H9P4111GPRSRadioData Terminal including 3 Radios

DIAD IV Terminal Regulatory Information Patents This product is covered by one or more of the following U.S. and foreign Patents: U.S. Patent No. 4,593,186; 4,603,262; 4,607,156; 4,652,750; 4,673,805; 4,736,095; 4,758,717; 4,760,248; 4,806,742; 4,816,660; 4,845,350; 4,896,026; 4,897,532; 4,923,281; 4,933,538; 4,992,717; 5,015,833; 5,017,765; 5,021,641; 5,029,183; 5,047,617; 5,103,461; 5,113,445; 5,130,520; 5,140,144; 5,142,550; 5,149,950; 5,157,687; 5,168,148; 5,168,149; 5,180,904; 5,216,232; 5,229,591; 5,230,088; 5,235,167; 5,243,655; 5,247,162; 5,250,791; 5,250,792; 5,260,553; 5,262,627; 5,262,628; 5,266,787; 5,278,398; 5,280,162; 5,280,163; 5,280,164; 5,280,498; 5,304,786; 5,304,788; 5,306,900; 5,324,924; 5,337,361; 5,367,151; 5,373,148; 5,378,882; 5,396,053; 5,396,055; 5,399,846; 5,408,081; 5,410,139; 5,410,140; 5,412,198; 5,418,812; 5,420,411; 5,436,440; 5,444,231; 5,449,891; 5,449,893; 5,468,949; 5,471,042; 5,478,998; 5,479,000; 5,479,002; 5,479,441; 5,504,322; 5,519,577; 5,528,621; 5,532,469; 5,543,610; 5,545,889; 5,552,592; 5,557,093; 5,578,810; 5,581,070; 5,589,679; 5,589,680; 5,608,202; 5,612,531; 5,619,028; 5,627,359; 5,637,852; 5,664,229; 5,668,803; 5,675,139; 5,693,929; 5,698,835; 5,705,800; 5,714,746; 5,723,851; 5,734,152; 5,734,153; 5,742,043; 5,745,794; 5,754,587; 5,762,516; 5,763,863; 5,767,500; 5,789,728; 5,789,731; 5,808,287; 5,811,785; 5,811,787; 5,815,811; 5,821,519; 5,821,520; 5,823,812; 5,828,050; 5,848,064; 5,850,078; 5,861,615; 5,874,720; 5,875,415; 5,900,617; 5,902,989; 5,907,146; 5,912,450; 5,914,478; 5,917,173; 5,920,059; 5,923,025; 5,929,420; 5,945,658; 5,945,659; 5,946,194; 5,959,285; 6,002,918; 6,021,947; 6,029,894; 6,031,830; 6,036,098; 6,047,892; 6,050,491; 6,053,413; 6,056,200; 6,065,678; 6,067,297; 6,082,621; 6,084,528; 6,088,482; 6,092,725; 6,101,483; 6,102,293; 6,104,620; 6,114,712; 6,115,678; 6,119,944; 6,123,265; 6,131,814; 6,138,180; 6,142,379; 6,172,478; 6,176,428; 6,178,426; 6,186,400; 6,188,681; 6,209,788; 6,209,789; 6,216,951; 6,220,514; 6,243,447; 6,244,513; 6,247,647; 6,308,061; 6,250,551; 6,295,031; 6,308,061; 6,308,892; 6,321,990; 6,328,213; 6,330,244; 6,336,587; 6,340,114; 6,340,115; 6,340,119; 6,348,773; 6,380,949; 6,394,355; D305,885; D341,584; D344,501; D359,483; D362,453; D363,700; D363,918; D370,478; D383,124; D391,250; D405,077; D406,581; D414,171; D414,172; D418,500; D419,548; D423,468; D424,035; D430,158; D430,159; D431,562; D436,104. Invention No. 55,358; 62,539; 69,060; 69,187, NI-068564 (Taiwan); No. 1,601,796; 1,907,875; 1,955,269 (Japan); European Patent 367,299; 414,281; 367,300; 367,298; UK 2,072,832; France 81/ 03938; Italy 1,138,713 rev. 06/02 © 2003 SYMBOL TECHNOLOGIES, INC. All rights reserved. Symbol and UPS' rights and obligations with relation to the DIAD IV product, including without limitation product liability and license grants, will be in accordance with Purchase Agreements number: 2001 - 11204 - 01, 2001 - 11204 - 02 and 2001 - 11204 - 03, dated February 13, 2003. Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol and the Symbol logo are registered trademarks of Symbol Technologies, Inc. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. Symbol Technologies, Inc. One Symbol Plaza Holtsville, N.Y. 11742-1300 http://www.symbol.com 72-63596-01 Revision A— May 2003 For Vehicle installations and use 1.An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result. 2.Position your device within easy reach. Be able to access your device without removing your eyes from the road. 3.Do not take notes or use the device while driving to the point of distracting from driving. Reading or Jotting down text takes attention away from your primary responsibility, driving safely. Cell Phone/Terminal Warnings Effect on Vehicles RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles (including safety systems). Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle. An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result. Safety on Aircraft You are required to switch OFF mobile phones when on board an aircraft as operation may be dangerous and illegal. Pacemakers It is recommended by pacemaker manufacturers that a minimum of 15cm (6 inches) be maintained between a handheld wireless phone and a pacemaker to avoid any possible interference with the pacemaker. These recommendations are consistent with independent research and recommendations by Wireless Technology Research. Persons with Pacemakers: • Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned ON • Should not carry the device in a breast pocket • Should use the ear furthest from the pacemaker to minimise the potential for interference. • If you have any reason to suspect that interference is taking place, turn OFF your device. Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment. Antenna's, use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could…

