H9PLA4121PDT81462.4GHz Pen Terminal w/ Internal DSSS LAN Radio Car

Symbol Technologies Inc

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Feb 14, 2002
Application Purpose: Original Equipment
Date of Application: Nov 11, 2001
Equipment Note: 2.4GHz Pen Terminal w/ Internal DSSS LAN Radio Car
Frequency Range: 2412.00000000 - 2462.00000000
Company: Symbol Technologies Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

October 25, 2001 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 2 1046 Re: Symbol Technologies FCC ID: H9PLA4 12 1PDT8146 Confidentiality Dear Reviewer, Symbol Technologies (“Symbol”), requests that the Block Diagram, Schematics, and operational Description exhibits of the referenced application be withheld from routine availability for public inspection pursuant to Section 0.459 of the Commissions Rules an Freedom of Information Act (“FOIA) Exemption 4, 5 U.S.C. 552 (b) (4). ‘These exhibits consist of “trade secrets (or) commercial or financial information obtained from a person and privileged or confidential” 5 U.S.C. 552 (b) (4), and is therefore entitled to protection from disclosure under FOIA. The documents in question contain trade secrets: detailed technical descriptions, specifications and schematics for a product to be offered for sale. This information would give Symbol’s competitors an unearned and unwarranted competitive advantage. The documents contain “commercial information” within the scope of FOIA exemption 4. This information is the product of Symbol’s investment of money, personnel, and other resources. The result of the investment is a fairly earned position in the marketplace. Premature release of the information threatens substantial and unwarranted harm to Symbol’s competitive position. These materials provide particulars on the product design. For these reasons, Symbol has taken pains to keep this technical information confidential, and intends to continue doing so. Symbol customarily witholds this information from persons outside the employ of Symbol and certain of its suppliers and contractors, and even within these groups routinely limits access to persons having a particular need for the information. If the Commissions were to make these documents public, it would be giving away hard won fruits of Symbols labors without compensation. The filing fee that is required for this confidentiality request is included in the check that accompanies this application. If there are any questions about this request, please call me at the number above. Thank you for your attention. Respectfully Submitted, Sandy Mazzola

Cover Letter(s)

November 8, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SYMBOL TECHNOLOGIES INC. FCC ID: H9PLA4121PDT8146 Gentlemen: Attached herewith, on behalf of SYMBOL TECHNOLOGIES INC. is an application for Part 15.247 Certification of the following 2.4GHz Pen Terminal w/ Internal DSSS LAN Radio Card: FCC ID: H9PLA4121PDT8146 TRADE / MODEL(s): SYMBOL PDT8146 EUT TYPE: 2.4GHz Pen Terminal w/ Internal DSSS LAN Radio Card Tx / Rx Freq. Range: 2412 — 2462 MHz Max. RF Output Power: 0.135 W (21.31 dBm) Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Symbol Technologies Inc.

Cover Letter(s)

January 15, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Steve Dayhoff SUBJECT: Symbol Technologies, Inc. FCC ID: H9PLA4121PDT8146 731 Confirmation No.: EA362370 Correspondence Reference No.: 21724 Request for Tech. Info.: 1/10/02 Dear Steve: Transmitted herewith, on behalf of Symbol Technologies, Inc., is an amendment provided in response to the request for technical information dated January 10, 2002. 1. Please find the attached EIRP and radiated spurious data. The FCC ID for the PCMCIA card is H9PLA4121. 2. Please find the attached EIRP data taken with the unit's internal antenna. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: Symbol Technologies, Inc.

External Photos

© 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal DSSS Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz)

ID Label/Location Info

© 2001 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) Sample FCC Label Symbol Technologies Inc. Model: PDT8146 FCC ID: H9PLA4121PDT8146 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. This is a sample draft of the label that will be located on the underside of the product. Sandy Mazzola

