Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
1 USER MANUAL VS-5L Version 0.1 VACOM WIRELESS, INC. 2 CONTENTS IMPORTANT SAFETY INFORMATION GETTING TO KNOW YOUR PHONE DISPLAY INDICATORS BATTERY INFORMATION BASIC FUNCTIONS 1. Making Calls 2. Ending Calls 3. Answering Calls 4. Correcting Entry Errors 5. Storing Phone Numbers 6. Adjusting In-Call Mic Volume 7. Volume 8. Using Caller ID 9. Redialing Last Dialed, Received, or Missed Number 10. Speed Dial 11. Keypad Lock 12. Etiquette Mode 13. Silence Mode 14. Shortcut MENUS I. PHONE BOOK 1. Phone Book Search 2. Phone Number Addition 3. Call List 4. My Number 5. Delete Phone Book 3 II. PHONE SETTINGS MENU 1. Wallpaper 2. Languages 3. Selecting Font 4. Backlight 5. LCD Contrast 6. Screen Saver 7. Auto Keylock III. VOLUME & ALERT 1. Ring Type 2. Selecting Bell 3. Roam Ringer 4. Volume 5. Alert Setting 6. Beep Length IV. PERSONAL INFORMATION MANAGEMENT 1. Alarm 2. Schedule 3. Calendar View 4. Calculator 5. Memo 6. World Time View V. SECURITY FUNCTIONS 1. Phone Lock 2. Changing Password 3. Restricting 4. Privacy Information 5. Initialization VI. CALL INFORMATION 1. Auto Answer 2. Call Answer 3. Auto Redial 4. Call Time 4 VII. GAMES 1. Black Jack 2. Othello 3. Game Sound MESSAGE SERVICES I. TEXT MESSAGE SERVICES (SMS) 1. Reading Text Messages 2. Sending Text Messages II. VOICE MAIL SERVICE III. SMS Settings 1. Alert 2. Save Message 3. Direct View 4. Delivery ACK 5. Priority 6. Delete All USING MENU DURING CALLS 1. Phone Book Search 2. Mute 3. DTMF Mute 4. Volume 5. Mic Volume 6. Voice Privacy 5 IMPORTANT SAFETY INFORMATION Some of the following information may not apply specifically to your phone. However, as with any electronic product, these safety precautions should be observed when using this product. ? Please keep this manual in a safe place, for it contains important safety information and operating instructions. ? Please follow and adhere to all warning, safety, and operating instructions indicated on both the phone and in this manual before use. ? Do Not expose the phone to water or moisture. ? Do Not expose the phone to extreme heat or cold. ? Do Not expose the phone to open flame. ? Do Not allow objects to fall or liquids to spill on the product. ? Use Original Accessories only. Any damage incurred from the use of non-approved accessories will void the warranty. ? Use approved chargers only and connect to a power source designated on the product. ? To reduce the risk of injury, remove the electrical cord from an outlet by pulling on the charger, rather than the cord. ? Ensure that the electrical cord is positioned accordingly so that it will not be vulnerable to damage. ? To reduce the risk of electrical shock, unplug the phone from the power source before cleaning. Once unplugged, use a soft cloth dampened with water to clean. ? DANGER: Do Not modify the cord or the plug. If the plug does not fit into an outlet, have a proper outlet installed by a qualified electrician. Improper connection can result in electrical shock. ? Do Not attempt to disassemble the product – doing so will void the warranty. This product does not contain consumer-serviceable components. Service should be performed only by authorized service centers. ? Do Not remove the antenna. A detached antenna can be a choking hazard for children. ? Do Not place the battery inside the mouth. The battery contains toxic electrolytes that are harmful for your health. 6 GETTING TO KNOW YOUR PHONE LED Indicator : Flashes to indicate an incoming call or message. It also lights up (flashes) when you turn on the phone. Backlit LCD Screen : The LCD screen contains three areas; - The top line displays indication about your phone’s operating mode. - Two lines in the middle are the display areas for numbers and characters. - The bottom line displays menus. Menu Keys ( / ) : This key performs several useful functions. - During incoming calls, press it to answer the incoming call. - In Standby mode, press it briefly to access Main Menu and Select Menu. - When navigating a menu, press it to select the highlighted selection. SMS Key () : When in Standby Mode, press this key to access Message Menu items. Navigation Key (??) : This key allows you to navigate the phone’s variable functionality and useful shortcut. Microphone : Your typical voice microphone for conversation and you can also mute the microphone during conversation by pressing “MENU” “2”. DC Jack : The location where you connect your charging device. CLR Key : This key is used to erase numbers or characters you may have entered incorrectly, or to return to a previous screen. - To erase one character from the display screen, briefly press it once. - To erase all of them, hold it for one second. - To back up one menu level, press it once. - To return to Standby Mode, hold it for one second. - During a call, press it to control earpiece volume. 7 END() Key : Press this key to disconnect a call or to return to Standby Mode from any menu. Press and hold this key to turn the phone On or Off. SEND() Key : This key performs several useful functions. - Dial a number and press it to connect. - Press it once to redial the last outgoing number. Numeric Keys : These keys are to dial and to input numbers and characters. ?* : This key performs several useful functions. - Change bells to vibration - Use as navigation key. # ? : This key performs several useful functions. - Use as instance phone lock. - Use as navigation key. Antenna 8 DISPLAY INDICATORS Display indicators appear across the bottom of your phone’s LCD screen. These display indicators (or icons) will vary based on your phone’s operating modes. Signal strength : This icon shows your current signal strength. More lines indicate more signal strength. Five lines indicate maximum strength, and one line indicates least strength. No service indicator : This icon indicates your phone cannot find a signal because you’re outside a service area. When this is displayed, you cannot make or receive calls. Wait a little while for a signal or mov…
Text truncated - open the document above for the full version.
