H9PMC9090Portable Computer

Regulatory Information for Symbol MC9090 Rev 8.0 4thMarch 2005 1. Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Regulatory Information is available in French, Italian, German, Spanish (Spain), Portuguese, Japanese, Korean, Russian and simplified Chinese. Please see following website: http://www.symbol.com/services/manuals/ and look for your specific product. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user’s authority to operate the equipment. CAUTION: Only use Symbol approved and UL Listed accessories, battery packs and battery chargers. Do NOT attempt to charge damp/wet mobile computers or batteries. All components must be dry before connecting to an external power source. Radio Modules The device contain approved radio module(s). These module(s) are identified below. Symbol Modular RLAN radio card, Type:21-21160 Symbol MC9090 Bluetooth radio, Type: MC9090 Products equipped with Bluetooth ® Wireless Technology This product contains Bluetooth Complimentary Subsystems: ƒ BT ID:Bxxxxx ƒ BT ID:Bxxxxx 2. Country Approvals Regulatory markings are applied to the device signifying the radio (s) are approved for use in the following countries: United States, Canada, Australia, Japan and Europe 1,2 . Please refer to the Symbol Declaration of Conformity (DoC) for details of other country markings. This is available at http://www2.symbol.com/doc/ . Note 1 : For 2.4GHz Products: Europe includes, Austria, Belgium, Czech Republic, Croatia, Cyprus, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovak Republic, Slovenia, Spain, Sweden, Switzerland and the United Kingdom. Note 2 : The use of 5GHz RLAN’s has varying restrictions of use; please refer to the Symbol Declaration of Conformity (DoC) for details. Operation of the device without regulatory approval is illegal. Regulatory Information for Symbol MC9090 Rev 8.0 4thMarch 2005 3. Health and Safety Recommendations Ergonomic Recommendations Caution: In order to avoid or minimize the potential risk of ergonomic injury follow the recommendations below. Consult with your local Health & Safety Manager to ensure that you are adhering to your company’s safety programs to prevent employee injury. • Reduce or eliminate repetitive motion • Maintain a natural position • Reduce or eliminate excessive force • Keep objects that are used frequently within easy reach • Perform tasks at correct heights • Reduce or eliminate vibration • Reduce or eliminate direct pressure • Provide adjustable workstations • Provide adequate clearance • Provide a suitable working environment • Improve work procedures. Vehicle Installation RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles (including safety systems). Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle. An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result. Position your device within easy reach. Be able to access your device without removing your eyes from the road. Note: Connection to an alert device that will cause a vehicle horn to sound or lights to flash, on receipt of a call on public roads, is not permitted. Safety on the Road Do not take notes or use the device while driving. Jotting down a “to do” list or flipping through your address book takes attention away from your primary responsibility, driving safely. When driving a car, driving is your first responsibility - Give full attention to driving. Check the laws and regulations on the use of wireless devices in the areas where you drive. Always obey them. Regulatory Information for Symbol MC9090 Rev 8.0 4thMarch 2005 Warni Warnings for Use of Wireless Devices Please observe all warning notices with regard to the usage of wireless devices. Potentially Hazardous Atmospheres You are reminded of the need to observe restrictions on the use of radio devices in fuel depots, chemical plants etc. and areas where the air contains chemicals or particles (such as grain, dust, or metal powders) and any other area where you would normally be advised to turn off your vehicle engine. Safety in Aircraft Switch off your wireless device whenever you are instructed to do so by airport or airline staff. If your device offers a ‘flight mode’ or similar feature, consult airline staff as to its use in flight. Pacemakers Pacemaker manufacturers recommended that a minimum of 15cm (6 inches) be maintained between a handheld wireless device and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with independent research and recommendations by Wireless Technology Research. Persons with Pacemakers: • Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned ON • Should not carry the device in a breast pocket • Should use the ear furthest from the pacemaker to minimise the potential for interference. • If you have any reason to suspect that interference is taking place, turn OFF your device Other Medical Devices Please consult your physician or the manufacturer of the medical device, to determine if the operation of your wireless product may interfere with the medical device. FCC / EU RF Exposure Guidelines Safety Information The device complies with Internationally recognised standards covering Specific Absorption Rate (SAR) related to human exposure to electromagnetic fields from radio de…

Text truncated - open the document above for the full version.