Text truncated - open the document above for the full version.

Introduction The LA-4137 CFWL adapter allows CF Card slot equipped handheld computer systems to configure, connect to and establish a Spectrum24 network. Features Include: • 50-pin Type I adapter card fully compliant with PCMCIA electrical and mechanical specifications • Low-power operation for battery-powered devices with CF Card slots • Pocket PC and Windows CE driver support • Compact Flash form factor (CF+Type I extended) • Automatic data rate and channel selection of 1, 2, 5.5 and 11 Mbps • Wireless software upgrade • Wired Equivalent Privacy (WEP) encryption and decryption • An integrated antenna • Card and Socket Services support • Power management [Continuously Aware Mode (CAM) and Power Save Polling (PSP)]. Scope This Quick Reference Guide contains the CFWL adapter installation and configuration instructions for Windows CE/Pocket PC. Preparation Before beginning the installation, verify the hardware package contains: • LA-4137 CFWL adapter with an integrated antenna • Spectrum24 High Rate 11 Mbps Wireless LAN Software CDROM. Note: Verify the model indicated on the card and packaging before use. Contact the Symbol Support Center if an item is missing or not functioning. Supported Devices The LA-4137 CFWL adapter has been qualified by Symbol Technologies to support the following devices: • Palm/Handheld (PH) computers running Windows CE/Pocket PC • Palm OS (i.e. Hand ERA/TRG Pro). Installing the LA-4137 CFWL Adapter The LA-4137 CFWL adapter installation requires: • a handheld computer with a Type I CF Card slot • a desktop computer with a CDROM drive or Web access • a Spectrum24 High Rate 11 Mbps Wireless LAN Software CDROM. To install the CFWL adapter: 1. Insert the CFWL adapter into the CF Card slot. Arrows on the front of the CFWL adapter indicate the insertion point to the slot. 2. Slide in the CFWL adapter until it firmly seats. Caution! Align the CFWL adapter properly when inserting. Insert the CFWL adapter firmly without forcing. Forcing the CFWL adapter into the slot can damage the device or the adapter. Note: If the CFWL adapter does not fit into the CF Card slot, a 68-pin, male reciever PCMCIA adapter is needed. Additional Information Obtain additional information by contacting Symbol at: 1-800-722-6234, inside North America. +1-516-738-5200, in/outside North America http://www.symbol.com/ Copyright Copyright 2001 by Symbol Technologies, Inc. All rights reserved. No part of this publication may be modified or adapted in any way, for any purposes without permission in writing from Symbol Technologies, Inc. (Symbol). The material in this manual is subject to change without notice. Symbol reserves the right to make changes to any product to improve reliability, function, or design. No license is granted, either expressly or by implication, estoppel, or otherwise under any Symbol Technologies, Inc., intellectual property rights. An implied license only exists for equipment, ciecuits, and subsystems contained in Symbol products. Symbol, the Symbol logo and Spectrum24 are registerd trademarks of Symbol Technologies, Inc. Other product names mentioned in this manual may be trademarks or registered trademark of their respective companies and are hereby acknowledged. IBM is a registered trademark of International Business Machine Corporation. Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Novell and LAN Workplace are registered trademarks of Novell Inc. Patents This product is covered by one or more of the following U.S. and foreign Patents: U.S. Patent No. 4,387,297; 4,460,120; 4,496,831; 4,593,186; 4,603,262; 4,607,156; 4,652,750; 4,673,805; 4,736,095; 4,758,717; 4,816,660; 4,845,350; 4,896,026; 4,897,532; 4,923,281; 4,933,538; 4,992,717; 5,015,833; 5,017,765; 5,021,641; 5,029,183; 5,047,617; 5,103,461; 5,113,445; 5,130,520; 5,140,144; 5,142,550; 5,149,950; 5,157,687; 5,168,148; 5,168,149; 5,180,904; 5,216,232; 5,229,591; 5,230,088; 5,235,167; 5,243,655; 5,247,162; 5,250,791; 5,250,792; 5,260,553; 5,262,627; 5,262,628; 5,266,787; 5,278,398; 5,280,162; 5,280,163; 5,280,164; 5,280,498; 5,304,786; 5,304,788; 5,306,900; 5,321,246; 5,324,924; 5,337,361; 5,367,151; 5,373,148; 5,378,882; 5,396,053; 5,396,055; 5,399,846; 5,408,081; 5,410,139; 5,410,140; 5,412,198; 5,418,812; 5,420,411; 5,436,440; 5,444,231; 5,449,891; 5,449,893; 5,468,949; 5,471,042; 5,478,998; 5,479,000; 5,479,002; 5,479,441; 5,504,322; 5,519,577; 5,528,621; 5,532,469; 5,543,610; 5,545,889; 5,552,592; 5,557,093; 5,578,810; 5,581,070; 5,589,679; 5,589,680; 5,608,202; 5,612,531; 5,619,028; 5,627,359; 5,637,852; 5,664,229; 5,668,803; 5,675,139; 5,693,929; 5,698,835; 5,705,800; 5,714,746; 5,723,851; 5,734,152; 5,734,153; 5,742,043; 5,745,794; 5,754,587; 5,762,516; 5,763,863; 5,767,500; 5,789,728; 5,789,731; 5,808,287; 5,811,785; 5,811,787; 5,815,811; 5,821,519; 5,821,520; 5,823,812; 5,828,050; 5,850,078; 5,861,615; 5,874,720; 5,875,415; 5,900,617; 5,902,989; 5,907,146; 5,912,450; 5,914,478; 5,917,173; 5,920,059; 5,923,025; 5,929,420; 5,945,658; 5,945,659; 5,946,194; 5,959,285; 6,002,918; D305,885; D341,584; D344,501; D359,483; D362,453; D363,700; D363,918; D370,478; D383,124; D391,250; D405,077; D406,581; D414,171; D414,172; D419,548 Invention No. 55,358; 62,539; 69,060; 69,187 (Taiwan); No. 1,601,796; 1,907,875; 1,955,269 (Japan); European Patent 367,299; 414,281; 367,300; 367,298; UK 2,072,832; France 81/03938; Italy 1,138,713 Symbol Technologies, Inc. One Symbol Place Holtsville, NY 11742-1300 *73-20990-01A*1 72-52486-01 Revision A ORGI nser Anat PC2MbpsShort.cdr ® LA-4137 Compact Flash Wireless LAN Adapter Quick Reference Guide www.symbol.com Installing and Configuring the Driver in Windows CE Install the Spectrum24 Windows CE device driver from the Spectrum24 High Rate 11 Mbps Wireless LAN Software CDROM or download the driver from the Symbol Web site to a desktop computer. Symbol has bundled the NICTT and NCPA utilities with the Spectrum24 Windows CE driver. Use these utilitie…