Internal Photos

RF Exposure Info

SYMBOL FCC ID: H9PLA4121PDT8146 -- 2.4GHz DSSS Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.20 mho/m ε r = 52.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.610 mW/g, SAR (10g): 0.256 mW/g SYMBOL Pocket PC Terminal w/Integrated 11MB DSSS radio card (FCC ID:H9PLA4121) Model: PDT8146; CW Mode, Low Channel [2412MHz] EIRP Power = 21.31dBm [135mW]; Spacing = 2.5cm from flat phantom to rear panel of EUT, w/Holster Test Date -- 10/12/2001 SAR Tot [mW/g] 6.74E-2 2.02E-1 3.37E-1 4.72E-1 6.07E-1 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID: H9PLA4121PDT8146 -- 2.4GHz DSSS Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.20 mho/m ε r = 52.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.542 mW/g, SAR (10g): 0.233 mW/g SYMBOL Pocket PC Terminal w/Integrated 11MB DSSS radio card (FCC ID:H9PLA4121) Model: PDT8146; CW Mode, Mid Channel [2437MHz] EIRP Power = 21.31dBm [135mW]; Spacing = 2.5cm from flat phantom to rear panel of EUT, w/Holster Test Date -- 10/12/2001 SAR Tot [mW/g] 5.42E-2 1.63E-1 2.71E-1 3.79E-1 4.88E-1 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID: H9PLA4121PDT8146 -- 2.4GHz DSSS Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.20 mho/m ε r = 52.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.514 mW/g, SAR (10g): 0.220 mW/g SYMBOL Pocket PC Terminal w/Integrated 11MB DSSS radio card (FCC ID:H9PLA4121) Model: PDT8146; CW Mode, Igh Channel [2462MHz] EIRP Power = 21.31dBm [135mW]; Spacing = 2.5cm from flat phantom to rear panel of EUT, w/Holster Test Date -- 10/12/2001 SAR Tot [mW/g] 5.28E-2 1.58E-1 2.64E-1 3.70E-1 4.75E-1 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID: H9PLA4121PDT8146 -- 2.4GHz DSSS Hand SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.20 mho/m ε r = 52.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.664 mW/g, SAR (10g): 0.294 mW/g SYMBOL Pocket PC Terminal w/Integrated 11MB DSSS radio card (FCC ID:H9PLA4121) Model: PDT8146; CW Mode, Low Channel [2412MHz] EIRP Power = 21.31dBm [135mW]; Spacing = back of EUT (internal antenna side) touching flat phantom Test Date -- 10/12/2001 SAR Tot [mW/g] 2.95E-2 8.85E-2 1.47E-1 2.06E-1 2.65E-1 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID: H9PLA4121PDT8146 -- 2.4GHz DSSS Hand SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.20 mho/m ε r = 52.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.648 mW/g, SAR (10g): 0.271 mW/g SYMBOL Pocket PC Terminal w/Integrated 11MB DSSS radio card (FCC ID:H9PLA4121) Model: PDT8146; CW Mode, Mid Channel [2437MHz] EIRP Power = 21.31dBm [135mW]; Spacing = back of EUT (internal antenna side) touching flat phantom Test Date -- 10/12/2001 SAR Tot [mW/g] 3.40E-2 1.02E-1 1.70E-1 2.38E-1 3.06E-1 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID: H9PLA4121PDT8146 -- 2.4GHz DSSS Hand SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.20 mho/m ε r = 52.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.637 mW/g, SAR (10g): 0.259 mW/g SYMBOL Pocket PC Terminal w/Integrated 11MB DSSS radio card (FCC ID:H9PLA4121) Model: PDT8146; CW Mode, High Channel [2462MHz] EIRP Power = 21.31dBm [135mW]; Spacing = back of EUT (internal antenna side) touching flat phantom Test Date -- 10/12/2001 SAR Tot [mW/g] 2.99E-2 8.97E-2 1.49E-1 2.09E-1 2.69E-1 PCTEST Engineering Laboratory, Inc.

