Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
1 OPERATING MANUAL (VP-5X) Revision : 0.3 VACOM WIRELESS, INC 2 IMPORTANT SAFETY INFORMATION GETTING TO KNOW YOUR PHONE DISPLAY INDICATOR BATTERY INFORMATION BASIC FUNCTIONS Making a Call Ending a Call Answering a Call Correcting dialing Mistakes Storing Phone Numbers Adjusting Earpiece Volume During a Call Last Number Redial Speed Dialing Using Caller ID MENUS I. SEARCH a phone number Last 10 Numbers You Dialed Last 10 Numbers You Received ABC Search Menu Name Search Menu Location Search Menu Search by Phone Number II. PHONE SETTING Backlight Auto Answer Auto Redial Anykey Answer DTMF tone Language III. SOUND Incoming Calls 3 Ring Type Vo l u m e Alert IV. SECURITY Auto Lock Changing Password Memory Clear Initialization Voice Pivacy Send Call Restrict System Selection LCD Contrast V. MY DIALY Alarm Set Phone Number Store World Time View Call Time VI. MY PHONE NUMBER My Phone Number Software Version MESSAGE SERVICES I. TEXT MESSAGE SERVICES (SMS) Read Text Messages Send Text Messages Delete Messages II. VOICE MAIL SERVICE Listen Voice Mails Delete Messages III. MESSAGE ALERTS IV. MESSAGE SAVE USING MENU During a Call Sending My Phone Number Storing a Phone Number Mute DTMF Mute 4 My Phone Number View Earpiece Volume Control Voice Privacy DTMF Tone ENTERING LETTERS & NUMBERS 5 IMPORTANT SAFETY INFORMATION Some of the following information may not apply to your particular product. However, as with any electronic product, you should observe safety precautions when you use this product. ◈ Save this manual : it contains important safety information and operating instructions. ◈ Before using this product, please follow and adhere to all warnings, safety and operating instructions located on the product and in this User’s Manual. ◈ Do Not expose the product to water or moisture. ◈ Do Not expose the product to extreme hot or cold temperatures. ◈ Do Not expose the product to open flames. ◈ Do Not allow objects to fall on, or liquids to spill on the product. ◈ Use only Original Accessories. Damage from use of non-approved accessories will void your phone warranty. ◈ Connect the approved charger only to designed power sources as marked on the product. ◈ To reduce the risk of damage, remove the electrical cord from an outlet by pulling the charger rather than the cord. ◈ Make sure the electric cord is located so that it will not be subjected to damage. ◈ To reduce the risk of electric shock, unplug the product from the power source before attempting any cleaning. Once unplugged, use a soft cloth dampened with water. ◈ DANGER : Never alter the cord or plug. If the plug will not fit into the outlet, have a proper outlet installed by a qualified electrician. Improper connection can result in electric shock. ◈ Do Not attempt to disassemble the product – doing so will void the warranty. This product 6 does not contain consumer-serviceable components. Service should be performed only by Authorized Service Centers. ◈ Do Not remove the antenna. A detached antenna may be a choking hazard for children. ◈ Do Not allow battery to be placed in the mouth. Electrolytes could release and may be toxic if swallowed. 7 GETTING TO KNOW YOUR PHONE LED Indicator : Flashes to indicate an incoming call or message. Also lights up (flashes) when you turn on the phone. Backlit LCD Screen : The LCD screen contains three areas; - The top line displays indications about your phone’s operating mode. - Two lines in the middle are the display area of numbers and characters. - The bottom line displays memus. Menu Keys ( / ) : This key performs several useful functions. - During incoming calls, press it to answer the incoming call. - In Standby mode, press it briefly to access Main Menu and Select menus. - When navigating a menu, press it to select the highlighted selection. SMS Key ( ) : When in Standby mode, press this key to access Message Menu items. - During incoming calls, press it to answer the incoming call. - From Standby mode, press it briefly to access Message Services. Microphone : Your typical voice microphone for conversation and you can also mute the microphone during conversation by pressing “MENU” “3”. Accessories Connector : The location where you connect your charging device. It can also be used to connect a wireless data device or hands-free car kit. CLR Key : This key is used to erase numbers or characters you may have entered incorrectly, or to return to a previous screen. - To erase one character from the display screen, briefly press it once. - To erase all of them, hold it for one second. - To back up one menu level, press it once. - To return to Standby mode, hold it for one second. - During a call, press it to control a earpiece volume. 8 END/ Key : Press this key to disconnect a call or to return to Standby mode from any menu. Press and hold this key to turn the phone On or Off. SEND Key : This key performs several useful functions. - Dial a number and press it to connect. - Press it once to redial the last outgoing number. Numeric Keys : These keys are to dial and to input numbers and characters. ◀ ◀◀ ◀* : This key performs several useful functions. - Change bells to vibration - Use as navigation keys. # ▶ ▶▶ ▶ : This key performs several useful functions. - Use as instance lock.(Key lock) - Use as navigation keys.. Antenna 9 DISPLAY INDICATORS Display indicators appear across the bottom of your phone’s LCD screen. These display indicators (or icons) will vary based your phone’s operating mode. Signal strength : This icon shows your current signal strength. More lines indicate more signal strength. Four lines indicate maximum strength, and one line indicates least strength. Digital mode : This icon indicates your phone is operating in digital mode. If you are in analog service area, “D” will be disappeared. No service indicator : This icon indicates your phone cannot find a signal because you’re outside a service area. When this is displayed, you cannot make or receive calls. Wait a little while for a sig…
Text truncated - open the document above for the full version.
