Portable 3G Wireless Router Quick Installation Guide 5 IN 1:Power bank,3G Hotspot, Mini AP, cloud storage, multimedia share Product pictures are only for reference and please consult the objectives Package Contents 1. 1 x product 2. 1 x Quick installation Guide 3. 1 x USB Charging Cable 4. 1 x connecters Overview Charging Instruction (mobile power) (1) Powering off for charging: Push the switch to gear C, then select the correct tip for your device and connect the charger lead of the digital product to the USB port. Then it will charge the intelligent mobile phone of iPhone, iPad and other smart phone. (2) Powering on for charging: Push the switch to gear R, then select the correct tip for your device and connect the charger lead of the 5.The 3G Dongle’s FCC ID:Q78-K5006-Z,Model:K5006-Z digital product to the USB port. Then it will charge the intelligent mobile phone of iPhone and other smartphone. The charge current is 500mA. (3)Charging the Power Bank: Connect the Micro USB tip to the Input port of the Power Bank, then plug the USB connector into an empty USB port on your Laptop/PC, or other USB power equipment. Check power method (1) Method to see the battery electric quantity: no matter what condition I6 is in, press the display button of electric quantity (beside the switch) and then observe the electric quantity according to the indication status of the electric quantity lights (if four lights are on, it shows that the battery is fully charged). (2) Method to see the battery with a full charge: charging is done under the condition of powering off, if the blue light is one, it indicates charging and if the blue light is off, it shows that the battery is fully charged. Instruction to the connection of the wireless network The computer is connected to the operating instructions of I6 (XP) (1) Choose “wireless network connection ”in the property option of the “network connection” on the desktop. Following the instruction of the picture, set the computer Internet protocol to be “Obtain an IP Address Automatically”. (2) Then, there will be an icon at the bottom right corner of the computer. Right click the mouse and choose “View Available Wireless Networks” in the prompt box. (3) In the pop-up network list, choose the required wireless network: MiFi_XX, click the “connection” button and input the password of WIFI. Factory default of WIFI no password (4) When the interface displays “Already Connected”, which indicates that the computer is successfully connected to this wireless network. Modification of the WIFI Name and Password. (1) Through WIFI, connect the Internet device wirelessly to I6, input 192.168.169.1 into the address bar of the device’s browser and enter the management interface. (2)Modify the WIFI Name and Password in the interface of wireless setting (3) After done the modification, click"Apply", then the network will restart, just connect it again, then the internet can be visited. The setting of all network model The setting of 3G wireless Modem (1) Push the switch to gear R. The default network mode is intelligent. Insert the wireless network card into the USB port. The device will connect to the Internet through automatic dial without any setting. (3)The 3G Dongle 's FCC ID:Q78-K5006-Z,Model:K5006-Z (2) When the status indicator for I6 is “Blue light is on continuously” (3G network) or purple light (2G network) is on continuously, it means the direct dial is successful. Through WIFI, connect the Internet device wirelessly to I6 and the Internet can be visited. Network setting for ADSL (1) Push the switch to gear R. Under the intelligent mode, connect the LAN port of modem to network port of I6 through the network cable. (2) Through WIFI, connect the Internet device wirelessly to I6, input 192.168.169.1 into the address bar of the device’s browser then enter the management interface which can be seen in the picture below. Click” ADSL”, input the ADSL account and password, then click”Apply”, then the network will restart, just connect it again, “Blue light is on continuously” then the internet can be visited. Network setting for the hotel (1) Push the switch to gear R. Under the intelligent mode, connect the network cable of the hotel or LAN port of upper-level router to network port of I6. (2) Through WIFI, connect the Internet device wirelessly to I6. When the status indicator for I6 is “Blue light is on continuously” it means the network connection is successful and the Internet can be visited. Network setting for static IP and DHCP (1) Push the switch to gear R. Connect LAN port of upper-level router to the WAN port of I6. (2) Through WIFI, connect the internet device wirelessly to I6, input 192.168.169.1 into the address bar of the browser then enter the setting interface of I6, click "Conn to Router", choose the mode of wireless router and input relevant parameter, then click “Apply”. After restart, just connect it again, then the internet can be visited. Multi-Media Sharing Multi-Media function support DLNA and Samba protocol, Can realize single or more multimedia file sharing. Remark: DLNA (Digital Living Network Alliance) (1) DLNA entertainment sharing IOS Platform: a. Insert U disk, Hard Drive or other storage device insert USB Port. b. Connect the wifi hotspot through WIFI. c. Download "Goodplayer" in App Store or other website d. Run Goodplayer, refresh device and find "ishare-MPRouter", then choose the corresponding multimedia documents to browsing, music broadcast and video broadcast. Remark: If can't automatically find DLNA server in Goodplayer, you can click to choose “UPnP/DLNA Client”, click to find “ishare-MPRouter” If some video format can't play or can't play smoothly, open the "Settings" ->"plug-in settings"-"Ipod" ,then choose "play by iPod plugin". Android Platform: a. Insert U disk, Hard Drive or other storage device insert USB Port. b. Connect the wifi hotspot through WIFI. c. Download "Goodplayer" in "Android Market" or other website d. Run Goodp…
Text truncated - open the document above for the full version.