Text truncated - open the document above for the full version.

Exhibit 3 Please see TUVPS report no. OR610741-2

P/N: LA-4137-1020-WW S/N: XXXXXXXXXXXXXXXSYMBOL TECHNOLOGIES INC., HOLTSVILLE N.Y. BAR CODE FCC ID: H9PLA4137P CANADA: 1549104431A N410 FREQ: MAX 2400 - 2483.5 MHz 0168 IF APPLICABLEAFFIX COUNTRY STAMP HERE MADE IN XXX.... XXXX.... TYPE: LA-4137 MAX 100 mW R NYDA0XXX/GZDA0XXX LA-4137-1 THIS DEVICE CONTAINS AN APPROVED RLAN MODULE P/N: LA-4137-1020-WW S/N: XXXXXXXXXXXXXXXSYMBOL TECHNOLOGIES INC., HOLTSVILLE N.Y. BAR CODE FCC ID: H9PLA4137P CANADA: 1549104431A N410 FREQ: MAX 2400 - 2483.5 MHz 0168 IF APPLICABLEAFFIX COUNTRY STAMP HERE MADE IN XXX.... XXXX.... TYPE: LA-4137 MAX 100 mW R NYDA0XXX/GZDA0XXX LA-4137-1 THIS DEVICE CONTAINS AN APPROVED RLAN MODULE

Regulatory compliance Symbol Technologies, Inc. Page 1 of 1 4111-GPRS Label/01 Symbol 4111-GPRS1 terminal – product label Type: 4111-GPRS

Label Position Scanner Labeling 630-680nm LASER 1.0 mW MAX OUTPUT CLASS II LASER PRODUCT LASER LIGHT-DO NOT STARE INTO BEAM LASER LIGHT- DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT LASERLICHT - NICHT IN DEN STRAHL BLICKEN LASER KLASSE 2 LUMIERE LASER - NE PAS REGARDER DANS LE FAISCEAU APPAREIL À LASER DE CLASSE 2 630-680nm, 1mW THIS DEVICE CONTAINS APPROVED RADIO MODULES MADE IN XXXXX XXXX MODEL NUMBER: 4111-GPRS1 SERIAL NUMBER: XXXXXXXXXXXXXXX IMEI: XXXXXXXXXXXXXXX SN BAR CODE MOD BAR CODE MFD: XXXXXXXXX , XXXX TYPE: 4111-GPRS FCC ID:H9P4111GPRS IC: 1549D-4111GPRS MANUFACTURED FOR UPS, ATLANTA ,GEORGIA BY SYMBOL TECHNOLOGIES R 0168