From: Helen Zhao Sent: Wednesday, October 16, 2002 12:31 PM To: Mike Kuo Cc: Steve Cheng Subject: RE: COMPAL ELECTRONICS, INC., FCC ID :GKRVP-5X, AN02T2294 Mike, Item #1, #4: See revised test report. Item #2: See revised FCC ID Label. Item #3: See revised Operation Manual Item #5: The power output (200mW) listed on the Technical Description is Conducted average, and 630mW which is listed on RF report is Conducted Peak and 966mW is Radiated Peak. Item #6: See revised Tune-up Procedure Item #7: The data listed on SAR report(23.65dB) is Conducted Average, and the data listed on RF report (28dB) is Conducted Peak. Item #8, 9, 10: See newly uploaded files. Thank you! Helen -----Original Message----- From: Mike Kuo Sent: Thursday, October 10, 2002 5:33 PM To: CLIENT ADVOCATES Cc: Steve Cheng Subject: FW: COMPAL ELECTRONICS, INC., FCC ID :GKRVP-5X, AN02T2294 -----Original Message----- From: CERTADM Sent: Thursday, October 10, 2002 5:32 PM To: '[email protected]' Subject: COMPAL ELECTRONICS, INC., FCC ID :GKRVP-5X, AN02T2294 Notice_content ------------- Question #1:Section 6.1 RF output power: The test setup diagram is for antenna conducted measurement. However, power EIRP measurement result is included in this section. Please provide test procedure and instrument setting was used to obtain EIRP readings. Question #2: FCC ID label indicates this device complies with Part 22 and Part 24 of FCC rules. This device is a PCS single band operates under Part 24 of FCC rules only. Please update your FCC ID label. Question #3: There is no RF exposure statement contained in the User manual. Please provide it. Question #4: Please provide frequency stabilities tests at battery end-point. Question #5: The max. transmitting power listed in the technical description is 200mW. However, the max. EIRP measured is 966mW and the conducted output power is 630mW. Please explain. Question #6: The tune up procedure lists AMPS operation but this device is for PCS operation only. Please explain. SAR portion: Question #7: The max. conducted output power measured during the SAR tests is 23.65dBm. The max. conducted output reported in Part 24 test report is 28dBm. Please explain. Question #8:Please provide system validation plots Question #9:Please provide SAR plots and SAR Vs Z at the highest SAR value . Question #10: Please provide dipole and probe calibration file. Since required SAR data have not been provided, SAR technical review will be continued after receiving the requested data. Best Regards Mike Kuo / TCB Certifier The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.