775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 Shenzhen Yichen Technology Development Co., Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013/11/19 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Shenzhen Yichen Technology Development Co., Ltd.__ hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product: Portable 3G Wireless Router Trade Name: Model Name: JWA-2018R Serial Model: N/A FCC ID: HHOJWA-2018R We affirm that between SIEMIC and ___ Shenzhen Yichen Technology Development Co., Ltd. ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Zhou Yong Title: Manager Tel: +86-0755-33019922 Fax: +86-0755-86238830
SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenzhen Yichen Technology Development Co., Ltd. 2013-11-19 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: HHOJWA-2018R We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Client’s name / title : Zhou Yong / Manager Contact information / address : 5F, No.1, Honghualing 2nd Industrial Zone, Xili Town, Nanshan District,Shenzhen,China
APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6
FCC ID LABELING AND LOCATION FCC ID Label Portable 3G Wireless Router Model NO.: JWA-2018R Input Rating: DC 3.7V FCC ID: HHOJWA-2018R Shenzhen Yichen Technoloy Development Co.,LTD Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)
APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 WIFI ANT Photo 5
Wifi TX 802.11b Mode Frequency Maximum Peak Conducted Output Power(PK) Maximum Peak Conducted Output Power(AV) Maximum Peak Conducted Output Power (AV) Te s t Channe (MHz) (dBm) (dBm) mW CH01 2412 13.85 9.63 9.18 CH06 2437 13.44 9.46 8.83 CH11 2462 13.73 9.55 9.02 TX 802.11g Mode CH01 2412 12.71 8.16 6.55 CH06 2437 12.86 8.34 6.82 CH11 2462 12.08 8.62 7.28 TX 802.11n(20) Mode CH01 2412 10.32 7.57 5.71 CH06 2437 10.27 7.43 5.53 CH11 2462 10.41 7.66 5.83 TX 802.11n(40) Mode CH03 2422 9.91 7.43 5.53 CH06 2437 9.82 7.36 5.45 CH09 2452 9.77 7.29 5.36 Remark: The best case gain of the antenna is 1.0dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.26 RF EXPOSURE TEST FCC ID: HHOJWA-2018R SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] WIFI: Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [√f(GHz)] Result 802.11B CH01 9.18 5 2.412 2.85 CH06 8.83 5 2.437 2.76 CH11 9.02 5 2.462 2.83 802.11G CH01 6.55 5 2.412 2.03 CH06 6.82 5 2.437 2.13 CH11 7.28 5 2.462 2.28 802.11N(20) CH01 5.71 5 2.412 1.77 CH06 5.53 5 2.437 1.73 CH11 5.83 5 2.462 1.83 802.11N(40) CH03 5.53 5 2.422 1.72 CH06 5.45 5 2.437 1.70 CH09 5.36 5 2.452 1.68 . Simultaneous transmission SAR test exclusion considerations When standalone SAR test exclusion applies to an antenna that transmits simultaneously with other antennas, the standalone SAR must be estimated according to following to determine simultaneous transmission SAR test exclusion: (max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)]·[√f (GHz)/x] W/kg for test separation distances ≤ 50 mm; where x = 7.5 for 1-g SAR, and x = 18.75 for 10-g SAR. 0.4 W/kg for 1-g SAR and 1.0 W/kg for 10-g SAR, when the test separation distances is > 50 mm. 21 So( 9.18/5)* [√2.412/7.5]=0.38W/kg The 3G Dongle’s FCC ID:Q78-K5006-Z, the Max Sar Value is 1.18W/kg Totally Sar=0.38W/kg+1.18W/kg≤1.6W/kg Conclusion: no Simultaneously SAR is required