Exhibit 9 Please see TUVPS report no OR610741-2

REPORT ON FCC Part 15 Testing in support of an Application for Grant of Equipment Authorisation of a Symbol 4111-GPRS Hand Held Data Terminal FCC ID: H9P4111GPRS Report No OR610741-2Jul y 2003 TUV Product Service Ltd, Segensworth Road, Titchfield Fareham, Hampshire, United Kingdom, PO15 5RH Tel: +44(0) 1329 443459, Fax: +44(0) 1329 443331 www.tuvps.co.uk Report No OR610741/2Page 1 of 42 REPORT ONFCC Part 15C Testing in support of an Application for Grant of Equipment Authorisation of a Symbol 4111-GPRS Hand Held Data Terminal FCC ID: H9P4111GPRS Report No OR610741-2 July 2003 PREPARED FORSymbol Technologies Inc One Symbol Plaza Holtsville NY 11742-1300 New York United States of America APPROVED BY C H GOULD Chief Engineer DATED09-07-03 DISTRIBUTIONSymbol Technologies IncCopy 1 (CD) TÜV Product ServiceCopy 2 Copy No Total No of Pages 42 Report No OR610741/2FCC ID: H9P4111GPRSPage 2 of 42 Table of Contents Page No STATUS ................................................................................................................................................3 TEST RATIONALE................................................................................................................................4 SYSTEM CONFIGURATION ............................................................................................................... 5 TEST SETUP PHOTOGRAPH .............................................................................................................6 EQUIPMENT INFORMATION .............................................................................................................7 EUT IN RLAN MODE, CONFIGURATION RADIATED EMISSIONS MEASUREMENT AT THE BANDEDGE (MARKER DELTA METHOD) .....8 RADIATED EMISSIONS RLAN MODE ................................................................................................ 10 MAXIMUM PEAK OUTPUT POWER.................................................................................................... 15 EUT IN BLUETOOTH MODE, CONFIGURATION RADIATED EMISSIONS MEASUREMENT AT THE BANDEDGE (MARKER DELTA METHOD) ..... 16 RADIATED EMISSIONS BLUETOOTH MODE .................................................................................... 18 MAXIMUM PEAK OUTPUT POWER................................................................................................... 22 PHOTOGRAPHS OF EQUIPMENT...................................................................................................... 23 MANUFACTURERS LABEL DIAGRAM ............................................................................................... 39 FCC SITE COMPLIANCE LETTER ......................................................................................................40 SYSTEM MEASUREMENT UNCERTAINTY ....................................................................................... 41 COPYRIGHT STATEMENT ................................................................................................................. 42 Report No OR610741/2FCC ID: H9P4111GPRSPage 3 of 42 STATUS OBJECTIVETo undertake measurements to determine the Equipment Under Test's (EUT's) compliance with the specification. MANUFACTURING DESCRIPTIONHand Held Data Terminal APPLICANTSymbol Technologies Inc One Symbol Plaza Holtsville NY 11742-1300 New York United States of America TYPE NUMBER4111-GPRS MANUFACTURERS MODEL NUMBER4111-GPRS1 SERIAL NUMBERALP67837 (IMEI: 350030951706681) HARDWARE VERSIONRev 2 TEST SPECIFICATION NUMBERFCC Part 15 Subpart C REGISTRATION NUMBEROR610741/05 QUANTITY OF ITEMS TESTEDOne SECURITY CLASSIFICATION OF EUTUnclassified INCOMING RELEASEDeclaration of Build Status SERIAL NUMBEROR610741 DATE DISPOSALHeld pending disposal REFERENCE NUMBERN/A DATEN/A START OF TEST9 th June 2003 FINISH OF TEST13 th June 2003 TEST ENGINEERSS C Hartley A Guy RELATED DOCUMENTSANSI C63.4 2001. Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. FCC Public Notice document (DA 00-705 released 30 March 2000) Report No OR610741/2FCC ID: H9P4111GPRSPage 4 of 42 TEST RATIONALE The information contained within this report is intended to show verification of compliance of the Symbol Technologies Inc 4111-GPRS Hand Held Data Terminal to the requirements of FCC Specification Part 15. FCC ID H9P4111GPRS The unit supplied for testing was a 4111-GPRS hand held data terminal, which offers Tri Band GSM/GPRS, 2.4GHz 802.11b Wireless LAN and Bluetooth connectivity. The terminal utilizes the Motorola G18 GSM/GPRS module to offer GSM GPRS data connectivity. Also included in the terminal is the approved LA-4137 Symbol Compact Flash 802.11b RLAN radio card and the 21-58466 Symbol Bluetooth module. FCC ID numbers are detailed below: Type: Description Approval FCC IDDate G18 Motorola GSM/GPRS module, FCC Part 24IHDT6AC1 8/01/2000. LA4137Symbol Compact Flash RLAN Radio FCC Part15H9PLA4137 21/03/2000 21-58466 Symbol Bluetooth ModuleFCC Part15H9PSNAPPER 10/11/2002 This report details testing carried out in accordance with: • FCC: Part 15.247(c), Radiated Emission Measurement at the Band Edge (Marker Delta method) • FCC: Part 15.247(c), Radiated Emissions • FCC: Part 15.247(b), Maximum Peak Output Power Report No OR610741/2FCC ID: H9P4111GPRSPage 5 of 42 SYSTEM CONFIGURATION DURING EMC TESTING The EUT was set-up simulating a typical user installation on the Alternative Open Field Test Site identified on page 42, and tested in accordance with the specification. The test software in the EUT enabled the Test Engineer to select full power and continuous transmit on the following channels; 2.4GHz RLAN functionality Channel 1: 2412MHz Channel 6:2437MHz Channel 11: 2462MHz The Output Power level (controlled by application software) was set to 169. 2.4GHz Bluetooth functionality Channel 2: 2402MHz Channel 41: 2441MHz Channel 80: 2480MHz Report No OR610741/2FCC ID: H9P4111GPRSPage 6 of 42 TEST SETUP PHOTOGRAPH The photograph below shows the …

