Re: Certification for TRW 39350-S3V-A0 Receiver Model: 39350-S3V-A0 FCC ID: GQ4-3QR IC: 1470A-2R USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: GQ4-3QR IC: 1470A-2R This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.

August 14, 2003 TRW Automotive U.S. LLC d.b.a TRW Automotive Electronics 24175 Research Drive Farmington Hills, MI 48335 Tel: 248.478.7210 Fax: 248.478.7241 RE: Certification for TRW TPM ’04 Receiver Model #: 39350-S3V-A0 FCC ID: GQ4-3QR Canada IC: 1470A-2R EXHIBIT_______ Confidential / Trade Secret Information Page ___ of ___ TRW BLOCK DIAGRAM Receiver Batt. + to Init K-Line LED Drive 7 5 5 4 EEPROM Voltage Regulator Micro Controller LED Drive RF Filter / Amplifier RF Demod. 5.086MHz xtal Discrete Input Buffer K-Line 125KHz - 160KHz Cond. LF Ground Cond. LF Power- Supply Cond. 10MHz xtal Figure 2. TPM Receiver Block Diagram August 14, 2003 TRW Automotive U.S. LLC d.b.a TRW Automotive Electronics 24175 Research Drive Farmington Hills, MI 48335 Tel: 248.478.7210 Fax: 248.478.7241 RE: Certification for TRW TPM ’04 Receiver Model #: 39350-S3V-A0 FCC ID: GQ4-3QR Canada IC: 1470A-2R EXHIBIT_______ Page ___ of ___ TRW GENERAL DESCRIPTION The TPM receiver is used to demodulate and decode information transmitted from the wheel- mounted sensors. This information is then sent to a display unit. The receiver shall directly illuminate the display with discrete light emitting diode (LED) drivers. The receiver can initiate the transmitter to send configuration data or pressure and temperature data by activating the low frequency initiator mounted in the wheel well. This activation can also be used to determine if a new transmitter has been placed in the TPM. The receiver shall be able to do diagnostics on the system to determine if the system needs to be serviced. The receiver can also place the transmitter in a low current mode when the ignition is off to prolong the battery life of the transmitter. When the ignition is turned on, the receiver should put the transmitter in to a high update rate mode and immediately get the tire and pressure information from the transmitter. Activating the transmitter with the low frequency initiator does the mode changes. August 14, 2003 TRW Automotive U.S. LLC d.b.a TRW Automotive Electronics 24175 Research Drive Farmington Hills, MI 48335 Tel: 248.478.7210 Fax: 248.478.7241 RE: Certification for TRW TPM ’04 Receiver Model #: 39350-S3V-A0 FCC ID: GQ4-3QR Canada IC: 1470A-2R EXHIBIT_______ Confidential / Trade Secret Information Page ___ of ___ TRW PRINCIPLES OF CIRCUIT OPERATION The receiver contains a microprocessor and firmware that control the entire TPM system. The microprocessor sends low frequency (125KHz) amplitude-shift-keying data to the initiator via a signal conditioning circuit and wire harness. The initiator, which is located in the wheel well, amplifies this signal and transmits data to the tire pressure sensor located in the wheel. The sensor responds with data modulated at 315MHz. The receiver demodulates this 315MHz signal to receive the data sent from the pressure sensor. Tire pressure problems are reported to the driver via light emitting diodes on the dashboard. The receiver illuminates the LEDs with LED driver circuitry.

