H9PSPT18422.4GHz Pen Terminal w/ Internal FHSS LAN Radio Card

Symbol Technologies Inc

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Sep 17, 2001
Application Purpose: Original Equipment
Date of Application: Jun 14, 2001
Equipment Note: 2.4GHz Pen Terminal w/ Internal FHSS LAN Radio Card
Frequency Range: 2402.00000000 - 2480.00000000
Company: Symbol Technologies Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

SPT 1800 Series SPT 1800 Series © 2001 SYMBOL TECHNOLOGIES, INC. All rights reserved. Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein. No license is granted, either expressly or by implication, estoppel, or otherwise under any patent right or patent, covering or relating to any combination, system, apparatus, machine, material, method, or process in which Symbol products might be used. An implied license only exists for equipment, circuits, and subsystems contained in Symbol products. Symbol and the Symbol logo are registered trademarks of Symbol Technologies, Inc. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. Symbol Technologies, Inc. One Symbol Plaza Holtsville, N.Y. 11742-1300 http://www.symbol.com Patents This product is covered by one or more of the following U.S. and foreign Patents: U.S. Patent No. 4,460,120; 4,496,831; 4,593,186; 4,603,262; 4,607,156; 4,652,750; 4,673,805; 4,736,095; 4,758,717; 4,816,660; 4,845,350; 4,896,026; 4,897,532; 4,923,281; 4,933,538; 4,992,717; 5,015,833; 5,017,765; 5,021,641; 5,029,183; 5,047,617; 5,103,461; 5,113,445; 5,130,520; 5,140,144; 5,142,550; 5,149,950; 5,157,687; 5,168,148; 5,168,149; 5,180,904; 5,216,232; 5,229,591; 5,230,088; 5,235,167; 5,243,655; 5,247,162; 5,250,791; 5,250,792; 5,260,553; 5,262,627; 5,262,628; 5,266,787; 5,278,398; 5,280,162; 5,280,163; 5,280,164; 5,280,498; 5,304,786; 5,304,788; 5,306,900; 5,321,246; 5,324,924; 5,337,361; 5,367,151; 5,373,148; 5,378,882; 5,396,053; 5,396,055; 5,399,846; 5,408,081; 5,410,139; 5,410,140; 5,412,198; 5,418,812; 5,420,411; 5,436,440; 5,444,231; 5,449,891; 5,449,893; 5,468,949; 5,471,042; 5,478,998; 5,479,000; 5,479,002; 5,479,441; 5,504,322; 5,519,577; 5,528,621; 5,532,469; 5,543,610; 5,545,889; 5,552,592; 5,557,093; 5,578,810; 5,581,070; 5,589,679; 5,589,680; 5,608,202; 5,612,531; 5,619,028; 5,627,359; 5,637,852; 5,664,229; 5,668,803; 5,675,139; 5,693,929; 5,698,835; 5,705,800; 5,714,746; 5,723,851; 5,734,152; 5,734,153; 5,742,043; 5,745,794; 5,754,587; 5,762,516; 5,763,863; 5,767,500; 5,789,728; 5,789,731; 5,808,287; 5,811,785; 5,811,787; 5,815,811; 5,821,519; 5,821,520; 5,823,812; 5,828,050; 5,850,078; 5,861,615; 5,874,720; 5,875,415; 5,900,617; 5,902,989; 5,907,146; 5,912,450; 5,914,478; 5,917,173; 5,920,059; 5,923,025; 5,929,420; 5,945,658; 5,945,659; 5,946,194; 5,959,285; 6,002,918; 6,021,947; 6,036,098; 6,047,892; 6,050,491; 6,053,413; 6,056,200; 6,065,678; 6,067,297; 6,068,190; 6,082,621; 6,084,528; 6,088,482; 6,092,725; 6,101,483; 6,102,293; 6,104,620; 6,114,712; 6,115,678; 6,119,944; 6,123,265; 6,131,814; 6,138,180; 6,142,379; 6,172,478; 6,176,428; 6,178,426; 6,186,400; 