Text truncated - open the document above for the full version.

FCC CFR47 PART 15 CERTIFICATION TEST REPORT FOR 802.11b 2.4GHz WIRELESS DSSS Tx/Rx MODULE MODEL: LA4137 FCC ID: H9PLA4137 REPORT NUMBER: 01U1098-1 ISSUE DATE: January 24, 2002 Prepared for SYMBOL TECHNOLOGIES, INC. 6480 VIA DEL ORO DRIVE SAN JOSE, CA 95119-1208 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 01U1098-1 FCC ID: H9PLA4137 DATE: DECEMBER 13, 2001 EUT: 802.11b 2.4 GHz WIRELESS DSSS Tx/Rx MODULE Page 2 of 46 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION---------------------------------------------------------------------------3 2. EUT DESCRIPTION---------------------------------------------------------------------------------------------4 3. TEST METHODOLOGY----------------------------------------------------------------------------------------4 4. TEST FACILITY--------------------------------------------------------------------------------------------------4 5. ACCREDITATION AND LISTING--------------------------------------------------------------------------4 5.1. Laboratory Accreditations and Listings-------------------------------------------------------------------5 6. MEASURING INSTRUMENT CALIBRATION----------------------------------------------------------6 6.1. Measurement Uncertainty-----------------------------------------------------------------------------------6 7. SUPPORT EQUIPMENT / TEST DIAGRAM-------------------------------------------------------------7 8. APPLICABLE RULES AND BRIEF TEST RESULT----------------------------------------------------8 9. TEST SETUP, PROCEDURE AND RESULT------------------------------------------------------------13 9.1. PEAK POWER OUTPUT----------------------------------------------------------------------------------13 9.2. 6 dB BANDWIDTH MEASUREMENT-------------------------------------------------------------------20 9.3. CONDUCTED SPURIOUS EMISSION-----------------------------------------------------------------22 9.4. PEAK POWER SPECTRAL DENSITY-------------------------------------------------------------------26 9.5. PROCESSING GAIN---------------------------------------------------------------------------------------30 9.6. RESTRICTED BAND EDGE MEASUREMENT-------------------------------------------------------31 9.7. RADIATED EMISSION------------------------------------------------------------------------------------33 9.8. POWER LINE CONDUCTED EMISSION--------------------------------------------------------------39 9.9. SETUP PHOTOS--------------------------------------------------------------------------------------------41 ATTACHMENTS • EUT PHOTOGRAPHS REPORT NO: 01U1098-1 FCC ID: H9PLA4137 DATE: DECEMBER 13, 2001 EUT: 802.11b 2.4 GHz WIRELESS DSSS Tx/Rx MODULE Page 3 of 46 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: SYMBOL TECHNOLOGIES, INC. 6480 VIA DEL ORO DRIVE SAN JOSE, CA 85040 USA CONTACT PERSON: NORM NELSON / SENIOR EMC ENGINEER TELPHONE NO: 408-528-2649 EUT DESCRIPTION: 802.11b 2.4 GHz WIRELESS DSSS Tx/Rx MODULE MODEL NAME: LA4137 DATES TESTED: DECEMBER 13, 2001, January 22-24,2002 TYPE OF EQUIPMENT INTENTIONAL RADIATOR EQUIPMENT TYPE 2.4GHz TRANSCEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992, TIA/EIA 603 PROCEDURE CERTIFICATION FCC RULE CFR 47 PART 15.247 Compliance Certification Services, Inc. tested the above equipment for compliance with the requirement set forth in CFR 47, PART 15.247. The equipment in the configuration described in this report, shows the measured emission levels emanating from the equipment do not exceed the specified limit. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Approved & Released For CCS By: Tested By: STEVE CHENG JESSE SALDIVAR EMC ENGINEERING MANAGER ASSOCIATE EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 01U1098-1 FCC ID: H9PLA4137 DATE: DECEMBER 13, 2001 EUT: 802.11b 2.4 GHz WIRELESS DSSS Tx/Rx MODULE Page 4 of 46 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. EUT DESCRIPTION The PRO WIRELESS 2011B is an 802.11b 2.4GHz Direct Sequence Spread Spectrum Wireless Networking Transceiver Module. Its Frequency Range is from 2.412 to 2.462 GHz. Only one sleeved dipole antenna with a 2.2 dBi gain was tested to both ports to determine the worse case. Therefore, only the worse case test data was reported in the test report. The antenna is equipped with unique connector which cannot be replace by standard jack or electrical connector. 3. TEST METHODOLOGY Both conducted and radiated testing were perf…