.$9 6TFS(VJEF P r e l i m i n a r y .$ 96TFS(V JE F  P r e l i m i n a r y 6TJOH #MVFUPPUI $POUFOUT P r e l i m i n a r y .$ 9*OUFH SB UP S(VJEF P r e l i m i n a r y 6TJOH#MVF UP PUI *OUSPEVDUJPO # MV FU PP UI F R VJ QQ F E EF W JD FT D BO D P NNVO JD B UF XJ UI PV U XJS FT V T JO H GS FR V FO DZ  IP QQ JO H T QS FB E T QF D US VN :')4 4  3' U P US BO T NJU BO E  SF DF JW F E BU B JO U IF   ()[ *O EV T US Z4 D JF O UJG JD B OE . FE JD BM :* 4. C B OE :      # MV F UP PU I XJS FM FT T UF D IO PM PH Z JT T Q FD JG JD BM MZ EF T JH OF E GP S TI P SU S BO H F:  G F FU   NFU F ST D P NNVO JD B UJP O T BO E MP XQ P XFS D PO T VNQ UJ PO  .PCJMFDPNQVUFSTXJUI#MVFUPPUIDBQBCJMJUJFTDBOFYDIBOHFJOGPSNBUJPO:FH GJMFT BQQPJOUNFOUTBOEUBTLT XJUIPUIFS#MVFUPPUI FOBCMFEEFWJDFTTVDIBTQIPOFT QSJOUFST BDDFTTQPJOUTBOEPUIFSNPCJMFDPNQVUFST*OBEEJUJPO BEJBMVQNPEFNDPOOFDUJPODBOC F  DSFBUFECFUXFFOUIF#MVFUPPUINPCJMFDPNQVUFSBOEB#MVFUPPUIFOBCMFEQIPOF5IF#MVFUPPUIQIPOFDBOUIFOCFVTFEBTBNPEFN 4ZNCPMNPCJMFDPNQVUFSTXJUI#MVFUPPUIUFDIOPMPHZVTFUIF4UPOF4USFFU#MVFUPPUITUBDL5PQSPHSBN#MVFUPPUIXJUIJOUIFNPCJMF DPNQVUFSSFGFSUPUIF.JDSPTPGU&NCFEEFE7JTVBM$ IFMQ 5VSOJOHUIF#MVFUPPUI3BEJP.PEF0OBOE0GG 5VS OP GG U I F# MV FU PP U ISB E JP U PT BW F Q P XF SPS JGF OU FS JO H B O B SF B X JUI SB EJ PS FT US JD UJP O T:F H  B O BJS Q MB OF  8 IF OU IF SB EJ PJTPGG UIF NPCJMFDPNQVUFSDBOOPUCFTFFOPSDPOOFDUFEUPCZPUIFS#MVFUPPUIEFWJDFT5VSOPOUIF#MVFUPPUISBEJPUPFYDIBOHFJOGPSNBUJPO XJUIPUIFS#MVFUPPUIEFWJDFT:XJUIJOSBOHF $PNNVOJDBUFPOMZXJUI#MVFUPPUISBEJPTJODMPTFQSPYJNJUZ 5PBDIJFWFUIFCFTUCBUUFSZMJGFJONPCJMFDPNQVUFSTXJUINVMUJQMFSBEJPT UVSOPGGUIFSBEJPTUIBUBSFOPUCFJOH VTFE #MVFUPPUI1PXFS4UBUFT $PME#PPU 8IFOBDPMECPPUJTQFSGPSNFEPOUIFNPCJMFDPNQVUFS #MVFUPPUIUVSOTPGGBGUFSJOJUJBMJ[BUJPO:XIJDIUBLFTBGFXNPNFOUT *UJT OPSNBMUPTFFUIF#MVFUPPUIJ DP O BQ Q FB S BO E E JT BQ Q FB