1. Testing set up: LCD OPEN LCD CLOSE 600 cm HORN Standard Antenna R3767CG Network Analyzer Rotator Controller Radiation Pattern Testing - Anechoic Chamber DUT Antenna Clockwise Well Green Technology Co., Ltd 2004/4/13 3 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 2. Mechanical dimensions Antenna E14A Cable φ 1.13 Wireless LAN Right up Antenna E14A Cable φ 1.13 Wireless LAN Left up Well Green Technology Co., Ltd 2004/4/13 4 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt Test results-Left 1.VSWR Antenna Application Cable dia. Φ mm E14A Wireless 1.13 VSWR Antenna Center freg. @MHz BW @MHz 2.4GHz 2.45GHz 2.5GHz E14A 2450 1.23 1.13 1.17 Well Green Technology Co., Ltd 2004/4/13 5 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 2. Return Loss Return Loss Antenna Center freg. @MHz BW @MHz 2.4GHz 2.45GHz 2.5GHz E14A 2450 -19.62 -23.89 -22.81 Well Green Technology Co., Ltd 2004/4/13 6 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 3. Smith Chart Well Green Technology Co., Ltd 2004/4/13 7 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 4. Radiation Pattern of XY Plane (Azimuth)-2.414GHz 0 90 180 270 Well Green Technology Co., Ltd 2004/4/13 8 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 5. Radiation Pattern of XY Plane (Azimuth)-2.442GHz 0 90 180 270 Well Green Technology Co., Ltd 2004/4/13 9 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 6. Radiation Pattern of XY Plane (Azimuth)-2.484GHz 0 90 180 270 Well Green Technology Co., Ltd 2004/4/13 10 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 7. Peak Gain and Average Gain Gain of XY Plane (Azimuth) Antenna Polarization 2.414GHz-L Peak -0.01 V Average -5.92 Peak -1.66 H Average -6.83 Peak 1.31 E14A H+V Average -3.34 Gain of XY Plane (Azimuth) Antenna Polarization 2.442GHz-L Peak 0.02 V Average -5.92 Peak -2.02 H Average -6.82 Peak 1.20 E14A H+V Average -3.44 Gain of XY Plane (Azimuth) Antenna Polarization 2.484GHz-L Peak -1.80 V Average -6.11 Peak -2.15 H Average -7.05 Peak 0.03 E14A H+V Average -3.54 Well Green Technology Co., Ltd 2004/4/13 11 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt Test results-Right 1.VSWR Antenna Application Cable dia. Φ mm E14A Wireless 1.13 VSWR Antenna Center freg. @MHz BW @MHz 2.4GHz 2.45GHz 2.5GHz E14A 2450 1.42 1.45 1.57 Well Green Technology Co., Ltd 2004/4/13 12 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 2. Return Loss Return Loss Antenna Center freg. @MHz BW @MHz 2.4GHz 2.45GHz 2.5GHz E14A 2450 -15.06 -14.64 -12.95 Well Green Technology Co., Ltd 2004/4/13 13 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 3. Smith Chart Well Green Technology Co., Ltd 2004/4/13 14 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 4. Radiation Pattern of XY Plane (Azimuth)-2.414GHz 0 90 180 270 Well Green Technology Co., Ltd 2004/4/13 15 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 5. Radiation Pattern of XY Plane (Azimuth)-2.442GHz 0 90 180 270 Well Green Technology Co., Ltd 2004/4/13 16 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 6. Radiation Pattern of XY Plane (Azimuth)-2.484GHz 0 90 180 270 Well Green Technology Co., Ltd 2004/4/13 17 No. 20, Alley51 ,Lane 118,ShuangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 wgt 7. Peak Gain and Average Gain Gain of XY Plane (Azimuth) Antenna Polarization 2.414GHz-R Peak -0.67 V Average -5.78 Peak -1.46 H Average -5.81 Peak 1.05 E14A H+V Average -2.78 Gain of XY Plane (Azimuth) Antenna Polarization 2.442GHz-R Peak -0.74 V Average -5.84 Peak -1.27 H Average -6.13 Peak 0.55 E14A H+V Average -2.97 Gain of XY Plane (Azimuth) Antenna Polarization 2.484GHz-R Peak -1.45 V Average -6.18 Peak -2.07 H Average -7.21 Peak -0.18 E14A H+V Average -3.65