6,188,681; D305,885; D341,584; D344,501; D359,483; D362,453; D363,700; D363,918; D370,478; D383,124; D391,250; D405,077; D406,581; D414,171; D414,172; D418,500; D419,548; D423,468; D424,035; D430,158; D430,159; D431,562; D436,104. Invention No. 55,358; 62,539; 69,060; 69,187 (Taiwan); No. 1,601,796; 1,907,875; 1,955,269 (Japan). European Patent 367,299; 414,281; 367,300; 367,298; UK 2,072,832; France 81/03938; Italy 1,138,713. rev. 04/01 1 Quick Reference Introduction Congratulations on your purchase of Symbol Technologies’ SPT 1800 Series Terminal! The unique combination of capabilities offered by this product makes it superior for use in a wide range of applications: •Personal Information Management software •RF communication via Symbol’s Spectrum24 ® wireless net- work (SPT 184X) or wide area network (SPT 183X) •pocket size •printing support •1-D and 2-D scanning capability. About This Guide This guide covers the procedures for the setup and use of the terminal. Specific topics covered include: • Parts of the SPT 1800 on page 2 • Installing the SIM Card (SPT 1834 Only) on page 5 •Installing the Battery on page 6 • Starting the SPT 1800 on page 8 • Using the SPT 1800 on page 9 •Writing with the Stylus on page 10 • Resetting the SPT 1800 on page 12 • Attaching the Handstrap on page 13 •Scanning 1-D Bar Codes on page 14 • Scanning PDF417 (2-D) Bar Codes on page 14 • Initiating a Network Connection on page 15 •Maintaining the SPT 1800 on page 16 • Troubleshooting on page 17. The SPT 1800 Product Reference Guide (p/n 72-51337-xx), available from Symbol or your Reseller, details the applications available on the SPT 1800. 2 SPT 1800 Series Parts of the SPT 1800 The following illustration indicates each part of the SPT 1800. Menu Icon Front View Application Buttons Scroll Button (Up and Down) Center Scan Button Right Scan Trigger LCD (Screen) Find Icon Contrast Button Laser Decode LED Scroll Button (Up and Down) Applications Icon Power Button Graffiti Input Area WAN Antenna (SPT 1833/34 only) Calculator Icon 3 Quick Reference Parts of the SPT 1800 (continued) Bottom View Top View Serial Port Scanner Exit Window Left Scan Trigger Left View 4 SPT 1800 Series Parts of the SPT 1800 (continued) Speaker Handstrap Connector Handstrap Connector WAN Antenna Back View Stylus Stylus Silo Handstrap Connectors Battery Latches Lithium-Ion Battery Reset Button Infrared Port SIM Socket Battery Compartment WAN Antenna Headset Connector Battery Cover 5 Quick Reference Getting Started Before you can use your SPT 1800, perform the basic setup procedures: •Install the SIM card (SPT 1834 only) •Install and charge the battery •Start the SPT 1800 •Initiate the network connection (SPT 183X/184X only). Installing the SIM Card (SPT 1834 Only) Open the latches on the battery cover and lift it away from the SPT1834. Metal Clip SIM Card Contact Area 1. Slide the metal clip to the left to release the SIM cardholder. 2. Lift the cardholder to an upright position. 3. Insert the card between the cardholder body and the metal clip; be sure the…

