FCC ID: H9PCB3000 Report No.RF940301L04 Technical Description The transmitter of the EUT (Client Bridge 3000 Series) is powered by AC adapter. The antenna type used in this product is Dipole antenna with UFL antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. This device is a Client Bridge 3000 Series, which operates in both of the 5GHz and 2.4GHz bands and can not transmitting simultaneously, the maximum data rate could be 54Mbps. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

FCC ID: H9PCB3000 Report No: SA940301L04 1 RF EXPOSURE REPORT REPORT NO.: SA940301L04 MODEL NO.: CB3000 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: SYMBOL TECHNOLOGIES, INC. ADDRESS: One Symbol Plaza, Holtsville, NY 11742-1300 U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS:No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: H9PCB3000 Report No: SA940301L04 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: H9PCB3000 Report No: SA940301L04 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: H9PCB3000 Report No: SA940301L04 4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 3dBi or 1.9953(numeric) (for 2.4GHz) 4dBi or 2.5119(numeric)(for 5GHz). 6.2 Output Power Into Antenna & RF Exposure Distance: 802.11b DSSS modulation Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241280.3530.0321.0 6243779.7990.0321.0 11246280.7240.0321.0 802.11g OFDM modulation Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241250.3500.0201.0 6243789.7430.0361.0 11246245.1860.0181.0 802.11a OFDM modulation Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1518010.6910.0051.0 4524027.9900.0141.0 5526028.3790.0141.0 8532026.8530.0131.0 9574579.9830.0401.0 11578580.3530.0401.0 13582080.7240.0401.0

FCC ID: H9PCB3000 Report No.: RF940301L041Report Format Version 2.0.2 FCC TEST REPORT (15.247) REPORT NO.: RF940301L04 MODEL NO.: CB3000 RECEIVED: Mar. 04, 2005 TESTED: Mar. 07 ~ Mar. 16, 2005 ISSUED: Mar. 21, 2005 APPLICANT: SYMBOL TECHNOLOGIES, INC. ADDRESS: One Symbol Plaza, Holtsville, NY 11742- 1300 U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 100 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: H9PCB3000 Report No.: RF940301L042Report Format Version 2.0.2 Table of Contents 1.CERTIFICATION........................................................................................................ 5 2.SUMMARY OF TEST RESULTS............................................................................... 6 2.1MEASUREMENT UNCERTAINTY............................................................................ 7 3.GENERAL INFORMATION........................................................................................ 8 3.1GENERAL DESCRIPTION OF EUT.......................................................................... 8 3.2DESCRIPTION OF TEST MODES............................................................................ 9 3.2.1CONFIGURATION OF SYSTEM UNDER TEST..................................................... 10 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.........................11 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS......................................... 13 3.4DESCRIPTION OF SUPPORT UNITS.................................................................... 14 4.TEST TYPES AND RESULTS(802.11b & g 2412~2462MHz BAND).................... 15 4.1CONDUCTED EMISSION MEASUREMENT.......................................................... 15 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................... 15 4.1.2TEST INSTRUMENTS............................................................................................. 15 4.1.3 TEST PROCEDURES ............................................................................................. 16 4.1.4 DEVIATION FROM TEST STANDARD................................................................... 16 4.1.5 TEST SETUP........................................................................................................... 17 4.1.6 EUT OPERATING CONDITIONS............................................................................ 17 4.1.7 TEST RESULTS....................................................................................................... 18 4.2RADIATED EMISSION MEASUREMENT............................................................... 24 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT............................................ 24 4.2.2TEST INSTRUMENTS............................................................................................. 25 4.2.3 TEST PROCEDURES ............................................................................................. 26 4.2.4 DEVIATION FROM TEST STANDARD................................................................... 26 4.2.5 TEST SETUP........................................................................................................... 27 4.2.6 EUT OPERATING CONDITIONS............................................................................ 27 4.2.7 TEST RESULTS....................................................................................................... 28 4.36dB BANDWIDTH MEASUREMENT....................................................................... 36 4.3.1 LIMITS OF 6dBBANDWIDTH MEASUREMENT.................................................... 36 4.3.2TEST INSTRUMENTS............................................................................................. 36 4.3.3 TEST PROCEDURE................................................................................................ 37 4.3.4 DEVIATION FROM TEST STANDARD................................................................... 37 4.3.5 TEST SETUP........................................................................................................... 37 4.3.6 EUT OPERATING CONDITIONS............................................................................ 37 4.3.7 TEST RESULTS....................................................................................................... 38 4.4MAXIMUM PEAK OUTPUT POWER...................................................................... 44 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ...................... 44 4.4.2 INSTRUMENTS........................................................................................................ 44 FCC ID: H9PCB3000 Report No.: RF940301L043Report Format Version 2.0.2 4.4.3 TEST PROCEDURES ............................................................................................. 45 4.4.4 DEVIATION FROM TEST STANDARD................................................................... 45 4.4.5 TEST SETUP........................................................................................................... 45 4.4.6 EUT OPERATING CONDITIONS............................................................................ 45 4.4.7 TEST RESULTS....................................................................................................... 46 4.5POWER SPECTRAL DENSITY MEASUREMENT.................................................. 48 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT............................... 48 4.5.2TEST INSTR…

Text truncated - open the document above for the full version.

