H9PRD11320XR400 RFID Reader

XR400 RFID Reader Integrator Guide XR400 RFID Reader Integrator Guide 72-71773-01 Revision .2 April 2005 © 2005 by Symbol Technologies, Inc. All rights reserved. No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from Symbol. This includes electronic or mechanical means, such as photocopying, recording, or information storage and retrieval systems. The material in this manual is subject to change without notice. The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on a licensed basis. Symbol grants to the user a non-transferable and non-exclusive license to use each software or firmware program delivered hereunder (licensed program). Except as noted below, such license may not be assigned, sublicensed, or otherwise transferred by the user without prior written consent of Symbol. No right to copy a licensed program in whole or in part is granted, except as permitted under copyright law. The user shall not modify, merge, or incorporate any form or portion of a licensed program with other program material, create a derivative work from a licensed program, or use a licensed program in a network without written permission from Symbol. The user agrees to maintain Symbol’s copyright notice on the licensed programs delivered hereunder, and to include the same on any authorized copies it makes, in whole or in part. The user agrees not to decompile, disassemble, decode, or reverse engineer any licensed program delivered to the user or any portion thereof. Symbol reserves the right to make changes to any software or product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein. No license is granted, either expressly or by implication, estoppel, or otherwise under any Symbol Technologies, Inc., intellectual property rights. An implied license only exists for equipment, circuits, and subsystems contained in Symbol products. Symbol, Spectrum One, and Spectrum24 are registered trademarks of Symbol Technologies, Inc. Bluetooth is a registered trademark of Bluetooth SIG. Microsoft, Windows and ActiveSync are either registered trademarks or trademarks of Microsoft Corporation. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. Symbol Technologies, Inc. One Symbol Plaza Holtsville, New York 11742-1300 http://www.symbol.com Patents This product is covered by one or more of the patents listed on the website: www.symbol.com/patents Contents About This Guide Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Chapter Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Notational Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Related Documents and Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x Symbol Support Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x Chapter 1. Getting Started Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1- 3 RFID Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 RFID Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 The XR400 RFID Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 Multiple Connection Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 Flexible Read Point Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 Configuration and Upgrading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 Tag Management Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 Event Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 Device Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 LED Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 Chapter 2. Installation and Communication XR400 Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2- 3 XR400 Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Warranty (A) Warranty Symbol Technologies (hereafter “Seller”) hardware Products are warranted against defects in workmanship and materials for a period of twelve (12) months from the date of shipment, unless otherwise provided by Seller in writing, provided the Product remains unmodified and is operated under normal and proper conditions. Warranty provisions and durations on software, integrated installed systems, Product modified or designed to meet specific customer specifications (“Custom Products”), remanufactured products, and reconditioned or upgraded products, shall be as provided in the applicable Product specification in effect at the time of purchase or in the accompanying software license. (B) Spare Parts Spare parts (i.e. parts, components, or subassemblies sold by Seller for use in the service and maintenance of Products) are warranted against defects in workmanship and materials for a period of thirty (30) days from the date of shipment. Spare parts may be new or originate from returned units under the conditions set forth in subsection D below. (C) Repair of