Wacom DigitizerWacom Digitizer Implementation GuideImplementation Guide Component Business Division Wacom Co., Ltd. 1 • 30.10.2007 • Wacom Confidential Contents 1. Principle of Wacom EMR 2. General Specification 3. Structure 4. Digitizer Lineup 5. Display Lineup 6. Customizing Digitizer 7. System Designing (EM noise) 8. System Designing2 (metal parts) 9. System Calibration 10. Driver 2 • 30.10.2007 • Wacom Confidential 1. Principle of Wacom EMR Receivin g and transmittin g coil in st y lus Pen Y axis Xaxis ggy Antenna coil Sensor Board X axis Coil switching transmit/receive Receiver V High frequency Receiver source Signal strength 3 • 30.10.2007 • Wacom Confidential 2. General Specification WDiitiUit Technology EMR (Electro-Magnetic Resonance)  W acom Di g iti zer U n it Active Area 263.12 * 165.2 mm for SU5E-12W16AS-00X Resolution 0.01mm (2540 ppi) Coordinate Accuracy ± 0 4mm (see Note 1 and 2) Coordinate Accuracy ± 0 . 4mm (see Note 1 and 2) Coordinate Deviation When Tilting Pen ± 3mm (tilted ± 50º from vertical) (see Note 3) Detectable Pen tilt U p to 50 ° from vertical p Detectable Height 4 to 14mm above the Sensor Board (see Note 1) Position Report Rate 133 pps Pressure Resolution 256 levels @ full scale Power Consumption 35mA (max.70mA) @133pps  Note 1: The digitizer sensor unit and pen only, at ordinary temperature.  Note 2: The pen held vertically at 7mm high from sensor board. Nt 3Th hldi th t fth ti 4 • 30.10.2007 • Wacom Confidential  N o t e 3 : Th e pen h e ld i n th e cen t er o f th e ac ti ve area. 3-1. Structure  EMR digitizer be inserted under the LCD 5 • 30.10.2007 • Wacom Confidential 3-2. Structure  EMR digitizer be inserted under the LCD 6 • 30.10.2007 • Wacom Confidential 4-1. Digitizer Lineup  Sensor : G4 ･･･ glass epoxy sensor G4.5 ･･･ glass epoxy sensor G5 ･･･ PET film or FPC (Polyimide) G4/G4.5 G5 7 • 30.10.2007 • Wacom Confidential 4-2. Digitizer Lineup  G5 sensor 8 • 30.10.2007 • Wacom Confidential 4-3. Digitizer Line up Technology : 1. EMR onl y y 2. Resistive-DualTouch ･･･ sensor + Resistive Touch screen interface 3. Capacitive-DualTouch ･･･ sensor + Capacitive Touch screen interface EMR only R-Dual C-Dual 9 • 30.10.2007 • Wacom Confidential 4-4. Digitizer Lineup Interface : UART, USB Si l i t (UART) Si gna l ass i gnmen t (UART) Signal assignment (USB) 10 • 30.10.2007 • Wacom Confidential 4-5. Digitizer Lineup 11 • 30.10.2007 • Wacom Confidential 5. Display Lineup  LCD---Kangaroo type ・ E-ink display 12 • 30.10.2007 • Wacom Confidential 6-1. Customizing Digitizer Condition for digitizer customization1. Minimum Volume: 30K/ y ea r y 2. There will be NRE and Tooling Cost 13 • 30.10.2007 • Wacom Confidential 6-2. Customizing Digitizer  Sensor Board Design 1. Must be square shape rectangle square round heart 2. Must be flat 3 Non acti e area m st be at least 4mm at each side OK NG 3 . Non - acti v e area m u st be at least 4mm at each side tli at least 4mm ou tli ne active area digitizer 14 • 30.10.2007 • Wacom