S  BT XF MM B T B XBJ UD V ST PS XI FO J OJ UJB MJ [B UJ PO Q SP D FF E T JO B MMN PE F T 8BSN# PPU 8IFOBXBSNCPPUJTQFSGPSNFEPOUIFNPCJMFDPNQVUFS #MVFUPPUISFUVSOTUPUIFMBTUTUBUFBGUFSJOJUJBMJ[BUJPO 4VT QFOE 8IFOUIFNPCJMFDPNQVUFSTVTQFOET #MVFUPPUIUVSOTPGG 8IFOUIFNPCJMFDPNQVUFSJTQMBDFEJOTVTQFOENPEF UIF#MVFUPPUISBEJPNPEFQPXFSTPGGBOEUIFQJDPOFU :#MVFUPPUIDPOOFDUJPO JTESPQQFE8IFOUIFNPCJMFDPNQVUFSSFTVNFT JUUBLFBQQSPYJNBUFMZTFDPOETGPS UIF#MVFUPPUISBEJPESJWFSUPSFJOJUJBMJ[FUIFSBEJP 3FT VNF 8IFOUIFNPCJMFDPNQVUFSSFTVNFT #MVFUPPUIUVSOTPOJGJUXBTPOQSJPSUPTVTQFOE "EBQUJWF'SFRVFODZ)PQQJOH "EBQUJWF'SFRVFODZ)PQQJOH:"') JTBNFUIPEPGBWPJEJOHGJYFEGSFRVFODZJOUFSGFSFST"')DBOCFVTFEXJUI#MVFUPPUIWPJDF"MM EF W JD FT J O UI F QJ DP OF U :# MV F UP PU I OF U XPS L NV TU C F "') DB Q BC MF J OP S EF S GP S "' )U P XPS L 5 IF S F JT OP "' )XI F O DP OO F DU JO H BO E  EJ TD P WF SJ OH EF W JDF T "W PJE NBL JO H # MV F UP PU I D PO O FD U JPO T B O EE JT DP WF S JFT EV SJ OH DS JU JDB M    CD PNNV O JD BU JP OT "')GP S# MV FU P PUI DBOCFCSPLFOEPXOJOUPGPVSNBJOTFDUJPOT t$IBOOFM$MBTTJGJDBUJPO"NFUIPEPGEFUFDUJOHBOJOUFSGFSFODFPOBDIBOOFMCZ DIBOOFMCBTJT PSQSFEFGJOFEDIBOOFMNBTL t-JOL.BOBHFNFOU$PPSEJOBUFTBOEEJTUSJCVUFTUIF"')JOGPSNBUJPOUPUIFSFTUPGUIF#MVFUPPUIOFUXPSL P r e l i m i n a r y .$ 9*OUFH SB UP S(VJEF t)PQ4FRVFODF.PEJGJDBUJPO"WPJETUIFJOUFSGFSFODFCZTFMFDUJWFMZSFEVDJOHUIFOVNCFSPGIPQQJOHDIBOOFMT t$IBOOFM.BJOUFOBODF"NFUIPEGPSQFSJPEJDBMMZSFFWBMVBUJOHUIFDIBOOFMT 8IFO"')JTFOBCMFE UIF#MVFUPPUISBEJPiIPQTBSPVOEw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r e l i m i n a r y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r e l i m i n a r y .$ 9*OUFH SB UP S(VJEF 5BQ /FYU 5IFNPCJMFDPNQVUFSTFBSDIFTGPSPUIFS#MVFUPPUIEFWJDFTJOUIFBSFB5IF4 FM F DU 3F NP UF %F WJ DFXJOEPX BQQFBST ' JHVSF  4FMFDU3FN PUF %FWJDF8JOEPX "MMEJTDPWFSFE#…

