H4JVT-4E150VHF Base Station Transmitter

JULY 25, 2006 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: H4JVT-4E150 Product Name: VT-4E150 VHF TRANSMITTER Compliance with 47 CFR Part 90.203 (g), (j)(3) Pursuant to 47 CFR Sections 90.203(g) and (j)(3) of the commission’s rules we hereby certify that the above listed transmitter is fully compliant with these guidelines for the following listed reasons. The VT-4E150 transmit frequency is capable of being programmed within the range of 136 to 174 MHz via an external USB connection and Radio Services Software (RSS) package, which is made available only to service and/or maintenance personnel. The narrowband setting of this equipment operates from 0.5 to 8 Watts and meets a spectrum efficiency standard of one voice channel per 12.5 kHz of channel bandwidth in analog transmit mode. In the digital transmit mode, the equipment supports the minimum data rate of 9600 bits per second per 12.5 kHz of channel bandwidth. Dated this 25 Day of JULY 20 06 By: MICHAEL J CYR Signature Printed Title: COMMUNICATION SYSTEMS DESIGNER On behalf of : DANIELS ELECTRONICS LTD Telephone: (250)382-8268

2. Transmitter Block Diagram COAX ENABLE RF AMPLIFIER MODULE Synthesizer Module MODULATOR Mainboard MICROPHONE CSEL0CSEL3 CSEL2 CSEL1 BANK A/B Channel/Bank Select Universal Daughter Board (UDB) PTT NORM OFF KEY TX A / D MIC MODE SELECT RJ45 FRONT PANEL RSS Programming/ Flashing Analog PTT Digital PTT LVDS 600 OHM BALANCED I/P TX Audio Level Adjust LED1 LED2 DIGITAL LED ANALOG LED Mmicrophone Aaudio Level Adjust Balance I/P Level Adjust Codec Interface Analog/Digital Select Vocoder Per-emp Filter CTCSS/ DCS Encoder WB/NB Select USB Synthesizer Module PTT Out RF Output Power 0.5-8 Watts RF Frequency Range136-174 MHz380-406 MHz406-470 MHz470-512 MHz RF RF Input RF Output RF R F I n t e r f a c e Interface Channel Type (Analog, Digital, Mixed Mode PTT Control

JULY 25, 2006 Equipment Authorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: H4JVT-4E150 Product Name: VT-4E150 VHF TRANSMITTER Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: • Operational Description • All Schematics • All Parts Lists (BOMs) • All Internal Photographs • User’s Guide These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 25 Day of JULY 20 06 By: MICHAEL J CYR Signature Printed Title: COMMUNICATION SYSTEMS DESIGNER On behalf of : DANIELS ELECTRONICS LTD Telephone: (250)382-8268

Transmitter Front View with Case (1) Transmitter Front View with Case (2) Transmitter Side View with Case (1) Transmitter Side View with Case (2) Transmitter Rear View with Case

FRONT PANEL BOTTOM TOP LEFT SIDE COVER 2.250 1.375 DATE: 25 July 2006 TITLE: VT-4E150 VHF TX Body Tube Label Format and Location DRAWN BY: M. Cyr REV DATE: 25 July 2006 DWG No: DANIELS ELECTRONICS LTD. TM 1 11 21 2 12 22 3 13 23 4 14 24 5 15 25 6 16 26 7 17 27 8 18 28 9 19 29 10 20 30 A

