H9PCA5090VoIP Phone with 802.11 a/b/g Radio

© 2007 SYMBOL TECHNOLOGIES, INC. All rights reserved. Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein. No license is granted, either expressly or by implication, estoppel, or otherwise under any patent right or patent, covering or relating to any combination, system, apparatus, machine, material, method, or process in which Symbol products might be used. An implied license exists only for equipment, circuits, and subsystems contained in Symbol products. Symbol and the Symbol logo are registered trademarks of Symbol Technologies, Inc. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. Symbol Technologies, Inc. One Symbol Plaza Holtsville, N.Y. 11742-1300 http://www.symbol.com Patents This product is covered by one or more patents. For patent information go to: www.symbol.com/patents. Warranty For the complete Symbol hardware product warranty statement, go to:: http://www.symbol.com/warranty. Waste Electrical and Electronic Equipment (WEEE) English: For EU Customers: All products at the end of their life must be returned to Symbol for recycling. For information on how to return product, please go to: http://www.symbol.com/environmental_compliance. Dansk: Til kunder i EU: Alle produkter skal returneres til Symbol til recirkulering, når de er udtjent. Læs oplysningerne om returnering af produkter på: http://www.symbol.com/environmental_compliance. Deutsch: Für Kunden innerhalb der EU: Alle Produkte müssen am Ende ihrer Lebensdauer zum Recycling an Symbol zurückgesandt werden. Informationen zur Rücksendung von Produkten finden Sie unter http:// www.symbol.com/environmental_compliance. Eesti: EL klientidele: kõik tooted tuleb nende eluea lõppedes tagastada taaskasutamise eesmärgil Symbol'ile. Lisainformatsiooni saamiseks toote tagastamise kohta külastage palun aadressi: http:// www.symbol.com/environmental_compliance. Español: Para clientes en la Unión Europea: todos los productos deberán entregarse a Symbol al final de su ciclo de vida para que sean reciclados. Si desea más información sobre cómo devolver un producto, visite: http://www.symbol.com/environmental_compliance.. Français : Clients de l'Union Européenne : Tous les produits en fin de cycle de vie doivent être retournés à Symbol pour recyclage. Pour de plus amples informations sur le retour de produits, consultez : http:// www.symbol.com/environmental_compliance. Italiano: per i clienti dell'UE: tutti i prodotti che sono giunti al termine del rispettivo ciclo di vita devono essere restituiti a Symbol al fine di consentirne il riciclaggio. Per informazioni sulle modalità di restituzione, visitare il seguente sito Web: http://www.symbol.com/environmental_compliance. Service Information Before use the Pharma Stand must be assembled and the digital imager scanner must be configured to operate in your facility’s network and run your applications. If you have a problem assembling the stand, operating the digital imager scanner or using your equipment, contact your facility’s Technical or Systems Support. If there is a problem with the equipment, they will contact the Symbol Global Customer Interaction Center. For the latest Symbol Global Customer Interaction Center contact information, go to: www.symbol.com/contactsupport. For the latest version of this and all Symbol guides go to: http://www.symbol.com/manuals. 72-96711-01 Rev. A - February 2007 CD50 Regulatory Guide Health and Safety Recommendations Ergonomic Recommendations Caution: In order to avoid or minimize the potential risk of ergonomic injury follow the recommendations below. Consult with your local Health & Safety Manager to ensure that you are adhering to your company's safety programs to prevent employee injury. • Reduce or eliminate repetitive motion • Maintain a natural position • Reduce or eliminate excessive force • Keep objects that are used frequently within easy reach • Perform tasks at correct heights • Reduce or eliminate vibration • Reduce or eliminate direct pressure • Provide adjustable workstations • Provide adequate clearance • Provide a suitable working environment • Improve work procedures. Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Local langauge translations are available at the following website: http://www.symbol.com/services/manuals/. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment. Caution: Only use Symbol approved and UL Listed accessories, battery packs and battery chargers. Do NOT attempt to charge damp/wet mobile computers or batteries. All components must be dry before connecting to an external power source. This guide is available in local languages, translations can be downloaded from the following website: http://www.symbol.com/ services/manuals/. Radio Modules The device contain approved radio module(s). These module(s) are identified below. Symbol 802.11 a/b/g radio card, Model: 21-92955 Country Approvals Regulatory markings are applied to the device signifying the radio (s) are approved for use in the following countries: United States, Canada, Australia, Japan and Europe. Please refer to the Symbol Declaration of Conformity (DoC) for details of other country markings. This is available at http:// www2.symbol.com/doc/. Note 1: For 2.4GHz Products: Europe includes, Austria, Belgium, Czech Republic, Croatia, Cyprus, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovak Republic, …

Text truncated - open the document above for the full version.

