H6M-SB400SB400 Bi-Directional Amplifier

Powerwave Technologies Inc.

Click to zoom

Application Details

Equipment Class: AMP - Amplifier
Date of Grant: Sep 22, 2003
Application Purpose: Original Equipment
Date of Application: Aug 10, 2003
Equipment Note: SB400 Bi-Directional Amplifier
Frequency Range: 403.00000000 - 512.00000000
Company: Powerwave Technologies Inc.
Country: United States

Documents & Files

Select a file to view

Users Manual

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Block Diagram

In-Hancer Plus BDA z USER MANUAL Printed: 03.08.01,15:54 Revision Date:8/1/03 6 Modular Construction The basic In-Hancer Plus BDA building blocks are. • RF-Deck: an Amplifier and Controller assembly mounted on a heat-sink ready to install in an enclosure or rack. These include RF output Isolators. • Enclosure including Power Supply. • Optional Batteries for backup. • Filter Kit including Duplexers, Filters and mounting hardware, if not already included in base Model. This manual lists complete Standard Models, some of which are complete products as is, and others require the selection of a Filter Kit. There is also a series of add- on Accessories and Options. Theory Of Operation The In-Hancer Plus BDA uses the RF-Deck as the fundamental active element. RF- Decks include both Uplink and Downlink RF Amplifiers, Microprocessor based Controller, and Power Supply / Battery Charging... CONTROLLER DOWNLINK AMPLIFIER UPLINK AMPLIFIER UPLINK RF OUT DOWNLINK RF INDOWNLINK RF OUT UPLINK RF IN These are assembled into an enclosure with a Filter Kit... RF-DECK DL OUTDL IN UL OUTUL IN FILTER FILTER DUPLEXER DUPLEXER UPLINK / DONOR RF PORT DOWNLINK / RF PORT DISTRIBUTION POWER SUPPLY I/O PORTS

Cover Letter(s)

z Page 1 60 Gough Rd., Markham, Ontario, L3R8X7 www.kaval.com, 905-940-3860, 905-946-3003 FAX July 4, 2003 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia, MD, 21046, USA Subject: CONFIDENTIALTY REQUEST Dear Sir or Madam; Kaval Wireless Technologies respectfully requests confidentiality of certain materials provided with the submission of the SB400 under FCC ID H6M-SB400 in accordance with FCC Regulations 0.459. The confidentiality request applies to the schematic diagrams, SCH000000065 and SCH000000077, contained in Exhibit 2. The SB400 has been developed at considerable effort and expense by Kaval Wireless Technologies. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this manner. Yours sincerely, Name: Alan C. Aslett, P.Eng. Signature: _________________________________ Title: Director of Engineering - Product Development Date: July 4, 2003

Cover Letter(s)

z Page 1 60 Gough Rd., Markham, Ontario, L3R8X7 www.kaval.com, 905-940-3860, 905-946-3003 FAX July 4, 2003 Federal Communications Commission P.O. Box 429 Columbia, MD, 21045, USA Subject: AGENCY AGREEMENT Dear Sir or Madam; I hereby appoint Ultratech Engineering Labs Inc. to act as our agent in the preparation of an application for equipment authorization of the SB400 under parts as required of the FCC Rules and Regulations. I certify that Exhibit 2 properly describes the device for which authorization is sought, that the information described in the User’s Manual will be provided with each item manufactured or distributed by Kaval Wireless Technologies, and that the labels described by exhibit 3 will be affixed to each item manufactured by the applicant. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission’s requirements. I further certify by signature below that no party (per 47 CFR 1.20012(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Yours sincerely, Name: Alan Aslett, P.Eng. Signature: _________________________________ Title: Director of Engineering - Product Development Date: July 4, 2003

External Photos

Annex 2 – External Photographs of The EUT Photo # 1 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 2 – External Photographs of The EUT Photo # 2 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400

ID Label/Location Info

Kaval Wireless Technologies LAB000000040, Rev.0 July 4, 2003 Model SB400 FCC ID H6M-SB400 Industry Canada IC:1541A-SB400 Serial # Freq Range MHz Power Volts Hz VA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Manufactured in Canada by KAVAL WIRELESS TECHNOLOGIES To be attached to the inside of the door of the SB400 Unit.