Confidential 6-3. Customizing Digitizer Sensor Board Design (continued)4. Di g itizer active area needs at lease 1mm buffer from LCD active g area at each side LCD outline 1mm 1mm 1mm LCD outline LCD active areadigitizer outline 1mm digitizer outline digitizer active area 15 • 30.10.2007 • Wacom Confidential 6-4. Customizing Digitizer  Baby Board Design Onl y standard desi g n available. yg  Interface connector C t di iti DF19L 14P 1H (HIROSE) i l t  C onnec t or on di g iti zer: DF19L - 14P - 1H (HIROSE) or equ i va l en t  Counterpart connector: DF19-14S-1S, DF19G-14S-1C (HIROSE) or equivalent 16 • 30.10.2007 • Wacom Confidential 6-5. Customizing Digitizer Dl tShdl  D eve l opmen t S c h e d u l e No. Step Lead Time 1 Cfi t di i t 1 C on fi rm cus t om d es i gn requ i remen t 2 Release of tentative shipping specification At the same time as ES sample shipment 3 ES sample shipment 8 10 weeks 3 ES sample shipment *handmade sample with default firmware 8 - 10 weeks 4 Customer confirmation of shipping specification 5 System calibration 2 weeks 6 Customer approval of ES sample 7 CS l hi t 8 10 k 7 CS samp l e s hi pmen t *tooled sample with final calibrated firmware 8 - 10 wee k s 8 Release of final shipping specification At the same time as CS sample shipment 8 Customer approval of MP (including shipping specification, FW and CS sample) 9 MP shipment 8-10 weeks 17 • 30.10.2007 • Wacom Confidential Note: Lead time stated here is only refe rence and may change depending on digitizer design. Please confirm the final development schedule with Wacom sales. 7-1. System Designing Prevention of EM noise problemSome transformers or coils in the po er nit generates EM noiseSome transformers or coils in the po w er u nit generates EM noise . To prevent this To prevent this • Use transformers or coils that won’t allow magnetic flux leakage. • Place them underneath the shield or in a distance as much as possible from the sensor board. • Position them so that EM noise flux did not across the senso r board. EM noise source • Inverter of LCD back light • Inverter of LCD back light • DC to DC converter in power circuit 18 • 30.10.2007 • Wacom Confidential 7-2. System Designing B View B-B’ LCD EM Noise Countermeasure B’ Digitizer Inverter Shield or IMPORTANT ! Digitizer is sensitive to Electromagnetic Noise. Inverter is one of the strongest EM source.Shielding the inverter with shield plate*1, would improve an affection of the EM noise from the Inverter As far as you can,please SEPARATE the Digitizer Unit ! 19 • 30.10.2007 • Wacom Confidential an affection of the EM noise from the Inverter . from the Inverter 7-3. System Designing PC Case EM Noise Countermeasure2 LCD Digitizer COIL Like DC-DC Converter In case of PC in one body, mot herboard is located right beneath the Di g itizer unit. Coils in the p ower unit g enerates the EM noise and it will gpg cause of inaccuracy of the Digitizer. Shield the COIL with shield plate*1 for better Digitizer quality…

