GKRVC-5UAMPS/CDMA Cellular Phone

1 OPERATING MANUAL (VC-5U) Revision : 0.1 Page# Modification Remark VACOM WIRELESS, INC 2 IMPORTANT SAFETY INFORMATION GETTING TO KNOW YOUR PHONE DISPLAY INDICATOR BATTERY INFORMATION BASIC FUNCTIONS 1. Making a Call 2. Ending a Call 3. Answering a Call 4. Correcting Dialing Mistakes 5. Storing Phone Numbers 6. Adjusting Earpiece Volume During a Call 7. Using Caller ID 8. Speed Dialing 9. Short Cut a. Keypad Lock b. Phone Lock c. Etiquette Mode d. Phone Number Search e. Calendar f. Alarm 10. Current Time Setting MENUS I. Phone Book 1. Call List (missed call / incoming call / outgoing call) 2. Phone Book Search (by name / by location / by phone number / by group) 3. Storing Phone Numbers 4. Call Time View 5. My Phone Number 6. Delete Phone Book 3 II. MESSAGE SERVICE 1. SMS (Short Message Service) a. Read Text Messages b. Send Text Message Send New Message Send from Message Box Send Message That You Already Sent Out Group Edit c. Message Box d. SMS Setting Message Alert Direct View Delivery Ack 2. Voice Mail Service 3. Message Delete III. PHONE SETTING 1. Wallpaper 2. Language 3. Backlight 4. LCD Contrast 5. Auto Answer 6. Any Key Answer 7. Auto Redial 8. DTMF Tone 9. Auto Keypad Lock IV. SOUND MENU 1. Incoming Calls 2. Ring Type 4 3. Roam Ringer 4. Volume Control 5. Alert V. SECURITY FUNCTION 1. Phone Lock 2. Changing Password 3. Restrict Sending Calls 4. Voice Privacy 5. Network Change 6. Initialization VI. PIM (Personal Information Management) 1. Alarm 2. Schedule 3. Calendar 4. Calculator 5. Memo 6. World Time View VII. CALL FUNCTION 1. Call Forward 2. Call Waiting 3. Caller Identification 4. Service Access Number Edit Using Menu During a Call 1. Phone Book 2. Message 3. Phone Setting 4. Sounds (Earpiece / Mic / Key Tone / Alert / Mic Mute / Key Tone Mute / Alert Setting) ENTERING LETTERS & NUMBERS FCC RF EXPOSURE INFORMATION 5 IMPORTANT SAFETY INFORMATION Some of the following information may not apply to your particular product. However, as with any electronic product, you should observe safety precautions when you use this product. Save this manual : it contains important safety information and operating instructions. Before using this product, please follow and adhere to all warnings, safety, and operating instructions located on the product and in this User’s Manual. Do Not expose the product to water or moisture. Do Not expose the product to extreme hot or cold temperatures. Do Not expose the product to open flames. Do Not allow objects to fall on, or liquids to spill on the product. Use only Original Accessories. Damage from the use of non-approved accessories will void your phone warranty. Connect the approved charger only to designed power sources as marked on the product. To reduce the risk of damage, remove the electrical cord from an outlet by pulling the charger rather than the cord. Make sure the electric cord is located accordingly, so that it will not be subjected to damage. To reduce the risk of electric shock, unplug the product from the power source before attempting any cleaning. Once unplugged, use a soft cloth dampened with water. DANGER : Never alter the cord or plug. If the plug does not fit into the outlet, have a proper outlet installed by a qualified electrician. Improper connection can result electric shock. 6 Do Not attempt to disassemble the product – doing so will void the warranty. This product does not contain consumer-serviceable components. Service should be performed only by Authorized Service Centers. Do Not remove the antenna. A detached antenna may be a choking hazard for children. Do Not allow battery to be placed inside the mouth. Electrolytes could be released and may be toxic if swallowed. 7 GETTING TO KNOW YOUR PHONE LED Indicator : Flashes to indicate an incoming call or message. It also lights up (flashes) when you turn on the phone. Backlit LCD Screen : The LCD screen contains three areas; - The top line displays indication about your phone’s operating mode. - Two lines in the middle are the display areas for numbers and characters. - The bottom line displays menus. Menu Keys ( / ) : This key performs several useful functions. - During incoming calls, press it to answer the incoming call. - In Standby mode, press it briefly to access Main Menu and Select Menu. - When navigating a menu, press it to select the highlighted selection. SMS Key () : When in Standby Mode, press this key to access Message Menu items. Navigation Key () : This key allows you to navigate the phone’s variable functionality and useful shortcut. Microphone : Your typical voice microphone for conversation and you can also mute the microphone during conversation by pressing “MENU” “4” “5”. Accessories Connector : The location where you connect your charging device. It can also be used to connect wireless data device or hands-free car kit. CLR Key : This key is used to erase numbers or characters you may have entered incorrectly, or to return to a previous screen. - To erase one character from the display screen, briefly press it once. - To erase all of them, hold it for one second. - To back up one menu level, press it once. - To return to Standby Mode, hold it for one second. 8 - During a call, press it to control earpiece volume. END/ Key : Press this key to disconnect a call or to return to Standby Mode from any menu. Press and hold this key to turn the phone On or Off. SEND Key : This key performs several useful functions. - Dial a number and press it to connect. - Press it once to redial the last outgoing number. Numeric Keys : These keys are to dial and to input numbers and characters. * : This key performs several useful functions. - Change bells to vibration - Use as navigation key. # : This key performs several useful functions. - Use as instance phone lock. - Use as navigation key. Antenna 9 DISPLAY INDICATORS Display indicators appear across the bottom of your phone’s LCD screen. These display indicators (or icons) will vary based on your phone’s operating mode…

