GLE32-0200DPToy Walkie Talkie

APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP CIRCUIT DESCRIPTION: When Unit A is turned on it transmits on 49.86MHz, under 15.235. The crystal controlled oscillator Q4 generates the RF signal on 49.86MHz. The RF signal is coupled to Q5 through C20. The micro- phone audio is amplified in Q7 and then fed into the audio traansformer T4 which modulates the supply voltage to Q5, the modulated stage. The output of Q5 is fed through the double tuned circuit T1 and then to L1 and then to the antenna. A small por- tion of the oscillator signal is coupled to the mixer Q1.The receive frequency 49.405MHz comes in the antenna to T1 and then is coupled through C2 to RF mixer Q1. From Q1 the signal is coupled through the tunded circuit T3 to the IF amplifier/detec- tor IC1. From IC1 the detected audio signal is amplified in Q2, which in turn drives the output transformer T5. T5 is connected to the speaker. Unit B transmitts on 49.405MHz, under 15.209. When Unit B is turned on it transmits on 49.405MHz, under 15.209. The crystal controlled oscillator Q4 generates the RF signal on 49.405MHz. The RF signal is coupled to Q5 through C20. The microphone audio is amplified in Q7 and then fed into the audio traansformer T4 which modulates the supply voltage to Q5, the modulated stage. The output of Q5 is fed through the double tuned circuit T1 and then to L1 and then to the antenna. A small sprtion of the oscil- lator signal is coupled to the mixer Q1. The receive frequency 49.86MHz comes in the antenna to T1 and then is coupled through C2 to RF mixer Q1. From Q1 the signal is coupled through the tunded circuit T3 to the IF amplifier/detector IC1. From IC1 the detected audio signal is amplified in Q2, which in turn drives the output transformer T5. T5 is connected to the speaker. ANTENNA AND GROUND CIRCUITRY This unit makes use of an 8" external antenna. The antenna is inductively coupled. The unit is powered from a 9.0 volt battery. No ground connection is provided. The unit relies on the ground track of the printed circuit board. APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP REPORT #: F:\CUS\S\SUNCON\SUN252H8.CIR PAGE #: 3

TABLE OF CONTENTS APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP TEST REPORT CONTAINING: PAGE 1-2....TEST PROCEDURE PAGE 3......CIRCUIT DESCRIPTION PAGE 4......49.86MHz Tx RADIATION INTERFERENCE TEST DATA PAGE 5......49.405MHz Tx RADIATION INTERFERENCE TEST DATA PAGE 6......OCCUPIED BANDWIDTH TEST DATA EXHIBITS ATTACHMENTS: EXHIBIT 1..........POWER OF ATTORNEY LETTER EXHIBIT 2..........BLOCK DIAGRAM EXHIBIT 3..........SCHEMATIC EXHIBIT 4A-B-C.....PARTS LIST EXHIBIT 5..........INSTRUCTION MANUAL EXHIBIT 6..........FCC ID LABEL SAMPLE EXHIBIT 7..........FCC ID LABEL LOCATION EXHIBIT 8..........FRONT VIEW EXTERNAL PHOTOGRAPH EXHIBIT 9..........REAR VIEW EXTERNAL PHOTOGRAPH EXHIBIT 10.........INTERNAL COMPONENT SIDE PHOTOGRAPH EXHIBIT 11.........INTERNAL COPPER SIDE PHOTOGRAPH EXHIBIT 12.........OCCUPIED BANDWIDTH PLOT - TX/49.86 EXHIBIT 13.........OCCUPIED BANDWIDTH PLOT - TX/49.405 EXHIBIT 14.........OCCUPIED BANDWIDTH LOUD VOICE - TX/49.86 EXHIBIT 15.........OCCUPIED BANDWIDTH LOUD VOICE - TX/49.405 EXHIBIT 16.........OCCUPIED BANDWIDTH RINGER _ TX/49.86 EXHIBIT 17.........OCCUPIED BANDWIDTH RINGER _ TX/49.405 APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP REPORT #: F:\CUS\S\SUNCON\SUN242H8.RPT TABLE OF CONTENTS PAGE APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP TEST EQUIPMENT LIST 1. Spectrum Analyzer: Hewlett Packard 8566B - Opt 462, w/ preselector 85685A, & Quasi-Peak Adapter HP 