GLE13614926.96-27.28 MHz Wireless R/CTX

InterTAN Warranty Care & Use Battery Notes • Use only fresh batteries of the required size and recommended type. • Use only the recommended battery pack and charger. You may purchase a charger at your local RadioShack store.• When the transmitter’s range decreases, replace its battery. Never leave dead or weak batteries in the vehicle or transmitter.• Do not charge the battery pack while it is in the vehi cle or immediately after use. Allow it to cool first. • After you charge the battery pack (12 to 14 hours), disconnect it from the charger. Overcharging the battery pack might damage it. • Do not mix old and new batteries, different types of batteries (alkaline, standard, or rechargeable), or rechargeable batterie s of different capacities. • If you do not plan to use the vehicle for a week or more, remo ve the batteries from it and the transmitter. Batteries can leak chemicals that may destroy electronic parts. • Ensure the connectors and wires are positioned so they do not touch moving parts.• Dispose of old batteries promptly and properly. Do not burn or bury them. • Driving your racer for long periods of time can generate a high heat level, which causes wear and tear on the motor. To help keep heat levels down, when your vehicle’s battery power dies, let it cool for at least 10 minutes before recharging the battery. • Do not touch the motor immediately after using the racer, as it may become hot during use. • If your vehicle’s motor runs, but does not respond to the transmitter, move closer to the vehicle and try again. • If someone uses a CB nearby, it might interfere with the control of your racer. If this happens, move the vehicle away from the CB. • You cannot operate your vehicle near devices with transmitters that use the same frequency as your vehicle (27MHz or 49MHz). Check the box to see which frequency you have. • If your vehicle moves slowly, or not at all, and you have installed a fully charged battery pack, check the wheel mechanism for lint, dust, hair or thread. • When the transmitter’s range decreases, replace its battery. • If your vehicle does not drive in a straight line, adjust the wheel alignment control on the bot-tom of the vehicle. If the vehicle pulls to the right, turn the control toward left, and if it pulls to the left, turn the control toward right. • Do not play with your vehicle in the street.• The racer reaches speeds (110m/360 ft. per minute). Avoid high-impact collisions with people and objects. • If the racer gets stuck under an object, imme- diately release both controls on the transmit-ter. Then, retrieve the vehicle. • Wipe the vehicle occasionally with a damp cloth to keep it looking new. • Tampering with your vehicle’s electronic parts may cause damage to the vehicle. If your vehicle does not operate properly, take it to your local RadioShack store for assistance. Hints & Tips InterTAN warrants that this product will be free from defects in materials and workmanship for a period of ninety (90) days from the date of purchase. Within this period, simply take the product and your proof of purchase to any InterTAN store or dealer and the product will be repaired without charge for parts and labour. InterTAN reserves the right to charge for transportation. Any product which has been subject to misuse or accidental dam-age is excluded from this warranty.This warranty is only applicable to a product purchased through InterTAN’s company owned stores and dealers and to a product that is presented for repair in a country where InterTAN offers the product for sale. While this warranty does not confer any legal rights other than those set out above, you may have addi-tional statutory rights which will vary under the laws of the vari-ous countries, states, provinces and other governmental entities in which InterTAN operates. This warranty is subject to all stat-utory rights you may have in the country of purchase. Important: This car can use nickel-cadmium rechargeable batteries. At the end of a nickel-cadmium battery's useful life, it must be recycled or disposed of properly. Contact your local hazardous waste management authorities for information on recycling or disposal programs in your area. Important : • Not suitable for children under 3 years of age as the toy is electrical and mechanical in nature. • Keep this owner's manual so that you can trace back to the importer whenever necessary. InterferenceYour racer or transmitter might cause TV or radio interference even when it is operating properly. To determine whether your racer or transmitter is causing the interference, turn off your racer and release the control levers. If the interference goes away, your racer or transmitter is causing it. Try to eliminate the interference by: • Moving your racer and transmitter away from the TV or radio• Contacting your local RadioShack store for helpIf you cannot eliminate the interference, you maybe required to stop using your racer.This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1) this device may not cause interference, and2) this device must accept any interference, including interference that may cause undesired operation of the device. Note: This digital apparatus does not exceed the Class B limits for Radio noise emissions from digital apparatus set out in the Radio interference Regulations of Industry Canada. MANUFACTURED IN CHINA. IMPORTED FOR/IMPORTÉ POUR InterTAN CANADA LTD., BARRIE, CANADA, L4M 4W5 REGISTERED TRADEMARK OF InterTAN, CANADA LTD. REGISTERED TRADEMARK LICENSED TO InterTAN CANADA LTD © 2004 InterTAN Canada Ltd. All Rights Reserved. 60-8994/8995/8996/8997 RadioShack is a trademark licensed to 05A04 InterTAN Canada Ltd. by RadioShack Corporation. Printed in China