Re: Certification for TRW 39350-S3V-A0 Receiver Model: 39350-S3V-A0 FCC ID: GQ4-3QR IC: 1470A-2R POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for TRW 39350-S3V-A0 Receiver Model: 39350-S3V-A0 FCC ID: GQ4-3QR IC: 1470A-2R REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, TRW requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) TRW has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan October 22, 2003 Re: Certification for TRW 39350-S3V-A0 Receiver Model: 39350-S3V-A0 FCC ID: GQ4-3QR IC: 1470A-2R STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for TRW 39350-S3V-A0 Receiver Model: 39350-S3V-A0 FCC ID: GQ4-3QR IC: 1470A-2R GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: TRW Inc. 24175 Research Drive Farmington Hills, MI 48335-2642 David Kapolka Tel: 248.478.7210 ext 4858 Fax: 248.478.7241 It will be manufactured by: TRW Automotive Electronics 2240 Cranbrook Drive Auburn, New York, 13021 David Kapolka Tel: 248.478.7210 ext 4858 Fax: 248.478.7241 Canadian Contact: TRW Canada Limited 16643 Highway 12 Midland, Ontario, Canada L4R4L5 Phone Number: 705.526.8791 FAX: 705.527.6232 Contact: Bob Millett ext 4103

October 24, 2003 RE: TRW Inc. FCC ID: GQ4-3QR The following is in response to comments made on the above referenced Application. Q: It is not certain if the labeling should be placed as indicated. TRW wants to place the labels as indicated primarily for identification, marketing, and inventory reasons. Since the RX is entirely contained in the control module, its label will be on main module. For the LF transmitter, the circuitry is split between the control module and the “initiator” module. Here, TRW requests that the label be placed on the “initiator” module because, in the users/manufacturers view, the initiator is this module and the transmitting coil is contained therein. Essentially, the labels are placed as such to avoid confusion and provide a means of identifying the RX and LF TX separately to the customer. Both modules will be sold together as part of the same model, 39360-S3V-A0.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 ` October 23, 2003 RE: TRW Inc. FCC ID: GQ4-3QR After a review of the submitted information, I have a few comments on the above referenced Application. General 1) Please refer to question 3 of FCC ID: GQ4-22T just reviewed. This question could affect how this application may be processed. Please let us know. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

August 14, 2003 TRW Automotive U.S. LLC d.b.a TRW Automotive Electronics 24175 Research Drive Farmington Hills, MI 48335 Tel: 248.478.7210 Fax: 248.478.7241 RE: Certification for TRW TPM ’04 Receiver Model #: 39350-S3V-A0 FCC ID: GQ4-3QR Canada IC: 1470A-2R EXHIBIT_______ Page ___ of ___ TRW FCC/IC IDENTIFIER AND MODEL NUMBER Please see Figure 1 for the FCC/IC identifier location and the model number location. Figure 1. Model Number and FCC/IC Identifier The model number for the receiver is: 39350-S3V-A0 The FCC ID for the receiver is: GQ4-3QR The Canada IC number for the receiver is: 1470A-2R

August 14, 2003 TRW Automotive U.S. LLC d.b.a TRW Automotive Electronics 24175 Research Drive Farmington Hills, MI 48335 Tel: 248.478.7210 Fax: 248.478.7241 RE: Certification for TRW TPM ’04 Receiver Model #: 39350-S3V-A0 FCC ID: GQ4-3QR Canada IC: 1470A-2R EXHIBIT_______ Page ___ of ___ TRW GENERAL DESCRIPTION The TPM receiver is used to demodulate and decode information transmitted from the wheel- mounted sensors. This information is then sent to a display unit. The receiver shall directly illuminate the display with discrete light emitting diode (LED) drivers. The receiver can initiate the transmitter to send configuration data or pressure and temperature data by activating the low frequency initiator mounted in the wheel well. This activation can also be used to determine if a new transmitter has been placed in the TPM. The receiver shall be able to do diagnostics on the system to determine if the system needs to be serviced. The receiver can also place the transmitter in a low current mode when the ignition is off to prolong the battery life of the transmitter. When the ignition is turned on, the receiver should put the transmitter in to a high update rate mode and immediately get the tire and pressure information from the transmitter. Activating the transmitter with the low frequency initiator does the mode changes. August 14, 2003 TRW Automotive U.S. LLC d.b.a TRW Automotive Electronics 24175 Research Drive Farmington Hills, MI 48335 Tel: 248.478.7210 Fax: 248.478.7241 RE: Certification for TRW TPM ’04 Receiver Model #: 39350-S3V-A0 FCC ID: GQ4-3QR Canada IC: 1470A-2R EXHIBIT_______ Confidential / Trade Secret Information Page ___ of ___ TRW PRINCIPLES OF CIRCUIT OPERATION The receiver contains a microprocessor and firmware that control the entire TPM system. The microprocessor sends low frequency (125KHz) amplitude-shift-keying data to the initiator via a signal conditioning circuit and wire harness. The initiator, which is located in the wheel well, amplifies this signal and transmits data to the tire pressure sensor located in the wheel. The sensor responds with data modulated at 315MHz. The receiver demodulates this 315MHz signal to receive the data sent from the pressure sensor. Tire pressure problems are reported to the driver via light emitting diodes on the dashboard. The receiver illuminates the LEDs with LED driver circuitry.