Text truncated - open the document above for the full version.

Attestation Statements

Sandy Mazzola Symbol Technologies, Inc. 1 Symbol Plaza Holtsville, N.Y. 11742 Voice : (516) 738-5373 Fax: (516) 738-3318 Letter of Confidentiality Request Dear Reviewer, Symbol Technologies (“Symbol”), requests that the Block Diagram, Schematics, and operational Description exhibits of the referenced application be withheld from routine availability for public inspection pursuant to Section 0.459 of the Commissions Rules an Freedom of Information Act (“FOIA) Exemption 4, 5 U.S.C. 552 (b) (4). These exhibits consist of “trade secrets (or) commercial or financial information obtained from a person and privileged or confidential” 5 U.S.C. 552 (b) (4), and is therefore entitled to protection from disclosure under FOIA. The documents in question contain trade secrets: detailed technical descriptions, specifications and schematics for a product to be offered for sale. These materials provide particulars on the product design. This information would give Symbol’s competitors an unearned and unwarranted competitive advantage. The documents contain “commercial information” within the scope of FOIA exemption 4. This information is the product of Symbol’s investment of money, personnel, and other resources. The result of the investment is a fairly earned position in the marketplace. Premature release of the information threatens substantial and unwarranted harm to Symbol’s competitive position. For these reasons, Symbol has taken pains to keep this technical information confidential, and intends to continue doing so. Symbol customarily witholds this information from persons outside the employ of Symbol and certain of its suppliers and contractors, and even within these groups routinely limits access to persons having a particular need for the information. If the Commissions were to make these documents public, it would be giving away hard won fruits of Symbols labors without compensation. The filing fee that is required for this confidentiality request is included in the check that accompanies this application. If there are any questions about this request, please call me at the number above. Thank you for your attention. Respectfully submitted, Sandy Mazzola

Cover Letter(s)

June 13, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SYMBOL TECHNOLOGIES INC. FCC ID: H9PSPT1842 Gentlemen: Attached herewith, on behalf of SYMBOL TECHNOLOGIES INC. is an application for Part 15.247 Certification of the following 2.4GHz Pen Terminal w/ FHSS Internal LAN Radio Card: FCC ID: H9PSPT1842 TRADE / MODEL(s): SYMBOL SPT1842 EUT TYPE: 2.4GHz Pen Terminal w/ FHSS Internal LAN Radio Card Tx / Rx Freq. Range: 2402.0 — 2480.0 MHz Max. RF Output Power: 0.331 W (25.2 dBm) Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Symbol Technologies Inc.

Cover Letter(s)

September 13, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Andy Leimer SUBJECT: Symbol Technologies, Inc. FCC ID: H9PSPT1842 731 Confirmation No.: EA101375 Correspondence Reference No.: 20208 Request for Tech. Info.: 8/10/01 Dear Andy: Transmitted herewith, on behalf of Symbol Technologies, Inc. is an amendment provided in response to the request for technical information dated August 10, 2001. 1. The device has an internal antenna and is the only one used with the SPT1842. The external antennas shown in the user’s manual (SPT1833/34) are for different devices. 2. Please see attached photos of the internal PCMCIA card. 3. The receiver bandwidth is the same as the transmitter bandwidth. 4. Please see attached revised operational description and SAR test data. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Symbol Technologies, Inc.

External Photos

© 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) © 2001 PCTEST Lab 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card NVLAP Lab Code: 100431-0 SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz)

ID Label/Location Info

(SEE NEXT PAGE) FCC ID Sample Label & Location LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase.