One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com Date: 14 May 2007 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Testing Division of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS Testing Division as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, David C. Heald, EMC Engineer Symbol Technologies, Inc., the Enterprise Mobility business of Motorola, Inc.

One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com DATE: 14 May 2007 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality Gentlemen: In reference to the application under FCC ID: H9PCA5090, and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block Diagrams Theory of Operation . These documents contain detailed system and equipment description and related information about the product that Symbol Technologies, Inc considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Symbol Technologies, Inc considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, David C Heald Symbol Technologies, Inc., the Enterprise Mobility business of Motorola, Inc.

Chris Harvey From: September Radecki [[email protected]] Sent: Monday, August 06, 2007 5:51 PM To: Chris Harvey; Thu Chan Subject: RE: Symbol Technologies, Inc. , FCC ID: H9PCA5090, Assessment NO.: AN07T6975, Notice#2 Attachments: Label availability declaration.pdf Page 1 of 2 8/7/2007 Hi Chris, Below are the replies to your questions on the above application. For the first question, the client's replies are in line in blue. Hopefully, this is okay. 1. This appears to be a Slave (Client) Device with Radar detection per page 12 of 20. This type of device is on the TCB Exclusion list. Please reference above on page 12 and the next two pages (pp13-14) which clearly state that the UUT is operating as a Client without Radar Detection. Also, the grant of equipment authorization for the modular radio H9P2192955 (used in the device) states that it does not support radar detection. The report does not document the FCC ID of the Master device used for testing. See section 2.1.4. ID: LDK102056The DFS test report is for a module FCC ID: H9P2192955 , and the FCC application is for a final device (VoIP Phone). Yes. The module is integrated into the end device, although we are not using the modular approval ID on the device since the module will be used across several product families and our experience has been that it is almost impossible to track device approvals when a module that is used in more than just a few devices (too many permissive change records to sift through once you hit 4-5 end devices - and we will likely have this in 10-15 end devices). Also, since the end device (CA5090) has no GUI and no text entry method, there is no way to run a media player program & direct it to go fetch & play the appropriate file. The DFS report does not specify which antenna was used on the UUT (but does indicate that the gain was 2.8dBi) The antenna was a dipole of 2.8dBi gain. DFS testing should be performed with the minimum gain antenna if the radiated method is performed All diagrams in the report show a conducted setup. The FCC required measurement procedure uses an MPEG file, but this DFS report indicates that a WAV file was used. It appears as though this device was not tested using the FCC's required measurement procedure. The device is an audio only device that cannot display video. Please see http://ntiacsd.ntia.doc.gov/dfs/ where this MPEG you mention is sourced from - the WAV file is just below it, along with the description of when it can be used (such as in audio devices that cannot play video). Please reconfirm the capabilities of this device and submit DFS compliance documentation that complies with the FCC requirements. The device does not support radar detection. If this device is on the TCB Exclusion list, the application must be submitted to the FCC. 2. Also, please submit documentation that indicates that the FCC ID Label which is now documented as being inside the battery compartment is visible at the time of purchase, per the FCC labeling policy. <CCS ANSWER:> Please see attached Statement. Best regards, September -----Original Message----- From: Chris Harvey Sent: Monday, August 06, 2007 10:48 AM To: Thu Chan Cc: Chris Harvey; September Radecki Subject: Symbol Technologies, Inc. , FCC ID: H9PCA5090, Assessment NO.: AN07T6975, Notice#2 Thu & September, Thank you for submitting the DFS test report. This appears to be a Slave (Client) Device with Radar detection per page 12 o f 20. This type of device is on the TCB Exclusion list. The report does not document the FCC ID of the Master device used for testing. The DFS test report is for a module, and the FCC application is for a final device (VoIP Phone). The DFS report does not specify which antenna was used on the UUT (but does indicate that the gain was 2.8dBi). DFS testing should be performed with the minimum gain antenna if the radiated method is performed. The FCC required measurement procedure uses an MPEG file, but this DFS report indicates that a WAV file was used. It appears as though this device was not tested using the FCC's required measurement procedure. Please reconfirm the capabilities of this device and submit DFS compliance documentation that complies with the FCC requirements. If this device is on the TCB Exclusion list, the application must be submitted to the FCC. Also, please submit documentation that indicates that the FCC ID Label which is now documented as being inside the battery compartment is visible at the time of purchase, per the FCC labeling policy. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Chris Harvey [email protected] Page 2 of 2 8/7/2007