Sincerely, Andy Suen Senior Director COMPAL ELECTRONICS, INC. Tel : +886-2-8797 8599 Fax : +886-2-8751 3808 Email: [email protected]
PROPOSED FCC ID LABEL AND LOCATION Compal Electronics, Inc. This device complies with Part 22 of the FCC Rules. FCC ID: GKRVS-5L FCC ID LABEL LOCATION
IN ACCORDANCE WITH THE REQUIREMENTS OF FCC REPORT AND ORDER: ET DOCKET 93-62, AND OET BULLETIN 65 SUPPLEMENT C FOR Single Band Single Mode CDMA Cellular Phone MODEL: VS-5L FCC ID: GKRVS-5L REPORT NUMBER: 04I3099-3 ISSUE DATE: December 17, 2004 Prepared for Compal Electronics Inc No. 581, Jui-Kuang Rd. Neihu, Taipei, 114, Taiwan, R.O.C. Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 04I3099-3 DATE: December 17, 2004 FCC ID: GKRVS-5L COMPLIANCE CERTIFICATION SERVICES Page: 2 of 31 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By REPORT NO: 04I3099-3 DATE: December 17, 2004 FCC ID: GKRVS-5L COMPLIANCE CERTIFICATION SERVICES Page: 3 of 31 This report shall not be reproduced except in full, without the written approval of CCS. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: December 17, 2004 APPLICANT: Compal Electronics Inc ADDRESS: No. 581, Jui-Kuang Rd Neihu, Taipei, 114, Taiwan R.O.C. FCC ID: GKRVS-5L MODEL: VS-5L DEVICE CATEGORY: Portable Device EXPOSURE CATEGORY: General Population/Uncontrolled Explosure Single Band Single Mode CDMA Cellular Phone Test Sample is a: Production unit Modulation type: CDMA FCC Rule Parts Frequency Range [MHz] The Highest SAR Values [1g_mW/g] Max. Power Output [dBm] Head: 1.17 22H (CDMA Cell) 824.76 – 848.25 Body: 0.906 24.2 Note: A separation distance of 1.5 cm between the back of the device and a flat phantom This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Explosure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (Edition 01-01). Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Released For CCS By: Hsin-Fu Shih (Sunny Shih) COMPLIANCE CERTIFICATION SERVICES REPORT NO: 04I3099-3 DATE: December 17, 2004 FCC ID: GKRVS-5L COMPLIANCE CERTIFICATION SERVICES Page: 4 of 31 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1 EQUIPMENT UNDER TEST (EUT) DESCRIPTION............................................................................ 5 2 FACILITIES AND ACCREDITATION ................................................................................................... 5 3 SYSTEM DESCRIPTION ..................................................................................................................... 6 4 SYSTEM COMPONENTS .................................................................................................................... 7 4.1 DASY4 MEASUREMENT SERVER.............................................................................................. 7 4.2 DATA ACQUISITION ELECTRONICS (DAE)............................................................................... 7 4.3 EX3DV3 ISOTROPIC E-FIELD PROBE FOR DOSIMETRIC MEASUREMENTS ....................... 7 4.4 LIGHT BEAM UNIT ....................................................................................................................... 8 4.5 SAM PHANTOM (V4.0)................................................................................................................. 8 4.6 DEVICE HOLDER FOR SAM TWIN PHANTOM .......................................................................... 9 4.7 SYSTEM VALIDATION KITS ........................................................................................................ 9 4.8 COMPOSITION OF INGREDIENTS FOR TISSUE SIMULATING LIQUID .................................. 9 5 TEST POSITIONS FOR DEVICES OPERATING NEXT TO A PERSON’S EAR.............................. 10 5.1 CHEEK/TOUCH POSITION........................................................................................................ 11 5.2 EAR/TILT POSITION .................................................................................................................. 12 6 TEST POSITIONS FOR BODY-WORN AND OTHER SIMILAR CONFIGURATIONS ..................... 13 7 SIMULATING LIQUID PARAMETERS CHECK ................................................................................. 14 7.1 SIMULATING LIQUID PARAMETER CHECK RESULT............................................................. 15 8 SYSTEM PERFORMANCE CHECK .................................................................................................. 17 8.1 SYSTEM PERFORMANCE CHECK RESULTS ......................................................................... 18 9 SAR MEASUREMENT PROCEDURES............................................................................................. 19 10 PROCEDURES USED TO ESTABLISH TEST SIGNAL.................................................................... 21 11 SAR MEASUREMENT RESULTS .....................................................................................................22 11.1 LEFT HEAD TOUCH POSITION ................................................................................................ 22 11.2 LEFT HEAD TILT POSITION...................................................................................................... 23 11.3 RIGHT HEAD TOUCH POSITION .............................................................................................. 24 11.4 RIGHT HEAD TILT POSITION .........................................…
Text truncated - open the document above for the full version.
