H9PMC7070EDA (Enterprise Digital Assistant)

© 2005 SYMBOL TECHNOLOGIES, INC. All rights reserved. Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein. No license is granted, either expressly or by implication, estoppel, or otherwise under any patent right or patent, covering or relating to any combination, system, apparatus, machine, material, method, or process in which Symbol products might be used. An implied license exists only for equipment, circuits, and subsystems contained in Symbol products. Symbol and the Symbol logo are registered trademarks of Symbol Technologies, Inc. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. Symbol Technologies, Inc. One Symbol Plaza Holtsville, N.Y. 11742-1300 http://www.symbol.com Patents This product is covered by one or more of the patents listed on the Web site: www.symbol.com/patents. Warranty Subject to the terms of Symbol’s hardware warranty statement, the MC70 mobile computer products are warranted against defects in workmanship and materials for a period of one year from the date of shipment. For the complete Symbol hardware product warranty statement, go to: http://www.symbol.com/warranty. Battery Information Symbol rechargeable battery packs are designed and constructed to the highest standards within the industry. However, there are limitations to how long a battery can operate or be stored before needing replacement. Many factors affect the actual life cycle of a battery pack, such as heat, cold, harsh environmental conditions and severe drops. When batteries are stored over six (6) months, some irreversible deterioration in overall battery quality may occur. Store batteries discharged in a dry, cool place, removed from the equipment to prevent loss of capacity, rusting of metallic parts and electrolyte leakage. When storing batteries for one year or longer, they should be charged and discharged at least once a year. If an electrolyte leakage is observed, avoid any contact with affected area and properly dispose of the battery. Replace the battery when a significant loss of run time is detected. Standard warranty period for all Symbol batteries is 30 days, regardless if the battery was purchased separately or included as part of the mobile computer or bar code scanner. For more information on Symbol batteries, please visit: http:/mysymbolcare.symbol.com/battery/batbasics1.html. Battery Charging Note To charge the battery for the mobile device, battery and charger temperatures must be between +32° F and +104° F (0° C and +40° C). Ta i w a n EPA (Environmental Protection Administration) requires dry battery producing or importing firms in accordance with Article 15 of the Waste Disposal Act are required to indicate the recycling marks on the batteries used in sales, giveaway or promotion. Contact a qualified Taiwanese recycler for proper battery disposal. Service Information Before you use the unit, it must be configured to operate in your facility’s network and run your applications. If you have a problem running your unit or using your equipment, contact your facility’s Technical or Systems Support. If there is a problem with the equipment, they will contact the Symbol Support Center: For the latest version of this guide go to: http://www.symbol.com/manuals United States1-800-653-5350 Canada905-629-7226 United Kingdom0800 328 2424Asia/Pacific337-6588 Australia1-800-672-906Austria/ Österreich 01-5055794-0 Denmark/Danmark 7020-1718Finland/Suomi9 5407 580 France01-40-96-52-21 Germany/ Deutschland 6074-49020 Italy/Italia2-484441Mexico/México5-520-1835 Netherlands/ Nederland 315-271700 Norway/Norge+47 2232 4375 South Africa11-809 5311Spain/España+913244000 Sweden/Sverige08 445 29 00 Europe/Mid-East Distributor Operations Contact local distributor or call +44 118 945 7360 Latin America Sales Support Inside USA: 1-800-347-0178; Outside USA: +1.954.255.2610 72-71767-01 Revision A — November 2005 MC70 REGULATORY INFORMATION Microsoft ® Mobile ® 5.0 END-USER LICENSE AGREEMENT • You have acquired a device (“DEVICE”) that includes software licensed by Symbol Technologies, Inc. from an affiliate of Microsoft Corporation (“MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online” or electronic documentation (“SOFTWARE”) are protected by international intellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights reserved. • IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT (“EULA”), DO NOT USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY CONTACT Symbol Technologies, Inc. FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND. ANY USE OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATION OF ANY PREVIOUS CONSENT). • SOFTWARE includes software already installed on the DEVICE (“DEVICE Software”) and MS software contained on the CD-ROM disk (“Companion CD”). GRANT OF SOFTWARE LICENSE. This EULA grants you the following license: DEVICE Software. You may use the DEVICE Software as installed on the DEVICE. Companion CD. A Companion CD is included with your DEVICE, and you may install and use the Microsoft® ActiveSync® component on one (1) or more personal computers to exchange information with one (1) or more computing devices that contain a compatible version of the Microsoft® Windows Mobile™ Version 5.0 operating system. For other software component(s) contained on the Companion CD, you may install and use such components only in accordance with the terms of the printed or online end user license agreement(s) provided with such component(s). In the absence of an end user license agreement for particular component(s) of the…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7