Internal Photos

Annex 3 – Internal Photographs of The EUT Photo # 1 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 2 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 3 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 4 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 5 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 6 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 7 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 8 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 9 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 10 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 11 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 12 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 13 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 14 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 15 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 16 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 17 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 18 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 3 – Internal Photographs of The EUT Photo # 19 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400

Operational Description

RF Exposure Info

In-Hancer Plus BDA z USER MANUAL Printed: 03.08.01,15:54 Revision Date:8/1/03 5 Off-Air Operation BDA's Off-Air BDA's are intended to extend coverage into areas with coverage deficiency such as inside office buildings, shopping malls, hospitals, etc. They are designed to be located independently of the donor site and must be equipped with their own antenna systems - one to communicate with the donor site and the other(s) to communicate with portables in the shadow zone. A typical in-building coverage extension system is shown below. The "Head-End" BDA is responsible for the amplification of both incoming “Off-Air” downlink signals and outgoing uplink signals. The in-building distribution antenna system comprises of Coaxial cable, Signal taps, splitters and antennas to extend coverage on every floor, basement and underground parking garage. ROOF TOP ANTENNA FROM / TO DONOR TRANSMITTER D1D2 A1 A2 SIGNAL TAP SIGNAL TAP COAXIAL CABLE N N - 1 B F1 F2 KAVAL 800/900 MHz BDA This distributed antenna system is based on Kaval Wireless Technologies’ “Tapped Radiator” RF signal distribution approach. The technology makes use of coaxial cable with Signal Taps strategically located and connected to Omni-directional ground plane antennas. This technology offers flexibility in system design, installation and optimization. Once the RF cable backbone has been installed, additional signal taps and antennas can quickly and easily be added to a live system, without the need to take the system out of service. Hence, new coverage areas can be added, or the system can easily be modified if the layout should change (e.g. modernization retrofits or process modifications).

RF Exposure Info

In-Hancer Plus BDA z USER MANUAL DCM000000105 Printed: 03.08.01,15:54 Revision Date:8/1/03 25 • All Antenna Installation to be performed by Qualified Technical Personnel only. • Antenna Installation Instructions and locations below are for the purpose of satisfying FCC RF Exposure Compliance requirements. • The Roof Top Antenna or Antennae for linking to the Donor Site(s) is/are directional (high gain) Antennae, fixed-mounted physically on the side or top of a building, or on a tower. The Antenna Gain must be no more than 10 dB. The Roof Top Antennae location should be such that only Qualified Technical Personnel can access it, and that under normal operating conditions no other person can touch the Antenna, or approach within 10 meters of the Antenna. • The In-Building Antenna connection is via a coaxial cable distribution system with Signal Taps at various points connected to the fixed-mounted Indoor Antennae. This is shown in the figure in the Introduction. The Indoor Antennae are simple 1/4 Wavelength (0 dB Gain) types. They are used with KAVAL WIRELESS TECHNOLOGIES 12, 16, or 20 dB Cable Taps. As such the maximum EIRP will be at the first Tapped Antenna, which will be 12 dB below the maximum signal level of the BDA (+40 dBm); +28 dBm, or 0.63 Watts EIRP. These Antennae are to be installed such that no person can touch the Antenna, or approach within 0.2 Meters. ANTENNA INSTALLATION WARNING ALL ANTENNA INSTALLATION IS TO BE PERFORMED BY QUALIFIED TECHNICAL PERSONNEL ONLY. ANTENNA INSTALLATION INSTRUCTIONS AND LOCATIONS ARE FOR THE PURPOSE OF SATISFYING FCC RF EXPOSURE COMPLIANCE REQUIREMENTS, AND ARE NOT OPTIONAL. ALL ROOF TOP ANTENNA INSTALLATION MUST BE SUCH THAT NO PERSON CAN TOUCH THE ANTENNA, OR APPROACH CLOSER THAN 10 METERS. ALL IN-BUILDING ANTENNAE INSTALLATIONS MUST BE SUCH THAT NO PERSON CAN TOUCH THE ANTENNAE, OR APPROACH CLOSER THAN 0.2 METERS. Please consult Kaval Wireless for assistance as required. Antenna Installation In-Hancer Plus BDA z USER MANUAL DCM000000105 Printed: 03.08.01,15:54 Revision Date:8/1/03 26 • This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provided reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. WARNING CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY KAVAL COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. FCC Information to Users