Text truncated - open the document above for the full version.

No.581,Jui-Kuang Rd. Neihu, Taipei, Taiwan 114 Phone : +886-2-8797 8588 Fax : +886-2-2658 5001 COMPAL AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Handheld Portable Cellular Telephone (FCC ID: GKRVC-5U) is so designed that it complies with all the requirements for ESN protection specified in Section 22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. C) The ESN is factory-set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely, Eric Liu Manager of Management Division COMPAL ELECTRONICS, INC. No.581,Jui-Kuang Rd. Neihu, Taipei, Taiwan 114 Phone : +886-2-8797 8588 Fax : +886-2-2658 5001 COMPAL December 19, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Compal Electronics Inc. FCC ID: GKRVC-5U FCC E911 Requirements Per §22.921 Gentlemen: Compal Electronics Inc. hereby certifies that the analog cellular telephone (FCC ID: GKRVC-5U), using the Automatic A/B Roaming – Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a “9-1-1” call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned. Eric Liu Manager of Management Division COMPAL ELECTRONICS, INC.

PROPOSED FCC ID LABEL AND LOCATION Compal Electronics, Inc. This device complies with Part 22 of the FCC Rules. FCC ID: GKRVC-5U FCC ID LABEL LOCATION

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for Dual Mode AMPS/CDMA Cellular Phone MODEL: VC-5U FCC ID: GKRVC-5U December 12, 2003 REPORT NO: 03T2379-2 Prepared for Compal Electronics Inc No. 581, Jui-Kuang Rd. Neihu, Taipei, 114, Taiwan, R.O.C. Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 03I2379-2 DATE: December 12, 2003 FCC ID: GKRVC-5U COMPLIANCE CERTIFICATION SERVICES Page: 2 of 30 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: December 12, 2003 APPLICANT: Compal Electronics Inc No. 581, Jui-Kuang Rd Neihu, Taipei, 114, Taiwan R.O.C. MODEL: VC-5U FCC ID: GKRVC-5U DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: AMPS/CDMA Operating Mode: Maximum continuous output Tx Frequency: 824.04 MHz to 848.97 MHz (AMPS) 824.7 MHz to 848.31 MHz (CDMA) Max. O/P Power: (Conducted/Average) 26.52 dBm (AMPS) 24.35 dBm (CDMA) Max. SAR (1g): AMPS: 1.51 mW/g (Left head touched position) 0.743 mW/g (Body worn) CDMA: 0.731 mW/g (Left head tilted position) 0.388 mW/g (Body worn) Application Type: Certification FCC Rule Part(s): § 22H This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 03I2379-2 DATE: December 12, 2003 FCC ID: GKRVC-5U COMPLIANCE CERTIFICATION SERVICES Page: 3 of 30 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENTS 1. EQUIPMENT UNDER TEST (EUT) DESCRIPTION....................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC..................................4 3. DOSIMETRIC ASSESSMENT SETUP.........................................................................................4 3.1. MEASUREMENT SYSTEM DIAGRAM...............................................................................................................................5 3.2. SYSTEM COMPONENTS..................................................................................................................................................6 4. EVALUATION PROCEDURES....................................................................................................8 5. MEASUREMENT UNCERTAINTY.............................................................................................12 6. EXPOSURE