H9PMC906RAMobile Data Terminal with two radio modules

Symbol Technologies Inc

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Aug 23, 2004
Application Purpose: Original Equipment
Date of Application: Aug 23, 2004
Equipment Note: Mobile Data Terminal with two radio modules
Frequency Range: 902.00000000 - 928.00000000
Company: Symbol Technologies Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 2 3 1 Battery Removal MC9000-G Quick Start Guide http://www.symbol.com/mc9000g See Product Reference Guide for more information Trigger Strap Lanyard Cable Adapter Module Magnetic Stripe Reader Stylus Stored in handle Battery Insertion Stylus Removal Snap-on Accessory Installation Charging Instructions Microphone Optional Headphone Jack Optional Display Data Slow Flash = Normal Charge = LED Indicator Location Solid Amber = Full ChargeFast Flash = Charging Error Power Data Power POST IN WORK AREAPOST IN WORK AREA Four Slot Spare Battery ChargerSingle Slot Serial CradleFour Slot Cradles Charge-Only Cradle and Ethernet Cradle Power Indicator LED Bar Scan Button Keypad

Users Manual

Warranty (A) Warranty Symbol Technologies (hereafter “Seller”) hardware Products are warranted against defects in workmanship and materials for a period of twelve (12) months from the date of shipment, unless otherwise provided by Seller in writing, provided the Product remains unmodified and is operated under normal and proper conditions. Warranty provisions and durations on software, integrated installed systems, Product modified or designed to meet specific customer specifications (“Custom Products”), remanufactured products, and reconditioned or upgraded products, shall be as provided in the applicable Product specification in effect at the time of purchase or in the accompanying software license. (B) Spare Parts Spare parts (i.e. parts, components, or subassemblies sold by Seller for use in the service and maintenance of Products) are warranted against defects in workmanship and materials for a period of thirty (30) days from the date of shipment. Spare parts may be new or originate from returned units under the conditions set forth in subsection D below. (C) Repair of Symbol-branded hardware For repairs on Symbol-branded hardware Products under this Agreement, including repairs covered by warranty, the repair services provided are warranted against defects in workmanship and materials on the repaired component of the Product for a period of thirty (30) days from the shipment date of the repaired Product, or until the end of the original warranty period, whichever is longer. (D) Product Service Products may be serviced or manufactured with parts, components, or subassemblies that originate from returned products and that have been tested as meeting applicable specifications for equivalent new material and Products. The sole obligation of Seller for defective hardware Products is limited to repair or replacement (at Seller’s option) on a “return to service depot” basis with prior Seller authorization. Customer is responsible for shipment to the Seller and assumes all costs and risks associated with this transportation; return shipment to the Customer will be at Seller's expense. Customer shall be responsible for return shipment charges for product returned where Seller determines there is no defect (“No Defect Found”), or for product returned that Seller determines is not eligible for warranty repair. No charge will be made to Buyer for replacement parts for warranty repairs. Seller is not responsible for any damage to or loss of any software programs, data or removable data storage media, or the restoration or reinstallation of any software programs or data other than the software, if any, installed by Seller during manufacture of the Product. (E) Original Warranty Period Except for the warranty applying solely to the repaired component arising from a repair service as provided in Section C above, the aforementioned provisions do not extend the original warranty period of any Product that had either been repaired or replaced by Seller. (F) Warranty Provisions The above warranty provisions shall not apply to any Product (i) which has been repaired, tampered with, altered or modified, except by Seller’s authorized service personnel; (ii) in which the defects or damage to the Product result from normal wear and tear, misuse, negligence, improper storage, water or other liquids, battery leakage, use of parts or accessories not approved or supplied by Symbol, or failure to perform operator handling and scheduled maintenance instructions supplied by Seller; (iii) which has been subjected to unusual physical or electrical stress, abuse, or accident, or forces or exposure beyond normal use within the specified operational and environmental parameters set forth in the applicable Product specification; nor shall the above warranty provisions apply to any expendable or consumable items, such as batteries, supplied with the Product. EXCEPT FOR THE WARRANTY OF TITLE AND THE EXPRESS WARRANTIES STATED ABOVE, SELLER DISCLAIMS ALL WARRANTIES ON PRODUCTS FURNISHED HEREUNDER INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED IN DURATION TO THE LIMITED WARRANTY PERIOD. SOME STATES OR COUNTRIES DO NOT ALLOW A LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS. IN SUCH STATES OR COUNTRIES, FOR SUCH PRODUCTS, SOME EXCLUSIONS OR LIMITATIONS OF THIS LIMITED WARRANTY MAY NOT APPLY. The stated express warranties are in lieu of all obligations or liabilities on the part of Seller for damages, including but not limited to, special, indirect or consequential damages arising out of or in connection with the use or performance of the Product or service. Seller’s liability for damages to Buyer or others resulting from the use of any Product or service furnished hereunder shall in no way exceed the purchase price of said Product or the fair market value of said service, except in instances of injury to persons or property. Service Information Before you use the unit, it must be configured to operate in your facility’s network and run your applications. If you have a problem running your unit or using your equipment, contact your facility’s Technical or Systems Support. If there is a problem with the equipment, they will contact the Symbol Support Center: For the latest version of this guide go to: http://www.symbol.com/manuals. United States1-800-653-5350 1-631-738-2400 Canada905-629-7226 72-68756-01 Revision A — June 2004 MC9060-G RFID With Windows ® Mobile 2003 Software for Pocket PCs Licensing, Patent and Regulatory Information © 2004 SYMBOL TECHNOLOGIES, INC. All rights reserved. Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application desc…