Text truncated - open the document above for the full version.

Wireless Applications Contents MC909X Integrator Guide4-2 Wireless Applications4-3 Introduction Wireless LANs allow mobile computers to communicate wirelessly and to send captured data to a host device in real time. Before a mobile computer can be used on a Spectrum24 WLAN, the facility must be set up with the required hardware to run the wireless LAN and the mobile computer must be properly configured. Refer to the documentation that came with the Access Points (APs) for instructions on setting up the hardware. To configure the mobile computer, a set of wireless applications provide the user with the tools to configure and test the wireless radio embedded the mobile computer. The following wireless applications are available on the task tray from the Wireless Application menu: •Wireless Status •Wireless Diagnostics •Find WLANs •Manage Profiles •Options •Log On/Off. Tap the Signal Strength icon to display the Wireless Application menu. Figure 4-1. Wireless Applications Menu Signal Strength Icon The Signal Strength icon in the task tray indicates the mobile computer’s wireless signal strength as follows: Table 4-1. Wireless Applications Icons, Signal Strength Descriptions IconStatusAction Excellent signal strengthWireless LAN network is ready to use. Very good signal strengthWireless LAN network is ready to use. Good signal strengthWireless LAN network is ready to use. Fair signal strengthWireless LAN network is ready to use. Notify the network administrator that the signal strength is only “Fair”. Poor signal strengthWireless LAN network is ready to use. Performance may not be optimum. Notify the network administrator that the signal strength is “Poor”. Out-of-network range (not associated)No wireless LAN network connection. Notify the network administrator. No wireless LAN network card detected.No wireless LAN network card detected. Notify the network administrator. Signal Strength Icon MC909X Integrator Guide4-4 Find WLANs Application Use the Find WLANs application to discover available networks in the vicinity of the user and mobile computer. To open the Find WLANs application, tap the Signal Strength icon - Find WLANs. The Find WLANs window displays. Figure 4-2. Find WLAN Window Find WLAN display is limited to 32 items (ESSIDs or MAC addresses). A combination of up to 32 ESSIDs/APs may be displayed. Valid ESSIDs that were not displayed in the Find WLAN Window may be entered manually. See Figure 4-3 on page 4-5. The Find WLANs list displays: •WLAN Networks - Available wireless networks with an icon that indicates signal strength and encryption type. The signal strength and encryption icon is described in tables Table 4-2 and Table 4-3. •Network Type - Type of network. •Channel - Channel that the AP is transmitting on. •Signal Strength - Displays the signal strength of the signal from the AP. Table 4-2. Signal Strength Icon IconDescription Excellent signal Very good signal Good signal Fair signal Poor signal Out of range or no signal Table 4-3. Encryption Icon IconDescription No encryption WLAN is an infrastructure network. WLAN is an Ad-Hoc network. WLAN access is encrypted and requires a password. Wireless Applications4-5 Tap-and-hold on a WLAN network to launch a context sensitive menu. The menu provides two options: Connect and Refresh. Select Refresh to refresh the WLAN list. Wireless profiles may also be created from one of the listed networks by selecting a network from the list and then selecting Connect. Selecting Connect displays the Profile Editor Wizard. The wizard is initialized to set the values for the selected network. After the profile editing is completed, it automatically connects to the newly edited profile. Profile Editor Wizard The Profile Editor Wizard displays when creating a new profile, or editing an existing profile. If editing a profile, the fields are populated with the current settings for that profile. If creating a new profile, the known information for that WLAN network are populated into the fields. Navigate through the wizard using the Next and Back buttons. Tap X to quit, a notification box appears asking the user to confirm the quit. Tap No to return to the wizard or tap Yes to quit and return to the Manage Profiles window. Profile ID The Profile ID dialog box is the first dialog box in the Profile Editor Wizard. Use the Profile ID dialog box to input the fields for the profile name and the ESSID. Figure 4-3. Profile ID Dialog Box Two profiles with the same user friendly name are valid but not recommended. Tap Next. The Operating Mode dialog box displays. Table 4-4. Profile ID Fields FieldDescription NamePopulated with the name and (WLAN) identifier of the network connection. Use the Name: field to enter a user friendly name of the mobile computer profile used to connect to either an AP or another networked computer. Example: The Public LAN. ESSIDPopulated with the name and (WLAN) identifier of the network connection, or use the ESSID field to enter the name and (WLAN) identifier of a WLAN network connection that was not listed on the Find WLANs window. The ESSID is the 802.11 extended service set identifier. The ESSID is 32-character (maximum) string identifying the WLAN. The ESSID assigned to the mobile computer is required to match the AP ESSID for the mobile computer to communicate with the AP. MC909X Integrator Guide4-6 Operating Mode Use the Operating Mode dialog box to select the operating mode (Infrastructure or Ad-Hoc) and the country location. Figure 4-4. Operating Mode Dialog Box Tap Next. If Ad-Hoc mode was selected the Ad-Hoc dialog box displays. If Infrastructure mode was selected the Authentication dialog box displays. See Authentication on page 4-7 for instruction on setting up authentication. Table 4-5. Operating Mode Fields FieldDescription Operating ModeInfrastructure: Select Infrastructure to enable the mobile computer to transmit and receive data with an AP. Infrastructure is the mobile computer default mode. Ad Hoc: Select Ad H…