Test Report

August 5, 2003 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Type Acceptance Application under FCC CFR 47, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the frequency bands 403 - 512 MHz (12.5 kHz and 25 kHz Channel Spacings). Applicant: KAVAL WIRELESS TECHNOLOGIES INC. Product: Bi-Directional Amplifier Model: SB400 FCC ID: H6M-SB400 Dear Sir/Madam, As appointed agent for KAVAL WIRELESS TECHNOLOGIES INC., we would like to submit the application to the Federal Communications Commission for certification of the above product. Please review all necessary files uploaded to FCC OET site for detailed information. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.: 1-877-747-6381 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH Encl. UltraTech Group of Labs 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] 31040/SIT C-1376 46390-2049 200093-0 2 00-034 SL2-IN-E-1119R August 5,2003 KAVAL WIRELESS TECHNOLOGIES INC. 60 Gough Road Markham, Ontario Canada, L3R 8X7 Attn.: Alan Aslett Subject: Certification Testing in accordance with FCC CFR 47, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the frequency bands 403 - 512 MHz (12.5 kHz and 25 kHz Channel Spacings). Product: Bi-Directional Amplifier Model: SB400 FCC ID: H6M-SB400 Dear Aslett, The product sample has been tested in accordance with FCC CFR 47, Parts 2 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the frequency bands 403 - 512 MHz 12.5 kHz and 25 kHz Channel Spacings), and the results and observation were recorded in the engineering report, Our File No.: KTI-029Q Enclosed you will find copy of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P.Eng Vice President - Engineering Encl. UltraTech Group of Labs 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] 31040/SIT C-1376 46390-2049 200093-0 2 00-034 SL2-IN-E-1119R Bi-Directional Amplifier Model No.: SB400 FCC ID: H6M-SB400 Applicant: KAVAL WIRELESS TECHNOLOGIES INC. 60 Gough Road Markham, Ontario Canada, L3R 8X7 Tested in Accordance With Federal Communications Commission (FCC) CFR 47, PARTS 2 and 90 (Subpart I) UltraTech's File No.: KTI-029Q This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: August 5,2003 Report Prepared by: Dharmajit Solanki, RFI Engineer Tested by: Hung Trinh, RFI Technician Issued Date: Aug. 05 Test Dates: Jul 15 – July 30, 2003 The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] 2 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 00-034 FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Contents i Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 ULTRATECH GROUP OF LABS File #: KTI-029Q 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST...................................................................................................................... 1 EXHIBIT 2. INTRODUCTION ....................................................................................................................................... 2 2.1. SCOPE....................................................................................................................................................................... 2 2.2. RELATED SUBMITAL(S)/GRANT(S) ...............................................................................................................................2 2.3. NORMATIVE REFERENCES ................................................................................................................................. 2 EXHIBIT 3. PERFORMANCE ASSESSMENT ............................................................................................................ 3 3.1. CLIENT INFORMATION ........................................................................................................................................... 3 3.2. EQUIPMENT UNDER TEST (EUT) INFORMATION.................................................................................................... 3 3.3. EUT’S TECHNICAL SPECIFICATIONS................................................................................................................ 4 3.4. LIST OF EUT’S PORTS................................................................................................................................................ 5 3.5. ANCILLARY EQUIPMENT............................................................................................................................................. 5 3.6. DRAWING OF TEST SETUP .................................................................................................................................. 5 EXHIBIT 4. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................. 6 4.1. CLIMATE TEST CONDITIONS....................................................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Annex 1 – Photographs of Test Setup Photo # 1 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400 Annex 1 – Photographs of Test Setup Photo # 2 Bi-Directional Amplifier, Model SB400 FCC ID: H6M-SB400