Text truncated - open the document above for the full version.

Cover Letter(s)

Regulatory Engineering MB/TCB/Confidentiality/H9PMC906RA 29 th July 2004 BABT 34 Molesey Road WALTON-ON-THAMES Surrey KT12 4RQ Confidentiality Request Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Symbol Technologies Inc. hereby requests confidential treatment of information accompanying as outlined below: • Schematics • Block Diagrams • Parts List (Bill of Materials) • Theory of Operation • Antenna Specifications The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Marco Belli Symbol Regulatory Compliance Direct Tel: +44 118 945 7313 Direct Fax: +44 118 945 7274 Email: [email protected] Regulatory Engineering • Web Site: http://ww.symbol.com

External Photos

ID Label/Location Info

FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER ID Label/Location Left Hand Side View

Internal Photos

FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the permission of TÜV Product Service LtdPage 1 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 1 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 2 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 2 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 3 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 3 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 4 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 4 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 5 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 5 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 6 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 6 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 7 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 7 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 8 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 8 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 9 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 9 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 10 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 10 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 11 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 11 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 12 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 12 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 13 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 13 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 14 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 14 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 15 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 15 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 16 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 16 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 17 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 17 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 18 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 18 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 19 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 19 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 20 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 20 FCC ID: H9PMC906RA SYMBOL TECHNOLOGIES INC MC906R (RFID AND 802.11B ENABLED) MOBILE COMPUTER 2004 Not to be reproduced without the Permission of TÜV Product Service LtdPage 21 of 21 PHOTOGRAPHS OF EQUIPMENT Internal View 21