The University of Michigan Radiation Laboratory 3228 EECS Building Ann Arbor, MI 48109-2122 Tel: (734) 764-0500 Measured Radio Frequency Emissions From TRW Receiver Model: 39350-S3V-A0 Report No. 415031-177 October 22, 2003 Copyright © 2003 For: TRW, Inc. 24175 Research Drive Farmington Hills, MI 48335-2642 Contact: David Kapolka Tel: 248.478.7210 ext 4858 Fax: 248.478.7241 PO: Verbal Tests supervised by: Measurements made by: Report approved by: _____________________ Edward M. Courtney Valdis V. Liepa Valdis V. Liepa Research Scientist Summary Tests for compliance with FCC Regulations Part 15, Subpart B, and Industry Canada RSS-210, were performed on TRW model 39350-S3V-A0. This device is subject to the Rules and Regulations as a Receiver. As a Digital Device it is exempt, but such measurements were made to assess the receiver's overall emissions. In testing completed on 7-Jul-03, the device tested in the worst case met the allowed FCC (Class B) specifications for radiated emissions by 6.7 dB (see p. 6). The conducted emissions tests do not apply, since the device is powered from a 12 VDC system. 2 1. Introduction TRW model 39350-S3V-A0 was tested for compliance with FCC Regulations, Part 15, adopted under Docket 87-389, April 18, 1989, and with Industry Canada RSS-210, Issue 5, November, 2001. The tests were performed at the University of Michigan Radiation Laboratory Willow Run Test Range following the procedures described in ANSI C63.4-1992 "Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". The Site description and attenuation characteristics of the Open Site facility are on file with FCC Laboratory, Columbia, Maryland (FCC Reg. No: 91050) and with Industry Canada, Ottawa, ON (File Ref. No: IC 2057). 2. Test Procedure and Equipment Used The pertinent test equipment commonly used in our facility for measurements is listed in Table 2.1 below. The middle column identifies the specific equipment used in these tests. Table 2.1 Test Equipment. Test Instrument Eqpt. Used Manufacturer/Model Spectrum Analyzer (0.1-1500 MHz) Hewlett-Packard, 182T/8558B Spectrum Analyzer (9kHz-22GHz) X Hewlett-Packard 8593A SN: 3107A01358 Spectrum Analyzer (9kHz-26GHz) X Hewlett-Packard 8593E, SN: 3412A01131 Spectrum Analyzer (9kHz-26GHz) Hewlett-Packard 8563E, SN: 3310A01174 Spectrum Analyzer (9kHz-40GHz) Hewlett-Packard 8564E, SN: 3745A01031 Power Meter Hewlett-Packard, 432A Power Meter Anritsu, ML4803A/MP Harmonic Mixer (26-40 GHz) Hewlett-Packard 11970A, SN: 3003A08327 Harmonic Mixer (40-60 GHz) Hewlett-Packard 11970U, SN: 2332A00500 Harmonic Mixer (75-110 GHz) Hewlett-Packard 11970W, SN: 2521A00179 Harmonic Mixer (140-220 GHz) Pacific Millimeter Prod., GMA, SN: 26 S-Band Std. Gain Horn S/A, Model SGH-2.6 C-Band Std. Gain Horn University of Michigan, NRL design XN-Band Std. Gain Horn University of Michigan, NRL design X-Band Std. Gain Horn S/A, Model 12-8.2 X-band horn (8.2- 12.4 GHz) Narda 640 X-band horn (8.2- 12.4 