RF Exposure Info

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Symbol Technologies Inc. Dates of Tests: October 12, 2001 1 Symbol Plaza Test Report S/N: SAR.211011625.H9P Holtsville, NY 11742-1300 Test Site: PCTEST Lab, Columbia MD U.S.A. Attn: Sandy Mazzola, Regulatory Engineer cc: Dean La Rosa, Senior Design Engineer FCC ID H9PLA4121PDT8146 APPLICANT SYMBOL TECHNOLOGIES INC. EUT Type: 2.4GHz Pen Terminal w/ 11Mb Direct Sequence Spread Spectrum (DSSS) Internal LAN radio card (PCMCIA internal card FCC ID: H9PLA4121) Tx/Rx Frequency: 2412 — 2462 MHz Max. Radiated Power: 0.135 Watts (21.3dBm) Max. Peak SAR: 0.610 mW/g (1 g. avg) DSSS Body SAR; 0.294 mW/g (10 g. avg) DSSS Hand SAR Trade Name/Model(s): SYMBOL PDT8146 FCC Classification: Part 15 Spread Spectrum Transmitter Application Type: Certification Tx Original Grant Date: Internal 11Mb DSSS LAN Radio PCMCIA Card Symbol FCC ID: H9PLA4121 July 31, 2000 Serial Number: n/a (pre-production) FCC Rule Part(s): § 2.1093; ET Docket 96.326 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992 (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 211011625.H9P SAR Measurement Report FCC Certification © 2001 PCTEST Lab i Table of Contents ATTACHMENT A - COVER LETTER ATTACHMENT B - ATTESTATION STATEMENT(S) ATTACHMENT C - SAR MEASUREMENT REPORT 1.1 SCOPE 1 2.1 INTRODUCTION / SAR DEFINITION 2 3.1 SAR MEASUREMENT SET-UP 3 4.1 E-FIELD PROBE SYSTEM 4 5.1 E-FIELD PROBE CALIBRATION PROCESS 5 5.3 DATA EXTRAPOLATION 6 6.1 PHANTOM, HOLDER & EQUIVALENT TISSUES 7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS 9 9.1 TEST POSITION OF THE PHONE 10 10.1 BODY-WORN CONFIGURATION 11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS 12 12.1 MEASUREMENT UNCERTAINTIES 13 13.1 TEST DATA SUMMARY 14-15 14.1 SAR TEST EQUIPMENT LIST 16 15.1 CONCLUSION 17 16.1 REFERENCES 18 ATTACHMENT D - FCC ID LABEL & LOCATION ATTACHMENT E - BLOCK DIAGRAM(S) ATTACHMENT F - SCHEMATIC DIAGRAM(S) ATTACHMENT G - OPERATIONAL DESCRIPTION ATTACHMENT H - EXTERNAL PHOTOGRAPHS ATTACHMENT I - INTERNAL PHOTOGRAPHS ATTACHMENT J - TEST SETUP PHOTOGRAPHS ATTACHMENT K - USER’S MANUAL ATTACHMENT L - PART 15.247 MEASUREMENT REPORT ATTACHMENT M - SAR TEST DATA ATTACHMENT N - SAR TEST SETUP PHOTOGRAPHS ATTACHMENT O - DIPOLE VALIDATION PLOTS ATTACHMENT P - PROBE CALIBRATION DATA ATTACHMENT Q - COPY OF INTERNAL FHSS LAN RADIO CARD FCC GRANT Test Report S/N: SAR.211011625.H9P SAR Measurement Report Test Dates: October 12, 2001 FCC Part 15.247 Certification 2.4GHz Pen Terminal w/Internal DSSS LAN Radio Card © 2001 PCTEST Lab FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) 1 SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name: Symbol Technologies Inc. Address: 1 Symbol Plaza Holtsville, NY 11742-1300 Attention: Sandy Mazzola, Regulatory Engineer cc: Dean La Rosa, Senior Design Engineer • EUT Type: 2.4GHz Pen Terminal w/ 11Mb Direct Sequence Spread Spectrum (DSSS) Int. LAN radio card (PCMCIA int. card FCC ID: H9PLA4121) • Trade Name: SYMBOL • FCC IDENTIFIER: H9PLA4121PDT8146 • Model: SPT 1846 • S/N: Pre-production • Tx/Rx Frequency: 2412 — 2462 MHz • Application Type: Certification • FCC Classification: Part 15 Spread Spectrum Transmitter • Method/System: Direct Sequence Spread Spectrum System (DSSS) • FCC Rule Part(s): § 2.1093, Docket 96-326 • Max. Radiated Power: 0.135 Watts (21.3dBm) • Max. SAR Measurements: 0.610 mW/g (1 g. avg) DSSS Body SAR; 0.294 mW/g (10 g. avg) DSSS Hand SAR • Modulation: Spread Spectrum Transmitter (DSS) • Dates of Test(s): October 12, 2001 • Place of Test(s): PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.211011625.H9P • Original Grant Date: Internal 11Mb DSSS LAN Radio PCMCIA Card Symbol FCC ID: H9PLA4121 April 27, 2001 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.211011625.H9P SAR Measurement Report Test Dates: October 12, 2001 FCC Part 15.247 Certification 2.4GHz Pen Terminal w/Internal DSSS LAN Radio Card © 2001 PCTEST Lab FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) 2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Sa…

Text truncated - open the document above for the full version.