PROPOSED FCC ID LABEL AND LOCATION Compal Electronics, Inc. This device complies with Part 24 of the FCC Rules. FCC ID: GKRVP-5X FCC ID LABEL LOCATION
in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for SINGLE-BAND PCS PHONE MODEL NUMBER: VP-5X BRAND NAME: COMPAL FCC ID: GKRVP-5X September 18, 2002 REPORT NO: 02I1511-2 Prepared for COMPAL ELECTRONICS INC. 8F, NO. 500, JUI-KUANG RD. NEIHU, TAIPEI 114 TAIWAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 02I1511-2 DATE: September 18, 2002 FCC ID: GKRVP-5X COMPLIANCE CERTIFICATION SERVICES Page: 2 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: September 18, 2002 REPORT NO: 02I1511-2 APPLICANT: COMPAL ELECTRONICS INC. NO. 581, JUI-KUANG RD. NEIHU, TAIPEI 114 TAIWAN MODEL: VP-5X FCC ID: GKRVP-5X DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Operating Mode: Maximum continuous output Tx Frequency: 1851.25 ~ 1908.75 MHz Rx Frequency: 1931.25 ~ 1988.75 MHz Max. Conducted O/P Power: 23.65 dBm at 1851.25 MHz Max. SAR (1g): 1.16 mW/g (at 1851.25 MHz, Left hand tilt position) Application Type: Certification FCC Rule Part(s): § 24 (E) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 02I1511-2 DATE: September 18, 2002 FCC ID: GKRVP-5X COMPLIANCE CERTIFICATION SERVICES Page: 3 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION................................................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC........................5 3. DOSIMETRIC ASSESSMENT SETUP...................................................................................5 3.1. MEASUREMENT SYSTEM DIAGRAM....................................................................................................................6 3.2. SYSTEM COMPONENTS...........................................................................................................................................7 4. EVALUATION PROCEDURE.................................................................................................9 5. MEASUREMENT UNCERTAINTY.......................................................................................12 6. EXPOSURE LIMIT................................................................................................................13 7. EUT ARRANGEMENT..........................................................................................................14 8. MEASUREMENT RESULTS................................................................................................15 8.1. SYSTEM VALIDATION..............................................................................................................................................15 8.2. TEST LIQUID CONFIRMATION..............................................................................................................................16 8.3. EUT TUNE-UP PROCEDURE.................................................................................................................................17 8.4. EUT SETUP PHOTOS..............................................................................................................................................18 8.5. SAR MEASUREMENT RESULTS...........................................................................................................................21 9. EUT PHOTOS........................................................................................................................22 10. EQUIPMENTS LIST & CALIBRATION INFORMATION.....................................................23 11. REFERENCES......................................................................................................................24 12. ATTACHMANTS...................................................................................................................25 REPORT NO: 02I1511-2 DATE: September 18, 2002 FCC ID: GKRVP-5X COMPLIANCE CERTIFICATION SERVICES Page: 4 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EUT DESCRIPTION APPLICANT: COMPAL ELECTRONICS INC. NO. 581, JUI-KUANG RD. NEIHU, TAIPEI 114 TAIWAN MODEL: VP-5X FCC ID: GKRVP-5X DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Operating Mode: Maximum continuous output Tx Frequency: 1851.25 ~ 1908.75 MHz Rx Frequency: 1931.25 ~ 1988.75 MHz Max. Conducted O/P Power: 23.65 dBm at 1851.25 MHz Max. SAR (1g): 1.16 mW/g (at 1851.25 MHz, Left hand tilt position) Application Type: Certification FCC Rule Part(s): § 24 (E) Antenna Type Helix Antenna D…
Text truncated - open the document above for the full version.