Date/Time: 12/17/04 10:15:26 Test Laboratory: Compliance Certification Services System Performance Check @ 835 MHz DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN:4d002 Phantom section: Flat Section Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.935 mho/m; ε r = 42; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.5 deg. C; Liquid Temperature: 24.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(10.7, 10.7, 10.7); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 d=15mm, Pin=250mW/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.99 mW/g d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 57.9 V/m; Power Drift = -0.1 dB Peak SAR (extrapolated) = 3.64 W/kg SAR(1 g) = 2.41 mW/g; SAR(10 g) = 1.56 mW/g Maximum value of SAR (measured) = 2.96 mW/g 0 dB = 2.96mW/g Date/Time: 12/17/04 10:15:26 Test Laboratory: Compliance Certification Services System Performance Check @ 835 MHz DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN:4d002 Phantom section: Flat Section Measurement Standard: DASY4 (High Precision Assessment) d=15mm, Pin=250mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 1.96 mW/g
Date/Time: 12/17/04 11:22:21 Test Laboratory: Compliance Certification Services Left Hand Side DUT: Compal Electronics, Inc.; Type: VS-5L; Serial: 6725524C Phantom section: Left Section Frequency: 824.76 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 824.76 MHz; σ = 0.927 mho/m; ε r = 42.2; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.5 deg. C; Liquid Temperature: 24.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(10.7, 10.7, 10.7); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 Touch - L-ch/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.26 mW/g Touch - L-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 34.3 V/m; Power Drift = 0.1 dB Peak SAR (extrapolated) = 1.51 W/kg SAR(1 g) = 1.17 mW/g; SAR(10 g) = 0.846 mW/g Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.3 mW/g 0 dB = 1.3mW/g Date/Time: 12/17/04 11:22:21 Test Laboratory: Compliance Certification Services Left Hand Side DUT: Compal Electronics, Inc.; Type: VS-5L; Serial: 6725524C Phantom section: Left Section Measurement Standard: DASY4 (High Precision Assessment) Touch - L-ch/Z Scan (1x1x29): Measurement grid: dx=20mm, dy=20mm, dz=3.5mm Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.19 mW/g Date/Time: 12/17/04 11:22:21 Test Laboratory: Compliance Certification Services Left Hand Side DUT: Compal Electronics, Inc.; Type: VS-5L; Serial: 6725524C Phantom section: Left Section Frequency: 835.89 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 835.89 MHz; σ = 0.939 mho/m; ε r = 42; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.5 deg. C; Liquid Temperature: 24.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(10.7, 10.7, 10.7); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 Touch - M-ch/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.29 mW/g Touch - M-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 33.5 V/m; Power Drift = 0.2 dB Peak SAR (extrapolated) = 1.5 W/kg SAR(1 g) = 1.16 mW/g; SAR(10 g) = 0.832 mW/g Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.31 mW/g Touch - M-ch/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 33.5 V/m; Power Drift = 0.2 dB Peak SAR (extrapolated) = 1.52 W/kg SAR(1 g) = 1.07 mW/g; SAR(10 g) = 0.742 mW/g Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.24 mW/g 0 dB = 1.24mW/g Date/Time: 12/17/04 11:22:21 Test Laboratory: Compliance Certification Services Left Hand Side DUT: Compal Electronics, Inc.; Type: VS-5L; Serial: 6725524C Phantom section: Left Section Frequency: 848.25 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 848.25 MHz; σ = 0.949 mho/m; ε r = 41.9; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.5 deg. C; Liquid Temperature: 24.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(10.7, 10.7, 10.7); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 Touch - H-ch/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.28 mW/g Touch - H-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 34.5 V/m; Power Drift = -0.2 dB Peak SAR (extrapolated) = 1.48 W/kg SAR(1 g) = 1.15 mW/g; SAR(10 g) = 0.827 mW/g Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.3 mW/g 0 dB = 1.3mW/g Date/Time: 12/17/04 11:22:21 Test Laboratory: Compliance Certification Services Left Hand Side DUT: Compal Electronics, Inc.; Type: VS-5L; Serial: 6725524C Phantom section: Left Section Frequency: 824.76 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 824.76 MHz; σ = 0.927 mho/m; ε r = 42.2; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.5 deg. C; Liquid Temperature: 24.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(10.7, 10.7, 10.7); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 Tilt - L-ch/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 1.08 mW/g Tilt - L-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 30.7 V/m; Power Drift = 0.2 dB Peak SAR (extrapolated) = 1.48 W/kg SAR(1 g) = 0.941 …
Text truncated - open the document above for the full version.