5. Tune-up Procedure Transmitter programming is performed with the PC-based Radio Service Software (RSS).. The RSS runs under Microsoft Windows 95/98, 2000, ME, XP, or NT and allows the Transmitter to be programmed for operating frequencies, CTCSS and DCS signaling, and modulation type. Analog test modes may be selected by the Radio Service Software, as well as test modes specific to P25 digital operation. Transmitter settings are divided into two categories, Transmitter Wide options, which apply to all channels, and Channel Wide options, which can be programmed differently for each channel. When the Transmitter menu is selected from the main screen, both the Transmitter Wide and Channel Wide options for the current channel are displayed. The RSS may be used to save a Transmitter configuration to disk. This function allows the user to save a “standard” configuration, and use it as a starting configuration for all Transmitters. An archive of configurations from each radio system in operation may also be kept so that replacement radios can be programmed easily. 5.1. Transmitter Wide Settings Several options may be set which affect the operation of the Transmitter on a global basis. 5.1.1. Frequency Band There are four Frequency Bands available for Transmitters: VHF 136-174 MHz (0.5-8.Watt) UHF Low Band 380-406 MHz (0.5-8.Watt) UHF Mid Band 406-470 MHz (0.5-8.Watt) UHF High Band 470-512 MHz (0.5-8.Watt) When the Frequency Band is changed, the Frequency field in every Transmitter channel will be changed to the lowest frequency in the band. 5.1.2. Unit ID This field contains the unique Transmitter unit ID in Hexadecimal. (There is no need to enter an initial ‘$’character.) The default value is $1. The spin button to the right of this field allows you to incrementally change the ID. This unit ID will be transmitted in the source ID field along with every P25 voice frame if the transmitter is keyed using the Microphone PTT and each Transmitter should have a different number. 5.1.3. Secure Hardware Equipped This setting is not used for Repeater Transmitters, but is used for Daniels P25 Base Transmitters. Correct repeater operation does not require that an encrypted signal be decrypted. 5.1.4. Holdoff Delay This feature is to allow the use of a Tone Panel in analog mode. When enabled, it prevents the tone panel signal from interfering with the audio signal. The transmitter is activated 250ms after the rear connector PTTs (or the microphone PTT) are keyed. When disabled, the transmitter is activated immediately after the rear connector PTTs (or the microphone PTT) are keyed. This is the default configuration. 5.1.5. Hang Time Hang time is a selectable time delay, which can be enabled to keep the transmitter keyed after its PTT input is released. It can be used to keep an RF channel open in low signal conditions when the receiver might by squelching intermittently. It is also commonly used at the end of the transmission to keep the transmitter keyed long enough to provide confirmation that the repeater has been activated by mobile radios. The duration of the hang timer is selectable in 250ms increments from 0 (disabled) to 3.75 sec. Note that the Hang Time is applied only when the radio is keyed by the ANALOG_COR* or DIGITAL_COR* inputs, not from the front panel Mic connector or the PTT signal from the M-3 subrack. 5.1.6. Squelch Tail It is possible to add a burst of noise (a “squelch tail”) to the end of each transmission. This will occur for the duration of the hang time. When the transmitter is used in a repeater configuration in digital repeat mode, it may be difficult for mobile radio users to hear that they have successfully “hit” the repeater, since P25 radios usually operate in a “silent squelch” mode. The squelch tail noise is an audible indicator that the repeater was indeed keyed. Note that the squelch tail noise is applied only when the radio is keyed by the ANALOG_COR* or DIGITAL_COR* inputs. It is not applied when the transmitter is keyed by the PTT signal from the MT-3 subrack nor from the front panel Mic connector. In addition, if the radio is keyed again before the hang time has expired, the squelch tail noise will not be sent until the hang timer is set again by removal of the keying source. 5.1.7. Timeout Options The transmitter provides a selectable timeout timer for each channel, which causes the transmitter to be de- keyed after the selected interval of continuous transmission has been completed. Two transmitter timeout values are provided, and one of the timeout values may be used in each of the 32 programmable channels. The range of values is from 15 to 465 seconds in increments of 15 seconds, or Infinite Time may be chosen. These selected Timeouts can then be used in the Timeout Value field in each Transmitter Channel Setting. These fields are used to program the parameters for a single Transmitter channel only. There are 32 different available channels labeled A1 - A16 and B1 - B16. The parameters for each channel are independent of parameters in other channels. 5.2. Channel Wide Settings The transmitter may be programmed with up to 32 channels, each with a different frequency, channel bandwidth and modulation type. The channels are arranged in two banks of 16 channels each, referred to as Bank A and Bank B. In this manual, a specific channel is referred to by its bank and channel i.e. B12 would refer to channel 12 in bank B. The following are all the settings that may be programmed on a per- channel basis. 5.2.1. Channel Name Each channel may be assigned a text name of up to 11 characters. The name is stored in the radio, but is never broadcast. It is provided as a means of identifying the channel during configuration. The channel name will default to the bank and channel number (i.e. “A1” for bank A, channel 1). 5.2.2. Channel Type Each MT-4D Transmitter can be programmed in analog only, P25 digital only, or mixed mode. P25 signaling is a purely digital mode, compatible …

Text truncated - open the document above for the full version.

6. Principal DC Voltage and Current (13.8 VDC) 6.1. Standby Current Without Encryption Module <75 mA With Encryption Module <105 mA 6.2. Total Current 2 W RF Output Power <1.7A 8 W RF Output Power <2.8 A