Symbol-branded hardware For repairs on Symbol-branded hardware Products under this Agreement, including repairs covered by warranty, the repair services provided are warranted against defects in workmanship and materials on the repaired component of the Product for a period of thirty (30) days from the shipment date of the repaired Product, or until the end of the original warranty period, whichever is longer. (D) Product Service Products may be serviced or manufactured with parts, components, or subassemblies that originate from returned products and that have been tested as meeting applicable specifications for equivalent new material and Products. The sole obligation of Seller for defective hardware Products is limited to repair or replacement (at Seller’s option) on a “return to service depot” basis with prior Seller authorization. Customer is responsible for shipment to the Seller and assumes all costs and risks associated with this transportation; return shipment to the Customer will be at Seller's expense. Customer shall be responsible for return shipment charges for product returned where Seller determines there is no defect (“No Defect Found”), or for product returned that Seller determines is not eligible for warranty repair. No charge will be made to Buyer for replacement parts for warranty repairs. Seller is not responsible for any damage to or loss of any software programs, data or removable data storage media, or the restoration or reinstallation of any software programs or data other than the software, if any, installed by Seller during manufacture of the Product. (E) Original Warranty Period Except for the warranty applying solely to the repaired component arising from a repair service as provided in Section C above, the aforementioned provisions do not extend the original warranty period of any Product that had either been repaired or replaced by Seller. (F) Warranty Provisions The above warranty provisions shall not apply to any Product (i) which has been repaired, tampered with, altered or modified, except by Seller’s authorized service personnel; (ii) in which the defects or damage to the Product result from normal wear and tear, misuse, negligence, improper storage, water or other liquids, battery leakage, use of parts or accessories not approved or supplied by Symbol, or failure to perform operator handling and scheduled maintenance instructions supplied by Seller; (iii) which has been subjected to unusual physical or electrical stress, abuse, or accident, or forces or exposure beyond normal use within the specified operational and environmental parameters set forth in the applicable Product specification; nor shall the above warranty provisions apply to any expendable or consumable items, such as batteries, supplied with the Product. EXCEPT FOR THE WARRANTY OF TITLE AND THE EXPRESS WARRANTIES STATED ABOVE, SELLER DISCLAIMS ALL WARRANTIES ON PRODUCTS FURNISHED HEREUNDER INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED IN DURATION TO THE LIMITED WARRANTY PERIOD. SOME STATES OR COUNTRIES DO NOT ALLOW A LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS. IN SUCH STATES OR COUNTRIES, FOR SUCH PRODUCTS, SOME EXCLUSIONS OR LIMITATIONS OF THIS LIMITED WARRANTY MAY NOT APPLY. The stated express warranties are in lieu of all obligations or liabilities on the part of Seller for damages, including but not limited to, special, indirect or consequential damages arising out of or in connection with the use or performance of the Product or service. Seller’s liability for damages to Buyer or others resulting from the use of any Product or service furnished hereunder shall in no way exceed the purchase price of said Product or the fair market value of said service, except in instances of injury to persons or property. Service Information Before using the unit, it must be configured to operate in the facility’s network and run your applications. If you have a problem running your unit or using your equipment, contact your facility’s Technical or Systems Support. If there is a problem with the equipment, they will contact the Symbol Support Center: For the latest version of this guide and other supporting documentation, go to: http://www.symbol.com/manuals United States1-800-653-5350 1-631-738-2400 Canada Inside Canada 1-866-416-8545 Outside Canada 905-629-7226 United Kingdom0800 328 2424 Asia/Pacific+65-6796-9600 Australia1-800-672-906 Austria/Österreich1-505-5794-0 Denmark/Danmark7020-1718Finland/Suomi9 5407 580 France01-40-96-52-21Germany/Deutschland6074-49020 Italy/Italia2-484441Mexico/México5-520-1835 Netherlands/Nederland315-271700Norway/Norge+47 2232 4375 South Africa11-8095311Spain/España 91 324 40 00 Inside Spain Sweden/…