RF Exposure Info

Symbol Technologies MC906R OS612330Page 1 of 2 RFID Terminal Maximum Permitted Exposure (MPE) Calculations: rfc/612330/26.07.2004 1. Reference Document: The Reference Document for the MPE limits has been taken as the OET Bulletin 65 (Edition 97-01). 2. Applicable Limits: ‘Appendix A’ details the relevant exposure criteria in the above FCC Document. For the purposes of calculations on the RFID System the limits have been used which are applicable to General Population/Uncontrolled Exposure. See values detailed below: The following limits are applicable: Over the 300 – 1500MHz rangef/1500 mW/sq.cm This equates to the following power density levels: RFID operating at frequency 902MHz:0.601mW/sq.cm RFID operating at 928MHz:0.612mW/sq.cm WLAN operating at 2.4 – 2.483GHz1mW/sq.cm applicable over the 1.5GHz–100GHz range Note: These limits are only applicable to operation of equipment in the far field. Calculations show that at RFID frequencies the far field is beyond a distance of 53mm, and at WLAN frequencies beyond a distance of 19mm. Therefore, the proposed operational distance of 23cm is well into the far field. 3. Calculation of power density The RF power density at an operational distance R from the antenna is calculated by the following expressionS = (P.G)/4. π.R 2 where S = power density in mW/sq.cm P = power output in mW G = antenna gain (numeric gain value) R = operating distance from antenna in cm Symbol Technologies MC906R OS612330Page 2 of 2 3.1 WLAN Transmitted power100mW Antenna gain1.26(+1dBi) RF power density at 23cm from the antenna S = (100 x 1.26)/4.π.23 2 mW/sq.cm = 0.0189 mW/sq.cm The FCC limit is 1.0 mW/sq.cm (Note: for information, the minimum operational distance for the FCC limit is at 3.1cm) 3.2 RFID Transmitted power1000mW Antenna gain4.0(+6dBi) RF power density at 23cm from the antenna S = (1000 x 4.0)/4.π.23 2 mW/sq.cm = 0.601 mW/sq.cm The FCC limit is 0.601 mW/sq.cm at 902MHz The FCC limit is 0.612 mW/sq.cm at 928MHz 3.3 Co-locational operation Maximum possible combined transmitted power:1100mW Assuming the worst case Specification Limit of 0. 601mW/sq.cm applies, as for the operational lowest frequency and antenna gain of 4. The minimum ‘safe’ distance is calculated as((P max x G)/4 π.S) ½ cm. where P = 1100 G = 4 S = 0.601 Therefore, to comply with the FCC limit, the minimum safe operational distance is calculated from the above as 24.1cm. 4. Summary of results The RFID is within the FCC limits for General Population/Uncontrolled Exposure at a minimum operating distance of 23cm. The WLAN is within the FCC limits for General Population/Uncontrolled Exposure to a minimum distance of 3.1cm. Consideration of a possible increase in maximum transmitted power due to simultaneous, or co-location, operation indicates that a minimum operational distance of 24.1 cm should be specified.

Test Report

REPORT ON Limited FCC CFR 47: Parts 15 B and C Testing in support of an Application for Grant of Equipment Authorisation of a Symbol MC906R (RFID and 802.11b enabled) Mobile Computer FCC ID: H9PMC906RA Report No OR612330/01 Issue 1 August 2004 BABT, Segensworth Road, Fareham, Hampshire, PO15 5RH, United Kingdom Tel: +44 (0)1329 443300 Website: www.tuvps.co.uk Report No OR612330/01 Issue 1Page 1 of 65 COMMERCIAL-IN-CONFIDENCE REPORT ONLimited FCC CFR 47: Part 15 C Testing in support of an Application for Grant of Equipment Authorisation of a Symbol MC906R (RFID and 802.11b enabled) Mobile Computer FCC ID: H9PMC906RA Report No OR612330/01 Issue 1 August 2004 PREPARED FORSymbol Technologies Inc One Symbol Plaza Holtsville NY 11742-1300 New York United States of America PREPARED BY J Plummer Technical Author APPROVED BY C GouldM J Hardy UKAS EMC SignatoryUKAS Radio Signatory DATED 13 th August 2004 DISTRIBUTIONSymbolCopy 1 BABTCopy 2 Copy No ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47: Parts 15 B and C. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineers; M P HardyA GuyS HartleyG Lawler FCC ID: H9PMC906RA Report No OR612330/01 Issue 1Page 2 of 65 COMMERCIAL-IN-CONFIDENCE CONTENTS SectionPage No 1REPORT SUMMARY 1.1Status..................................................................................................................................4 1.2Introduction .........................................................................................................................5 1.3Product information............................................................................................................6 1.4Brief Summary of Results (and Observations) ...................................................................8 1.5Opinions and Interpretations ..............................................................................................9 1.6Test Conditions (Configuration)..........................................................................................9 1.7Deviations from the Standard .............................................................................................9 1.8 Modification Record............................................................................................................9 1.9 Alternative Test Site ...........................................................................................................9 2TEST DETAILS – RLAN MODE 2.1 Measurement At The Band Edge .......................................................................................12 2.2 Maximum Peak Output Power (Radiated)..........................................................................17 2.3 Spurious Radiated Emissions ............................................................................................19 2TEST DETAILS – RFID MODE 2.4 Channel Occupancy/Separation .......................................................................................26 2.5 Channel Dwell Time ...........................................................................................................28 2.6 Number of Channels..........................................................................................................33 2.7 20dB Bandwidth .................................................................................................................35 2.8 Maximum Peak Output Power (Conducted).......................................................................39 2.9 Maximum Peak Output Power (Radiated)..........................................................................41 2.10 Spurious Conducted Emissions On Antenna Port .............................................................43 2.11 Spurious Radiated Emissions ............................................................................................47 2TEST DETAILS – RECEIVE EMISSIONS 2.12 Spurious Radiated Emissions ............................................................................................54 3TEST EQUIPMENT USED 3.1Table of Test Equipment Used ...........................................................................................57 3.2Measurement Uncertainty ..................................................................................................59 4EUT PHOTOGRAPH 4.1EUT Photograph .................................................................................................................61 FCC ID: H9PMC906RA Report No OR612330/01 Issue 1Page 3 of 65 COMMERCIAL-IN-CONFIDENCE CONTENTS SectionPage No 5ACCREDITATION, DISCLAIMERS AND COPYRIGHT 5.1Accreditation, Disclaimers and Copyright..................................................................................63 APPENDICES ATitchfield FCC Site Compliance Letter ......................................................................................65 FCC ID: H9PMC906RA Report No OR612330/01 Issue 1Page 4 of 65 COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY Limited FCC CFR 47: Parts 15 B and C Testing in support of an Application for Grant of Equipment Authorisation of a Symbol MC906R (RFID and 802.11b enabled) Mobile Computer FCC ID: H9PMC906RA Report No OR612330/01 Issue 1Page 5 of 65 COMMERCIAL-IN-CONFIDENCE 1.1STATUS EQUIPMENT UNDER TESTMC906R Mobile Computer OBJECTIVETo undertake measurements to determine the Equipment Under Test's (EUT's) compliance with the specification. NAME AND ADDRESS OF CLIENTSymbol Technologies Inc One Symbol Plaza Holtsville 11742-1300, New York United States of America TYPE NUMBERMC906R (RFID and 802.11b enabled) Mobile Computer PART NUMBERMC906R-GK0HBEER4US (Colour) SERIAL NUMBERALP78944 HARDWARE VERSIONRev 04 (To be released as Rev A) DECLARED VARIANTSMC906R-GK0JBEER4US (Mono) TEST SPECIFICATIONFCC CFR 47: Part 15, Subparts B …