RF Exposure Info

Probe ET3DV6 SN:1560 Manufactured:December 1, 2000 Calibrated:February 20, 2001 Calibrated for System DASY3 Page 1 of 8 ET3DV6 SN:1560 DASY3 - Parameters of Probe: ET3DV6 SN:1560 Sensitivity in Free SpaceDiode Compression NormX1.48 μV/(V/m) 2 DCP X98mV NormY1.51 μV/(V/m) 2 DCP Y98mV NormZ1.43 μV/(V/m) 2 DCP Z98mV Sensitivity in Tissue Simulating Liquid Head450MHz ε r =43.5 ± 5% σ = 0.87 ± 10% mho/m ConvF X7.17 extrapolatedBoundary effect: ConvF Y7.17 extrapolatedAlpha0.25 ConvF Z7.17 extrapolatedDepth3.21 Head900MHz ε r =42 ± 5% σ = 0.97 ± 10% mho/m ConvF X6.59 ± 7% (k=2)Boundary effect: ConvF Y6.59 ± 7% (k=2)Alpha0.32 ConvF Z6.59 ± 7% (k=2)Depth2.93 Head1500MHz ε r =40.4 ± 5% σ = 1.23 ± 10% mho/m ConvF X5.82 interpolatedBoundary effect: ConvF Y5.82 interpolatedAlpha0.41 ConvF Z5.82 interpolatedDepth2.55 Head1800MHz ε r =40 ± 5% σ = 1.40 ± 10% mho/m ConvF X5.43 ± 7% (k=2)Boundary effect: ConvF Y5.43 ± 7% (k=2)Alpha0.46 ConvF Z5.43 ± 7% (k=2)Depth2.36 Sensor Offset Probe Tip to Sensor Center2.7mm Optical Surface Detection2.0 ± 0.2mm Page 2 of 8 ET3DV6 SN:1560 Receiving Pattern (φ), θ = 0° f = 30 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 100 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 300 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 900 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot Page 3 of 8 ET3DV6 SN:1560 Isotropy Error (φ), θ = 0° -1.00 -0.80 -0.60 -0.40 -0.20 0.00 0.20 0.40 0.60 0.80 1.00 060120180240300360 error[dB] 30 MHz 100 MHz 300 MHz 900 MHz 1800 MHz 2500 MHz f = 1800 MHz, WG R22 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 2500 MHz, WG R26 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot Page 4 of 8 ET3DV6 SN:1560 Frequency Response of E-Field ( TEM-Cell:ifi110, Waveguide R22) 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 050010001500200025003000 f [MHz] frequency response TEMR22 Page 5 of 8 ET3DV6 SN:1560 Dynamic Range f(SAR brain ) ( TEM-Cell:ifi110 ) ET3DV6 SN:1560 1.E+0 1.E+1 1.E+2 1.E+3 1.E+4 1.E+5 1.E+6 1.E+7 0.00010.0010.010.11.10.100. mW/cm 3 μ V not compensatedcompensated -2.0 -1.0 0.0 1.0 0.0010.010.1110100 mW/cm 3 errror[dB] Page 6 of 8 Conversion Factor Assessment Head900MHz ε r =42 ± 5% σ = 0.97 ± 10% mho/m ConvF X6.59 ± 7% (k=2)Boundary effect: ConvF Y6.59 ± 7% (k=2)Alpha0.32 ConvF Z6.59 ± 7% (k=2)Depth2.93 Head1800MHz ε r =40 ± 5% σ = 1.40 ± 10% mho/m ConvF X5.43 ± 7% (k=2)Boundary effect: ConvF Y5.43 ± 7% (k=2)Alpha0.46 ConvF Z5.43 ± 7% (k=2)Depth2.36 ET3DV6 SN:1560 f = 900 MHz, WG R9 (head) 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 0204060 z[mm] SAR[mW/cm 3 ] / W AnalyticalMeasuremets f = 1800 MHz, WG R22 (head) 0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 0204060 z[mm] SAR[mW/cm 3 ] / W AnalyticalMeasuremets Page 7 of 8 Deviation from Isotropy in HSL Error (θ,φ), f = 900 MHz 0 40 80 120 160 200 240 280 320 0 10 20 30 40 50 60 -1.00 -0.80 -0.60 -0.40 -0.20 0.00 0.20 0.40 0.60 0.80 1.00 Error [dB] θ φ -1.00--0.80-0.80--0.60-0.60--0.40-0.40--0.20-0.20-0.00 0.00-0.200.20-0.400.40-0.600.60-0.800.80-1.00 Page 8 of 8