Text truncated - open the document above for the full version.

Date: September 24, 2013 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: GKR-TP00062AWD To Whom It May Concern: This letter is to ascertain that Compal Electronics, INC Product Convertible Tablet Computer has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature : Joyce Ting Client’s name / title : Compal Electronics, INC / Design Leader Contact information / address : No. 581, Ruiguang RD., Neihu District, Taipei City 11492, Taiwan, R.O.C.

SCS-F26 Modular Approval Letter Page 1 of 4 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Modular Approval Declaration Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (Obsolete) 1.0 1.0 Dec-04-2006 Added IC Modular Letter (Obsolete) 1.0 2.0 Feb 16 2009 Add LMA and MA option (Obsolete) 2.0 3.0 April 14 2010 Revised per RSS Gen issue 3.0 (Obsolete) 3.0 4.0 Jan 12 2011 Removed Foot(2) (obsolete) 4.0 5.0 July 19 2011 Adding New note per KDB996369 D01 V01R03 (obsolete) 5.0 6.0 August 29 2011 Updated company template & Added text box (current) 6.0 7.0 Jan-31-2012 SCS-F26 Modular Approval Letter Page 2 of 4 Rev 7.0 Compal Electronics, INC (Date) October 2, 2013 (Product name) FCC ID : GKR-TP00062AWD , is seeking FCC Authorization as a Single Modular transmitter / Single Limited Modular Approval (Please check one). The EUT meets the requirements for Single Modular approval / Single Limited Modular Approval (please check one) as detailed in FCC public Notice DA00-1407. Compliance to each of the requirements is described below : Questions are: * Please provide a detailed explanation if the answer is “No.” 1. “The modular transmitter must have its own RF shielding.” Yes / No 2. “The modular transmitter must have buffered modulation/data inputs.” Yes / No 3. “The modular transmitter must have its own power supply regulation.” Yes / No 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(c).” Yes / No 5. “The modular transmitter must be tested in a stand-alone configuration.” Yes / No 6. “The modular transmitter must be labeled with its own FCC ID number.” Yes / No 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacture must provide adequate instruction along with the module to explain any such requirements.” Yes / No 8. “The modular transmitter must comply with any applicable RF exposure requirements.” Yes / No Note: (1) LMA may be granted when one or more of the requirements in the table above cannot be demonstrated. LMA will also be issued in those instances where applicants can demonstrate that they will retain control over the final installation of the device, such that compliance of the end product is assured. In such cases, an operating condition on the LMA for the module must state that the module is only approved for use when installed in devices produced by a specific manufacturer. When LMA is sought, the application for equipment certification must specifically state how control of the end product into which the module will be installed, and will be maintained, such that full compliance of the end product is always ensured. (2) Please provide Clear and specific instructions describing the conditions, limitations and procedures for third-parties to use and/or integrate the module into a host device. (3) For non-Software Defined Radio transmitter modules where software is used to ensure compliance of the device, technical description of how such control is implemented to ensure prevention of third party modification must be provided (see KDB 594280). Note 1: Compliance of a module in its final configuration is the responsibility of the applicant. A host device will not be considered certified if the instructions regarding antenna configuration provided in the original description, of one or more separately certified modules it contains, were not followed. Example: A separately certified low-power transceiver module using Bluetooth technology which is housed in a desktop computer, laptop or peripheral does not require the overall system to be recertified, if the desktop computer, laptop or peripheral, as a stand-alone unit, complies with all applicable technical standards. Client’s signature : Joyce Ting Client’s name / title : Compal Electronics, INC / Design Leader Contact information / address : No. 581, Ruiguang RD., Neihu District, Taipei City 11492, Taiwan, R.O.C. SCS-F26 Modular Approval Letter Page 3 of 4 Rev 7.0 Compal Electronics, INC (Date) October 2, 2013 (Product name) IC ID : 2533B-TP00062AWD , is seeking IC Authorization as a modular transmitter / Limited Modular Transmitter (Please check one). The EUT meets the requirements for modular approval / Limited Modular Approval (Please check one) as detailed in RSS GEN. Compliance to each of the requirements is described below: * Please provide a detailed explanation if the answer is “No.” a. The radio elements must have the radio frequency circuitry must be shielded. Physical/discrete and tuning capacitors may be located external to the shield, but must be on the module assembly. Yes / No b. The module shall have buffered modulation/data input(s) (if such inputs are provided) to ensure that the module will comply with the requirements set out in the applicable RSS standard under conditions of excessive data rates or over-modulation. Yes / No c. The module shall have its own power supply regulation on the module. This is to ensure that the module will comply with the requirements set out in the applicable standard regardless of the design of the power supplying circuitry in the host device which houses the module Yes / No d. The module shall comply with the provisions for external power amplifiers and antennas detailed in this standard. The equipment certification submission shall contain a detailed description of the configuration of all antennas that will be used with the module. Yes / No e. The module shall be tested for compliance with the applicable standard in a stand-alone configuration, i.e. the module must not be inside another device during testing Yes / No f. The module shall comply with the Category I equipment labelling requirements. Yes / No g. The module shall comply with applicable RSS-102 exposure requirements, which are based on the intended use/configurations. Yes / No h.…

Text truncated - open the document above for the full version.

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Compal Electronics, INC September 24, 2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: GKR-TP00062AWD We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Circuit Diagram - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Joyce Ting Client’s name / title : Compal Electronics, INC / Design Leader Contact information / address : No. 581, Ruiguang RD., Neihu District, Taipei City 11492, Taiwan, R.O.C. SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 Compal Electronics, INC September 24, 2013 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: GKR-TP00062AWD To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - External Photos - Internal Photos - User Manual - Set Up Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature : Joyce Ting Client’s name / title : Compal Electronics, INC / Design Leader Contact information / address : No. 581, Ruiguang RD., Neihu District, Taipei City 11492, Taiwan, R.O.C.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Compal Electronics, INC Date: September 24, 2013 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Compal Electronics, INC hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Convertible Tablet Computer Model name: TP00062A We affirm that between SIEMIC and Compal Electronics, INC , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature : Joyce Ting Client’s name / title : Compal Electronics, INC / Design Leader Contact information / address : No. 581, Ruiguang RD., Neihu District, Taipei City 11492, Taiwan, R.O.C.

Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 1 / 11 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF HOST EUT EXTERNAL PHOTOGRAPHS OF EUT Host Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 2 Rev. 00 Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 3 Rev. 00 Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 4 Rev. 00 Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 5 Rev. 00 Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 6 Rev. 00 Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 7 Rev. 00

1/1 ID Label & Location Host PC label: Model: SU8E-12H02AU-01A FCC ID: GKR-TP00062AWD IC: 2533B- TP00062AWD Applying Digitizer Unit Bottom view 10mm 20mm

Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 8 Rev. 00 INTERNAL PHOTOGRAPHS OF HOST EUT Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 9 Rev. 00 Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 10 Rev. 00 Compliance Certification Services Inc. Report No.: T130813W05 Date of Issue: September 18, 2013 A1 - 11 Rev. 00 Module OF EUT

Compliance Certification Services Inc. FCC ID: GKR-TP00062AWD IC ID: 2533B-TP00062AWD Report No.: T130813W05-RP1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 37 Rev.00 FCC 47 CFR PART 15 SUBPART C & INDUSTRY CANADA RSS-210 TEST REPORT For Digitizer I/O device Model: SU8E-12H02AU-01A Trade Name: Lenovo Issued to Compal Electronics, INC. No. 581, Ruiguang RD., Neihu District, Taipei City 11492, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No.81-1, Lane 210, Bade 2nd Rd., Lujhu Township, Taoyuan County 33841,Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 http://www.ccsrf.com [email protected] Compliance Certification Services Inc. FCC ID: GKR-TP00062AWD IC ID: 2533B-TP00062AWD Report No.: T130813W05-RP1 Page 2 Rev.00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 September 17, 2013 Initial Issue ALL Rachel Wu Compliance Certification Services Inc. FCC ID: GKR-TP00062AWD IC ID: 2533B-TP00062AWD Report No.: T130813W05-RP1 Page 3 Rev.00 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ............................................................................................. 4 2 EUT DESCRIPTION .................................................................................................................... 5 3 TEST METHODOLOGY ............................................................................................................. 6 3.1. DESCRIPTION OF TEST MODES ....................................................................................... 6 4 INSTRUMENT CALIBRATION ................................................................................................. 7 4.1. MEASURING INSTRUMENT CALIBRATION .................................................................. 7 4.2. MEASUREMENT EQUIPMENT USED .............................................................................. 7 4.3. MEASUREMENT UNCERTAINTY .................................................................................... 9 5 FACILITIES AND ACCREDITATIONS ................................................................................. 10 5.1. FACILITIES ......................................................................................................................... 10 5.2. EQUIPMENT ....................................................................................................................... 10 5.3. TABLE OF ACCREDITATIONS AND LISTINGS ............................................................ 11 6 SETUP OF EQUIPMENT UNDER TEST ................................................................................ 12 6.1. SETUP CONFIGURATION OF EUT .................................................................................. 12 6.2. SUPPORT EQUIPMENT ..................................................................................................... 12 7 APPLICABLE RULES ............................................................................................................... 13 8 RSS 210 REQUIREMENTS ....................................................................................................... 22 8.1. 99% BANDWIDTH ............................................................................................................. 22 8.2. RADIATED EMISSIONS .................................................................................................... 24 8.3. POWERLINE CONDUCTED EMISSIONS ........................................................................ 31 9 APPENDIX I PHOTOGRAPHS OF TEST SETUP ................................................................. 34 Compliance Certification Services Inc. FCC ID: GKR-TP00062AWD IC ID: 2533B-TP00062AWD Report No.: T130813W05-RP1 Page 4 Rev.00 1 TEST RESULT CERTIFICATION Applicant: Compal Electronics, INC. No. 581, Ruiguang RD., Neihu District, Taipei City 11492, Taiwan, R.O.C. Equipment Under Test: Digitizer I/O device Tr a d e N a m e : Lenovo Model: SU8E-12H02AU-01A Date of Test: September 12~16, 2013 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C & Industry Canada RSS-210 Issue 8 December, 2010 No non-compliance noted We hereby certify that: Compliance Certification Services Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Bill Cheng Section Manager Angel Hu Section Manager Compliance Certification Services Inc. FCC ID: GKR-TP00062AWD IC ID: 2533B-TP00062AWD Report No.: T130813W05-RP1 Page 5 Rev.00 2 EUT DESCRIPTION Product Digitizer I/O device Trade Name Lenovo Model Number SU8E-12H02AU-01A Power Supply 1. Power from power adapter. 2. Power from battery. Operating Frequency Range 531.25kHz, 562.50kHz Antenna Specification Loop Antenna Note The application is fo0r limited module approval. The host PC device show as following: Convertible Tablet Computer Brand: Lenovo / Model Number: TP00062AWD Power Rating Component Model / Specification Manufacturer Adapter ADLX45NDC2A AC Input: 100-240V, 1.2A, 50/60Hz DC Output: 20V, 2.25A lenovo Battery ASM P/N 45N1704 / 14.8V 3.18Ah 47Wh SONY ASM P/N 45N1706/ 14.8V 3.18Ah 47Wh SIMPLO Co…
