TWINHEAD INTERNATIONAL CORP. Declaration of Product differentiation The different of the each model is shown as below: Model xTablet®T7200 Fieldbook A2 Trademark MobileDemand LOGIC INSTRUMENT Button Apendix A Apendix B PC Board T7QD1-PCB T7QD1-PCB Model T7Q a7360X a7380X Trademark DURABOOK tabletkiosk tabletkiosk Button Apendix C Apendix C Apendix C PC Board T7QD1-PCB T7QD1-PCB T7QD1-PCB Signature: Date: 2012/06/18 James Lai / Manager 10F, No.550, Rueiguang Rd., Neihu Chic Taipei 114 Taiwan [email protected] TWINHEAD INTERNATIONAL CORP. Apendix A Front View No. Item Description 1 Light sensor Use to detect the current level of visible light in the surrounding environment. 2 Status Indicators (Power, Battery, HDD, Wireless) Indicate the corresponding function status. 3 Speaker Emit sound. 4 Power Press to power on and off the tablet PC. Yellow Key Press to trigger the Barcode scan function, or it can be customized for launching specific Win-base program assigned in Quick Menu. Blue Key Press to activate the Camera function. Backspace Key Go back to the previous context Numeric Key Including 0~9 Enter Press to emulate the Enter key. 123 4 TWINHEAD INTERNATIONAL CORP. No. Item Description Tab Press to emulate the Tab key. Arrow (up) Press to emulate the Up key. Arrow (down) Press to emulate the Down key. Arrow (left) Press to emulate the Left key. Arrow (right) Press to emulate the Right key. Fn+Arrow (up) Press to emulate the volume up Fn+Arrow (down) Press to emulate the volume down Fn+Arrow (left) Press to emulate the brightness up Fn+Arrow (right) Press to emulate the brightness down Fn +4 Key Pad backlight on / off switcher Fn + 7 Press to rotate the display Fn + 8 Press to activate wireless LAN or Bluetooth communication Fn + 9 Esc Key Fn+0 (Stealth mode) Press to disable all emitting lights and sound. Security Press to exit Windows and enter SAS (Secure Attention Sequence) mode. Fn (Function) Press to emulate NumLock key. n NOTE When the numerical mode is activated, the keypad backlight lights on. If the keypad is left idle for 60 seconds, the backlight will automatically turn off. Right View 123 TWINHEAD INTERNATIONAL CORP. No. Item Description 1 Serial port (RS-232) Connect a peripheral device, such as a printer or other device with serial port. 2 RJ-45 Connect LAN. 3 USB port Connect USB peripheral devices. Apendix B Front View No. Item Description 1 Light sensor Use to detect the current level of visible light in the surrounding environment. 2 Status Indicators (Power, Battery, Indicate the corresponding function status. 1 2 3 4 TWINHEAD INTERNATIONAL CORP. No. Item Description HDD, Wireless) 3 Speaker Emit sound. 4 Power Press to power on and off the tablet PC. 5 Security Press to exit Windows and enter SAS (Secure Attention Sequence) mode. 6 Fn Press to emulate function key. 7 Direction (up) Press to emulate the Up key. 8 Direction (left) Press to emulate the Left key. 9 Direction (right) Press to emulate the Right key. 10 Direction (down) Press to emulate the Down key. 11 Fn + Direction(up) volume up 12 Fn + Direction(left) volume down 13 Fn + Direction(right) brightness up 14 Fn + Direction(down) brightness down Right View No. Item Description I/O A 1 Serial port (RS-232) Connect a peripheral device, such as a printer or other device with serial port. 2 USB ports Connect USB peripheral devices. I/O A I/O 123 TWINHEAD INTERNATIONAL CORP. I/O B 1 Serial port (RS-232) Connect a peripheral device, such as a printer or other device with serial port. 2 RJ-45 Connect LAN 3 USB port Connect USB peripheral devices. Apendix C Front View No. Item Description 1 Light sensor Use to detect the current level of visible light in the surrounding environment. 2 Status Indicators (Power, Battery, HDD, Wireless) Indicate the corresponding function status. 3 Speaker Emit sound. 4 Power Press to power on and off the tablet PC. TWINHEAD INTERNATIONAL CORP. No. Item Description 5 Scanner Press to trigger the Barcode scan function. 6 Camera Press to activate the Camera function. 7 Stealth mode Press to disable all emitting lights and sound. 8 Quick menu Press to access the Quick menu. 9 Security Press to exit Windows and enter SAS (Secure Attention Sequence) mode. 10 NumLock Press to emulate NumLock key. n NOTE When the numerical mode is activated, the keypad backlight (blue) lights on. If the keypad is left idle for 60 seconds, the backlight will automatically turn off. 11 Program1 Press to access your favorite programs. 12 Enter Press to emulate the Enter key. 13 Program2 Press to access your favorite programs. 14 Arrow (up) Press to emulate the Up key. 15 Arrow (left) Press to emulate the Left key. 16 Arrow (right) Press to emulate the Right key. 17 WLAN (Wi-Fi and Bluetooth) Press to activate wireless LAN or Bluetooth communication. 18 Arrow (down) Press to emulate the Down key. 19 Rotate Press to rotate the display. 20 Number (0) Press to enter 0. TWINHEAD INTERNATIONAL CORP. Right View No. Item Description I/O A 1 Serial port (RS-232/RS-485) Connect a peripheral device, such as a printer or other device with serial port. 2 RJ-45 Connect LAN 3 USB port Connect USB peripheral devices. I/O B 1 Serial port (RS-232) Connect a peripheral device, such as a printer or other device with serial port. 2 USB ports Connect USB peripheral devices. I/O A I/O B