RF Exposure Info

Muscle Dipole Validation Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 1900 MHz Muscle: σ = 1.85 mho/m ε r = 54.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 9.50 mW/g, SAR (10g): 4.92 mW/g 1900MHz Muscle Dipole Validation (D1900V2 S/N: 502) Frequency: 1900 MHz; Antenna Input Power: 250 [mW] PCTEST Muscle Tissue Simulating Liquid [10/12/2001] SAR Tot [mW/g] 0.92E+0 2.78E+0 4.64E+0 6.49E+0 8.35E+0 PCTEST Engineering Laboratory, Inc.

Test Report

Test Report S/N: 15.211011625.H9P FCC Part 15.247 Dates of Tests: October 12, 2001 Certification © 2002 PCTEST Lab FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) 1 2.4GHz Pen Terminal w/Internal DSSS LAN Radio Card RADIATED Measurements (Fundamental & Harmonics) Operating Frequency: 2412 MHz Distance of Measurements: 3 meters Channel: Low FREQ. (MHz) Level* (dBm) AFCL (dB) POL (H/V) DET QP/AVG F/S (μV/m) F/S (dBμV/m) Margin (dB) 2412.0 - 23.2 32.7 V Peak 670656.0 116.5 n/a 4824.0 - 96.5 40.4 V Peak 350.3 50.9 3.1 7236.0 - 103.1 47.4 V Peak 368.1 51.3 65.2 9648.0 - 117.8 50.3 V Peak 94.4 39.5 11.4 12060.0 < - 132 NOTES: 1. All harmonics in the restricted bands specified in §15.205 are below the limit shown in table 2. (note: * Restricted Band) 2. All harmonics/spurs are at least 20 dB below the highest emission in the authorized band using RBW = 810kHz 3. Average Measurements > 1GHz using RBW = 1 MHz VBW = 81 Hz 4. The peak emissions above 1 GHz are not more than 20 dB above the average limit. 5. The antenna is manipulated through typical positions, polarity and length during the tests. 6. The EUT is supplied with nominal AC voltage or/and a new/fully recharged battery. 7. The spectrum is measured from 9kHz to the 81 th harmonic and the worst-case emissions are reported. 8. < - 132 are below the analyzer floor level. Figure 1. Restricted band harmonics and spurious limits. Above 1 GHz limit is 500 uV/m (54dBu/m) Test Report S/N: 15.211011625.H9P FCC Part 15.247 Dates of Tests: October 12, 2001 Certification © 2002 PCTEST Lab FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) 2 2.4GHz Pen Terminal w/Internal DSSS LAN Radio Card RADIATED Measurements (Fundamental & Harmonics) (Cont.) Operating Frequency: 2437Hz Distance of Measurements: 3 meters Channel: Mid FREQ. (MHz) Level* (dBm) AFCL (dB) POL (H/V) DET QP/AVG F/S (μV/m) F/S (dBμV/m) Margin (dB) 2437.0 - 23.3 32.8 V Peak 670656.0 116.5 n/a 4874.0 - 96.0 40.5 V Peak 375.8 51.5 2.5 7311.0 - 103.9 48.0 V Peak 358.9 51.1 2.9 9748.0 - 118.0 50.3 V Peak 92.3 39.3 14.7 12185.0 < - 132 NOTES: 1. All harmonics in the restricted bands specified in §15.205 are below the limit shown in table 2. (note: * Restricted Band) 2. All harmonics/spurs are at least 20 dB below the highest emission in the authorized band using RBW = 810kHz 3. Average Measurements > 1GHz using RBW = 1 MHz VBW = 81 Hz 4. The peak emissions above 1 GHz are not more than 20 dB above the average limit. 5. The antenna is manipulated through typical positions, polarity and length during the tests. 6. The EUT is supplied with nominal AC voltage or/and a new/fully recharged battery. 7. The spectrum is measured from 9kHz to the 81 th harmonic and the worst-case emissions are reported. 