Vacom_VP-5X; Frequency: 1851.25 MHz (Left Touch) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (95°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.59 mW/g, SAR (1g): 0.909 mW/g, SAR (10g): 0.512 mW/g, (Worst-case extrapolation) Penetration depth: 9.6 (8.9, 10.7) [mm]; Powerdrift: 0.00 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.7 SAR Tot [mW/g] 8.82E-2 2.65E-1 4.41E-1 6.17E-1 7.94E-1 09/18/02 COMPLIANCE CERTIFICATION SERVICES Vacom_VP-5X; Frequency: 1851.25 MHz (Left Touch) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:: , , () Penetration depth: 9.6 (8.9, 10.6) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.7 09/18/02 COMPLIANCE CERTIFICATION SERVICES 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 0102030405060708090 SAR tot [mW/g] [mm] Vacom_VP-5X; Frequency: 1880.00 MHz (Left Touch) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (95°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.24 mW/g, SAR (1g): 0.695 mW/g, SAR (10g): 0.386 mW/g, (Worst-case extrapolation) Penetration depth: 9.2 (8.5, 10.4) [mm]; Powerdrift: 0.03 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.6 SAR Tot [mW/g] 6.60E-2 1.98E-1 3.30E-1 4.62E-1 5.94E-1 09/18/02 COMPLIANCE CERTIFICATION SERVICES Vacom_VP-5X; Frequency: 1908.75 MHz (Left Touch) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (95°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 0.996 mW/g, SAR (1g): 0.559 mW/g, SAR (10g): 0.310 mW/g, (Worst-case extrapolation) Penetration depth: 9.1 (8.5, 10.2) [mm]; Powerdrift: -0.07 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 5.31E-2 1.59E-1 2.66E-1 3.72E-1 4.78E-1 09/18/02 COMPLIANCE CERTIFICATION SERVICES Vacom_VP-5X; Frequency: 1851.25 MHz (Left Tilt) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (110°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 2.07 mW/g, SAR (1g): 1.16 mW/g, SAR (10g): 0.647 mW/g, (Worst-case extrapolation) Penetration depth: 9.3 (8.6, 10.5) [mm]; Powerdrift: 0.12 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.6 SAR Tot [mW/g] 1.07E-1 3.22E-1 5.37E-1 7.52E-1 9.67E-1 09/18/02 COMPLIANCE CERTIFICATION SERVICES Vacom_VP-5X; Frequency: 1851.25 MHz (Left Tilt) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:: , , () Penetration depth: 9.4 (8.7, 10.5) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.6 09/18/02 COMPLIANCE CERTIFICATION SERVICES 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 2.2 0102030405060708090 SAR tot [mW/g] [mm] Vacom_VP-5X; Frequency: 1880.00 MHz (Left Tilt) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (110°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.59 mW/g, SAR (1g): 0.892 mW/g, SAR (10g): 0.496 mW/g, (Worst-case extrapolation) Penetration depth: 9.3 (8.6, 10.4) [mm]; Powerdrift: 0.04 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.5 SAR Tot [mW/g] 8.42E-2 2.53E-1 4.21E-1 5.89E-1 7.58E-1 09/18/02 COMPLIANCE CERTIFICATION SERVICES Vacom_VP-5X; Frequency: 1908.75 MHz (Left Tilt) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (110°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.35 mW/g, SAR (1g): 0.748 mW/g, SAR (10g): 0.409 mW/g, (Worst-case extrapolation) Penetration depth: 8.9 (8.3, 10.0) [mm]; Powerdrift: -0.06 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.6 SAR Tot [mW/g] 6.93E-2 2.08E-1 3.47E-1 4.85E-1 6.24E-1 09/18/02 COMPLIANCE CERTIFICATION SERVICES Vacom_VP-5X; Frequency: 1851.25 MHz (Right Touch) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Righ Hand Section; Position: (95°,300°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.50 mW/g, SAR (1g): 0.919 mW/g, SAR (10g): 0.551 mW/g, (Worst-case extrapolation) Penetration depth: 10.4 (10.0, 11.0) [mm]; Powerdrift: -0.14 dB Coarse: Dx = 16.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.2 SAR Tot [mW/g] 9.23E-2 2.77E-1 4.62E-1 6.46E-1 8.31E-1 09/18/02 COMPLIANCE CERTIFICATION SERVICES Vacom_VP-5X; Frequency: 1851.25 MHz (Right Touch) Frequency: 1900 MHz; Crest factor: 1.0 Medium: Head 1900 MHz: σ = 1.35 mho/m ε r = 40.3 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:: , , () Penetration depth: 10.9 (10.2, 11.9) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.2 09/18/02 COMPLIANCE CERTIFICATION SERVICES 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 0102030405060708090100110 SAR tot [mW/g] [mm] Vacom_VP-5X; Frequency: 1…
Text truncated - open the document above for the full version.
System Validation - D1800V2 S/N: 294 (Antenna input power: 250 mW) SAM-2; Flat Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); Crest factor: 1.0 Head 1800 MHz: σ = 1.39 mho/m ε r = 39.4 ρ = 1.00 g/cm 3 Cube 5x5x7: Peak: 17.5 mW/g, SAR (1g): 9.48 mW/g, SAR (10g): 4.97 mW/g, (Worst-case extrapolation) Penetration depth: 8.4 (8.0, 9.2) [mm] Powerdrift: -0.00 dB Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.7 SAR Tot [mW/g] 1.04E+0 3.12E+0 5.19E+0 7.27E+0 9.35E+0 09/18/02 COMPLIANCE CERTIFICATION SERVICES System Validation - D1800V2 S/N: 294 (Antenna input power: 250 mW) SAM-2; Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); Crest factor: 1.0 Head 1800 MHz: σ = 1.39 mho/m ε r = 39.4 ρ = 1.00 g/cm 3 : , , () Penetration depth: 8.4 (7.9, 9.3) [mm] Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 20.7 09/18/02 COMPLIANCE CERTIFICATION SERVICES 0 2 4 6 8 10 12 14 16 18 010203040506070 SAR tot [mW/g] [mm]