17 November 2005 Mike Cyr Daniels Electronic Ltd. 43 Erie Street, Victoria, British Columbia Canada V8V 1P8 Dear Mr. Cyr, Enclosed is the 47 CFR Part 2 Subpart J Section 2.1053 (Radiated Spurious Emissions) Test Report for VHF Transmitter, Model VT-4E150, and the CD-ROM containing this Test Report in PDF Format. Please check it thoroughly for discrepancies and please contact us immediately if you have any questions or if you identify any problems. This is an official copy of your Test Report, complete with the original Acme Testing Co. staff signatures. You should retain this Test Report as the official record of testing, as proof of compliance in the future. Please be aware that our internal controls require us to retain a historical copy of your Test Report on file for a three-year period, after which our copy of your Test Report will be destroyed. Please note that the FCC Certification Procedure Rules require that this Test Report (and all other Exhibits that form the FCC Filing Package on your VHF Transmitters) must be retained by the Responsible Party for two years after the manufacturing of the product has been permanently discontinued [cf., 47 CFR Part 2 Section 2.938(c)]. Please note that Acme Testing Co. is accredited by the American Association for Laboratory Accreditation (A2LA). Further, Acme Testing Co.’s Open Area Test Site [OATS] # 1 is registered with the FCC. Thank you for your business! We look forward to being of service to you in the future. Yours sincerely, :sg Enclosure Acme Testing Co. 2002 Valley Highway, P.O. Box 3, Acme, WA 98220-0003 USA Telephone: 1-360-595-2785 Fax: 1-360-595-2722 Document Number: 2005098 Document Date: 17 November 2005 Daniels Electronics Ltd. VHF Transmitter, Model VT-4E150 FCC Rules: 47 CFR Part 2 Subpart J Section 2.1053 (per Client Request) Page 1 of 30 TEST REPORT 47 CFR Part 2 Subpart J Section 2.1053 Measurements of Field Strength of Spurious Radiation From: Power Amplifier Family DEVICE: VHF TRANMITTER MODEL: VT-4E150 MANUFACTURER: DANIELS ELECTRONICS LTD. ADDRESS: 43 ERIE STREET, VICTORIA, BRITISH COLUMBIA CANADA V8V 1P8 WORK ORDER: 05-EMC-1003-0219 Acme Testing Co. 2002 Valley Highway, P.O. Box 3, Acme, WA 98220-0003 USA Telephone: 1-360-595-2785 Fax: 1-360-595-2722 Document Number: 2005098 Document Date: 17 November 2005 Daniels Electronics Ltd. VHF Transmitter, Model VT-4E150 FCC Rules: 47 CFR Part 2 Subpart J Section 2.1053 (per Client Request) Page 2 of 30 TABLE OF CONTENTS 1. GENERAL......................................................................................................................................................................3 1.1 DOCUMENT HISTORY...................................................................................................................................................3 1.2 PURPOSE......................................................................................................................................................................3 1.3 MANUFACTURER.........................................................................................................................................................4 1.4 TEST LOCATION...........................................................................................................................................................4 1.5 ACCREDITATIONS AND LISTINGS.................................................................................................................................4 2. TEST RESULTS SUMMARY......................................................................................................................................5 3. DESCRIPTION OF EQUIPMENT AND PERIPHERALS.......................................................................................6 3.1 EQUIPMENT UNDER TEST (EUT) .................................................................................................................................6 3.2 SUPPORT EQUIPMENT USED DURING EMISSIONS TESTING..........................................................................................6 3.3 TEST SETUP BLOCK DIAGRAM.....................................................................................................................................7 3.4 DESCRIPTION OF INTERFACE CABLES USED DURING EMISSIONS TESTING..................................................................7 3.5 MODE OF OPERATION DURING EMISSIONS TESTING....................................................................................................7 3.6 MODIFICATIONS REQUIRED FOR COMPLIANCE............................................................................................................7 4. RADIATED SPURIOUS EMISSIONS TESTS...........................................................................................................8 4.1 TEST EQUIPMENT.........................................................................................................................................................8 4.2 PURPOSE......................................................................................................................................................................9 4.3 TEST PROCEDURE......................................................................................................................................................10 4.3.1 General Procedure................................................................................................................................................... 10 4.3.2 Radiated Spurious Emissions Test Characteristics.................................................................................................. 10 4.4 TEST RESULTS...........................................................................................................................................................11 4.5 TEST SETUP PHOTOGRAPHS....................................................................................................…

Text truncated - open the document above for the full version.