8. < - 132 are below the analyzer floor level. Figure 2. Restricted band harmonics and spurious limits. Above 1 GHz limit is 500 uV/m (54dBu/m) Test Report S/N: 15.211011625.H9P FCC Part 15.247 Dates of Tests: October 12, 2001 Certification © 2002 PCTEST Lab FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) 3 2.4GHz Pen Terminal w/Internal DSSS LAN Radio Card RADIATED Measurements (Fundamental & Harmonics) (Cont.) Operating Frequency: 2462 MHz Distance of Measurements: 3 meters Channel: High FREQ. (MHz) Level* (dBm) AFCL (dB) POL (H/V) DET QP/AVG F/S (μV/m) F/S (dBμV/m) Margin (dB) 2462.0 - 23.4 32.9 V Peak 670656.0 116.5 N/a 4924.0 - 96.9 40.7 V Peak 346.7 50.8 3.2 7386.0 - 104.0 48.2 V Peak 363.1 51.2 2.8 9848.0 - 118.2 50.4 V Peak 91.2 39.2 14.8 12310.0 < - 132 NOTES: 1. All harmonics in the restricted bands specified in §15.205 are below the limit shown in table 2. (note: * Restricted Band) 2. All harmonics/spurs are at least 20 dB below the highest emission in the authorized band using RBW = 810kHz 3. Average Measurements > 1GHz using RBW = 1 MHz VBW = 81 Hz 4. The peak emissions above 1 GHz are not more than 20 dB above the average limit. 5. The antenna is manipulated through typical positions, polarity and length during the tests. 6. The EUT is supplied with nominal AC voltage or/and a new/fully recharged battery. 7. The spectrum is measured from 9kHz to the 81 th harmonic and the worst-case emissions are reported. 8. < - 132 are below the analyzer floor level. Figure 3. Restricted band harmonics and spurious limits. Above 1 GHz limit is 500 uV/m (54dBu/m) Test Report S/N: 15.211011625.H9P FCC Part 15.247 Dates of Tests: October 12, 2001 Certification © 2002 PCTEST Lab FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) 4 2.4GHz Pen Terminal w/Internal DSSS LAN Radio Card RADIATED Measurements (Spurious) Operating Frequency: 2412 — 2462 MHz Distance of Measurements: 3 meters FREQ. (MHz) Level* (dBm) AFCL** (dB) POL (H/V) Height (m) Azimuth (° angle) F/S (μV/m) Margin*** (dB) 33.3 - 78.6 - 0.4 V 3.6 170 25.2 - 12.0 66.4 - 80.8 5.8 V 2.1 30 39.9 - 8.0 99.6 - 84.1 9.6 H 1.4 10 42.2 - 11.0 180.0 - 86.4 13.7 H 2.4 210 51.9 - 9.2 165.9 - 87.7 14.7 V 2.3 180 50.2 - 9.5 818.0 - 104.6 31.6 V 1.2 200 50.2 - 12.0 NOTES: 1.All emissions were investigated and the worst case emissions are reported 2. For hand-held devices, the EUT is rotated through three orthogonal axis to determine which configuration produces the maximum emissions. 3. The EUT is supplied with the minimal AC voltage or/and a new/fully recharged battery. 4. The EUT was tested up to the 81 th harmonic (24 GHz) and no significant emission was found. Figure 4. Restricted band harmonics and spurious limits. Above 1 GHz limit is 500 uV/m (54dBu/m) Test Report S/N: 15.211011625.H9P FCC Part 15.247 Dates of Tests: October 12, 2001 Certification © 2002 PCTEST Lab FCC ID: H9PLA4121PDT8146 (Tx 2412-2462MHz) 5 2.4GHz Pen Terminal w/Internal DSSS LAN Radio Card Test Data Equivalent Isotropic Radiated Power (E.I.R.P.) Radiated measurements at 3 meters Supply Volta g e : 3 .6VDC M odulation: FREQ. LEVEL POL Azim uth EIRP EIRP (M H z) (dB m ) (H /V ) (o angle) (dB m ) (W ) 2412.00 -23.170 V 60 21.301 0.135 2437.00 -23.270 V 60 21.301 0.135 2462.00 -23.370 V 60 21.301 0.135 NOTES: DSSS Eq…

Text truncated - open the document above for the full version.

Test Setup Photos

Text truncated - open the document above for the full version.