FCC ID : H9PMC7070 Label Location

S&E XXXXXXX XXXX MODE L NO.: PART NAME: A/W NO.: SCA LE: UNIT : SHE ET OF DR AWN:REVIEWED: A PPROVED: RE VDES CRIPTIONSIGN DATE 1 : 1 m m 1 1 1 : 1 m m 1 1 P20 40.13H05.XXX LB L REGULATORY (MC7070) M0VG00 Benny Chen 11/03/2005 1. MATERIAL: MATERIAL: 0.127mm Velvet Lexan + 3M467 2. COLOR: BACKGROUND----SYMBOL BLACK 01 LETTERS-----------WHITE 3. ADHESIVE: S PEC REFE R TO E S- 811- R06 , S ONY 30 3 OR TOY O DF2700M R OR EQUIV 4. FINISH: P RINT FRONT SIDE 5. PR INT TOLERANCE OF DIM ENSION: +0. 3mm /-0 .3mm 6. PR INTER TYPE: THERM AL TRANSFER L ABE L P RINTE R (W EB ER 80 OR FARGO PRODIGY), SPEC R EFER TO ED -715-F09 7. FA CTORY INDEN TIFICATIO N OF CSA MUST BE PRINTED SEE REGULATORY GUIDE FOR PATENT INFORMATION ICES/NMB-003 CLASS B FCC ID: H9PMC7070 21.3 mm 46.3 mm 24.6 mm I.T.E. E145483 LISTED

Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16 Page 17 Page 18 Page 19 Page 20 Page 21 Page 22 Page 23 Page 24 Page 25

