GQ4-45TTire Pressure Monitoring Transmitter

TRW Automotive Legal name here February 15, 2010 TEE 24175 Research Dr. Farmington Hills, MI 48335-2642 Tel 248.478.7210 Fax 248.699.4241 RE: Certification for Toyota MY11 FSK 315MHz 20 o /40 o Fixed Angle Transmitters Model #: 226196 (20 degree) 226204 (40 degree) FCC ID: GQ4-45T Canada IC: 1470A-26T USER’S MANUAL & COMPLIANCE STATEMENT The TPM Transmitter is sold only as part of a vehicle by the retail automobile dealers and as such has no separate manual. This exhibit is provided electronically to the vehicle manufacturer after submission. The compliance statement for the TPM Receiver (FCC ID: GQ4-45T) will be integrated by the OEM into the vehicle owner’s manual. It will read: This device complies with part 15 of the FCC rules, and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by TRW Automotive U.S. LLC could void the user’s authority to operate the equipment. .

March 17, 2010 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for TRW Transmitter Model/PN(s): 226196 (20 degree) 226204 (40 degree) FCC ID: GQ4-45T IC: 1470A-26T Please find enclosed application materials for certification of TRW Transmitter. We tested it and found it to comply with FCC Part 15. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

February 12,2010 Federal Conmmnications Commission Applications Processing Branch 7435 Oakland Mills Road Colombia, MD 21046 Re: Letter of Agency for FCC Compliance Testing TRW ALltomotive TEE 24175 Research Dr. Farmington Hills, MI 48335-2642 Tel 248.478.7210 Fax 248.699.4241 Please be advised that TRW Automotive authorizes Professor Valdis V. Liepa of the University of Michigan, Department of Electrical Engineering and Computer Science, AIUl Arbor, Michigan, to act on our behalf in front of the Federal Communications Conmlission with respect to all matters relating to certification. Anti-Drug Abuse Cel1ification: I further certify that no party (as defined in 1.2002 ofCFR47, 1992) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 530 I of the Anti Dmg Abuse Act of 1988,21 U.S.C. 853(a). Dated this _-'-J=~_ day of By: Title: Director of Global Infrastructure & Engineering Services Email: jeff.roc [email protected] om On behalf of: TRW Automotive Telephone: 248.699.4235 Legal name here

Re: Certification for TRW Transmitter FCC ID: GQ4-45T IC: 1470A-26T REQUEST FOR CONFIDENTIALITY Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, TRW requests that a part of the subject application be held confidential. TRW has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Type of Confidentiality Requested Exhibit Short Term Permanent (1) ID Label & Location Short Term Permanent (3) External Photos Short Term Permanent 1 (4) Block Diagram Short Term Permanent (5) Schematics Short Term Permanent (7) Test Setup Photos Short Term Permanent (8) User’s Manual Short Term Permanent (9) Internal Photos Short Term Permanent (10) Parts List & Placement Short Term Permanent (11) RF Exposure Short Term Permanent (12) Description of Operation 1. Block Diagram includes internal oscillator frequency information that the manufacturer considers to be proprietary. Permanent Confidentiality: TRW requests the exhibits listed above as permanently confidential be permanently withheld from public review. Short-Term Confidentiality (FCC Only): TRW requests the exhibits selected above as short term confidential be withheld from public view for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa, Research Scientist University of Michigan

March 17, 2010 RE: ATCB008782 – Original Equipment & New Family Certification Applications (models 226196 & 226204) FCC ID: GQ4-24T & IC: 1470A-26T for TRW, Inc. The following is in response to the comments made on the above referenced application. 1. In the equipment label exhibit, Figure 2 has the wrong FCC ID number shown. Please provide a new equipment label exhibit with the correct FCC ID number shown in both Figure 1 and Figure 2 labels. There was a mistake in one of the drawing provided that resulted in an error in the paperwork provided. Both the label drawing and the associated paperwork has been updated to reflect the correct FCC ID: GQ4-45T. 2. In Table 6.1 of the submitted test report, there appears to be a note missing from the value of E3 stating that the duty cycle correction factor of -16 dB has been included in the reported value. Please correct this omission from the test report exhibit. The table has been corrected to include the duty cycle employed. 3. The operational description exhibit states that this device has an LF receiver as follows “This receiver supports Low Frequency (LF) magnetic field communications allowing the changing of measurement/monitoring states of the transmitter by commands sent via LF trigger tool, special hand held tool (LF transmitter). The RF signal operates at 315MHz and uses FSK Manchester modulation.” What is the operating frequency of the receiver contained in this device? (The last sentence in quotes seems to say that this receiver is a 315 MHz receiver. IC would require receiver measurements on a receiver operating above 30 MHz. I don’t see any such measurements in the submitted test report). The DUT employs only a 125 kHz passive detector that can be used to interrogate the units 315 MHz transmitter. The 315 MHz receiver discussed is employed as a separate device in the vehicle.

