H9PDS3578Bluetooth 2.0 EDR Scanner

One Motorola Plaza, Holtsville, NY 11742-1300, USA www.symbol.com March 1, 2011 Regulatory Engineering Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia MD 21046 Subject: Letter of Authorization As the designated signatory for FCC applications under the Grantee code H9P (Symbol Technologies, Inc), I hereby authorize Xinjian Zhang to sign all corresponding application documents relating to the processes of FCC Approval. This authorization is limited to the following Model(s):  DS3578  STB3578  FLB3578 If you have any questions regarding the authorization, please don’t hesitate to contact me. Respectfully, Mark S. Luksich Symbol Technologies, Inc. 631 738 5134 [email protected]

One Motorola Plaza, Holtsville, NY 11742-1300, USA www.symbol.com Date 23 February 2011 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Symbol Technologies, Inc. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: XinJian Zhang Telephone Number: +861084735117 Email: [email protected]

PROD FAM: DS35XX DESCRIPTION: LBL:LCD,DS3578 (GALAXIUS) CTRY CODE:WW COUNTRY:SEE REGULATORY WEBSITE FOR COUNTRY LIST SN POOL: STANDARD LBL STOCK PN: 63-66728-04 SEE NOTE 2 LBL SCRIPT: d485701X *SEE NOTE 1 CCG1:SA04 NOTES: UNLESS OTHERWISE SPECIFIED 1. SCRIPT FILE TO BE CREATED BY MANUFACTURING PER SP-10083-01 SCRIPT FILE MUST MATCH THIS DOCUMENT EXACTLY AND HAVE SAME REVISION. 2. LABEL STOCK P/N IS SUBJECT TO CHANGE. CHECK BOM FOR ACTUAL P ART NUMBER. 3. IN ALL CASES "XXX......" REPRESENTS VARIABLE FIELDS IN SCRIPT FILE. ACTUAL NUMBER OF CHARACTERS IN SCRIPT FILE MAY V ARY. 4. N/A 5. PART NUMBER MAY OR MAY NOT HAVE DASH BEFORE COUNTRY CODE. SEE BOM FOR ACTUAL MODEL DESCRIPTION. 6. "MFD:" REPRESENTS MANUFACTURE DAY, MONTH, YEAR (IE: 12SEP03 ) 7. COUNTRY OF ORIGIN REQUIRED 8. PLANT CODE REQUIRED. TO BE LOCATED BY MANUFACTURING FOR BEST FIT IN SCRIPT FILE. SEE NOTE 6 SEE NOTE 7 AND 8 BAR CODE SCANNER FOR ADDITIONAL REGULATORY INFORMATION SEE : BOM STI P/N 60-66858-(XX) 60-66859-(XX) REVISIONS DESCRIPTIONDATE REV.BYE.C.ZONEAPVD. No. RELEASED PER103970 ALL A REV'D PER EC49394 B 11/2/10 3/28/11 SIZE DWG. NO. SCALE: 1 / 1 ILLUSTRATOR SHEET 1 OF 1 X LBL:LCD, DS3578 (GALAXIUS) 69-144857-01 REV A LJM XZ MADE IN XXXXXX XXXX P/N: DS3578-XXXXXXXXXX BD_ADDR: XXXXXXXXXXXXX (S)SN: XXXXXXXXXXXXX MFD: XXXXXXX SN BAR CODE SYMBOL TECH INC. N.Y. FCC ID: H9PDS3578 IC: 1549D-DS3578 0168 MODEL:DS3578 CMIIT ID: XXXXYYZZ 50 R XXXXXXXXXXXX R32626 XXXXXXXXXXXXXX NOTE: ITEMS OUTLINED IN RED TO BE ADDED TO SCRIPT FILE AT LATER DATE WHEN APPROVALS RECEIVED MOTOROLA SOLUTIONS, INC. B KCC-CRM-SK1-DS3578 LJM XZ