D3: DAE SN: 579

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM

8 Liquid Level Photo Tissue HSL2450MHz D=155mm(Date:2005/10/17) Tissue HSL2450MHz D=151mm(Date:2005/10/18) 9 Tissue MSL2450MHz D=150mm(Date:2005/10/19) 10 Date/Time: 2005/10/17 11:34:40 Test Laboratory: Advance Data Technology Right Head-Cheek-11b-Ch1-Mode 1 DUT: EDA-Enterprise Digital Assistant ; Type: MC7070 ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 Phantom: SAM 12 Medium parameters used: f = 2412 MHz; σ = 1.76 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 ; Liquid level: 155mm Phantom section: Right Section ; DUT test position : Cheek ; Modulation type: CCK Antenna type : PIFA Antenna ; Air temp. : 22.6 degrees ; Liquid temp. : 21.7 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Touch position - Low Channel 1/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.271 mW/g Touch position - Low Channel 1/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.2 V/m Peak SAR (extrapolated) = 0.486 W/kg SAR(1 g) = 0.252 mW/g; SAR(10 g) = 0.133 mW/g Maximum value of SAR (measured) = 0.277 mW/g 11 Date/Time: 2005/10/17 12:22:23 Test Laboratory: Advance Data Technology Right Head-Cheek-11b-Ch6-Mode 1 DUT: EDA-Enterprise Digital Assistant ; Type: MC7070 ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 Phantom: SAM 12 Medium parameters used: f = 2437 MHz; σ = 1.79 mho/m; ε r = 38.4; ρ = 1000 kg/m 3 ; Liquid level: 155mm Phantom section: Right Section ; DUT test position : Cheek ; Modulation type: CCK Antenna type : PIFA Antenna ; Air temp. : 22.6 degrees ; Liquid temp. : 21.7 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Touch position - Mid Channel 6/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.477 mW/g Touch position - Mid Channel 6/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 14.1 V/m Peak SAR (extrapolated) = 0.905 W/kg SAR(1 g) = 0.438 mW/g; SAR(10 g) = 0.230 mW/g 12 13 Date/Time: 2005/10/17 13:16:41 Test Laboratory: Advance Data Technology Right Head-Cheek-11b-Ch11-Mode 1 DUT: EDA-Enterprise Digital Assistant ; Type: MC7070 ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 Phantom: SAM 12 Medium parameters used: f = 2462 MHz; σ = 1.82 mho/m; ε r = 38.3; ρ = 1000 kg/m 3 ; Liquid level: 155mm Phantom section: Right Section ; DUT test position : Cheek ; Modulation type: CCK Antenna type : PIFA Antenna ; Air temp. : 22.6 degrees ; Liquid temp. : 21.7 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Touch position - High Channel 11/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.225 mW/g Touch position - High Channel 11/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.22 V/m Peak SAR (extrapolated) = 0.447 W/kg SAR(1 g) = 0.207 mW/g; SAR(10 g) = 0.109 mW/g Maximum value of SAR (measured) = 0.224 mW/g 14 Date/Time: 2005/10/17 13:45:57 Test Laboratory: Advance Data Technology Right Head-Tilt-11b-Ch1-Mode 2 DUT: EDA-Enterprise Digital Assistant ; Type: MC7070 ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz; Duty Cycle: 1:1 Medium: HSL2450 Medium parameters used: f = 2412 MHz; σ = 1.76 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 ; Liquid level: 155 mm Phantom section: Right Section ; DUT test position : Tilt ; Modulation type: CCK Antenna type : PIFA Antenna ; Air temp. : 22.6 degrees ; Liquid temp. : 21.7 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Tilt position - Low Channel 1/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.189 mW/g Tilt position - Low Channel 1/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.87 V/m Peak SAR (extrapolated) = 0.398 W/kg SAR(1 g) = 0.175 mW/g; SAR(10 g) = 0.090 mW/g Maximum value of SAR (measured) = 0.191 mW/g 15 Date/Time: 2005/10/17 14:11:11 Test Laboratory: Advance Data Technology Right Head-Tilt-11b-Ch6-Mode 2 DUT: EDA-Enterprise Digital Assistant ; Type: MC7070 ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz; Duty Cycle: 1:1 Medium: HSL2450 Medium parameters used: f = 2437 MHz; σ = 1.79 mho/m; ε r = 38.4; ρ = 1000 kg/m 3 ; Liquid level: 155 mm Phantom section: Right Section ; DUT test position : Tilt ; Modulation type: CCK Antenna type : PIFA Antenna ; Air temp. : 22.6 degrees ; Liquid temp. : 21.7 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.…

Text truncated - open the document above for the full version.

