© 2012 Home Automation, Inc. www.homeauto.com Document: 113I00-2, Rev2.0 September 2012 HAI Omni-Bus 1-Channel Wall Remote Model 113A00-2 User’s Guide SPECIFICATIONS o For use with HAI Omni-Bus Output devices o Requires an HAI Omni-Bus RF Transceiver or HAI Omni-Bus Translator Interface on the Omni-Bus network o Frequency: 433.92MHz o Range: Up to 30m (98 feet) INSTALLATION Before installing the Wall Mount Remote Control, PROGRAM the Wall Mount Remote Control into the target receiving device. Programming is still possible after installation, but might require the co-operation of two people if the receiving device is situated far away from the Wall Mount Remote Control. The Wall Mount Remote Control does NOT require ANY wiring. It is a self-contained, battery-operated unit. FUNCTIONS To switch a device ON or OFF Press and release the button on the Wall Mount Remote Control. To DIM a light (when used with an Omni-Bus Dimmer unit) Press and hold the button on the Wall Mount Remote Control. To RESTORE to a previous light intensity when the light is switched OFF (Light Dimmer only) Simply press and hold the button on the Wall Mount Remote Control. Release the button as soon as the light turns on. OMNIBUS PROGRAMMING See the HAI OMNIBUS Software User Guide for more information on how to program the remote control into an Omni-Bus output device using the OMNIBUS Installation Software. MANUAL PROGRAMMING 1. Place the receiving device into the programming mode. This is normally done by pressing and holding the button on the receiving device until its LED starts flashing continuously. (See receiving device user guide for more information). 2. Press and hold the button on the Wall Mount Remote Control for exactly 10 seconds before releasing it. Check for a confirmation signal from the receiving device. (See receiving device user manual for more information). 3. Exit the programming mode on the receiving device. (See receiving device user guide for more information). OPERATIONAL MODES The Wall Mount Remote Control has two modes of operation: TOGGLE MODE (factory default) In this mode, the LED indicator on the Wall Mount Remote Control flashes 3 times when the button is pressed and released. Every time the button on the Wall Mount Remote Control is pressed and released, it instructs the receiving device to change its state. So if the receiving device had been ON, it would now switch OFF or vice versa. ON/OFF MODE In this mode, the LED indicator either flashes once or twice when the button is pressed and released. One flash indicates that the receiving device will be instructed to switch ON, regardless of its current state. Two flashes indicate that the receiving device will be instructed to switch OFF, regardless of its current state. CHANGING THE OPERATIONAL MODE Press and hold the channel button on the Wall Mount Remote Control until the indicator LED turns on without flashing. (this operation takes approximately 20 seconds). Release the button. Press and release the button three times rapidly while the LED is ON. If the Wall Mount Remote Control was in TOGGLE mode, it will change to the ON/OFF mode. If the Wall Mount Remote Control was in the ON/OFF mode, it will change to TOGGLE mode. DELETING A REMOTE CONTROL A Wall Mount Remote Control channel programmed into an Omni-Bus receiving device may be deleted from that device by following the procedure below: 1. Place the receiving device into the programming mode. This is normally done by pressing and holding the button on the receiving device until the receiving device LED starts flashing continuously. (See receiving device user guide for more information). 2. Press and hold the button on the Wall Mount Remote Control for exactly 14 seconds before releasing it. Check for a confirmation signal from the receiving device. (See receiving device user guide for more information). 3. Exit the programming mode on the receiving device. (See receiving device user guide for more information). REMOTE CONTROL BATTERY REPLACEMENT When the indicator LED does not function when the button is pressed, the battery needs to be replaced. The Wall Mount Remote Control uses one type 23A 12V battery. FCC ID: HHC-113A00-1 IC: 1516A-113A002 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. © 2012 Home Automation, Inc. www.homeauto.com Document: 113I00-4, Rev2.0 September 2012 HAI Omni-Bus 2-Channel Wall Remote Model 113A00-4 User’s Guide SPECIFICATIONS o 2 Channels o For use with HAI Omni-Bus Output devices o Requires an HAI Omni-Bus RF Transceiver or HAI Omni-Bus Translator Interface on the Omni-Bus network o Frequency: 433.92MHz o Range: Up to 30m (98 feet) INSTALLATION Before installing the Wall Mount Remote Control, PROGRAM the Wall Mount Remote Control into the target receiving device. Programming is still possible after installation, but might require the co-operation of two people if the receiving device is situated far away from the Wall Mount Remote Control. The Wall Mount Remote Control does NOT require ANY wiring. It is a self-contained, battery-operated unit. FUNCTIONS To switch a device ON or OFF Press and release the appropriate button on the Wall Mount Remote Control. To DIM a light (when used with an Omni-Bus Dimmer unit) Press and hold the appropriate button on the Wall Mount Remote Control. To RESTORE to a previous light intensity when the light is switched OFF (Light Dimmer only) Simply press and hold the button on the Wall Mount Remote Control. Release the button as soon as the light turns on. OMNIBUS PROGRAMMING See the HAI OMNIBUS Software User Guide for more information on how t…

Text truncated - open the document above for the full version.