Document 75912884 Report 03 Issue 3 May 2011 Report On RF Exposure Assessment of the Symbol Technologies Inc DS3578 Bluetooth 2.0 EDR Scanner TUV Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk Document 75912884 Report 03 Issue 3 Page 1 of 22 This report has been up issued to Issue 3 to correct specification information in Section 1.1.. REPORT ON RF Exposure Assessment of the Symbol Technologies Inc DS3578 Bluetooth 2.0 EDR Scanner Document 75912884 Report 03 Issue 3 May 2011 PREPARED FOR Symbol Technologies Inc One Symbol Plaza Holtsville New York 11742-1300 PREPARED BY M Whiting Project Manager APPROVED BY M J Hardy Authorised Signatory DATED 11 May 2011 Document 75912884 Report 03 Issue 3 Page 2 of 22 CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Product Information ...................................................................................................................... 7 1.4 Summary ...................................................................................................................................... 7 2 TEST DETAILS ............................................................................................................................ 8 2.1 Rationale for Assessment of the RF Exposure ............................................................................ 9 2.2 Defined Limits ............................................................................................................................. 10 2.3 Establishing Wavelength and 1/4 Wavelength ........................................................................... 10 2.4 Far Field Calculations ................................................................................................................. 11 2.5 Field Regions .............................................................................................................................. 11 3 FIGURES .................................................................................................................................... 12 3.1 Field Representations – ICNIRP ................................................................................................ 13 3.2 Field Representations – FCC ..................................................................................................... 15 3.3 Field Representations – IC ......................................................................................................... 17 3.4 Field Representations – ACMA .................................................................................................. 19 4 DISCLAIMERS AND COPYRIGHT ........................................................................................... 21 4.1 Disclaimers and Copyright .......................................................................................................... 22 Document 75912884 Report 03 Issue 3 Page 3 of 22 SECTION 1 REPORT SUMMARY RF Exposure Assessment of the Symbol Technologies Inc DS3578 Bluetooth 2.0 EDR Scanner Document 75912884 Report 03 Issue 3 Page 4 of 22 1.1 INTRODUCTION The information contained in this report is intended to show verification of the RF Exposure Assessment of the Symbol Technologies Inc DS3578 Bluetooth 2.0 EDR Scanner to the requirements of the applied test specifications. Objective To perform RF Exposure Assessment to determine the Equipment Under Test's (EUT’s) compliance of the applied rules. Applicant Symbol Technologies Inc Manufacturer Symbol Technologies Inc Manufacturing Description DS3578 Bluetooth 2.0 EDR Scanner Model Number(s) DS3578 Hardware Version Rev A Test Specification/Issue/Date 1. EN62311:2008 - Assessment of electronic and electrical equipment related to human exposure restrictions for electromagnetic fields (0 Hz – 300 GHz). 2. OET Bulletin 65 Edition 97-01 August 1997 - Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields 3. RSS-102 Issue 4 March 2010 Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) 4. Radiocommunications (Electromagnetic Radiation – Human Exposure) Standard 2003 Related Document(s) 5. Council Recommendation 1999/519/EC of 12 July 1999 on the limitation of exposure of the general public to electromagnetic fields (0 Hz to 300 GHz) (Official Journal L 197 of 30 July1999). 6. FCC Guidelines for Evaluating exposure to RF Emissions - 47 CFR § 1.1310; 47 CFR § 1.1307(b) & 47 CFR § 80.83. 7. Health Canada's Safety Code 6: Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 KHz to 300 GHz. 8. ARPANSA, ‘Radiation Protection Standard – Maximum Exposure Levels to Radiofrequency Fields – 3KHz to 300GHz’ 9. ICNIRP 1998,’Guidelines for limiting exposure to time-varying electric magnetic, and electromagnetic fields (up to 300GHz). Guidelines of the International Commission on Non-Ionizing Radiation Protection’, Health Physics, vol.74, no.4, pp.494-522. Document 75912884 Report 03 Issue 3 Page 5 of 22 10. National Council on Radiation Protection and Measurements (NRPC) - Report No. 86(1986) "Biological Effects and Exposure Criteria for Radio frequency Electromagnetic Fields". 11. EN 50383:2002 - Basic standard for the calculation and measurement of electromagnetic field strength and SAR related to human exposure from radio base stations and fixed terminal stations for wireless telecommunication systems (110 MHz - 40 GHz). 12. IEEE Std C95.1-2005: IEEE Stand…

Text truncated - open the document above for the full version.