Twinhead International Corporation FCC ID.: FKGT7Q 10F, No. 550, Rueiguang Rd, Neihu, Taipei, Taiwan, 114 Tel : (886) 2 5589-9999 FCC ID Label

Twinhead International Corporation FCC ID.: FKGT7Q 10F, No. 550, Rueiguang Rd, Neihu, Taipei, Taiwan, 114 Tel : (886) 2 5589-9999 The FCC ID and Doc Label will be placed on the equipment as shown in the photograph below.

Report No.: 122393R-RFUSP42V01 Page : 4 of 38 (7) EUT Photo (8) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 5 of 38 (9) EUT Photo (10) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 6 of 38 (11) EUT Photo (12) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 7 of 38 (13) EUT Photo (14) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 8 of 38 (15) EUT Photo (16) EUT Photo RFID Antenna Report No.: 122393R-RFUSP42V01 Page : 9 of 38 (17) EUT Photo (18) EUT Photo RFID Antenna Report No.: 122393R-RFUSP42V01 Page : 10 of 38 (19) EUT Photo (20) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 11 of 38 (21) EUT Photo (22) EUT Photo RFID Module Report No.: 122393R-RFUSP42V01 Page : 12 of 38 (23) EUT Photo (24) EUT Photo RFID Module Report No.: 122393R-RFUSP42V01 Page : 13 of 38 (25) EUT Photo (26) EUT Photo GPS Report No.: 122393R-RFUSP42V01 Page : 14 of 38 (27) EUT Photo (28) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 15 of 38 (29) EUT Photo (30) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 16 of 38 (31) EUT Photo (32) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 17 of 38 (33) EUT Photo (34) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 18 of 38 (35) EUT Photo (36) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 19 of 38 (37) EUT Photo (38) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 20 of 38 (39) EUT Photo (40) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 21 of 38 (41) EUT Photo (42) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 22 of 38 (43) EUT Photo (44) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 23 of 38 (45) EUT Photo (46) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 24 of 38 (47) EUT Photo (48) EUT Photo WLAN Antenna (Main) WLAN Antenna (Aux) Report No.: 122393R-RFUSP42V01 Page : 25 of 38 (49) EUT Photo (50) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 26 of 38 (51) EUT Photo (52) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 27 of 38 (53) EUT Photo (54) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 28 of 38 (55) EUT Photo (SSD) (56) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 29 of 38 (57) EUT Photo (58) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 30 of 38 (59) EUT Photo (60) EUT Photo 170mm WLAN Antenna (Aux) WLAN Antenna (Main) Report No.: 122393R-RFUSP42V01 Page : 31 of 38 (61) EUT Photo (62) EUT Photo Report No.: 122393R-RFUSP42V01 Page : 32 of 38 (63) EUT Photo (64) EUT Photo