Text truncated - open the document above for the full version.

One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com 5/25/2005 RE: Application for Approval of FCC ID: H9PMC9090 This application covers a FCC new application under the FCC ID listed below: • FCC ID: H9PMC9090 • Company: Symbol Technologies One Symbol Plaza Holtsville, NY 11742 • Type of Application: New Application • Product: MC9090 Mobile Computer • Reason for Application: Integration of an approved modular RLAN radio (FCC ID: H9P2121160) and a Bluetooth chip radio into a handheld computer. Please contact me via telephone (631-738-5373) or email ([email protected] ) if any questions arise or if additional information is required. Best Regards, David Heald EMC Engineer Worldwide Regulatory Department

One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com 5/25/2005 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Rd. Columbia, MD 21046 RE: Request for Confidentiality for Application H9PMC9090 Pursuant to CFR47 Section 0.459, Symbol Technologies would like to request that the following attachments remain confidential for the Application for Equipment Authorization for FCC ID: H9PMC9090: • Block Diagram • Operational Description • Parts List • Schematics These documents contain trade secrets and other proprietary and confidential information that is not generally available. Best Regards, David Heald EMC Engineer Worldwide Regulatory Department

One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com 22-Jun-05 Re: FCC ID H9PMC9090 Subject: Response to Correspondence Reference Number: 29073 (Confirmation Number EA382258) Diane, Each question you raised is followed by a response. 1) Please explain/clarify content and submit appropriate exhibits for both parts of this composite filing. LAN should be eqpt class DTS. Bluetooth can be added line item on DTS filing if it contains compliant test results per DTS requirements. Cover letter says this filing integrates FCC ID H9P2121160 with Bluetooth into a specific handheld. Orig. grant parameters FCC ID H9P2121160: Tc276756 10/1/2004_DTS_2412.00000 2462.00000_0.0869 Tc939313 10/1/2004_NII_5150.00000 5250.00000_0.04955 Tc939313 10/1/2004_NII_5250.00000 5350.00000_0.08375 Tc939313 10/1/2004_NII_5725.00000 5825.00000_0.07516 pending filings parameters: EA382258_5/25/2005_DSS_2402.00000 2480.00000_0.0025 EA382258_5/25/2005_DSS_2412.00000 2462.00000_0.1 EA382258_5/25/2005_DSS_5725.00000 5825.00000_0.08 EA574219_5/26/2005_NII_5150.00000 5250.00000_0.05 EA574219_5/26/2005_NII_5250.00000 5350.00000_0.085 Please explain changes needed in pending filings, and reasons for line items different from H9P2121160 if applicable. EA382258_5/25/2005_DSS_2402.00000 2480.00000_0.0025 – Please change this equipment class to DTS. The initial application under DSS was a mistake made during filing. EA382258_5/25/2005_DSS_2412.00000 2462.00000_0.1 – Please change this equipment class to DTS. The initial application under DSS was a mistake made during filing. EA574219_5/26/2005_NII_5150.00000 5250.00000_0.05 – This filing is correct and should remain as is. EA574219_5/26/2005_NII_5250.00000 5350.00000_0.085 – This filing is correct and should remain as is. EA382258_5/25/2005_DSS_5725.00000 5825.00000_0.08 – Please change this equipment class to NII and transfer to EA574219. The initial equipment class DSS was a mistake made during filing. Because of this mistake, this band was also filed under EA382258 instead of EA574219. One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com 2) User manual exhibit contains only regulatory info - per 2.1033(b) (3) please submit transmitter operating instructions. Draft transmitter operating instructions have been submitted. Please see the uploaded files “H9PMC9090 802_11 Op Instructions.pdf” and “H9PMC9090 Bluetooth Op Instructions.pdf” 3) Please explain why only 5800-band SAR system verification was done but not 5300-band, and/or revise if appropriate. SAR measurements were taken at 5260 MHz and are shown on page 20 and 25 of the RF Exposure Information SAR Test Report. Note 1 below the measurement stated that the test data reported reflects the worst-case measurement in the 5300 MHz band. Best Regards, David Heald