Text truncated - open the document above for the full version.

Mobile & Wireless Systems Compact Flash Dipole Compact Flash Dipole (CF Dipole) The CF Dipole antenna is a 2-dBi sleeved- dipole that is omni-directional in azimuth plane. The CF Dipole uses a Murata GSC connector to comply with FCC 15.203 “unique coupling” requirement. In its use as a modular transceiver it could be as close as 2 cm of a persons body. CCS SAR report lists a worst- case SAR, averaged over 1g [mW/g] of 0.923 mW/gm at a separation of 20 mm. This transceiver is designed for use in devices in General Population/Uncontrolled Exposure categories. Location Body worn device Pattern Omni Type Dipole Max Gain 2 dBi Physical See attached dwg Cable Murata 92 Symbol P/N All antenna/terminal configurations used with the LA4137 will maintain a separation distance of 2 cm and a maximum gain of 2 dBi. Antenna Photo Rev 1

SYMBOL LA4137 Peak output power measured with peak power meter. Base Unit (Antenna 1) Channel Frequency (MHz) Meter reading (dBm) Cable loss (dB) Corrected reading (dBm) 1 2412 16.48 3.52 20 6 2437 16.71 3.97 20.68 11 2462 17.96 3.57 21.53 Base Unit (Antenna 2) Channel Frequency (MHz) Meter reading (dBm) Cable loss (dB) Corrected reading (dBm) 1 2412 16.01 3.52 19.53 6 2437 16.40 3.97 20.37 11 2462 17.97 3.57 21.54 Previous peak reading Base Unit (Antenna 1) Channel Frequency (MHz) Peak Power (dBm) 1 2412 19.74 6 2437 19.38 11 2462 19.35 Base Unit (Antenna 2) Channel Frequency (MHz) Peak Power (dBm) 1 2412 19.68 6 2437 19.97 11 2462 19.95

Exhibit 7 Please see report nos. TUVPS OR610741-2 and 01U1098-1
