GQ43VT26RRKE Superheterodyne Reciever
BCS Access Systems US LLC
Click to zoom
Application Details
- Equipment Class
- CYY - Communications Receiver used w/Pt 15 Transmitter
- Date of Grant
- Jul 27, 2000
- Application Purpose
- Original Equipment
- Date of Application
- Jul 13, 2000
- Equipment Note
- RKE Superheterodyne Reciever
- Frequency Range
- 315.00000000 - 315.00000000
- Company
- BCS Access Systems US LLC
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Block Diagram
Automotive Electronics Group - IX - Re: Certification for TRW ’02 DR/DX Receiver Model No.: GQ43VT26R FCC ID: GQ43VT26R CANADA: BLOCK DIAGRAM The receiver circuit is comprised of a PCB antenna, RF amplifier, mixer, local oscillator, data filter, EEPROM and microprocessor. RF AMPLIFIER MICROPROCESSOR MIXER ANTENNA LOCAL OSCILLATOR DATA FILTER EEPROM OUTPUT DRIVE Figure 1. Receiver Block Diagram
Contact Information
Applicant
Jack Burr(Engineering Manager - Hardware)
Technical Contact
University of Michigan/EECSValdis V Liepa
[email protected]734-483-4211
1301 Beal Ave. · Ann Arbor, Michigan · United States
Non-Technical Contact
University of Michigan/EECSValdis V Liepa
[email protected]734-483-4211
Test Firm
University of MichiganValdis Liepa
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | 315 MHz - 315 MHz | - |