One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com 4-Aug-05 Re: FCC ID H9PMC9090 Subject: Response to Correspondence Reference Number: 29270, 29271, 29272, 29286, 29287, 29288 (Confirmation Numbers EA382258, EA574219) Diane, Each question you raised is followed by a response. Regarding reply to ea382258 corresp 29073 question 3, SAR report contains 5.3-GHz-band device test SAR data, but does not contain 5.3-GHz-band SAR system verification. Please explain and/or revise. A system verification report has been uploaded as an exhibit titled “H9PMC9090 RF Exposure2.pdf” Best Regards, David Heald

Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW

P/N: MC9090-SXXXXXXXXXXXWW MFD:XXXXXXX X SN BAR CODE LASERLICHT - NICHT IN DEN STRAHL BLICKEN. LASER KLASSE 2 LUMIÈRE LASER -NE PAS REGARDER DANS LE FAISCEAU APPAREIL À LASER DE CLASSE 2. CAUTION-LASER LIGHT. DO NOT STARE INTO BEAM. CLASS 2 LASER PRODUCT 630-680 nM, 1 mW BD ADDR: XXXXXXXXXXXXXXXXX (S)SN: XXXXXXXXXXXXX MADE IN XXXXXX SYMBOL TECH INC., HOLTSVILLE N.Y. 11742 SEE QRG FOR PATENT AND RADIO INFO 11-16 V 2A THIS DEVICE CONTAINS AN APPROVED RADIO MODULE 0168 N410 TYPE: MC9090 AND 21-21160 FCC: H9PMC9090 IC: 1549D-MC9090 XXXX P/N: MC9090-SXXXXXXXXXXXWW MFD:XXXXXXX X SN BAR CODE LASERLICHT - NICHT IN DEN STRAHL BLICKEN. LASER KLASSE 2 LUMIÈRE LASER -NE PAS REGARDER DANS LE FAISCEAU APPAREIL À LASER DE CLASSE 2. CAUTION-LASER LIGHT. DO NOT STARE INTO BEAM. CLASS 2 LASER PRODUCT 630-680 nM, 1 mW BD ADDR: XXXXXXXXXXXXXXXXX (S)SN: XXXXXXXXXXXXX MADE IN XXXXXX SYMBOL TECH INC., HOLTSVILLE N.Y. 11742 SEE QRG FOR PATENT AND RADIO INFO 11-16 V 2A THIS DEVICE CONTAINS AN APPROVED RADIO MODULE 0168 N410 TYPE: MC9090 AND 21-21160 FCC: H9PMC9090 IC: 1549D-MC9090 XXXX MC9090 LABEL DRAWING S E E N O T E 6 S E E N O T E 5 LASERLICHT - NICHT IN DEN STRAHL BLICKEN. LASER KLASSE 2 LUMIÈRE LASER -NE PAS REGARDER DANS LE FAISCEAU APPAREIL À LASER DE CLASSE 2. CAUTION-LASER LIGHT. DO NOT STARE INTO BEAM. CLASS 2 LASER PRODUCT 630-680 nM, 1 mW (S)S/N: XXXXXXXXXXXXXXXXXX P/N: MC9090-GXXXXXXXXWW MFD: XXXXXXX X S/N BAR CODE MADE IN XXXXXXX XXXX SEE QRG FOR PATENT AND RADIO INFO 11-16V /2A SYMBOL TECH INC., HOLTSVILLE, N.Y. TYPE: 21-21160 AND MC9090 THIS DEVICE