LIMIT...................................................................................................................13 7. EUT ARRANGEMENT............................................................................................................14 8. MEASUREMENT RESULTS.....................................................................................................17 8.1. SIMULATING LIQUIDS PARAMETER CHECK.................................................................................................................17 8.2. SYSTEM PERFORMANCE CHECK.................................................................................................................................19 8.3. EUT TUNE-UP PROCEDURES......................................................................................................................................20 8.4. SAR MEASUREMENT RESULTS...................................................................................................................................21 9. EUT PHOTOS........................................................................................................................26 10. EQUIPMENT LIST & CALIBRATION STATUS..........................................................................28 11. REFERENCES........................................................................................................................29 12. ATTACHMENTS......................................................................................................................30 REPORT NO: 03I2379-2 DATE: December 12, 2003 FCC ID: GKRVC-5U COMPLIANCE CERTIFICATION SERVICES Page: 4 of 30 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EQUIPMENT UNDER TEST (EUT) DESCRIPTION The following is the information provided by the applicant. Type of EUT: Dual Mode AMPS/CDMA Cellular Phone Type/Model No.: VC-5U Modulation Type: AMPS/CDMA TX Frequency: 824.04.04 MHz to 848.97 MHz (AMPS) 824.7 MHz to 848.31 MHz (CDMA) Duty Cycle: 100% Battery: Only one model with EUT 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC The US Federal Communications Commission has released the report and order “Guidelines for Evaluating the Environmental Effects of RF Radiation", ET Docket No. 93-62 in August 1996. The order re…

Text truncated - open the document above for the full version.

Date/Time: 12/12/03 09:07:16 Test Laboratory: Compliance Certification Services D900V2SN108_121203 DUT: Dipole 900 MHz; Type: D900V2; Serial: 108 Program Name: System Performance Check at 900 MHz Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: CW; Frequency: 900 MHz;Duty Cycle: 1:1 Medium: Head 900 MHz (σ = 0.9439 mho/m, ε r = 41.7523, ρ = 1000 kg/m 3 ) Phantom section: Flat Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 d=15mm, Pin=250mW/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 54.7 V/m Power Drift = 0.01 dB Maximum value of SAR = 2.69 mW/g d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Peak SAR (extrapolated) = 3.93 W/kg SAR(1 g) = 2.57 mW/g; SAR(10 g) = 1.66 mW/g Reference Value = 54.7 V/m Power Drift = 0.01 dB Maximum value of SAR = 2.77 mW/g 0 dB = 2.77mW/g Date/Time: 12/12/03 09:07:16 Test Laboratory: Compliance Certification Services D900V2SN108_121203 DUT: Dipole 900 MHz; Type: D900V2; Serial: 108 DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 d=15mm, Pin=250mW/Z Scan (1x1x51): Measurement grid: dx=20mm, dy=20mm, dz=2mm Reference Value = 54.7 V/m Power Drift = 0.009 dB Maximum value of SAR = 3.2 mW/g