Text truncated - open the document above for the full version.

Test Report

REPORT ON Simultaneous Transmitters: Limited FCC Testing in support of an Application for Grant of Equipment Authorisation of a Symbol MC906R (RFID and 802.11b enabled) Mobile Computer FCC ID: H9PMC906RA Report No OR612330/02 Issue 1 August 2004 BABT, Segensworth Road, Fareham, Hampshire, PO15 5RH, United Kingdom Tel: +44 (0)1329 443300 Website: www.tuvps.co.uk Report No OR612330/02 Issue 1Page 1 of 24 REPORT ONSimultaneous Transmitters: Limited FCC Testing in support of an Application for Grant of Equipment Authorisation of a Symbol MC906R (RFID and 802.11b enabled) Mobile Computer FCC ID: H9PMC906RA Report No OR612330/02 Issue 1 August 2004 PREPARED FORSymbol Technologies Inc One Symbol Plaza Holtsville NY 11742-1300 New York United States of America PREPARED BY Julie Plummer Technical Author APPROVED BY C Gould Chief Engineer, EMC Group DATED 05-08-04 DISTRIBUTIONSymbol TechnologiesCopy 1 BABTCopy 2 Copy No ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was c arried out on a sample equipment to demonstrate limited compliance with FCC CFR 47: Part 15. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineers; S HartleyA GuyG Lawler FCC ID: H9PMC906RA Report No OR612330/02 Issue 1Page 2 of 24 CONTENTS SectionPage No 1REPORT SUMMARY 1.1Status..................................................................................................................................4 1.2Introduction .........................................................................................................................5 1.3Product information ............................................................................................................6 1.4Brief Summary of Results (and Observations) ...................................................................8 1.5Opinions and Interpretations..............................................................................................9 1.6Test Conditions (Configuration)..........................................................................................9 1.7Deviations from the Standard .............................................................................................9 1.8 Modification Record............................................................................................................9 2TEST DETAILS 2.1 Spurious Radiated Emissions ............................................................................................11 3TEST EQUIPMENT USED 3.1Table of Test Equipment Used ...........................................................................................17 3.2Measurement Uncertainty ..................................................................................................18 4EUT PHOTOGRAPH 4.1EUT Photographs ...............................................................................................................20 5ACCREDITATION, DISCLAIMERS AND COPYRIGHT 5.1Accreditation, Disclaimers And Copyright.................................................................................22 APPENDICES ATitchfield FCC Site Compliance Letter.......................................................................................24 FCC ID: H9PMC906RA Report No OR612330/02 Issue 1Page 3 of 24 SECTION 1 REPORT SUMMARY Simultaneous Transmitters: Limited FCC Testing in support of an Application for Grant of Equipment Authorisation of a Symbol MC906R (RFID and 802.11b enabled) Mobile Computer FCC ID: H9PMC906RA Report No OR612330/02 Issue 1Page 4 of 24 1.1STATUS EQUIPMENT UNDER TESTMC906R Mobile Computer OBJECTIVETo undertake measurements to determine the Equipment Under Test's (EUT's) compliance with the specification. NAME AND ADDRESS OF CLIENTSymbol Technologies Inc One Symbol Plaza Holtsville 11742-1300, New York United States of America TYPE NUMBERMC906R (RFID and 802.11b enabled) Mobile Computer PART NUMBERMC906R-GK0HBEER4US SERIAL NUMBERALP78944 HARDWARE VERSIONRev 04 (To be released as Rev A) DECLARED VARIANTSMC906R-GK0JBEER4US (Mono) TEST SPECIFICATION FCC CFR 47: Part 15, Subpart C, ISSUE / DATE August 2002 NUMBER OF ITEMS TESTEDOne SECURITY CLASSIFICATION OF EUT Commercial In Confidence INCOMING RELEASEDeclaration of Build Status DATE15 th July 2004 DISPOSALHeld pending disposal REFERENCE NUMBERNot Applicable DATENot Applicable ORDER NUMBEREMEA 14241 DATE19 th May 2004 START OF TEST24 th June 2004 FINISH OF TEST24 th June 2004 RELATED DOCUMENTSANSI C63.4 2001. Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. FCC ID: H9PMC906RA Report No OR612330/02 Issue 1Page 5 of 24 1.2INTRODUCTION The information contained within this report is intended to show limited verification of compliance of the Symbol Technologies Inc MC906R (RFID and 802.11b enabled) Mobile Computer to the requirements of FCC Specification Parts 15 C for simultaneous transmission of co-located Transmitters. Testing was carried out in support of an application for Grant of Equipment Authorisation in the name of Symbol Technologies Inc. The purpose of this Test Report is to show compliance for simultaneous radio operation of RLAN and RFID. FCC ID: H9PMC906RA Report No OR612330/02 Issue 1Page 6 of 24 1.3PRODUCT INFORMATION 1.3.1Technical Description The unit supplied for testing is a Symbol MC906R Mobile Computer, which offers 2.4GHz 802.11b Wireless LAN and RFID connectivity with the following options: Pico Imager; Colour (touch) display; 64/64-memory option; Pocket PC; Audio; RFID EPC C1. The terminal utilises the Symbol 21-64436 Main Terminal Module with embedded RLAN Radio and the Alien ALR-9640-B RFID Module. FCC ID numbers are detailed in Section 1.3.4 “Declaration of Build Status”. 1.3.2Modes of Operation Modes of operation of the EUT during testing were as follows: Applicable testing was carried out with …

Text truncated - open the document above for the full version.

Test Setup Photos

2004 Not to be reproduced without the permission of TÜV Product Service Ltd Symbol Technologies I…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Qianlin Zhou(Regulatory Specialist)

[email protected]346-260-3543Fax: 631-627-7178

Technical Contact

Symbol Technologies Inc.Marco Belli

[email protected]+441189457313

One Symbol Plaza · New York, New York · United States

Non-Technical Contact

Symbol Technologies Inc.Marco Belli

[email protected]+441189457313

Test Firm

TUV SUD Product ServiceJensen Adams

[email protected]44-1489-558252Fax: 44-11489-558101

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission
1	15C	902 MHz - 928 MHz	1 W	373KL1D

Confidentiality

Long Term

Grant Notes

Power Output listed is Conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 24.1 cm from all persons. This transmitter must not be co-located or operated in conjunction with any antenna or transmitter not described in this application.