8565OA, & HP 8449B - OPT H02 Cal. 6/26/98 2. Signal Generator, Hewlett Packard 8640B, cal. 10/1/98 3. Eaton Biconnical Antenna Model 94455-1 20-200 MHz Serial No. 0997 Cal. 5/15/98 4. Electro-Metric Dipole Kit, 20-1000 MHz, Model TDA 25 cal. 5/15/97 5. Electro-Metric Horn 1-18 GHz, Model RGA-180, Cal. 8/15/98 6. Electro-Metric Antennas Model TDS-25-1, TDS-25-2, 5/15/97 7. Electro-Metric Line Impedance Stabilization Network Model No. EM-7821, Serial No. 101; 100KHz-30MHz 50uH. 12/3/97 8. Electro-Metric Line Impedance Stabilization Network Model No. EM-7820, Serial No. 2682; 10KHz-30MHz 50uH. 12/3/97 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-1992 using a HEWLETT PACKARD spectrum analyzer with a prese- lector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100KHz and the video bandwidth was 300KHz. The ambient temperature of the UUT was &tempr& with a humidity of &humr&. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was estab- lished by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor sup- plied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP REPORT #: F:\CUS\S\SUNCON\SUN242H8.RPT PAGE #: 1 TEST PROCEDURES CONTINUED APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP ANSI STANDARD C63.4-1992 10.1.7 MEASUREMENT PROCEDURES: The unit under test was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. The situation was similar for the conducted measurement except that the table did not rotate. The EUT was setup as described in ANSIC63.4-1992 with the EUT 40 cm from the vertical ground wall. APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP REPORT #: F:\CUS\S\SUNCON\SUN242H8.RPT PAGE #: 2 APPLICANT: SUNCON TOYS INDUSTRY LTD FCCID: GLE32-0200DP CIRCUIT_DESCRIPTION: When Unit A is turned on it transmits on 49.86MHz. This frequency is generated by oscillator Q1. The signal is coupled to the antenna by means of capacitor C1. This signal serves as a receiv- er local oscillator signal which hetrodynes an incoming 49.405 MHz to a 455kHz IF frequency. The IF amplifier, detector, and receiver audio amplifier stages are all incorporated in in- tregrated circuit - LC1600. When the ringer key is pressed the telephone sound IC -VM88 is activated and transmits. When Unit B is turned on it transmits on 49.405 MHz. This fre- quency again serves as both the transmitter carrier and the receiver local oscillator. This signal provides low side injec- tion to produce a 455 kHz IF from an 49.86 MHz signal. ANTENNA_AND_GROUND_CIRCUITRY This unit makes use of an 8" external antenna. The antenna is inductively coupled. The unit is powered from a 9.0 volt battery. No ground connection is provided. The unit relies on the ground track of the printed circuit board. APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP REPORT #: F:\CUS\S\SUNCON\SUN242H8.RPT PAGE #: 3 APPLICANT: SUNCON TOYS INDUSTRY LTD FCC ID: GLE32-0200DP NAME OF TEST: RADIATION INTERFERENCE RULES PART NO.: 15.235 REQUIREMENTS: CARRIER FREQUENCY WILL NOT EXCEED 80 dBuV/m AT 3M. OUT-OF-BAND EMISSIONS SHALL NOT EXCEED: 30 - 88 MHz 40.0 dBuV/M MEASURED AT 3 METERS 88 - 216 MHz 43.5 dBuV/M 216 - 960 MHz 46.0 dBuV/M ABOVE 960 MHz 54.0 dBuV/M * Harmonics must be less than the fundamental. TEST DATA: EMISSION METER READING COAX ANTENNA FIELD FREQUENCY AT 3 METERS LOSS CORRECTION STRENGTH MARGIN ANT. MHz dBuV dB FACTOR dB dBuV/m@3m dB POL. 49.86 58.50 0.25 10.99 69.74 10.26 H 99.70 18.90 0.80 8.39 28.09 15.41 H 149.60 23.20 0.80 16.90 40.90 2.60 H 199.40 19.00 0.90 12.66 32.56 10.94 H 249.30 26.30 1.20 13.35 40.85 5.15 H 299.20 21.30 1.40 15.65 38.35 7.65 H 349.00 18.50 1.40 15.52 35.42 10.5…