Compliance Certification Services Inc. Report No: B40405001-RP FCC ID:FKGE14A Date of Issue: May 7, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 69 FCC 47 CFR PART 15 SUBPART C TEST REPORT For TWINHEAD INTERNATIONAL CORP. Notebook built-in b/g WLAN Module Model: E14A Trade Name: Twinhead Prepared for TWINHEAD INTERNATIONAL CORP. 10F, No. 550, Rueiguang Rd., Neihu, Taipei, Taiwan, 114, R.O.C. Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: B40405001-RP FCC ID: FKGE14A Date of Issue: May 7, 2004 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION...................................................................................................................5 3.2 EUT EXERCISE...............................................................................................................................5 3.3 GENERAL TEST PROCEDURES........................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS...................................................6 3.5 DESCRIPTION OF TEST MODES......................................................................................................6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES ....................................................................................................................................8 5.2 EQUIPMENT...................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING.............................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS..................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 10 6.1 SETUP CONFIGURATION OF EUT..................................................................................................10 6.2 SUPPORT EQUIPMENT ..........................................................................................................10 7. FCC PART 15.247 REQUIREMENTS...................................................................................... 11 7.1 6DB BANDWIDTH........................................................................................................................11 7.2 PEAK POWER...............................................................................................................................17 7.3 BAND EDGES MEASUREMENT ...........................................................................................23 7.4 PEAK POWER SPECTRAL DENSITY...............................................................................................33 7.5 RADIO FREQUENCY EXPOSURE...................................................................................................39 7.6 SPURIOUS EMISSIONS ...........................................................................................................42 7.7 POWERLINE CONDUCTED EMISSIONS..........................................................................................64 Compliance Certification Services Inc. Report No: B40405001-RP FCC ID: FKGE14A Date of Issue: May 7, 2004 Page 4 2. EUT DESCRIPTION Product Notebook built-in b/g WLAN Module Trade Name Twinhead Model Number E14A Model Discrepancy N/A Power Supply Powered by an AC/DC power adapter Model Number: LSE9802A2060 I/P: AC 100-240V, 50/60Hz, 1.5A O/P: DC 20V, 3.0A Frequency Range 2412 ~ 2462 MHz Transmit Power (mean EIRP) 802.11b mode: 18.99 dBm 802.11g mode: 16.97 dBm Modulation Technique 802.11b: DSSS (CCK; DQPSK; DBPSK) 802.11g: OFDM Transmit Data Rate 802.11b: 11Mbps(CCK) with fall back rates of 5.5, 2, and 1Mbps 802.11g: 54Mbps with fall back rates of 48/36/24/18/12/9/6Mbps (OFDM) Number of Channels 11 Channels Antenna Specification Printed-on-board antenna Gain: 1.31 dBi (Max) Temperature Range 0 ~ + 55°C Note: This submittal(s) (test report) is intended for FCC ID: FKGE14A filing to comply with Section 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No: B40405001-RP FCC ID: FKGE14A Date of Issue: May 7, 2004 Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, and 15.247. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT (Notebook built-in b/g WLAN Module) was operated in the engineering mode to fix the TX frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.247 under the FCC Rule…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: B40405001-RP FCC ID: FKGE14A Date of Issue: May 7, 2004 Page 68 APPENDIX 1 PHOTOGRPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No: B40405001-RP FCC ID: FKGE14A Date of Issue: May 7, 2004 Page 69 Conducted Emission Set Up Photos