Internal Photos

Operational Description

FCC ID: H9PLA3021 Confidential Operational Description of FCC ID: H9PLA3021 Spectrum 24   2.4 MHz Wireless LAN PCMCIA Card FCC ID: H9PLA3021 Confidential TABLE OF CONTENTS 1.INTRODUCTION........................................................................................... 3 2.SYSTEM OVERVIEW ................................................................................... 3 2.1WLAN Adapter Architecture ........................................................................................................ 4 2.1.1Overview................................................................................................................................. 4 2.1.2Digital Section......................................................................................................................... 5 2.1.3Radio Section .......................................................................................................................... 6 3.HOPPING METHOD AND HOPPING PATTERNS....................................... 1 4.PERFORMANCE REQUIREMENTS AND OBJECTIVES............................ 4 4.1General ............................................................................................................................................ 4 4.2Transmit Performance ................................................................................................................... 5 4.3Receive Performance ...................................................................................................................... 5 4.4Timing Requirements..................................................................................................................... 5 4.5Interface Specification.................................................................................................................... 5 FCC ID: H9PLA3021 Confidential 1. Introduction The LA3021 PCMCIA PC Card can be used in hand held and notebook computers to provide a Wireless Local Area Network (WLAN) called Spectrum24. Spectrum24 is based on the IEEE 802.11 WLAN specification. The LA3021 PC Card is the latest in a family of Spectrum24 WLAN devices including: PCMCIA PC Card LA3020 (FCC ID:H9PLA3020), ISA Card LA2470 (FCC ID: H9PLA247O5AZK), hand held computers LRT 3840, PDT 3140 (FCC ID: H9P3840, H9P3 140), and several other devices. The LA3021 PC Card includes all of the functions including the digital circuits and software to implement the protocol for the communication with other devices on the network. The Spectrum24 WLAN operates from 2,4 to 2~5 GHz at 1 Mbps using binary GFSK modulation or at 2 Mbps using 4 level GFSK. The LA3021 PC Card device uses frequency hopping technology to provide robust communication, mitigating the effects of interference and multipath fading and providing for sharing of multiple wireless devices in the same area. 2. System Overview Host Access Point Access Point Access Point Station Station Station Station Station Wired Distribution Figure 1. Typical Spectrum24 WLAN Topology The Spectrum 24 network is a cellular infrastructure network using multiple access points (AP). Each AP controls a Basic Service Area (BSA) or cell consisting of a number of terminals that communicate entirely through the AP. Handoff is performed by the terminals and AP's when the terminal moves from one BSA to another within an Extended Service Area (ESA). Spectrum 24 uses a Frequency Hopped Spread Spectrum (FHSS) method of wireless communication. All AP's are asynchronous to each other in frequency hop timing as mandated by the FCC. A terminal entering the network must first scan for the hop frequency being used by all APs within range and select the strongest AP. FCC ID: H9PLA3021 Confidential The radio portion of the LA3021 PC Card provides a Received Signal Strength Indicator (RSSI) which facilitates initial AP selection, AP handoff, and antenna diversity. The data is processed through a data whitening algorithm prior to transmission to minimize long strings of zeroes or ones and to suppress the DC offset of the data. The LA3021 PC Card uses a physical modulation method called binary Gaussian Frequency Shift Keyed (GFSK) modulation to be compatible with the IEEE 802.11 standard in development. Wireless networks sharing common frequencies inherently produce co-channel interference. The amount of interference is minimized by using Carrier Sense Multiple Access with Collision Avoidance (CSMA/CA), random backoff in retries, and carrier sense deferrals. This protocol also allows ad hoc networks to share the same frequencies with infrastructure or other ad hoc networks in overlapping geographical areas. RTS/CTS is optionally used to provide carrier sense range extension for transmission of long packets. This minimize…

Text truncated - open the document above for the full version.