Date/Time: 12/12/03 13:07:38 Test Laboratory: Compliance Certification Services 1_Left Touch DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Left-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: AMPS 835; Frequency: 824.04 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0.923 mho/m, ε r = 41.8952, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Touch position -Low/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 32.1 V/m Power Drift = 0.1 dB Maximum value of SAR = 1.57 mW/g Touch position -Low/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Peak SAR (extrapolated) = 2.07 W/kg SAR(1 g) = 1.51 mW/g; SAR(10 g) = 1.02 mW/g Reference Value = 32.1 V/m Power Drift = 0.1 dB Maximum value of SAR = 1.62 mW/g Date/Time: 12/12/03 13:07:38 Test Laboratory: Compliance Certification Services 1_Left Touch DUT: Compal; Type: VC-5U; Serial: N/A DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Touch position -Low/Z Scan (1x1x51): Measurement grid: dx=20mm, dy=20mm, dz=2mm Reference Value = 32.1 V/m Power Drift = 0.1 dB Maximum value of SAR = 1.42 mW/g Date/Time: 12/12/03 12:43:32 Test Laboratory: Compliance Certification Services 1_Left Touch DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Left-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: AMPS 835; Frequency: 836.49 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0.923 mho/m, ε r = 41.8952, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Touch position - Middle/Area Scan (6x9x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 31.1 V/m Power Drift = 0.1 dB Maximum value of SAR = 1.47 mW/g Touch position - Middle/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Peak SAR (extrapolated) = 1.86 W/kg SAR(1 g) = 1.36 mW/g; SAR(10 g) = 0.922 mW/g Reference Value = 31.1 V/m Power Drift = 0.1 dB Maximum value of SAR = 1.46 mW/g Date/Time: 12/12/03 13:27:34 Test Laboratory: Compliance Certification Services 1_Left Touch DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Left-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: AMPS 835; Frequency: 848.97 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0.923 mho/m, ε r = 41.8952, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Touch position -High/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 30 V/m Power Drift = -0.0 dB Maximum value of SAR = 1.41 mW/g Touch position -High/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Peak SAR (extrapolated) = 1.82 W/kg SAR(1 g) = 1.33 mW/g; SAR(10 g) = 0.896 mW/g Reference Value = 30 V/m Power Drift = -0.0 dB Maximum value of SAR = 1.42 mW/g Date/Time: 12/12/03 11:15:32 Test Laboratory: Compliance Certification Services 2_Left Tilt DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Left-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: AMPS 835; Frequency: 824.04 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0.923 mho/m, ε r = 41.8952, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Tilt position -Low/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 31.2 V/m Power Drift = -0.001 dB Maximum value of SAR = 0.965 mW/g Tilt position -Low/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Peak SAR (extrapolated) = 1.27 W/kg SAR(1 g) = 0.947 mW/g; SAR(10 g) = 0.662 mW/g Reference Value = 31.2 V/m Power Drift = -0.001 dB Maximum value of SAR = 1.01 mW/g Date/Time: 12/12/03 11:15:32 Test Laboratory: Compliance Certification Services 2_Left Tilt DUT: Compal; Type: VC-5U; Serial: N/A DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Tilt position -Low/Z Scan (1x1x51): Measurement grid: dx=20mm, dy=20mm, dz=2mm Reference Value = 31.2 V/m Power Drift = -0.0 dB Maximum value of SAR = 0.906 mW/g Date/Time: 12/12/03 10:28:14 Test Laboratory: Compliance Certification Services 2_Left Tilt DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Left-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: AMPS 835; Frequency: 836.49 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0…

Text truncated - open the document above for the full version.