® www.homeauto.com HAI 4330 Michoud Blvd. New Orleans, LA 70129 Phone: 800-229-7256 Fax: 504-253-2955 December 20, 2011 Attention: Application Examiner Re: Request for confidentiality Applicant: Home Automation, Inc. FCC ID: HHC-113A00-7 To whom it may concern, Permanent Confidentiality Request is hereby submitted by Home Automation, Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description  Parts list Rationale for request for confidentiality: Home Automation, Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Sincerely, Ron Gumina VP, Product Development Home Automation, Inc.

HAI Model: 113A00-2 FCC ID: HHC-113A00 IC: 1516A-113A00 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. HAI Model: 113A00-4 FCC ID: HHC-113A00 IC: 1516A-113A00 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. HAI Model: 113A00-7 FCC ID: HHC-113A00 IC: 1516A-113A00 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report for Home Automation Inc on the 113A00-7 Page 1 of 21 TEST REPORT Report Number: 100468650DAL-005b Project Number: G100468650 Report Issue Date: 7/30/12 Product Designation: 433.92 MHz 3 Button Wall Mount Remote Control Model: 113A00-7 Standards: 47 CFR Part 15, Subpart C (15.231 - Periodic operation in the band 40.66-40.70 MHz and above 70 MHz) RSS-210, Issue 8, 2010 Tested by: Client: Intertek Testing Services NA, Inc. 1809 10 th St. Plano TX 75074 Home Automation Inc. 4330 Michoud Blvd New Orleans, LA 70129 Report prepared by Report reviewed by William Cullen EMC Team Lead Jeremy O. Pickens EMC Manager Intertek Report Number: 100468650DAL-005b Issued: 07/30/2012 EMC Report for Home Automation Inc. on the 113A00-7 Page 2 of 21 TABLE OF CONTENTS (OPTIONAL) 1 Introduction and Conclusion .............................................................................................................. 3 2 Test Summary ...................................................................................................................................... 3 3 Description of Equipment Under Test ............................................................................................... 4 4 System setup including cable interconnection details, support equipment and simplified block diagram ........................................................................................................................................................ 5 5 Duty Cycle Determination (FCC 15A - 15.35(c)) ................................................................................ 6 6 Radiated emissions (E-field) for low power intentional radiators................................................. 10 7 Bandwidth Requirements (FCC 15C - 15.231(c))............................................................................. 16 8 Conducted emissions on AC power lines ....................................................................................... 18 9 Restrictions (FCC 15C - 15.231(a)) ................................................................................................... 18 10 Revision History ................................................................................................................................... 21 Intertek Report Number: 100468650DAL-005b Issued: 07/30/2012 EMC Report for Home Automation Inc on the 113A00-7 Page 3 of 21 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 3.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the requirements of the standard indicated. The results obtained in this test report pertain only to the item tested. 2 Test Summary Section Test full name Test date Result 3 Description of Equipment Under Test 4 System setup including cable interconnection details, support equipment and simplified block diagram 5 Duty Cycle Determination (FCC 15A - 15.35(c)) 07/11/12 Pass 6 Radiated emissions (E-field) for low power intentional radiators 05/16/12 Pass 7 Bandwidth Requirements (FCC 15C - 15.231(c)) 07/11/12 Pass 8 Conducted Emissions testing is not required as EUT is battery powered. N/A N/A 9 Restrictions (FCC 15C - 15.231(a)) 05/16/12 Pass 10 10 Revision History --- --- Intertek Report Number: 100468650DAL-005b Issued: 07/30/2012 EMC Report for Home Automation Inc on the 113A00-7 Page 4 of 21 3 Description of Equipment Under Test Equipment Under Test Description Manufacturer Model Number Serial Number 3 Button Wall Mount Remote Control Home Automation Inc 113A00-7 11002856 Receive Date: 4/25/12 Received Condition: Good Type: Production Description of Equipment Under Test (provided by client) EUT is a Low Power Wireless transceiver that transmits a 433.92 MHz signal to the Omni-Bus Control system and allows a home owner to adjust various applications around their home (i.e. lights, security system, etc.) Transmitter Overview: FCC Identifier HHC-113A00-7 IC Identifier 1516A-113A007 Frequency Range 433.92MHz Modulation ASK - OOK Antenna type (15.203) integrated Equipment Under Test Power Configuration Rated Voltage Rated Current Rated Frequency Number of Phases 12V Battery-powered N/A N/A N/A Operating modes of the EUT: No. Descriptions of EUT Exercising 1 For Radiated emissions testing, EUT was Transmitting continuously @ 433.9MHz. The EUT is a wall mounted device and therefore has only one orientation for testing. 2 For Bandwidth testing, EUT was Transmitting @ 433.9MHz every 10 seconds. Intertek Report Number: 100468650DAL-005b Issued: 07/30/2012 EMC Report for Home Automation Inc on the 113A00-7 Page 5 of 21 4 System setup including cable interconnection details…

Text truncated - open the document above for the full version.

Intertek Report Number: 100468650DAL-005b Issued: 07/30/2012 EMC Report for Home Automation Inc on the 113A00-7 Page 12 of 21 6.4 Setup Photographs: Test setup