TRW Auto motive Legal name here February 12, 2010 TEE 24175 Research Dr . Farming ton Hills, MI 48335-2642 Tel 248.478.7210 Fax 248.699.4241 RE: Certif ication for Toyota MY11 FSK 315MHz 20 o /40 o Fixed Angle Tr ansmitters Model #: 226196 (20 degree) 226204 (40 degree) FCC ID: GQ4-45T Can ada IC: 1470A-26T FCC/I C IDENTIFI ER AND MODEL NUMBER Please see Figure 1 for the FCC/IC Identifi er location on 226196 (20 degree) and Fig ure 2 for 226204 (40 degree). Figure 1: Identifier Location Figure 2: Identifier Location

TRW Automotive Legal name here February 12, 2010 TEE 24175 Research Dr. Farmington Hills, MI 48335-2642 Tel 248.478.7210 Fax 248.699.4241 Certification for Toyota MY11 FSK 315MHz 20 o /40 o Fixed Angle Transmitters Model #: 226196 (20 degree) 226204 (40 degree) FCC ID: GQ4-45T Canada IC: 1470A-26T PRINCIPLES OF CIRCUIT OPERATION The sensor incorporates an ASIC to measure the parameters within the tire. The ASIC outputs the measured data in digital pulses. The digital data gates on and off a power amplifier which couples the RF carrier to the antenna. The transmitted signal uses Frequency Shift Keying (FSK). The carrier frequency of the sensor is 315MHz typically. The worst case frequency shift of the carrier is 314.77MHz for the low frequency and 315.15MHz for the high frequency shift. The receiver bandwidth must be wide enough to pass the transmitter worst case frequency shifts. TRW Automotive Legal name here February 12, 2010 TEE 24175 Research Dr. Farmington Hills, MI 48335-2642 Tel 248.478.7210 Fax 248.699.4241 RE: Certification for Toyota MY11 FSK 315MHz 20 o /40 o Fixed Angle Transmitters Model #: 226196 (20 degree) 226204 (40 degree) FCC ID: GQ4-45T Canada IC: 1470A-26T GENERAL DESCRIPTION This transmitter is a transmitter device with tire valve, which is mounted in the valve hole of the wheel rim and transmits the pressure and temperature inside the tire, the battery voltage flag of the transmitter, and the tire identification code (ID) at normal and abnormal condition with the radio wave (RF) that conforms to the used area. Also this device has a countermeasure function such as the random delay of transmission time so that the RF signal from each tire will not interfere such as due to the simultaneous transmission. The transmitter device also has a Low Frequency (LF) receiver. This receiver supports Low Frequency (LF) magnetic field communications allowing the changing of measurement/monitoring states of the transmitter by commands sent via LF trigger tool, special hand held tool (LF transmitter). The RF signal operates at 315MHz and uses FSK Manchester modulation. Description of Operations Mode of Operation for 226196 and 226204 Explanation Frequency of Transmission Storage Mode No transmission. Measures temperature & pressure 4 Packets when activation occurs with TPM diagnostic tool Normal Mode Measures temperature and pressure and accel. Transmits periodically. Enters this mode from storage when pressure goes above threshold.  4 Packets every 180+ 12 seconds  4 Packets when activation occurs with TPM diagnostic tool Alert Mode Transmits when: a) significant pressure delta detected b) high temperature is detected 8 Packets every 4 seconds for 1 minute