Date/Time: 12/12/03 13:53:10 Test Laboratory: Compliance Certification Services 1_Left Touch DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Left-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: CDMA; Frequency: 835.89 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0.923 mho/m, ε r = 41.8952, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Touch position - Middle/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 22.7 V/m Power Drift = -0.1 dB Maximum value of SAR = 0.761 mW/g Touch position - Middle/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Peak SAR (extrapolated) = 1.01 W/kg SAR(1 g) = 0.737 mW/g; SAR(10 g) = 0.496 mW/g Reference Value = 22.7 V/m Power Drift = -0.1 dB Maximum value of SAR = 0.794 mW/g Date/Time: 12/12/03 13:59:44 Test Laboratory: Compliance Certification Services 1_Left Touch DUT: Compal; Type: VC-5U; Serial: N/A DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Touch position - Middle/Z Scan (1x1x51): Measurement grid: dx=20mm, dy=20mm, dz=2mm Reference Value = 22.7 V/m Power Drift = -0.1 dB Maximum value of SAR = 0.699 mW/g Date/Time: 12/12/03 12:16:20 Test Laboratory: Compliance Certification Services 2_Left Tilt DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Left-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: CDMA; Frequency: 835.89 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0.923 mho/m, ε r = 41.8952, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Tilt position - Middle/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 21.1 V/m Power Drift = 0.13 dB Maximum value of SAR = 0.467 mW/g Tilt position - Middle/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Peak SAR (extrapolated) = 0.595 W/kg SAR(1 g) = 0.441 mW/g; SAR(10 g) = 0.310 mW/g Reference Value = 21.1 V/m Power Drift = 0.13 dB Maximum value of SAR = 0.469 mW/g Date/Time: 12/12/03 12:16:20 Test Laboratory: Compliance Certification Services 2_Left Tilt DUT: Compal; Type: VC-5U; Serial: N/A DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Tilt position - Middle/Z Scan (1x1x51): Measurement grid: dx=20mm, dy=20mm, dz=2mm Reference Value = 21.1 V/m Power Drift = 0.12 dB Maximum value of SAR = 0.444 mW/g Date/Time: 12/12/03 14:22:22 Test Laboratory: Compliance Certification Services 3_R-Touch DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Right-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: CDMA; Frequency: 835.89 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0.923 mho/m, ε r = 41.8952, ρ = 1000 kg/m 3 ) Phantom section: Right Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Touch position - Middle/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 23.8 V/m Power Drift = -0.12 dB Maximum value of SAR = 0.699 mW/g Touch position - Middle/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Peak SAR (extrapolated) = 0.950 W/kg SAR(1 g) = 0.695 mW/g; SAR(10 g) = 0.469 mW/g Reference Value = 23.8 V/m Power Drift = -0.12 dB Maximum value of SAR = 0.742 mW/g Date/Time: 12/12/03 14:22:22 Test Laboratory: Compliance Certification Services 3_R-Touch DUT: Compal; Type: VC-5U; Serial: N/A DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Touch position - Middle/Z Scan (1x1x51): Measurement grid: dx=20mm, dy=20mm, dz=2mm Reference Value = 23.8 V/m Power Drift = -0.13 dB Maximum value of SAR = 0.638 mW/g Date/Time: 12/12/03 17:27:06 Test Laboratory: Compliance Certification Services 4_R-Tilt DUT: Compal; Type: VC-5U; Serial: N/A Program Name: Right-Hand Side Ambient Temperature: 24.5 deg C; Liquid Temperature: 23.0 deg C Communication System: CDMA; Frequency: 835.89 MHz;Duty Cycle: 1:1 Medium: Head 835 MHz (σ = 0.923 mho/m, ε r = 41.8952, ρ = 1000 kg/m 3 ) Phantom section: Right Section DASY4 Configuration: z Probe: ES3DV2 - SN3021; ConvF(6.5, 6.5, 6.5); Calibrated: 7/29/2003 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn427; Calibrated: 2/4/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.8 Build 62 Tilt position - Middle/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 20.6 V/m Power Dri…

Text truncated - open the document above for the full version.

FCC CFR47 CERTIFICATION PART 22H TEST REPORT FOR DUAL-MODE AMPS/CDMA CELLULAR PHONE MODEL NUMBER: VC-5U BRAND NAME: COMPAL FCC ID: GKRVC-5U REPORT NUMBER: 02I2379-1 ISSUE DATE: DECEMBER 10, 2003 Prepared for COMPAL ELECTRONICS INC. 8F, NO. 500, JUI-KUANG RD. NEIHU, TAIPEI 114 TAIWAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02I2379-1 DATE: DECEMBER 10, 2003 FCC ID: GKRVC-5U EUT: DUAL-MODE AMPS/CDMA CELLULAR PHONE Page 2 of 52 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION..........................................................................................3 2. EUT DESCRIPTION...............................................................................................................4 3. TEST METHODOLOGY.........................................................................................................4 4. TEST FACILITY.....................................................................................................................4 5. ACCREDITATION AND LISTING.........................................................................................4 6. MEASURING INSTRUMENT CALIBRATION......................................................................4 7. TEST SETUP, PROCEDURE AND RESULT..........................................................................5 7.1. SECTION 2.1046: RF POWER OUTPUT.............................................................................5 7.2. SECTION 2.1047: MODULATION CHARACTERISTICS..…

Text truncated - open the document above for the full version.