One Motorola Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com 8/6/2007 RE: Packaging details and visibility of FCC ID Dear Sir or Madam: The device with FCC ID H9PCA5090 is shipped in two types of shipping containers. In both shipping containers, the device is shipped separated from its battery. The first container contains eight products and eight batteries separated into three plastic trays. The top and bottom tray contain the devices, and the middle tray contains the batteries. The other type of shipping container has one unit wrapped in bubblewrap with a separately packaged battery. The FCC ID will therefore be clearly visible to the end user when the product is unpacked. Sincerely, David Heald EMC Engineer Worldwide Regulatory Compliance Regulatory Engineering Label location

PROD FAM: UCA DESCRIPTION: LBL:LCD, CA5090 CTRY CODE: WW COUNTRIES: SEE REGULATORY SITE FOR COUNTRY LISTING SN POOL: STANDARD LBL STOCK PN: 63-90834-01 SEE NOTE 2 LBL SCRIPT :9408801 X *SEE NOTE 1 CCG1:S539 EC31150 69-94088-01B S E E N O T E 5 S E E N O T E 6 S E E N O T E 4 S E E N O T E 7 A N D 8 NOTE: FOR ADDITIONAL REGULATORY INFORMATION SEE BOM: STI P/N 60-91511-XX 5V 1.5A PN: CA5090-XXXXXXXXXXX SN BAR CODE MODEL: CA5090 (S)SN: XXXXXXXXXXXXXXX MADE IN XXXXXXXX XXXX MFD: XXXXXXX X NOTES: UNLESS OTHERWISE SPECIFIED 1. SCRIPT FILE TO BE CREATED BY MANUFACTURING PER SP-10083-01 SCRIPT FILE MUST MATCH THIS DOCUMENT EXACTLY AND HAVE SAME REVISION. 2. LABEL STOCK P/N IS SUBJECT TO CHANGE. CHECK BOM FOR ACTUAL P ART NUMBER. 3. IN ALL CASES "XXX......" REPRESENTS VARIABLE FIELDS IN SCRIPT FILE. ACTUAL NUMBER OF CHARACTERS IN SCRIPT FILE MAY V ARY. 4. SERIAL NUMBER MUST BE 4PT MINIMUM CHARACTER HEIGHT IN SCRIPT FILE. 5. PART NUMBER MAY OR MAY NOT HAVE DASH BEFORE COUNTRY CODE. SEE BOM FOR ACTUAL MODEL DESCRIPTION. 6. "MFD:" REPRESENTS MANUFACTURE DAY, MONTH, YEAR AND REVISION OF PART NUMBER(IE: 12SEP03 X) 7. COUNTRY OF ORIGIN REQUIRED 8. ADD VARIABLE FIELD FOR PLANT CODE 9. LEAVE SPACE FOR FUTURE VARIABLE FIELD REGULATORY LOGOS TO BE ADDED IN THIS AREA AS APPROVALS ARE RECEIVED SYMBOL TECHNOLOGIES INC., N.Y. 9B97 I.T .E. LISTED ACCESSORY FCC ID:H9PCA5090 IC:1549D-CA5090 PRELIMINAR Y Device Label will be placed here.