Document 75912884 Report 02 Issue 1 April 2011 Report On FCC and Industry Canada Testing of the Symbol Technologies Inc DS3578 Scanner In accordance with FCC CFR 47 Part 15C and Industry Canada RSS-210 COMMERCIAL-IN-CONFIDENCE FCC ID: H9PDS3578 IC ID: 1549D-DS3578 TUV Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75912884 Report 02 Issue 1 Page 1 of 65 COMMERCIAL-IN-CONFIDENCE REPORT ON FCC and Industry Canada Testing of the Symbol Technologies Inc DS3578 Scanner In accordance with FCC CFR 47 Part 15C and Industry Canada RSS-210 Document 75912884 Report 02 Issue 1 April 2011 PREPARED FOR Symbol Technologies Inc One Motorola Plaza Holtsville NY 11742-1300 USA PREPARED BY N Bennett Senior Administrator APPROVED BY M J Hardy Authorised Signatory DATED 21 April 2011 ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Part 15C and RSS-210. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); B Airs A Guy COMMERCIAL-IN-CONFIDENCE Document 75912884 Report 02 Issue 1 Page 2 of 65 COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Application Form ........................................................................................................................... 7 1.4 Product Information .................................................................................................................... 10 1.5 Test Conditions ........................................................................................................................... 11 1.6 Deviations From the Standard .................................................................................................... 11 1.7 Modification Record .................................................................................................................... 11 2 TEST DETAILS .......................................................................................................................... 12 2.1 20dB Bandwidth .......................................................................................................................... 13 2.2 Channel Separation .................................................................................................................... 17 2.3 Channel Dwell Time .................................................................................................................... 19 2.4 Number of Hopping Channels .................................................................................................... 26 2.5 Maximum Peak Conducted Output Power ................................................................................. 28 2.6 EIRP Peak Power ....................................................................................................................... 30 2.7 Radiated Emissions (Enclosure Port) ......................................................................................... 34 2.8 Spurious Emissions .................................................................................................................... 47 2.9 Band Edge Emissions ................................................................................................................. 55 3 TEST EQUIPMENT USED ......................................................................................................... 58 3.1 Test Equipment Used ................................................................................................................. 59 3.2 Measurement Uncertainty .......................................................................................................... 63 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 64 4.1 Accreditation, Disclaimers and Copyright ................................................................................... 65 COMMERCIAL-IN-CONFIDENCE Document 75912884 Report 02 Issue 1 Page 3 of 65 COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY FCC and Industry Canada Testing of the Symbol Technologies Inc DS3578 Scanner In accordance with FCC CFR 47 Part 15C and Industry Canada RSS-210 COMMERCIAL-IN-CONFIDENCE Document 75912884 Report 02 Issue 1 Page 4 of 65 COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of Symbol Technologies Inc DS3578 Scanner to the requirements of FCC CFR 47 Part 15C and Industry Canada RSS- 210. Objective To perform FCC Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Symbol Technologies Inc Manufacturing Description Handheld Scanner Model Number(s) DS3578 Serial Number(s) MIN25A34B M1N29F24C Software Version Rev A Hardware Version Rev A Number of Samples Tested Two Test Specification/Issue/Date FCC CFR 47 Part 15C: 2010 Industry Canada RSS-210 Issue 8:2010 Incoming Release Date Application Form 11 February 2011 Disposal Reference Number Date Held Pending Disposal Not Applicable Not Applicable Order Number Date NP5308873 19 October 2011 Start of Test 18 March 2011 Finish of Test 31 March 2011 Name of Engineer(s) B Airs A Guy Related Document(s) ANSI C63.4: 2003 COMMERCIAL-IN-CONFIDENCE Documen…

Text truncated - open the document above for the full version.

FCC ID: H9PDS3578 IC ID: 1549D-DS3578 Symbol Technologies Inc DS3578 Scanner 2011 Not to be reproduced, except in its entirety, Page 1 of 1 without the Permission of TÜV SÜD Product Service Ltd Reference: 75912884 PHOTOGRAPHS OF TEST SET UP Radiated Emissions