Text truncated - open the document above for the full version.

One Symbol Plaza, Holtsville, NY 11742-1300 • 1.631.738.2400 • www.symbol.com American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: H9PRD11320 Confidentiality Request Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Symbol Technologies Inc. hereby requests confidential treatment of information accompanying as outlined below: • Schematics • Block Diagrams • Parts List (Bill of Materials) • Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Dennis Cortes Symbol Regulatory Compliance Direct Tel: (631) 738-5358 Email: [email protected] Regulatory Engineering • Web Site: http://ww.symbol.com

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 April 14, 2005 RE: FCC ID: HP9RD11320_ATCB002303 Attention: Brian J. Dettling / Gregory M. Snyder I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that 15.19(a)(3) clearly states that the 2-condition statement is to be placed on the device unless it meets the exceptions listed in 15.19(a)(5). Please note that this device is more than sufficiently large to contain the label and thus does not appear to meet the exception criterion listed in 15.19(a)(5). Please provide a label that clearly shows the 2-condition statement as required by 15.19(a)(3). 2. FYI – no action needed. The theory of operation would seem to indicate that the device can be selected to operate on non-US frequencies even though the operational description says “However, different Versions of modules with modified design, and/or component stuffing, may be required to address the various regulatory requirements.” Please note that the word ‘may’ does not mean ‘will’. Consequently the parts list, which is not normally required for part 15 devices, will be considered part of this application for upload to the FCC. 3. Please note that the manual “RD11320 User Manual - QRG.pdf” states a minimum separation distance of 20cm is to be maintained. However, the MPE report and the integrator manual states that a minimum distance of 22.5cm and 23cm respectively is needed. Please reconcile the User Manual –ORG to reflect the other documentation for rf exposure safe distance. 4. Please note that page 18 section 2.7.1.11 of the operational description states, “This is necessary for two reasons. First, to comply with FCC regulations when the RF connector is a "standard" connector.” The use of a standard connector for the antenna would mandate professional installation. Please note that pages 73 and 74 of the integrators guide says that the rf connectors are reverse TNC. However, page 24 of the integrators manual states that an “N- Male plug” is actually used to connect to the antenna itself. Please note that 15.203 intend that no connection or interconnection between the antenna terminals on the device to the final connection at the approved antenna can be a standard connection. If any connection between the antenna terminal of the device and the final antenna is a standard connection, then it must be professionally installed. Please clearly explain the system of cabling between the antenna terminal and the antenna itself. If any standard connection is made then please include the statement in the manuals that this device must be professionally installed. 5. Please provide a sample of the pseudo-random hopping table for this device. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Response to ATCB Comments FCC ID: HP9RD11320 1 Washington Laboratories, Ltd. 7560 LINDBERGH DRIVE GAITHERSBURG, MD 20879 (301) 417 – 0220 FAX # (301) 417 - 9069 April 18, 2005 Mr. Dennis Ward American Telecommunications Certification Body Inc. 6731 Whittier Ave McLean, VA 22101 RE: Comments of April 14, 2005 APPLICATION: Symbol Technologies, Inc. HP9RD11320 Dear Mr. Johnson: Below are the comments that you have provided regarding the application for certification referenced above. Our responses to those comments are in bold italic. Many responses refer you to additional exhibit(s) which has been uploaded to the application folder at the ATCB website. Thank you for your attention. Please feel free to contact us for any additional information that you may require. Regards, Gregory M. Snyder Chief EMC Engineer, Wireless/Telco Services Manager Brian J. Dettling Documentation Specialist WLL Project: 8608/9 1) Please note that 15.19(a)(3) clearly states that the 2-condition statement is to be placed on the device unless it meets the exceptions listed in 15.19(a)(5). Please note that this device is more than sufficiently large to contain the label and thus does not appear to meet the exception criterion listed in 15.19(a)(5). Please provide a label that clearly shows the 2-condition statement as required by 15.19(a)(3). R. From the client, “The remaining area on the label is reserved for other international marks that are specifically required to be on the product label. The FCC will accept and has accepted these statements to be in the Quick Reference Guide.” 2) FYI – no action needed. The theory of operation would seem to indicate that the device can be selected to operate on non-US frequencies even though the operational description says “However, different Versions of modules with modified design, and/or component stuffing, may be required to address the various regulatory requirements.” Please note that the word ‘may’ does not mean ‘will’. Response to ATCB Comments FCC ID: HP9RD11320 2 Consequently the parts list, which is not normally required for part 15 devices, will be considered part of this application for upload to the FCC. R. Noted. 3) Please note that the manual “RD11320 User Manual - QRG.pdf” states a minimum separation distance of 20cm is to be maintained. However, the MPE report and the integrator manual states that a minimum distance of 22.5cm and 23cm respectively is needed. Please reconcile the User Manual –ORG to reflect the other documentation for rf exposure safe distance. R. The QRF manual has been revised to reflect the greater distance. Please see exhibit “RD11320 User Manual - QRG revised.pdf” 4) Please note that page 18 section 2.7.1.11 of the operational description states, “This is necessary for two reasons. First, to comply with FCC regulations when the RF connector is a "standard" connector.” The use of a standard connector for the antenna would mandate professional installation. Please note that pages 73 and 74 of the integrators guide says that the rf connectors are reverse TNC. However, page 24 of the integrators manual states that an “NMale plug” is actually used to connect to the antenna itself. Please note that 15.203 intend that no connection or interconnection between the antenna terminals on the device to the final connection at the approved antenna can be a standard connection. If any connection between the antenna terminal of the device and the final antenna is a standard connection, then it must be professionally installed. Please clearly explain the system of cabling between the antenna terminal and the antenna itself. If any standard connection is made then please include the statement in the manuals that this device must be professionally installed. R. From the client, “The unit is designed so that it will only transmit when the presence of the correct antenna is detected. Our antenna must have a 10K ohm resistor across its leads to be recognized by the reader. So if anything else (other than the correct antenna with a 10K ohm sense resistor) is connected to the port on the reader, the reader will not transmit. This feature was incorporated into the design to alleviate the potential problem of the unit being improperly connected.” 5) Please provide a sample of the pseudo-random hopping table for this device. R. Please see exhibit “RD11320 Operational Description - Freq Hop Table.pdf”.