Antenna Radio Module Antenna pads Antenna Detail

CONFIDENTIAL and PROPRIETARY The information contained in this document is Confidential and Proprietary to Laird Technologies and is subject to Non-Disclosure Agreements. It may not be reproduced without express written permission of Laird Technologies. P.O. Box 82846 3425 North 44 th Street Lincoln, Nebraska 68501 USA 402/325-3131 Symbol CA5090 Antenna Laird part CAS96209AB CONFIDENTIAL and PROPRIETARY The information contained in this document is Confidential and Proprietary to Laird Technologies and is subject to Non-Disclosure Agreements. It may not be reproduced without express written permission of Laird Technologies. P.O. Box 82846 3425 North 44 th Street Lincoln, Nebraska 68501 USA 402/325-3131 Peak Gain Free Space -2-1 01234 2.40E+09 2.42E+09 2.44E+09 2.46E+09 2.48E+09 2.50E+09 5.00E+09 5.20E+09 5.40E+09 5.60E+09 5.80E+09 5.90E+09 Free Space 2.4 GHz peak gain = 3.3dBi 5GHz peak gain = 0.4 dBi CONFIDENTIAL and PROPRIETARY The information contained in this document is Confidential and Proprietary to Laird Technologies and is subject to Non-Disclosure Agreements. It may not be reproduced without express written permission of Laird Technologies. P.O. Box 82846 3425 North 44 th Street Lincoln, Nebraska 68501 USA 402/325-3131 Testing Reference Page Phi 0 Keypad faces Phi 0 (+X) position for free space Phi 90+Y Phi 180 Theta 0 +Z Theta 90+X Theta –90 (270)-X -Y Keypad faces Phi 270 (-Y) position for head, device on Phi 90 (+Y) Side of Head (Right Side, face is towards Phi 180 (-X)) CONFIDENTIAL and PROPRIETARY The information contained in this document is Confidential and Proprietary to Laird Technologies and is subject to Non-Disclosure Agreements. It may not be reproduced without express written permission of Laird Technologies. P.O. Box 82846 3425 North 44 th Street Lincoln, Nebraska 68501 USA 402/325-3131 Radiation Pattern 2460 MHz Free space: XY Z-Y -X -Z -25 -20 -15 -10 -5 +5 0 dB CONFIDENTIAL and PROPRIETARY The information contained in this document is Confidential and Proprietary to Laird Technologies and is subject to Non-Disclosure Agreements. It may not be reproduced without express written permission of Laird Technologies. P.O. Box 82846 3425 North 44 th Street Lincoln, Nebraska 68501 USA 402/325-3131 Radiation Pattern 5400 MHz Free space: XY Z-Y -X -Z -25 -20 -15 -10 -5 +5 0 dB

IN ACCORDANCE WITH THE REQUIREMENTS OF FCC OET BULLETIN 65 SUPPLEMENT C FOR VOIP DEVICE MODEL: CA5090 FCC ID: H9PCA5090 REPORT NUMBER: 07U10908-7 ISSUE DATE: APRIL 30, 2007 Prepared for SYMBOL TECHNOLOGIES INC ONE SYMBOL PLAZA, HOLTSVILLE, NY 11742 UNITED STATES Prepared by COMPLIANCE CERTIFICATION SERVICES 47173 BENICIA STREET FREMONT, CA 94538 USA REPORT NO: 07U10908-7 DATE: May 1, 2007 FCCID: H9PCA5090 COMPLIANCE CERTIFICATION SERVICES Page: 2 of 46 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issued date Revisions Revised By -- May 1, 2007 Initial issue Sunny Shih REPORT NO: 07U10908-7 DATE: May 1, 2007 FCCID: H9PCA5090 COMPLIANCE CERTIFICATION SERVICES Page: 3 of 46 This report shall not be reproduced except in full, without the written approval of CCS. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: April 18, 19, 20, and 23, 2007 APPLICANT: ADDRESS: SYMBOL TECHNOLOGIES INC ONE SYMBOL PLAZA, HOLTSVILLE, NY 11742 UNITED STATES FCC ID: MODEL: H9PCA5090 CA5090 DEVICE CATEGORY: EXPOSURE CATEGORY: Portable Device General Population/Uncontrolled Exposure VoIP Device Has a WLAN that Operates on 2.4 GHz, 5.2 GHz, 5.5 GHz, and 5.8 GHz Band Test Sample is a: Production unit Modulation type: Direct Sequence Spread Spectrum (DSSS) for 802.11b Orthogonal Frequency Division Multiplexing (OFDM) for 802.11ag Rule Parts Frequency Range [MHz] The Highest SAR Values [1g_mW/g] 2412 - 2462 Head: 0.465 Body: 0.566 FCC 15.247 5745 - 5825 Head: 0.539 Body: 0.621 5180 - 5320 Head: 0.895 Body: 0.971 FCC 15.401 5500 - 5700 Head: 0.767 Body: 1.350 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (Edition 01-01). Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: Hsin Fu Shih Ninous Davoudi Engineering Supervisor EMC Engineer Compliance Certification Services Compliance Certification Services REPORT NO: 07U10908-7 DATE: May 1, 2007 FCCID: H9PCA5090 COMPLIANCE CERTIFICATION SERVICES Page: 4 of 46 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1 DEVICE UNDER TEST (DUT) DESCRIPTION ........................................................................... 5 2 FACILITIES AND ACCREDITATION........................................................................................... 6 3 SYSTEM DESCRIPTION.............................................................................................................7 3.1 COMPOSITION OF INGREDIENTS FOR TISSUE SIMULATING LIQUIDS .............................. 8 4 TEST POSITIONS FOR DEVICES OPERATING NEXT TO A PERSON’S EAR ....................... 9 4.1 CHEEK/TOUCH POSITION....................................................................................................... 10 4.2 EAR/TILT POSITION ................................................................................................................. 11 4.3 TEST POSITIONS FOR BODY-WORN AND OTHER SIMILAR CONFIGURATIONS ............. 12 5 SIMULATING LIQUID PARAMETERS CHECK ........................................................................ 13 5.1 SIMULATING LIQUID PARAMETER CHECK RESULT............................................................ 15 6 SYSTEM PERFORMANCE CHECK.......................................................................................... 23 6.1 SYSTEM PERFORMANCE CHECK RESULTS........................................................................ 25 7 SAR MEASURMENT PROCEDURE ......................................................................................... 26 7.1 DASY4 SAR MEASURMENT PROCEDURE............................................................................ 27 8 PROCEDURE USED TO ESTABLISH TEST SIGNAL.............................................................. 28 9 2.4 GHZ BAND SAR MEASURMENT RESULTS...................................................................... 29 9.1 LEFT HAND SIDE...................................................................................................................... 29 9.2 RIGHT HAND SIDE ................................................................................................................... 30 9.3 HELD TO FACE ......................................................................................................................... 31 9.4 BODY WORN – WITH LANYARD ............................................................................................. 32 9.5 BODY WORN – WITH HOLSTER ............................................................................................. 33 10 5 GHZ BAND SAR MEASURMENT RESULTS......................................................................... 34 10.1 LEFT HAND SIDE...................................................................................................................... 34 10.2 RIGHT HAND SIDE ................................................................................................................... 35 10.3 HELD TO FACE ......................................................................................................................... 36 10.4 BODY WORN – WITH LANYARD .........................…