Report No：122393R-HPUSP09V01 Page: 1 of 29 SAR Test Report Product Name ： Tablet PC Model No. ： xTablet ® T7200, Fieldbook A2, T7Q, a7360X, a7380X Applicant ： Twinhead International Corp Address ： 10F,550 Rueiguand Rd Neihu,Taipei,Taiwan 114,ROC Date of Receipt ：2012/02/21 Issued Date ：2012/06/27 Report No. ：122393R-HPUSP09V01 Report Version ：V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. Report No：122393R-HPUSP09V01 Page: 2 of 29 Test Report Certification Issued Date: 2012/06/27 Report No.:122393R-HPUSP09V01 Product Name ： Tablet PC Applicant ： Twinhead International Corp Address ： 10F,550 Rueiguand Rd Neihu,Taipei,Taiwan 114,ROC Manufacturer ： Twinhead International Corp Model No. ： xTablet ® T7200, Fieldbook A2, T7Q, a7360X, a7380X Trade Name ： MobileDemand, LOGIC INSTRUMENT, DURABOOK, tabletkiosk FCC ID ： FKGT7Q Applicable Standard ： FCC Oet65 Supplement C June 2001 IEEE Std. 1528-2003 47CFR § 2.1093 Measurement procedures ： KDB 447498 , KDB 248227, KDB616217 Test Result ： Max. SAR Measurement (1g) 802.11b/g(2.4GHz): 0.329 W/kg 802.11a(5 GHz): 1.530 W/kg Application Type ： Certification The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. Documented By ： (Adm. Assistant / April Chen) Tested By ： (Engineer / Wen Lee) Approved By ： (Manager / Vincent Lin) Report No：122393R-HPUSP09V01 Page: 3 of 29 TABLE OF CONTENTS Description Page 1. General Information.............................................................................. 5 1.1 EUT Description ............................................................................................................5 1.2 Antenna List ................................................................................................................... 6 1.3 Test Environment ...........................................................................................................6 2. SAR Measurement System .................................................................. 7 2.1 DASY5 System Description .......................................................................................... 7 2.1.1 Applications ................................................................................................................ 8 2.1.2 Area Scans................................................................................................................... 8 2.1.3 Zoom Scan (Cube Scan Averaging)............................................................................ 8 2.1.4 Uncertainty of Inter-/Extrapolation and Averaging .................................................... 8 2.2 DASY5 E-Field Probe ................................................................................................... 9 2.2.1 Isotropic E-Field Probe Specification ......................................................................... 9 2.3 Boundary Detection Unit and Probe Mounting Device ............................................... 10 2.4 DATA Acquisition Electronics (DAE) and Measurement Server ............................... 10 2.5 Robot ............................................................................................................................ 11 2.6 Light Beam Unit........................................................................................................... 11 2.7 Device Holder ..............................................................................................................12 2.8 SAM Twin Phantom .................................................................................................... 12 3. Tissue Simulating Liquid ................................................................... 13 3.1 The composition of the tissue simulating liquid .......................................................... 13 3.2 Tissue Calibration Result ............................................................................................. 13 3.3 Tissue Dielectric Parameters for Head and Body Phantoms ....................................... 15 4. SAR Measurement Procedure ........................................................... 16 4.1 SAR System Check ...................................................................................................... 16 4.1.1 Dipoles ...................................................................................................................... 16 4.1.2 System Check Result ................................................................................................ 16 4.2 SAR Measurement Procedure ...................................................................................... 18 5. SAR Exposure Limits ......................................................................... 19 6. Test Equipment List............................................................................ 20 7. Measurement Uncertainty .................................................................. 21 8. Average Power Measurement............................................................ 23 9. Test Results......................................................................................... 25 9.1 SAR Test Results Summary ......................................................................................... 25 Appendix ............................................................................................................................ 29 Report No：122393R-HPUSP09V01 Page: 4 of 29 Appendix A. SAR System Check Data Appendix B. SAR measurement Data Appendix C. Test Setup Photographs & EUT Photographs Appendix D. Probe Calibration Data Appendix E. Dipole Calibration Data Report No：122393R-HPUSP09V01 Page: 5 of 29 1. General Information 1.1 EUT Description Product Name Tablet PC Trade Name MobileDemand, LOGIC INSTRUMENT, DURABOOK, tabletkiosk Model No. xTablet ® T7200…

Text truncated - open the document above for the full version.