FCC ID: H9PCB3000 Report No.: RF940301L041Report Format Version 2.0.2 FCC TEST REPORT (15.407) REPORT NO.: RF940301L04 MODEL NO.: CB3000 RECEIVED: Mar. 04, 2005 TESTED: Mar. 07 ~ Mar. 16, 2005 ISSUED: Mar. 21, 2005 APPLICANT: SYMBOL TECHNOLOGIES, INC. ADDRESS: One Symbol Plaza, Holtsville, NY 11742- 1300 U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 56 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: H9PCB3000 Report No.: RF940301L042Report Format Version 2.0.2 Table of Contents 1.CERTIFICATION........................................................................................................4 2.SUMMARY OF TEST RESULTS...............................................................................5 2.1 MEASUREMENT UNCERTAINTY.............................................................................6 3.GENERAL INFORMATION........................................................................................7 3.1GENERAL DESCRIPTION OF EUT..........................................................................7 3.2DESCRIPTION OF TEST MODES............................................................................8 3.2.1CONFIGURATION OF SYSTEM UNDER TEST.......................................................9 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:........................10 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS.........................................12 3.4DESCRIPTION OF SUPPORT UNITS....................................................................12 4.TEST TYPES AND RESULTS (5150 ~ 5350MHz BAND).......................................13 4.1CONDUCTED EMISSION MEASUREMENT..........................................................13 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT.......................................13 4.1.2TEST INSTRUMENTS.............................................................................................13 4.1.3TEST PROCEDURES.............................................................................................14 4.1.4DEVIATION FROM TEST STANDARD...................................................................14 4.1.5TEST SETUP...........................................................................................................15 4.1.6EUT OPERATING CONDITIONS............................................................................15 4.1.7TEST RESULTS.......................................................................................................15 4.2RADIATED EMISSION MEASUREMENT...............................................................18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT............................................18 4.2.2LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS..........19 4.2.3TEST INSTRUMENTS.............................................................................................20 4.2.4TEST PROCEDURES.............................................................................................21 4.2.5DEVIATION FROM TEST STANDARD...................................................................21 4.2.6TEST SETUP...........................................................................................................22 4.2.7EUT OPERATING CONDITION...............................................................................22 4.2.8TEST RESULTS.......................................................................................................23 4.3PEAK TRANSMIT POWER MEASUREMENT........................................................28 4.3.1LIMITS OF PEAK TRANSMIT POWER MEASUREMENT.....................................28 4.3.2TEST INSTRUMENTS.............................................................................................28 4.3.3TEST PROCEDURE................................................................................................29 4.3.4DEVIATION FROM TEST STANDARD...................................................................29 4.3.5TEST SETUP...........................................................................................................29 4.3.6EUT OPERATING CONDITIONS............................................................................29 4.3.7TEST RESULTS.......................................................................................................30 4.4PEAK POWER EXCURSION MEASUREMENT.....................................................35 4.4.1LIMITS OF PEAK POWER EXCURSION MEASUREMENT..................................35 FCC ID: H9PCB3000 Report No.: RF940301L043Report Format Version 2.0.2 4.4.2TEST INSTRUMENTS.............................................................................................35 4.4.3TEST PROCEDURE................................................................................................36 4.4.4DEVIATION FROM TEST STANDARD...................................................................36 4.4.5TEST SETUP...........................................................................................................36 4.4.6EUT OPERATING CONDITIONS............................................................................36 4.4.7TEST RESULTS.......................................................................................................37 4.5PEAK POWER SPECTRAL DENSITY MEASUREMENT.......................................40 4.5.1LIMITS OF PEAK POWER SPECTRAL DENSITY MEASUREMENT....................40 4.5.2TEST INSTRUMENTS................…

Text truncated - open the document above for the full version.

FCC ID: H9PCB3000 Report No.: RF940301L0498Report Format Version 2.0.2 6. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: H9PCB3000 Report No.: RF940301L0499Report Format Version 2.0.2 RADIATED EMISSION TEST