Text truncated - open the document above for the full version.

Date/Time: 4/18/2007 11:18:16 AM Test Laboratory: Compliance Certification Services Head - LHS DUT: VoIP phone; Type: N/A;Serial: Project No: 07U10908 Communication System: 802.11bg;Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.82 mho/m; ε r = 40.7; ρ = 1000 kg/m 3 Phantom section: Left Section Room AmbientTemperature: 22.0deg. C; Liquid Temperature: 21.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and witha peak SAR value greater than 0.0012W/kg - Probe: EX3DV4 - SN3552; ConvF(7.4, 7.4, 7.4); Calibrated: 5/30/2006 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 11/16/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Touch - 802.11b - M ch/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.303 mW/g Touch - 802.11b - M ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 12.1 V/m; Power Drift = 0.170 dB Peak SAR (extrapolated) = 0.598 W/kg SAR(1 g) = 0.329 mW/g; SAR(10 g) = 0.167 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.357 mW/g Touch - 802.11b - M ch/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 12.1 V/m; Power Drift = 0.170 dB Peak SAR (extrapolated) = 0.587 W/kg SAR(1 g) = 0.271 mW/g; SAR(10 g) = 0.135 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.286 mW/g Date/Time: 4/18/2007 11:44:22 AM Test Laboratory: Compliance Certification Services Head - LHS DUT: VoIP phone; Type: N/A;Serial: Project No: 07U10908 Communication System: 802.11bg;Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.82 mho/m; ε r = 40.7; ρ = 1000 kg/m 3 Phantom section: Left Section Room AmbientTemperature: 22.0deg. C; Liquid Temperature: 21.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and witha peak SAR value greater than 0.0012W/kg - Probe: EX3DV4 - SN3552; ConvF(7.4, 7.4, 7.4); Calibrated: 5/30/2006 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 11/16/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Tilt - 802.11b - M ch/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.263 mW/g Tilt - 802.11b - M ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 12.1 V/m; Power Drift = -0.002 dB Peak SAR (extrapolated) = 0.544 W/kg SAR(1 g) = 0.241 mW/g; SAR(10 g) = 0.118 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.256 mW/g Date/Time: 4/18/2007 10:25:26 AM Test Laboratory: Compliance Certification Services Head - LHS DUT: VoIP phone; Type: N/A;Serial: Project No: 07U10908 Communication System: 802.11bg;Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.82 mho/m; ε r = 40.7; ρ = 1000 kg/m 3 Phantom section: Left Section Room AmbientTemperature: 22.0deg. C; Liquid Temperature: 21.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and witha peak SAR value greater than 0.0012W/kg - Probe: EX3DV4 - SN3552; ConvF(7.4, 7.4, 7.4); Calibrated: 5/30/2006 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 11/16/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Touch - 802.11g - M ch/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.…