Appendix E. Dipole Calibration Validation Dipole 2450 MHz M/N: ALS-D-2450 S/N: QTK-319 Appendix E. Dipole Calibration Validation Dipole 3-6 GHz M/N: D5GHzV2 S/N: 1041

Report No. 122393R-RFUSP43V01 Page: 1 of 100 Test Report Product Name Tablet PC Model No. xTablet ® T7200, Fieldbook A2, T7Q, a7360X, a7380X FCC ID. FKGT7Q Applicant Twinhead International Corp Address 10F, 550 Rueiguand Rd Neihu, Taipei, Taiwan 114, ROC Date of Receipt Feb. 21, 2012 Issued Date Jun 25, 2012 Report No. 122393R-RFUSP43V01 Report Version V1.0 The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 122393R-RFUSP43V01 Page: 2 of 100 Test Report Certification Issued Date: Jun 25, 2012 R eport No.: 122393R-RFUSP43V01 Product Name Tablet PC Applicant Twinhead International Corp Address 10F, 550 Rueiguand Rd Neihu, Taipei, Taiwan 114, ROC Manufacturer Twinhead International Corp Model No. xTablet ® T7200, Fieldbook A2, T7Q, a7360X, a7380X FCC ID. FKGT7Q EUT Rated Voltage AC 100-240V, 50-60Hz EUT Test Voltage AC 120V/60Hz Trade Name MobileDemand, LOGIC INSTRUMENT, DURABOOK, tabletkiosk Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2010 ANSI C63.4: 2003 Test Result Complied The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Documented By : ( Senior Adm. Specialist / Jinn Chen ) Tested By : ( Assistant Engineer / Jack Hsu ) Approved By : (Manager / Vincent Lin ) Report No. 122393R-RFUSP43V01 Page: 3 of 100 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ...............................................................................................................5 1.1. EUT Description......................................................................................................................................5 1.2. Operational Description...........................................................................................................................8 1.3. Tested System Details..............................................................................................................................9 1.4. Configuration of Tested System ..............................................................................................................9 1.5. EUT Exercise Software ...........................................................................................................................9 1.6. Test Facility ...........................................................................................................................................10 2. CONDUCTED EMISSION ................................................................................................................ 11 2.1. Test Equipment......................................................................................................................................11 2.2. Test Setup ..............................................................................................................................................11 2.3. Limits.....................................................................................................................................................12 2.4. Test Procedure .......................................................................................................................................12 2.5. Uncertainty ............................................................................................................................................12 2.6. Test Result of Conducted Emission.......................................................................................................13 3. PEAK POWER OUTPUT ..................................................................................................................17 3.1. Test Equipment......................................................................................................................................17 3.2. Test Setup ..............................................................................................................................................17 3.3. Limit......................................................................................................................................................17 3.4. Test Procedure .......................................................................................................................................17 3.5. Uncertainty ............................................................................................................................................17 3.6. Test Result of Peak Power Output.........................................................................................................18 4. RADIATED EMISSION .....................................................................................................................21 4.1. Test Equipment......................................................................................................................................21 4.2. Test Setup ..............................................................................................................................................21 4.3. Limits.....................................................................................................................................................22 4.4. Test Procedure .......................................................................................................................................23 4.5. Uncertainty ............................................................................................................................................23 4.6. Test Result of Radiated Emission....................................................................................................…

Text truncated - open the document above for the full version.