Daniel’s Electronics Ltd. 47 CFR Parts 22, 80 and 90 VT-4E150 Transmitter Page 1 of 28 Applicant: Daniels Electronics Ltd. 43 Erie St Victoria, BC V8V 1P8 Equipment Under Test: VT-4E150 VHF Transmitter FCC ID: H4JVT-4E150 In Accordance With: FCC Part 22 FCC Part 80 FCC Part 90 Tested By: Daniels Electronics Ltd. 43 Erie St Victoria, BC, V8V 1P8 And Acme Testing Co. 2002 Valley Highway Acme, WA, 98220-0003 Authorized By: ________________________________________ Dale Reitsma, D&D Manager Testing Verified By: ________________________________________ John Shields, Communication Systems Designer Date: 2 Aug 2006 Total Number of Pages: 28 Daniel’s Electronics Ltd. 47 CFR Parts 22, 80 and 90 VT-4E150 Transmitter Page 2 of 28 Table of Contents 1. Summary of Test Results ............................................................................................................. 3 2. General Equipment Specifications............................................................................................... 4 3. RF Power Output ......................................................................................................................... 5 4. Audio Frequency Response ......................................................................................................... 6 5. Audio Low-Pass Filter Response................................................................................................. 8 6. Modulation Limiting .................................................................................................................. 10 7. Occupied Bandwidth (with audio low-pass filter installed) ...................................................... 13 8. Spurious Emissions at Antenna Terminals ................................................................................ 17 9. Field Strength of Spurious Emissions........................................................................................21 10. Frequency Stability .................................................................................................................... 22 11. Transient Frequency Response .................................................................................................. 23 12. Block Diagrams ......................................................................................................................... 25 13. Test Equipment List ................................................................................................................... 28 Appendix A: VT-4E150 VHF Transmitter – Measurements of Field Strength of Spurious Radiation Daniel’s Electronics Ltd. 47 CFR Parts 22, 80 and 90 VT-4E150 Transmitter Summary of Test Results Page 3 of 28 1. Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 22, 80, and 90. This application is a new submission for approval of the VT-4E150 VHF Transmitter, operating in the 136 to 174 MHz frequency band of the Land Mobile Services. The equipment under test are pre- production units. 9 New Submission Production Unit Modification Filing 9 Pre-Production Unit Family Listing Summary of Test Data Name of Test Para No. Result RF Power Output 47 CFR §2.1046 Complies Audio Frequency Response 47 CFR §2.1047 a) Complies Audio Low-Pass Filter Response 47 CFR §2.1047 a) Complies Modulation Limiting 47 CFR §2.1047 b) Complies Occupied Bandwidth (with Audio Low-Pass Filter Installed) 47 CFR §2.1049 g), h) 47 CFR §90.210 d) Complies Spurious Emissions at Antenna Terminals 47 CFR §2.1051 47 CFR §90.210 d) Complies Field Strength of Spurious Emissions 47 CFR §2.1053 47 CFR §90.210 d) Complies Frequency Stability 47 CFR §2.1055 47 CFR §90.213 47 CFR §90.539 Complies Transient Frequency Behaviour 47 CFR §90.214 Complies Test Conditions: The following conditions apply to all of the testing except when otherwise specified. Temperature: 23°C Humidity: 30% Daniel’s Electronics Ltd. 47 CFR Parts 22, 80 and 90 VT-4E150 Transmitter General Equipment Specifications Page 4 of 28 2. General Equipment Specifications Manufacturer: Daniels Electronics Ltd. Model Number: VT-4E150 FCC ID: H4JVT-4E150 Starting Date of Testing: June 8, 2006 Serial Numbers of EUTs: R&D 10010 Note: Used for the majority of the tests. R&D 10011 Note: Used for Frequency Stability and Transient Frequency Behaviour Testing. R&D 10001 Note: Used for Field Strength of Spurious Emissions Testing Primary Power: 13.8V DC Emission Designators (Analog) 12.5kHz Channel Spacing: 11K0F3E 25kHz Channel Spacing: 16K0F3E Emission Designators (Digital): Voice: 12.5kHz Channel Spacing: 8K10F1E Data: 12.5kHz Channel Spacing: 8K10F1D Data: Paging with external modulator: 9K2F1D Rated RF Power Output: Variable: 0.5 to 8.0W Channel Spacing: 12.5kHz & 25kHz Frequency Range: 136 to 174MHz Daniel’s Electronics Ltd. 47 CFR Parts 22, 80 and 90 VT-4E150 Transmitter RF Power Output Page 5 of 28 3. RF Power Output Test Results: Complies Minimum Standard: 47 CFR §2.1046 ± 1dB (defined by the manufacturer) Test Procedure: TIA-603-C Sect 2.2.1 Notes: The center frequency is tested at the maximum and minimum output power; 8.0W (39.0dBm) and 0.5W (27.0dBm) respectively. EUT Model #: VT-4E150 Serial Number: R&D 10010 Test Equipment: Power Meter, Sensor, Rohde & Schwarz CMS 54 (DE #1545) 50 ohm Load Measurement Data: Rated Power = 8.0W (39.0dBm) Frequency (MHz) Rated Power (dBm) Measured Power (dBm) 159 8.0W (39.0dBm) 7.98W (39.0dBm) Rated Power = 0.5W (27.0dBm) Frequency (MHz) Rated Power (dBm) Measured Power (dBm) 159 0.5W (27.0dBm) 0.495W (26.9dBm) Daniel’s Electronics Ltd. 47 CFR Parts 22, 80 and 90 VT-4E150 Transmitter Audio Frequency Response Page 6 of 28 4. Audio Frequency Response Test Results: Complies Minimum Standard: 47 CFR §2.1047 a) Test Procedure: TIA-603-C Sect 2.2.6 Notes: The center frequency is tested using a 12.5kHz and 25kHz channel spacing. EUT Model …