RF Exposure Info

© 2001 PCTEST Engineering Lab., Inc. 1. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Symbol Technologies Inc. Dates of Tests: June 07-08, 2001 1 Symbol Plaza Test Report S/N: SAR.210531339.H9P Holtsville, NY 11742-1300 Test Site: PCTEST Lab, Columbia MD U.S.A. Attn: Sandy Mazzola, Regulatory Engineer cc: Dean La Rosa, Senior Design Engineer FCC ID H9PSPT1842 APPLICANT SYMBOL TECHNOLOGIES INC. EUT Type: 2.4GHz Pen Terminal w/ 2Mb Frequency Hopping Spread Spectrum (FHSS) Internal LAN radio card (PCMCIA internal card FCC ID: H9PLA3021-500) Tx/Rx Frequency: 2402 — 2480 MHz Max. Radiated Power: 0.331 Watts (25.2dBm) Max. Peak SAR: 0.943 mW/g (1 g. avg) FHSS Body SAR; 1.630 mW/g (10 g. avg) FHSS Hand SAR Trade Name/Model(s): SYMBOL SPT 1842 FCC Classification: Part 15 Spread Spectrum Transmitter Application Type: Certification Tx Original Grant Date: Internal 2Mb FHSS LAN Radio PCMCIA Card Symbol FCC ID: H9PLA3021-500 March 14, 2000 Serial Number: n/a (pre-production) FCC Rule Part(s): § 2.1093; ET Docket 96.326 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992 (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 21053339.H9P SAR Measurement Report FCC Certification © 2001 PCTEST Lab i Table of Contents ATTACHMENT A - COVER LETTER ATTACHMENT B - ATTESTATION STATEMENT(S) ATTACHMENT C - SAR MEASUREMENT REPORT 1.1 SCOPE 1 2.1 INTRODUCTION / SAR DEFINITION 2 3.1 SAR MEASUREMENT SET-UP 3 4.1 E-FIELD PROBE SYSTEM 4 5.1 E-FIELD PROBE CALIBRATION PROCESS 5 5.3 DATA EXTRAPOLATION 6 6.1 PHANTOM, HOLDER & EQUIVALENT TISSUES 7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS 9 9.1 TEST POSITION OF THE PHONE 10 10.1 BODY-WORN CONFIGURATION 11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS 12 12.1 MEASUREMENT UNCERTAINTIES 13 13.1 TEST DATA SUMMARY 14-16 14.1 SAR TEST EQUIPMENT LIST 17 15.1 CONCLUSION 18 16.1 REFERENCES 19 ATTACHMENT D - FCC ID LABEL & LOCATION ATTACHMENT E - BLOCK DIAGRAM(S) ATTACHMENT F - SCHEMATIC DIAGRAM(S) ATTACHMENT G - OPERATIONAL DESCRIPTION ATTACHMENT H - EXTERNAL PHOTOGRAPHS ATTACHMENT I - INTERNAL PHOTOGRAPHS ATTACHMENT J - USER’S MANUAL ATTACHMENT K - PART 15.247 MEASUREMENT REPORT ATTACHMENT L - SAR TEST DATA ATTACHMENT M - SAR TEST SETUP PHOTOGRAPHS ATTACHMENT N - DIPOLE VALIDATION PLOTS ATTACHMENT O - PROBE CALIBRATION DATA ATTACHMENT P - COPY OF INTERNAL FHSS LAN RADIO CARD FCC GRANT Test Report S/N: SAR.971008738.FFM SAR Measurement Report Test Dates: FCC Part 22 Certification 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card © 2001 PCTEST Lab SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) 1 SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name: Symbol Technologies Inc. Address: 1 Symbol Plaza Holtsville, NY 11742-1300 Attention: Sandy Mazzola, Regulatory Engineer cc: Dean La Rosa, Senior Design Engineer • EUT Type: 2.4GHz Pen Terminal w/ 2Mb Frequency Hopping Spread Spectrum (FHSS) Int. LAN radio card (PCMCIA int. card FCC ID: H9PLA3021-500) • Trade Name: SYMBOL • FCC IDENTIFIER: H9PSPT1842 • Model: SPT 1842 • S/N: Pre-production • Tx/Rx Frequency: 2402 — 2480 MHz • Application Type: Certification • FCC Classification: Part 15 Spread Spectrum Transmitter • Method/System: Frequency Hopping Spread Spectrum System (FHSS) • FCC Rule Part(s): § 2.1093, Docket 96-326 • Max. Radiated Power: 0.331 Watts (25.2dBm) • Max. SAR Measurements: 0.943 mW/g (1 g. avg) FHSS Body SAR; 1.630 mW/g (10 g. avg) FHSS Hand SAR • Modulation: Spread Spectrum Transmitter (DSS) • Dates of Test(s): June 07-08, 2001 • Place of Test(s): PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.210531339.H9P • Original Grant Date: Internal 2Mb FHSS LAN Radio PCMCIA Card Symbol FCC ID: H9PLA3021-500 July 16, 1999 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.971008738.FFM SAR Measurement Report Test Dates: FCC Part 22 Certification 2.4GHz Pen Terminal w/Internal FHSS LAN Radio Card © 2001 PCTEST Lab SYMBOL FCC ID: H9PSPT1842 (Tx 2402-2480MHz) 2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electro…

Text truncated - open the document above for the full version.