Report No. 122393R-RFUSP43V01 Page: 66 of 100 Product : Tablet PC Test Item : Band Edge Test Site : No.3 OATS Test Mode : Mode 3: Transmit - BLE (GFSK) Fundamental Filed Strength Antenna Pole Frequency [MHz] Correction Factor [dB/m] Reading Level [dBuV] Emission Level [dBuV/m] Detector Horizontal 2402 31.755 60.21 91.964 Peak Horizontal 2402 31.755 41.47 73.224 Average Vertical 2402 30.241 55.29 85.531 Peak Vertical 2402 30.241 38.22 68.461 Average Note: 1:Spectrum Analyzer setting: Peak detector: RBW=1MHz, VBW=1MHz Average detector: RBW=1MHz, VBW=10Hz Band Edge Test Data Antenna Pole Test Frequency (MHz) Fundamental (dBuV/m) Δ (dB) Band Edge Field Strength (dBuV/m) Limit (dBuV/m) Detector Horizontal 2362 91.964 52.929 39.035 74.000 Peak Horizontal 2362 73.224 40.921 32.303 54.000 Average Vertical 2362 85.531 52.929 32.602 74.000 Peak Vertical 2362 68.461 40.921 27.54 54.000 Average Note: The Band Edge Field Strength was calculated using the Fundamental and Conducted Band Edge measurements per the Marker-Delta Method with the following formula: Band Edge field Strength = F - Δ F = Fundamental field Strength (Peak or Average) Δ = Conducted Band Edge Delta (Peak or Average) Report No. 122393R-RFUSP43V01 Page: 67 of 100 Peak Detector of conducted Band Edge Delta Average Detector of conducted Band Edge Delta Report No. 122393R-RFUSP43V01 Page: 68 of 100 Product : Tablet PC Test Item : Band Edge Test Site : No.3 OATS Test Mode : Mode 3: Transmit - BLE (GFSK) Fundamental Filed Strength Antenna Pole Frequency [MHz] Correction Factor [dB/m] Reading Level [dBuV] Emission Level [dB(uV/m)] Detector Horizontal 2480 31.941 65.32 97.261 Peak Horizontal 2480 31.941 44.92 76.861 Average Vertical 2480 30.568 58.3 88.868 Peak Vertical 2480 30.568 40.3 70.868 Average Note: 1:Spectrum Analyzer setting: Peak detector: RBW=1MHz, VBW=1MHz Average detector: RBW=1MHz, VBW=10Hz Band Edge Test Data Antenna Pole Test Frequency (MHz) Fundamental (dBuV/m) Δ (dB) Band Edge Field Strength (dBuV/m) Limit (dBuV/m) Detector Horizontal 2483.5 97.261 43.498 53.763 74.000 Peak Horizontal 2483.5 76.861 39.812 37.049 54.000 Average Vertical 2483.5 88.868 43.498 45.37 74.000 Peak Vertical 2483.5 70.868 39.812 31.056 54.000 Average Note: The Band Edge Field Strength was calculated using the Fundamental and Conducted Band Edge measurements per the Marker-Delta Method with the following formula: Band Edge field Strength = F - Δ F = Fundamental field Strength (Peak or Average) Δ = Conducted Band Edge Delta (Peak or Average) Report No. 122393R-RFUSP43V01 Page: 69 of 100 Peak Detector of conducted Band Edge Delta Average Detector of conducted Band Edge Delta Report No. 122393R-RFUSP43V01 Page: 70 of 100 7. Channel Number 7.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun, 2012 Spectrum Analyzer Agilent E4407B / US39440758 Jun, 2012 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2012 Note: 1. All equipments are calibrated every one year. 2. The test instruments marked by “X” are used to measure the final test results. 7.2. Test Setup 7.3. Limit Frequency hopping systems operating in the 2400-2483.5 MHz bands shall use at least 75 hopping frequencies. 7.4. Test Procedure The EUT was setup to ANSI C63.4, 2003; tested to FHSS test procedure of FCC Public Notice DA 00-705 for compliance to FCC 47CFR 15.247 requirements. 7.5. Uncertainty N/A SMA Connecter EUT Spectrum Analyzer RF Cable Report No. 122393R-RFUSP43V01 Page: 71 of 100 7.6. Test Result of Channel Number Product : Tablet PC Test Item : Channel Number Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 1Mbps (GFSK) Frequency Range (MHz) Measurement (Hopping Channel) Required Limit (Hopping Channel) Result 2402 ~…