PROD FAM: XR400 DESCRIPTION: LBL:LCD, XR400 CTRY CODE:NA COUNTRY:N/A SN POOL: STANDARD LBL STOCK PN: 63-71337-01 SEE NOTE 2 LBL SCRIPT : 7133901X *SEE NOTE 1 CCG1: F406 NOTES: UNLESS OTHERWISE SPECIFIED 1. SCRIPT FILE TO BE CREATED BY MANUFACTURING. SCRIPT FILE MUST MATCH THIS DOCUMENT EXACTLY AND HAVE SAME REVISION. 2. LABEL STOCK P/N IS SUBJECT TO CHANGE. CHECK BOM FOR ACTUAL P ART NUMBER. 3. IN ALL CASES "XXX......" REPRESENTS VARIABLE FIELDS IN SCRIPT FILE. ACTUAL NUMBER OF CHARACTERS IN SCRIPT FILE MAY V ARY. 4. PART NUMBER MAY OR MAY NOT HAVE DASH BEFORE COUNTRY CODE. SEE BOM FOR ACTUAL MODEL DESCRIPTION. 5. "MFD:" REPRESENTS MANUFACTURE DAY, MONTH, YEAR AND REVISION OF PART NUMBER (IE: 12SEP03 X) 6. COUNTRY OF ORIGIN REQUIRED 7. ADD VARIABLE FIELD FOR PLANT CODE P P D: 81586 69-71339 - 01. 1 S/N: XXXXXXXXXXX S/N: BAR CODE P/N: RD11320-XXXXXXXXUS MADE IN XXXXXXXX XXXX MFD: XXXXXXX X FCC ID: H9PRD11320 IC: 1549D-RD11320 SEE QUICK REFERENCE GUIDE FOR RADIO AND PATENT INFORMATION LISTED ACCESSORY I.T .E. 9B97 ® 24 V 1.5A SYMBOL TECH INC., HOLTSVILLE, N.Y. 1 1742 SEE NOTES 4,6 AND 7 SEE NOTE 5 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003. CET APPAREIL NUMÉRIQUE DE LA CLASSE B EST CONFORME À LA NORME NMB-003 DU CANADA.