RF Exposure Info

SYMBOL FCC ID:H9PSPT1842 -- 2.4GHz Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.85 mho/m ε r = 52.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.943 mW/g, SAR (10g): 0.382 mW/g SYMBOL Pen Terminal w/Integrated FHSS PCMCIA card (FCC ID:H9PLA3021-500) Model: SPT1842; CW (Continuous Transmit) Mode, Low Channel [2402MHz] Radiated Power = 331mW; Spacing = 2.0cm from flat phantom to rear panel of EUT, w/Holster Test Date -- 06/08/2001 SAR Tot [mW/g] 5.33E-2 1.60E-1 2.67E-1 3.73E-1 4.80E-1 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID:H9PSPT1842 -- 2.4GHz Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.85 mho/m ε r = 52.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.904 mW/g, SAR (10g): 0.390 mW/g SYMBOL Pen Terminal w/Integrated FHSS PCMCIA card (FCC ID:H9PLA3021-500) Model: SPT1842; CW (Continuous Transmit) Mode, Mid Channel [2441MHz] Radiated Power = 309mW; Spacing = 2.0cm from flat phantom to rear panel of EUT, w/Holster Test Date -- 06/08/2001 SAR Tot [mW/g] 5.95E-2 1.78E-1 2.97E-1 4.16E-1 5.35E-1 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID:H9PSPT1842 -- 2.4GHz Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.85 mho/m ε r = 52.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.685 mW/g, SAR (10g): 0.306 mW/g SYMBOL Pen Terminal w/Integrated FHSS PCMCIA card (FCC ID:H9PLA3021-500) Model: SPT1842; CW (Continuous Transmit) Mode, High Channel [2480MHz] Radiated Power = 281mW; Spacing = 2.0cm from flat phantom to rear panel of EUT, w/Holster Test Date -- 06/08/2001 SAR Tot [mW/g] 4.44E-2 1.33E-1 2.22E-1 3.11E-1 4.00E-1 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID:H9PSPT1842 -- 2.4GHz Back-Side Hand SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.85 mho/m ε r = 52.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 3.27 mW/g, SAR (10g): 1.41 mW/g SYMBOL Pen Terminal w/Integrated FHSS PCMCIA card (FCC ID:H9PLA3021-500) Model: SPT1842; CW (Continuous Transmit) Mode, Low Channel [2402MHz] Radiated Power = 331mW; Spacing = back of EUT (internal antenna side) touching flat phantom Test Date -- 06/07/2001 SAR Tot [mW/g] 1.64E-1 4.92E-1 8.20E-1 1.15E+0 1.48E+0 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID:H9PSPT1842 -- 2.4GHz Back-Side Hand SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.85 mho/m ε r = 52.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 3.31 mW/g, SAR (10g): 1.39 mW/g SYMBOL Pen Terminal w/Integrated FHSS PCMCIA card (FCC ID:H9PLA3021-500) Model: SPT1842; CW (Continuous Transmit) Mode, Mid Channel [2441MHz] Radiated Power = 309mW; Spacing = back of EUT (internal antenna side) touching flat phantom Test Date -- 06/07/2001 SAR Tot [mW/g] 1.54E-1 4.62E-1 7.70E-1 1.08E+0 1.39E+0 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID:H9PSPT1842 -- 2.4GHz Back-Side Hand SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.85 mho/m ε r = 52.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.76 mW/g, SAR (10g): 1.17 mW/g SYMBOL Pen Terminal w/Integrated FHSS PCMCIA card (FCC ID:H9PLA3021-500) Model: SPT1842; CW (Continuous Transmit) Mode, High Channel [2480MHz] Radiated Power = 281mW; Spacing = back of EUT (internal antenna side) touching flat phantom Test Date -- 06/07/2001 SAR Tot [mW/g] 1.20E-1 3.59E-1 5.98E-1 8.37E-1 1.08E+0 PCTEST Engineering Laboratory, Inc. SYMBOL FCC ID:H9PSPT1842 -- 2.4GHz Front-Side Hand SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 2450 MHz Muscle: σ = 2.85 mho/m ε r = 52.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 3.87 mW/g, SAR (10g): 1.63 mW/g SY…

Text truncated - open the document above for the full version.