FCC ID: H9PMC7070 Report No.: SA941012L011Report Format Version 2.0.2 SAR TEST REPORT REPORT NO.: SA941012L01 MODEL NO.: MC7070 RECEIVED: Oct. 17, 2005 TESTED: Oct. 17 ~ Oct. 19, 2005 ISSUED: Oct. 27, 2005 APPLICANT: Symbol Technologies, Inc. ADDRESS: One Symbol Plaza, Holtsville, NY 11742, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 57 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: H9PMC7070 Report No.: SA941012L012Report Format Version 2.0.2 TABLE OF CONTENTS 1.CERTIFICATION........................................................................................................................ 3 2.GENERAL INFORMATION........................................................................................................ 4 2.1GENERAL DESCRIPTION OF EUT ................................................................................. 4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS................................................... 6 2.3GENERAL INOFRMATION OF THE SAR SYSTEM ......................................................... 7 2.4GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION...................... 10 3.DESCRIPTION OF SUPPORT UNITS............................................................................ 13 4.DESCRIPTION OF TEST POSITION ............................................................................. 14 4.1.DESCRIPTION OF ANTENNA LOCATION.................................................................... 14 4.2.DESCRIPTION OF TEST POSITION ............................................................................. 17 4.2.1.TOUCH/CHEEK TEST POSITION .................................................................................. 18 4.2.2.TILT TEST POSITION ..................................................................................................... 19 4.2.3.BODY-WORN CONFIGURATION ................................................................................... 19 4.3.DESCRIPTION OF ASSESSMENT POSITION .............................................................. 20 4.4.DESCRIPTION OF TEST MODE .................................................................................... 22 4.5.SUMMARY OF TEST RESULT ....................................................................................... 23 5.TEST RESULTS ...................................................................................................................... 26 5.1TEST PROCEDURES ..................................................................................................... 26 5.2MEASURED SAR RESULTS .......................................................................................... 28 5.3SAR LIMITS..................................................................................................................... 39 5.4RECIPES FOR TISSUE SIMULATING LIQUIDS............................................................ 40 5.5TEST EQUIPMENT FOR TISSUE PROPERTY ............................................................. 44 6.SYSTEM VALIDATION ............................................................................................................45 6.1TEST EQUIPMENT ......................................................................................................... 45 6.2TEST PROCEDURE ....................................................................................................... 46 6.3VALIDATION RESULTS .................................................................................................. 48 6.4SYSTEM VALIDATION UNCERTAINTIES ...................................................................... 49 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES ...................................................... 50 7.1PROBE CALIBRATION UNCERTAINTY......................................................................... 50 7.2ISOTROPY UNCERTAINTY............................................................................................ 51 7.3BOUNDARY EFFECT UNCERTAINTY ........................................................................... 51 7.4PROBE LINEARITY UNCERTAINTY .............................................................................. 52 7.5READOUT ELECTRONICS UNCERTAINTY .................................................................. 52 7.6RESPONSE TIME UNCERTAINTY................................................................................. 52 7.7INTEGRATION TIME UNCERTAINTY ............................................................................ 53 7.8PROBE POSITIONER MECHANICAL TOLERANCE ..................................................... 54 7.9PROBE POSITIONING ................................................................................................... 54 7.10PHANTOM UNCERTAINTY ............................................................................................ 55 7.11DASY4 UNCERTAINTY BUDGET .................................................................................. 56 8.INFORMATION ON THE TESTING LABORATORIES............................................................ 57 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: H9PMC7070 Report No.: SA941012L013Report Format Version 2.0.2 1. CERTIFICATION PRODUCT : EDA (Enterprise Digital Assistant) MODEL NO. : MC7070 BRAND NAME : Symbol …

Text truncated - open the document above for the full version.