CONTAINS AN APPROVED RADIO MODULE FCC ID: H9PMC9090 IC: 1549D-MC9090 DE V 0168 LASERLICHT - NICHT IN DEN STRAHL BLICKEN. LASER KLASSE 2 LUMIÈRE LASER -NE PAS REGARDER DANS LE FAISCEAU APPAREIL À LASER DE CLASSE 2. CAUTION-LASER LIGHT. DO NOT STARE INTO BEAM. CLASS 2 LASER PRODUCT 630-680 nM, 1 mW (S)S/N: XXXXXXXXXXXXXXXXXX P/N: MC9090-GXXXXXXXXWW MFD: XXXXXXX X S/N BAR CODE MADE IN XXXXXXX XXXX SEE QRG FOR PATENT AND RADIO INFO 11-16V /2A SYMBOL TECH INC., HOLTSVILLE, N.Y. TYPE: 21-21160 AND MC9090 THIS DEVICE CONTAINS AN APPROVED RADIO MODULE FCC ID: H9PMC9090 IC: 1549D-MC9090 DE V 0168 MC9090 LABEL DRAWING

Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW Symbol FCC ID: H9PMC9090 EUT Photographs © 2005 PCTEST Lab. Handheld Terminal Model: MC9090- KKOH9AFFA7WW

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: 050412255 Test Dates: April 15-28, 2005 EUT Type: Handheld Terminal FCC ID: H9PMC9090 Page 1 of 34 © 2005 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: Symbol Technologies, Inc. Dates of Tests: April 15-28, 2005 One Symbol Plaza MS B5 Test Report S/N: 0504120255 Holtsville, NY 11742-1300 Test Site: PCTEST Lab, Columbia MD FCC ID: H9PMC9090 APPLICANT: SYMBOL TECHNOLOGIES, INC. EUT Type: Handheld Terminal Tx/Rx Frequency: 2402 – 2480 MHz / 2412 – 2462 MHz (CCK/OFDM) 5180 – 5320 MHz / 5745 – 5825 MHz (OFDM) Max. RF Output Power: 19.30 / 19.62 dBm Peak Conducted (2.4 GHz CCK/OFDM) 18.95 dBm Peak Conducted (5.8 GHz OFDM) 18.94 dBm Peak Conducted (5.2 GHz OFDM) Max. SAR Measurement: 0.077 W/kg 802.11b Body SAR; 0.067 W/kg 802.11g Body SAR; 0.173 W/kg 802.11a (5300MHz) Body SAR; 0.281 W/kg 802.11a (5800MHz) Body SAR Trade Name/Model(s): MC9090-KKOH9AFFA7WW/-SKOH9AFA7WW/-GKOHBEGA7WW FCC Classification(s): Digital Transmission System (DTS) Unlicensed National Information Infrastructure (NII) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype [S/N: #ALP81783, ALP8163, ALP81775] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528 - 2003. The WLAN tested for this filing has previously been certified under Symbol FCC ID: H9P2121160. The unit comes in three model types. Each type has its own body worn a…

Text truncated - open the document above for the full version.