FCC RADIO TEST REPORT FCC ID: HHOJWA-2018R Product: Portable 3G Wireless Router Trade Name: Model Name: JWA-2018R Serial Model: N/A Report No.: NTEK- 2013NT1014403F Prepared for Shenzhen Yichen Technoloy Development Co.,Ltd. 5F,NO.1, Honghualing 2nd industrial Zone, Xili Town,Nanshan District,Shenzhen, China. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 70 Report No.: NTEK-2013NT1014403F TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Yichen Technoloy Development Co.,Ltd. Address ................................. : 5F,NO.1, Honghualing 2nd industrial Zone, Xili Town,Nanshan District,Shenzhen, China. Manufacture's Name ............ : Shenzhen Yichen Technoloy Development Co.,Ltd. Address ................................. : 5F,NO.1, Honghualing 2nd industrial Zone, Xili Town,Nanshan District,Shenzhen, China. Product description Product name ........................... : Portable 3G Wireless Router Model and/or type reference : JWA-2018R Serial Model .............................. : N/A Standards ............................. : FCC Part15.247 Test procedure ..............................ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 14 Oct. 2013 ~ 13 Nov. 2013 Date of Issue ........................................... : 13 Nov. 2013 Test Result ............................................... : Pass Testing Engineer : (Polo Cha) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 70 Report No.: NTEK-2013NT1014403F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 26 4 . POWER SPECTRAL DENSITY TEST 40 4.1 APPLIED PROCEDURES / LIMIT 40 4.1.1 TEST PROCEDURE 40 4.1.2 DEVIATION FROM STANDARD 40 4.1.3 TEST SETUP 40 4.1.4 EUT OPERATION CONDITIONS 40 4.1.5 TEST RESULTS 41 5 . BANDWIDTH TEST 49 5.1 APPLIED PROCEDURES / LIMIT 49 5.1.1 TEST PROCEDURE 49 Page 4 of 70 Report No.: NTEK-2013NT1014403F Table of Contents Page 5.1.2 EUT OPERATION CONDITIONS 49 5.1.3 TEST RESULTS 50 6 . PEAK OUTPUT POWER TEST 58 6.1 APPLIED PROCEDURES / LIMIT 58 6.1.1 TEST PROCEDURE 58 6.1.2 DEVIATION FROM STANDARD 58 6.1.3 TEST SETUP 58 6.1.4 EUT OPERATION CONDITIONS 58 6.1.5 TEST RESULTS 59 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 60 7.1 DEVIATION FROM STANDARD 60 7.2 TEST SETUP 60 7.3 EUT OPERATION CONDITIONS 60 7.4 TEST RESULTS 61 8 . ANTENNA REQUIREMENT 67 8.1 STANDARD REQUIREMENT 67 8.2 EUT ANTENNA 67 9 . EUT TEST PHOTO 68 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 70 Report No.: NTEK-2013NT1014403F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 70 Report No.: NTEK-2013NT1014403F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U,where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 70 Report No.: NTEK-2013NT1014403F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Portable 3G Wireless Router Trade Name Model Name JWA-2018R Serial Model N/A Model Difference N/A Product Description The EUT is a Portable 3G Wireless Route r. Operation Frequency: 802.11b/g/n(20MHz):2412~2462 MHz 802.11n(40MHz):2422~2452 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20/40MHz):150/144.44/130/1 17/115.56/104/86.67/78/52/6.5Mbps Number Of Channel 802.11b/g/n20MHz:11CH 802.11n40MHz:7CH Antenna Designation: Please see Note 3. Output Power(Conducted): 802.11b: 13.85 dBm (Max.) 802.11g: 12.86 dBm (Max.) …