FCC ID: H9PMC7070 Report No.: RF941012L011Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF941012L01 MODEL NO.: MC7070 RECEIVED: Sep. 02, 2005 TESTED: Sep. 02 ~ Oct. 17, 2005 ISSUED: Oct. 26, 2005 APPLICANT: Symbol Technologies, Inc. ADDRESS: One Symbol Plaza, Holtsville, NY 11742- 1300, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 128 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: H9PMC7070 Report No.: RF941012L012Report Format Version 2.0.4 Table of Contents 1.CERTIFICATION...............................................................................................................5 2.SUMMARY OF TEST RESULTS........................................................................................6 2.1 MEASUREMENT UNCERTAINTY............................................................................................6 3.GENERAL INFORMATION................................................................................................7 3.1GENERAL DESCRIPTION OF EUT...................................................................................7 3.2DESCRIPTION OF TEST MODES.....................................................................................9 3.2.1CONFIGURATION OF SYSTEM UNDER TEST...............................................................10 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL....................................12 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS...................................................17 3.4DESCRIPTION OF SUPPORT UNITS.............................................................................17 4.TEST TYPES AND RESULTS (FOR 802.11b & g 2412~2462MHz BAND).......................18 4.1CONDUCTED EMISSION MEASUREMENT....................................................................18 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT..................................................18 4.1.2TEST INSTRUMENTS.....................................................................................................18 4.1.3TEST PROCEDURES.....................................................................................................19 4.1.4DEVIATION FROM TEST STANDARD............................................................................19 4.1.5TEST SETUP..................................................................................................................20 4.1.6EUT OPERATING CONDITIONS.....................................................................................20 4.1.7TEST RESULTS..............................................................................................................21 4.2RADIATED EMISSION MEASUREMENT........................................................................33 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT......................................................33 4.2.2TEST INSTRUMENTS.....................................................................................................34 4.2.3TEST PROCEDURES.....................................................................................................35 4.2.4DEVIATION FROM TEST STANDARD............................................................................35 4.2.5TEST SETUP..................................................................................................................36 4.2.6EUT OPERATING CONDITIONS.....................................................................................36 4.2.7TEST RESULTS..............................................................................................................37 4.36dB BANDWIDTH MEASUREMENT...............................................................................46 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT..............................................................46 4.3.2TEST INSTRUMENTS.....................................................................................................46 4.3.3TEST PROCEDURE........................................................................................................47 4.3.4DEVIATION FROM TEST STANDARD............................................................................47 4.3.5TEST SETUP..................................................................................................................47 4.3.6EUT OPERATING CONDITIONS.....................................................................................47 4.3.7TEST RESULTS..............................................................................................................48 4.4MAXIMUM PEAK OUTPUT POWER...............................................................................54 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.................................54 4.4.2INSTRUMENTS...............................................................................................................54 4.4.1TEST PROCEDURES.....................................................................................................55 FCC ID: H9PMC7070 Report No.: RF941012L013Report Format Version 2.0.4 4.4.2DEVIATION FROM TEST STANDARD............................................................................55 4.4.3TEST SETUP..................................................................................................................55 4.4.4EUT OPERATING CONDITIONS.....................................................................................55 4.4.3TES…

Text truncated - open the document above for the full version.

FCC ID: H9PMC7070 Report No.: RF941012L01127Report Format Version 2.0.4 6. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST TEST MODE A FCC ID: H9PMC7070 Report No.: RF941012L01128Report Format Version 2.0.4 TEST MODE B FCC ID: H9PMC7070 Report No.: RF941012L01129Report Format Version 2.0.4 RADIATED EMISSION TEST TEST MODE A FCC ID: H9PMC7070 Report No.: RF941012L01130Report Format Version 2.0.4 TEST MODE B FCC ID: H9PMC7070 Report No.: RF941012L01131Report Format Version 2.0.4 TEST MODE C

FCC ID: H9PMC7070 Report No.: SA941012L0114Report Format Version 2.0.2 4. DESCRIPTION OF TEST POSITION 4.1. DESCRIPTION OF ANTENNA LOCATION BLUETOOTH ANTENNA: FCC ID: H9PMC7070 Report No.: SA941012L0115Report Format Version 2.0.2 WIRELESS LAN ANTENNA: MAIN ANTENNA FCC ID: H9PMC7070 Report No.: SA941012L0116Report Format Version 2.0.2 AUXILIARY ANTENNA 1 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA A1: TEST CONFIGURATION Right Head Cheek Position 2 Right Head Tilt Position 3 Left Head Cheek Position 4 Left Head Tilt Position 5 Body Worn Position The front of the EUT to the flat phantom distance 0 mm 6 EUT Photo Reference Point(Body) Reference Point(Head) Wireless Antenna BT Antenna 7