FCC CFR47 PART 22 SUBPART H CERTIFICATION TEST REPORT FOR SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE MODEL NUMBER: VS-5L FCC ID: GKRVS-5L REPORT NUMBER: 04I3099-1 ISSUE DATE: DECEMBER 24, 2004 Prepared for COMPAL ELECTRONICS, INC. 7F, NO. 500, JUIKUANG ROAD NEIHU, TAIPEI TAIWAN ROC 114 Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 2 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 3 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY.......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5. EQUIPMENT UNDER TEST............................................................................................................6 5.1. DESCRIPTION OF EUT ..............................................................................................................6 5.2. MAXIMUM OUTPUT POWER .................................................................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................................. 6 5.4. WORST-CASE CONFIGURATION AND MODE......................................................................... 6 5.5. DESCRIPTION OF TEST SETUP ................................................................................................ 7 6. TEST AND MEASUREMENT EQUIPMENT ................................................................................ 9 7. LIMITS AND RESULTS ................................................................................................................. 10 7.1. OCCUPIED BANDWIDTH ........................................................................................................ 10 7.2. RF POWER OUTPUT.................................................................................................................17 7.3. FREQUENCY STABILITY .......................................................................................................... 19 7.4. SPURIOUS EMISSION AT ANTENNA TERMINAL................................................................... 20 8. DIGITAL DEVICE CONFIGURATION - LIMITS AND RESULTS ........................................ 27 8.1. RADIATED EMISSIONS.............................................................................................................27 8.2. POWERLINE CONDUCTED EMISSIONS ................................................................................ 30 9. SETUP PHOTOS .............................................................................................................................. 34 REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 4 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: COMPAL ELECTRONICS INC. 8F, NO. 500, JUI-KUANG RD. NEIHU, TAIPEI 114 TAIWAN EUT DESCRIPTION: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE MODEL: VS-5L SERIAL NUMBER: 6725524B DATE TESTED: DECEMBER 15 – 17, 2004 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 22 SUBPART H NO NON-COMPLIANCE NOTED DIGITAL DEVICE CONFIGURATION: FCC PART 15 SUBPART B NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: THU CHAN CHIN PANG EMC SUPERVISOR EMC TECHNICIAN COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 5 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F …
Text truncated - open the document above for the full version.
REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 34 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 9. SETUP PHOTOS ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP ANTENNA PORT CONDUCTED PHOTO REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 35 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. RADIATED RF MEASUREMENT SETUP FOR FREQUENCY V.S. TEMPERATURE FREQUENCY TEMPERATURE PHOTO REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 36 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. RADIATED RF MEASUREMENT SETUP FOR PORTABLE CONFIGURATION X-AXIS PHOTO REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 37 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Y-AXIS PHOTO REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 38 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Z-AXIS PHOTO REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 39 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. DIGITAL DEVICE RADIATED EMISSIONS SETUP DIGITAL DEVICE FRONT PHOTO REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 40 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. DIGITAL DEVICE BACK PHOTO REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 41 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP LINE CONDUCTED FRONT PHOTO REPORT NO: 04I3099 DATE: DECEMBER 23, 2004 EUT: SINGLE BAND SINGLE MODE CDMA CELLULAR PHONE FCC ID: GKRVS-5L Page 42 of 42 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. END OF REPORT LINE CONDUCTED BACK PHOTO
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 22H | 824.76 MHz - 848.25 MHz | 1.288 W | 1M27F9W | 2.5000000000 ppm |