FCC CFR47 CERTIFICATION PART 24E TEST REPORT FOR SINGLE-BAND PCS PHONE MODEL NUMBER: VP-5X BRAND NAME: COMPAL FCC ID: GKRVP-5X REPORT NUMBER: 02I1511-1 ISSUE DATE: SEPTEMBER 20, 2002 Prepared for COMPAL ELECTRONICS INC. 8F, NO. 500, JUI-KUANG RD. NEIHU, TAIPEI 114 TAIWAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02I1511-1 DATE: SEP 20,2002 FCC ID: GKRVP-5X EUT: SINGLE-BAND PCS PHONE Page 2 of 39 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION.................................................................................................. 3 2. EUT DESCRIPTION.......................................................................................................................... 4 3. FACILITIES, LABORATORY AND ACCREDITATION ............................................................ 4 3.1. F ACILITIES ..................................................................................................................................... 4 3.2. L ABORATORY A CCREDITATION .................................................................................................... 4 3.3. L IST OF A CCREDITATIONS ............................................................................................................. 5 4. CALIBRATION, METHODOLOGY AND UNCERTAINTY....................................................... 6 4.1. E QUIPMENT C ALIBRATION ............................................................................................................ 6 4.2. T EST M ETHODOLOGY ................................................................................................................... 6 4.3. M EASUREMENT U NCERTAINTY .................................................................................................... 6 4.4. T EST AND M EASUREMENT E QUIPMENT ........................................................................................ 7 5. APPLICABLE RULES....................................................................................................................... 8 5.1. RF POWER OUTPUT §2.1046 .................................................................................................... 8 5.2. MODULATION CHARACTERISTICS §2.1047 ........................................................................ 8 5.3. OCCUPIED BANDWIDTH §2.1049 ........................................................................................... 8 5.4. SPURIOUS EMISSIONS AT ANTENNA TERMINALS §2.1051 ............................................. 9 5.5. FIELD STRENGTH OF SPURIOUS RADIATION §2.1053 ...................................................... 9 5.6. FREQUENCY STABILITY §2.1055 ........................................................................................... 9 5.7. FREQUENCY RANGE TO BE INVESTIGATED §2.1057 ..................................................... 10 6. TEST SETUP, PROCEDURE AND RESULT............................................................................... 11 6.1. RF POWER OUTPUT ................................................................................................................11 6.2. OCCUPIED BANDWIDTH ....................................................................................................... 17 6.3. SPURIOUS EMISSION AT ANTENNA TERMINAL ............................................................. 21 6.4. FIELD STRENGTH OF SPURIOUS RADIATION .................................................................. 30 6.5. FREQUENCY STABILITY ....................................................................................................... 36 7. EUT SETUP PHOTOS..................................................................................................................... 39 REPORT NO: 02I1511-1 DATE: SEP 20,2002 FCC ID: GKRVP-5X EUT: SINGLE-BAND PCS PHONE Page 3 of 39 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: COMPAL ELECTRONICS INC. 8F, NO. 500, JUI-KUANG RD. NEIHU, TAIPEI 114 TAIWAN EUT DESCRIPTION: SINGLE-MODE PCS PHONE MODEL NUMBER: VP-5X DATE TESTED: SEPTEMBER 16, 2002 - SEPTEMBER 19, 2002 EQUIPMENT TYPE INTENTIONAL RADIATOR 1850-1910 MHz paired with 1930- 1990 MHz (part 24) MEASUREMENT PROCEDURE ANSI 63.4 / 1992, TIA/EIA 603 PROCEDURE CERTIFICATION FCC RULE CFR 47 PART 24 Subpart E Compliance Certification Services, Inc. tested the above equipment for compliance with the requirement set forth in CFR 47, PART 24 Subpart E-Broadband PCS. The equipment in the configuration described in this report, shows the measured emission levels emanating from the equipment do not exceed the specified limit. Note : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Test By: Released For CCS By: FRANK IBRAHIM MIKE HECKROTTE EMC ENGINEER SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REP…
Text truncated - open the document above for the full version.
REPORT NO: 02I1511-1 DATE: SEP 20,2002 FCC ID: GKRVP-5X EUT: SINGLE-BAND PCS PHONE Page 37 of 39 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 7. EUT SETUP PHOTOS CONDUCTED RF MEASUREMENTS REPORT NO: 02I1511-1 DATE: SEP 20,2002 FCC ID: GKRVP-5X EUT: SINGLE-BAND PCS PHONE Page 38 of 39 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. FREQUENCY STABILITY REPORT NO: 02I1511-1 DATE: SEP 20,2002 FCC ID: GKRVP-5X EUT: SINGLE-BAND PCS PHONE Page 39 of 39 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. RADIATED EMISSIONS END OF REPORT
REPORT NO: 02I1511-2 DATE: September 18, 2002 FCC ID: GKRVP-5X COMPLIANCE CERTIFICATION SERVICES Page: 18 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revisi…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 24E | 1.85 GHz - 1.91 GHz | 966.00 mW | 1M25F9W | 2.5000000000 ppm |