FCC ID: GLE136149 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221095056 email [email protected] APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 REPORT #: THRU-403020 COVER SHEET Test Report Product Name: 26.96-27.28 MHz Wireless R/C Toy - TX FCC ID: GLE136149 Applicant: SUNCON TOYS INDUSTRY LTD. 11/F., Kai Tak Factory Building, 99 King Fuk Street, San Po Kong’ Kowloon,Hong Kong. Date Receipt: 03/13/2004 Date Tested: 03/19/2004 THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221095056 email [email protected] APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 REPORT #: THRU-403020 TABLE OF CONTENTS TABLE OF CONTENTS LIST APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 TEST REPORT CONTAINING: PAGE 1...............TEST EQUIPMENT LIST PAGE 2...............TEST PROCEDURE PAGE 3-5.............RADIATION INTERFERENCE TEST DATA PAGE 6...............OCCUPIED BANDWIDTH PAGE 7...............OCCUPIED BANDWIDTH PLOT EXHIBITS CONTAINING: EXHIBIT 2............BLOCK DIAGRAM EXHIBIT 3............SCHEMATIC EXHIBIT 4A-4B........PARTS LIST EXHIBIT 5............INSTRUCTION MANUAL EXHIBIT 6............SAMPLE OF FCC ID LABEL EXHIBIT 7............LOCATION OF FCC ID LABEL EXHIBIT 8............EXTERNAL PHOTO - FRONT SIDE EXHIBIT 9............EXTERNAL PHOTO - BACK SIDE EXHIBIT 10...........INTERNAL PHOTO - COMPONENT SIDE EXHIBIT 11...........INTERNAL PHOTO - COPPER SIDE EXHIBIT 14...........CIRCUIT DESCRIPTION THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221095056 email [email protected] APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 REPORT #: THRU-403020 Page 1 of 7 Test Equipment List DEVICE MODEL MFGR SERNO DUE.CAL EMI Test Receiver ESVS 10 Rohde & Schwarz 830489/001 2004.04.25. Spectrum Analyzer 8566B Hewlett Packard 2311A02394 2004.03.17 Spectrum Display 85662A Hewlett Packard 2542A12429 2004.03.17 Quasi-Peak Adapter 85650A Hewlett Packard 2521A00887 2004.03.17 RF Preselector 85685A Hewlett Packard 2648A00504 2004.03.17 Pre- Amplifier 8449B Hewlett Packard 3008A00375 2004.03.17 Pre- Amplifier 8447F Hewlett Packard 3113A05367 2004.03.17 Spectrum Monitor EZM Rohde & Schwarz 862304/007 2004.03.17 Bico- Antenna 94455-1 Eaton 977 2004.03.17 Log- Periodic Antenna 3146 EMCO 2051 2004.03.17 Dipole Antenna TDA25/1/2 Electro Metrics 176/200/200 2004.03.17 Horn Antenna SAS-571 A.H Systems 414 2004.03.17 Spectrum Analyzer R3261C Advantest 71720189 2004.04.26 LISN KNW-242 Kyoritsu 8-923-2 2004.07.12 LISN 8012-50-R-24 Solar 8379121 2004.07.12 Loop Ant 6507 EMCO 1435 2004.10.06 THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221095056 email [email protected] APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 REPORT #: THRU-403020 Page 2 of 7 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of Thrulab & Engineering. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4- 1992 using a HEWLETT PACKARD spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100 kHz and the video bandwidth was 300 kHz. The ambient temperature of the UUT was 11ºC with a humidity of 40%. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI STANDARD C63.4-1992 10.1.7 MEASUREMENT PROCEDURES: The unit under test was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. The situation was similar for the conducted measurement except that the table did not rotate. The EUT was setup as described in ANSIC63.4-1992 with the EUT 40 cm from the vertical ground wall. Not Applicable, battery operated. THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221095056 email [email protected] APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 REPORT #: THRU-403020 Page 3 of 7 APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 NAME OF TEST: RADIATION INTERFERENCE RULES PART NO.: 15.227(a) REQUIREMENTS: CARRIER FREQUENCY SHALL NOT EXCEEDS 10,000 microvolts/meter AT 3M. Frequency (MHz) Reading Receiver dBuv/m PK Reading Receiver dBuv/m AV Polar Ant Height m Antenna Factor dB Cable Loss dB Result dBuv PK Result dBuv AV Limit dBuv/m PK Limit dBuv/m AV Margin dBuv/m PK Margin dBuv/m AV 27.145 49.3 45.1 H 2.0 15.9 0.9 66.1 61.9 100 80 -33.9 -18.1 27.145 64.6 59.9 V 1.50 15.9 0.9 81.4 76.7 100 80 -18.6 -3.3 SAMPLE CALCULATION: FSdBuV/m = MR (dBuV) + ACFdB. TEST PROCEDURE : The procedure used was ANSI STANDARD C63.4-1992. The spectrum was scanned from 30 MHz to 1000 MHz. When an emission was found, the table was rotated to produce the maximum signal strength. The antenna was placed in both the horizontal and vertical planes and the worse case emissions were reported. The UUT was tested in 3 orthogonal planes. TEST RESULTS: THE UNIT DOES MEET THE FCC REQUIREMENTS. PERFORMED BY: K.M CHOI DATE: 03/19/2004 THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221…

Text truncated - open the document above for the full version.

THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221095056 email [email protected] APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 REPORT #: THRU-403020 THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221095056 email [email protected] APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 REPORT #: THRU-403020 THRUlab & Engineering. RM1105,11FL, ACE TECHNO TOWER 197-22,GURO-DONG GURO-GU SEOUL KOREA T81221095059F81221095056 email [email protected] APPLICANT: SUNCON Toys Industry Ltd. FCC ID: GLE136149 REPORT #: THRU-403020