Document 8608-MPE, Rev. 0 FCC ID: H9PRD11320 RF Exposure Evaluation Washington Laboratories, Ltd April 2005 Maximum Permissible Exposure Evaluation for Symbol Technologies, Inc. RD11320 XR-400 RFID Device FCC ID: H9PRD11320 IC ID: 1549D-RD11320 April 11, 2005 WLL PROJECT #: 8608X This report may not be reproduced, except in full, without the prior written consent of Washington Laboratories, Ltd. RF Exposure Evaluation Document 8608-MPE, Rev. 0 FCC ID: H9PRD11320 RF Exposure Test Evaluation Washington Laboratories, Ltd April 2005 1 Maximum Permissible Exposure Evaluation for FCC ID: H9PRD11320 IC ID: 1549D-RD11320 1.0 Introduction This report has been prepared on behalf of Symbol Technologies, Inc. RD11320 XR-400 FHSS RFID Device to show compliance with the RF exposure requirements as defined in FCC §1.1307. 1.1 Requirements Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable and are defined as follows: ƒ Fixed Installations: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. ƒ Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR §2.1091. ƒ Portable Devices: a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC's Rules (47 CFR§2.1093). For this test report the Symbol Technologies, Inc. RD11320 XR-400 RFID device with 6dBi antenna is considered a fixed installation as it is used for the purpose of reading tags. The FCC also categorizes the use of the device as based upon the user’s awareness and ability to exercise control over his or her exposure. The two categories defined are Occupational/ Document 8608-MPE, Rev. 0 FCC ID: H9PRD11320 RF Exposure Test Evaluation Washington Laboratories, Ltd April 2005 2 Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows: ƒ Occupational/Controlled Exposure: In general, occupational/controlled exposure limits are applicable to situations in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure and can exercise control over their exposure. This exposure category is also applicable when the exposure is of a transient nature due to incidental passage through a location where the exposure levels may be higher than the general population/uncontrolled limits, but the exposed person is fully aware of the potential for exposure and can exercise control over his or her exposure by leaving the area or by some other appropriate means. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF safety program. If appropriate, warning signs and labels can also be used to establish such awareness by providing prominent information on the risk of potential exposure and instructions on methods to minimize such exposure risks. ƒ General Population/Uncontrolled Exposure: The general population / uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their employment may not be made fully aware of the potential for exposure or cannot exercise control over their exposure. Members of the general public would come under this category when exposure is not employment-related; for example, in the case of a wireless transmitter that exposes persons in its vicinity. Warning labels placed on low-power consumer devices such as cellular telephones are not considered sufficient to allow the device to be considered under the occupational/controlled category, and the general population/uncontrolled exposure limits apply to these devices. Since there are no warnings or training associated with this unit and it can be used by anyone, the Symbol Technologies, Inc. RD11320 XR-400 RFID device is evaluated to the General Population/Uncontrolled Exposure limits. 1.2 Radio Frequency Radiation Exposure Evaluation The highest RF output power of the unit was measured at 29.82dBm at 902.75 MHz. According to §1.1310 of the FCC rules, the power density limit for General Population/Uncontrolled Exposure at 902.75 MHz is 0.602mW/cm 2 . The MPE is calculated to show the required separation distance that must be maintained during installation to maintain compliance with the power density limit. The following formula was used to calculate the Power Density: 2 4R PG S π = Where: S = Power Density Document 8608-MPE, Rev. 0 FCC ID: H9PRD11320 RF Exposure Test Evaluation Washington Laboratories, Ltd April 2005 3 P = Output Power at the Antenna Terminals G = Gain of Transmit Antenna (linear gain) R = Distance from Transmitting Antenna To solve for the minimum mounting distance required: S PG R π4 = For this device, the calculation is as follows: S = 0.602 mW/cm 2 P = Output Power = 959.4 mW G = Worst Case Gain = 6dBi = INVLOG(6/10) = 4 602.04 )4()4.959( ×× × = π R = 22.5 cm (Based on continuous transmission) Based on the above calculation the Symbol Technolog…

Text truncated - open the document above for the full version.

Document 8608-9-01, Rev. 0 FCC ID: H9PRD11320 IC ID: 1549D-RD11320 FCC and IC Certification Test Report Washington Laboratories, Ltd April 2005 FCC & Industry Canada Certification Test Report for Symbol Technologies, Inc. FCC ID: H9PRD11320 IC ID: 1549D-RD11320 April 11, 2005 Prepared for: Symbol Technologies, Inc. 1 Symbol Plaza Holtsville, NY 11742 Prepared By: Washington Laboratories, Ltd. 7560 Lindbergh Drive Gaithersburg, Maryland 20879 FCC & IC Certification Test Report Document 8608-9-01, Rev. 0 FCC ID: H9PRD11320 IC ID: 1549D-RD11320 FCC and IC Certification Test Report Washington Laboratories, Ltd April 2005 FCC & Industry Canada Certification Test Report for the Symbol Technologies, Inc. RD11320-16114121US XR-400 FCC ID: H9PRD11320 IC ID: 1549D-RD11320 April 11, 2005 WLL JOB# 8608-9 Prepared by: Brian J. Dettling Documentation Specialist Reviewed by: Gregory M. Snyder Chief EMC Engineer Document 8608-9-01, Rev. 0 FCC ID: H9PRD11320 IC ID: 1549D-RD11320 FCC and IC Certification Test Report Washington Laboratories, Ltd April 2005 ii Abstract This report has been prepared on behalf of Symbol Technologies, Inc. to support the attached Application for Equipment Authorization. The test report and application are submitted for a Frequency Hopping Spread Spectrum Transmitter under Part 15.247 of the FCC Rules and Reg…

Text truncated - open the document above for the full version.