GHz) Scientific Atlanta , 12-8.2, SN: 730 K-band horn (18-26.5 GHz) FXR, Inc., K638KF Ka-band horn (26.5-40 GHz) FXR, Inc., U638A U-band horn (40-60 GHz) Custom Microwave, HO19 W-band horn(75-110 GHz) Custom Microwave, HO10 G-band horn (140-220 GHz) Custom Microwave, HO5R Bicone Antenna (30-250 MHz) X University of Michigan, RLBC-1 Bicone Antenna (200-1000 MHz) X University of Michigan, RLBC-2 Dipole Antenna Set (30-1000 MHz) X University of Michigan, RLDP-1,-2,-3 Dipole Antenna Set (30-1000 MHz) EMCO 2131C, SN: 992 Active Rod Antenna (30 Hz-50 MHz) EMCO 3301B, SN: 3223 Active Loop Antenna (30 Hz-50 MHz) EMCO 6502, SN:2855 Ridge-horn Antenna (300-5000 MHz) X University of Michigan Amplifier (5-1000 MHz) X Avantak, A11-1, A25-1S Amplifier (5-4500 MHz) X Avantak Amplifier (4.5-13 GHz) Avantek, AFT-12665 Amplifier (6-16 GHz) Trek Amplifier (16-26 GHz) Avantek LISN Box University of Michigan Signal Generator X Hewlett-Packard 8657B 3 3. Configuration and Identification of Device Under Test The DUT is a 315 MHz superheterodyne receiver, designed for onboard automobile security/convenience applications, and as such, it is powered from an automotive 12 VDC source. It is housed in a plastic case approximately 6 by 4 by 1.5 inches. Antenna is internal. For testing, a generic harness was provided by the manufacturer. In the receiver digital section, the decoding, signal processing, etc. are performed by a microprocessor timed by a 10 MHz oscillator. The RFIC used in this receiver operates at 2 x LO frequency of 651.4 MHz, the LO is generated through the use of a divider, resulting in a LO of 325.7 MHz and IF of 10.7 MHz. The DUT was designed by TRW, Inc., 24175 Research Drive, Farmington Hills, MI 48335-2642. It is identified as: TRW Receiver Model: 39350-S3V-A0 FCC ID: GQ4-3QR IC: 1470A-2R 3.1 Modifications Made There were no modifications made to the DUT by this laboratory. 4. Emission Limits The DUT tested falls under Part 15, Subpart B, "Unintentional Radiators". The pertinent test frequencies, with corresponding emission limits, are given in Tables 4.1 and 4.2 below. 4.1 Radiated Emission Limits Table 4.1. Radiated Emission Limits (Ref: 15.33, 15.35, and 15.109). Freq. (MHz) E lim (3m) μV/m E lim dB(μV/m) 30-88 100 40.0 88-216 150 43.5 216-960 200 46.0 960-2000 500 54.0 Note: Quasi-Peak readings apply to 1000 MHz (120 kHz BW) Average readings apply above 1000 MHz (1 MHz BW) 4.2 Conducted Emission Limits Table 4.3 Conducted Emission Limits (FCC:15.107 (CISPR); IC: RSS-210, 6.6). Frequency Class A (dBμV) Class B (dBμV) MHz Quasi-peak Average Quasi-peak Average .150 - 0.50 79 66 66 - 56* 56 - 46* 0.50 - 5 73 60 56 46 5 - 30 73 60 60 50 Notes: 1. The lower limit shall apply at the transition frequency 2. The limit decreases linearly with the logarithm of the frequency in the range 0.15-0.50 MHz: *Class B Quasi-peak: dBμV = 50.25 - 19.12*log( f ) *Class B Average: dBμV = 40.25 - 19.12*log( f ) 3. 9 kHz RBW 4 4.3 Antenna …