University of Michigan Radiation Laboratory FCC Part 15, IC RSS-210/Gen - Test Report No. 417124-552 Page 1 of 11 The University of Michigan Radiation Laboratory 3228 EECS Building Ann Arbor, MI 48109-2122 Tel: (734) 764-0500 Fax: (734) 647-2106 Measured Radio Frequency Emissions From TRW Inc. Transmitter FCC ID: GQ4-45T IC: 1470A-26T Test Report No. 417124-552 February 24, 2010 Copyright © 2010 For: TRW Inc. 24175 Research Drive Farmington Hills, MI 48335-2642 Contact: Jeff Rochette [email protected] Phone: (248) 699-4235 Fax: (248) 699-4241 Testing supervised by: Measurements made by: Valdis V. Liepa Report Approved by:__________________________ Valdis V. Liepa Test report written by: Joseph D. Brunett Research Scientist Summary Tests for compliance with FCC Regulations, CFR 47, Part 15 and with Industry Canada RSS-210/Gen, were performed on a TRW, FCC ID: GQ4-45T, IC: 1470A-26T . This device under test (DUT) is subject to the rules and regulations as a Transmitter. In testing completed on January 19, 2010, the DUT tested met the allowed specifications for radiated emissions by 7.5 dB. Conducted emissions are not subject to regulation as the DUT is powered by a 3 VDC battery. University of Michigan Radiation Laboratory FCC Part 15, IC RSS-210/Gen - Test Report No. 417124-552 Page 2 of 11 Table of Contents 1. Introduction ...................................................................................................................................... 3 2. Equipment Used ............................................................................................................................... 3 3. Device Under Test ........................................................................................................................... 4 3.1 Description & Block Diagram .............................................................................................. 4 3.2 Variants & Samples .............................................................................................................. 4 3.3 Modes of Operation .............................................................................................................. 4 3.4 Exemptions ........................................................................................................................... 4 3.5 EMC Relevant Modifications ............................................................................................... 4 4. Emissions Limits .............................................................................................................................. 5 4.1 Radiated Emissions Limits .................................................................................................... 5 4.2 Power Line Conducted Emissions Limits ............................................................................. 5 5. Measurement Procedures ................................................................................................................. 6 5.1 Semi -Anechoic Chamber Radiated Emissions ...................................................................... 6 5.2 Outdoor Radiated Emissions ................................................................................................. 6 5.3 Radiated Field Computations ................................................................................................ 6 5.4 Indoor Power Line Conducted Emissions ............................................................................. 6 5.5 Supply Voltage Variation ...................................................................................................... 7 6. Test Results ...................................................................................................................................... 7 6.1 Radiated Emissions ............................................................................................................... 7 6.1.1 Correction for Pulse Operation ......................................................................................... 7 6.1.2 Emission Spectrum ........................................................................................................... 7 6.1.3 Emission Bandwidth ......................................................................................................... 7 6.1.4 Supply Voltage and Supply Voltage Variation ................................................................. 7 6.2 Conducted Emissions ............................................................................................................ 7 University of Michigan Radiation Laboratory FCC Part 15, IC RSS-210/Gen - Test Report No. 417124-552 Page 3 of 11 1. Introduction This TRW transmitter was tested for compliance with FCC Regulations, Part 15, adopted under Docket 87-389, April 18, 1989 as subsequently amended, and with Industry Canada RSS-210/Gen, Issue 7, June 2007. Tests were performed at the University of Michigan Radiation Laboratory Willow Run Test Range following t he pr ocedures de scribed i n A NSI C 63.4-2003 " Methods of M easurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kH z to 40 G Hz". The Site d escription a nd a ttenuation c haracteristics o f th e O pen Site f acility a re o n f ile w ith FC C Laboratory, Columbia, Maryland (FCC Reg. No: 91050) and with Industry Canada, Ottawa, ON (File Ref. No: IC 2057A-1). 2. Equipment Used The test equipment commonly used in our facility is listed in Table 2.1. Except where indicated as a pre- test, monitoring, or support device; all equipment listed below is a part of the University of Michigan Radiation Laboratory (UMRL) q uality system. This q uality system h as b een est ablished t o en sure al l equipment has a clearly identifiable classification, calibration expiry date, and that all calibrations are traceable to national standards. Table 2.1 Test Equipment. Test Instrument Used Manufacturer/Model Q Number Spectrum Analyze…
