HHOJYL-AC120Dual Band Wireless USB Adapter

IEEE802.11a,IEEE80211n. IEEE802.11g,IEEE802.11b Introduction Thank you for purchasing the Wireless-LAN USB Adapter. Wireless-LAN USB3.0 Adapter allows you to connect notebook or desktop to any Wireless-LAN networks suitable for in your home or office environment. Spotlight 1). 2). Wireless security encryption easily at a push of WPS button Dual Band (2.4G : 300 Mbps ; 5G : 867Mbps) Product description The product is a high-speed USB3.0 WLAN adapter,supports 2.4G/5G.Complies with standards.Supports 64/128-bit WEP,WPA,WPA2 encryption methods and 802.1x security authentication standards. Additionally,this product supports WPS function,which can help you create a wireless connection with effortless security setup, prevent outside intrusion and protect your personal information from being exposed. Featuring high performance transmission rates,simple installation and adaptability,as well as strong security,this USB WLAN Adapter is a perfect solution for small office and home need. Product Specifications System Requirements Notebook or desktop PC with Pentium 1 GHz-compatible or higher Processor Windows XP/Vista/WIN7,MAC OS , Linux Available Hi-Speed USB 2.0or 3.0 port Standard Wireless Modes Interface Frequency Range Radio Data Rate Spread Spectrum Modulation Transmission Distance Receive Sensitivity@PE Transmit Power Antenna LED Indicator Data Security Environment . IEEE 802.11a、IEEE 802.11n、 IEEE 802.11g、IEEE 802.11b Ad-Hoc / Infrastructure mode USB 3.0 2.4GHz/5GHz 2.4G: 300Mbps 5G: 867Mbps DSSS BPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/64-QAM) Indoor up to 100m , outdoor up to 300m (it is limited in an environment) 11a : -68dBm@10% PER 11n : -70dBm@10% PER 11g : -70dBm@10% PER 11b: -85dBm@8% PER 1dBm Internal Antenna Status 64/128-bits WEP;WPA/WPA2 Operating Temperature: 0°C~40°C (32°F~104°F) Operating Humidity: 10%~90%RH (non-condensing) 79mmx26mmx10mm Dimensions Installation IMPORTANT:For proper operation,do not connect the Wireless- LAN USB Adapter to your computer before you install the software. If you do,wait for the Found New Hardware screen to display and click “Cancel”,otherwise, the installation process will likely be adversely affected. 1). Insert the included setup CD in the CD-ROM drive and start the Setup.exe program. 2). Insert the included setup CD in the CD-ROM drive and start the Setup.exe program. Click “NEXT” 3). The installer will automatically install the program.When done Select ”Yes,I want to restart my computer now” and click”Finish” to reboot your computer after the driver install successfully. Configuration Once the installation complete,you can configure the Wireless-Lan USB Adapter to connect to a wireless access point(AP). The wireless configuration utility will start automatically and you’ll also find a tray icon at the lower right corner in your Windows systems tray. 1Right-click the Wireless tray icon and select “Open Config Utility”). 2). “Refresh” to refresh the list of available wireless networks. To join a particular network that displays,select it and click “ Add to Profile.” The configuration utility will scan for wireless networks with in range.Click 3). If the wireless network use encryption,you need to input the correct encryption key.The configuration utility automatically suggests the correct authentication type (see the drop-down list),and you should not change the suggested value. NOTE For WPA/WPA2 networks, you need to select the correct encryption type,as well as(AES or TKIP). These settings depend on how the wireless network is set up .Only the owner of the wireless network can provide the required information. 4). see the following dialogue box If the wireless access point is connected successfully , you’ll 1 2 3 4 5 6 7 JCG JCG JCG 3 FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC RF warning statement: the device has been evaluated to meet general RF exposure requirement , The device can be used in portable exposure condition without restriction.

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 Shenzhen Yichen Technology Development Co., Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2014/2/21 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Shenzhen Yichen Technology Development Co., Ltd.__ hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： Dual Band Wireless USB Adapter Trade Name： Model Name： JYL-AC120 Serial Model： N/A FCC ID： HHOJYL-AC120 We affirm that between SIEMIC and ___ Shenzhen Yichen Technology Development Co., Ltd. ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Zhou Yong Title: Manager Tel: +86-0755-33019922 Fax: +86-0755-86238830

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenzhen Yichen Technology Development Co., Ltd. 2014/2/21 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: HHOJYL-AC120 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Client’s name / title : Zhou Yong / Manager Contact information / address : 5F, No.1, Honghualing 2nd Industrial Zone, Xili Town, Nanshan District,Shenzhen,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

FCC ID LABELING AND LOCATION FCC ID Label Dual Band Wireless USB Adapter Model NO.: JYL-AC120 Input Rating: DC 5V FCC ID: HHOJYL-AC120 Shenzhen Yichen Technoloy Development Co.,LTD Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Ant A Ant B Photo 3 Photo 4

FCC ID:HHOJYL-AC120 WIFI 2.4G Maximum output power. Antenna port Total Power Frequency (PK) (dBm) (AV) (dBm) (PK) (AV) Maxim um output power (AV) Te s t Channe (MHz) ANT A ANT BANT A ANT B dBm dBm mW TX 802.11b Mode CH01 2412 10.43 9.64 6.53 5.66 13.06 9.13 8.185 CH06 2437 10.75 9.73 6.74 5.86 13.28 9.33 8.570 CH11 2462 10.54 9.47 6.65 5.53 13.05 9.14 8.204 TX 802.11g Mode CH01 2412 10.45 9.75 5.64 4.85 13.12 8.27 6.714 CH06 2437 10.64 9.64 5.84 4.78 13.18 8.35 6.839 CH11 2462 10.76 9.75 5.56 4.35 13.29 8.01 6.324 TX 802.11n/20M Mode CH01 2412 8.65 7.43 5.64 4.33 11.09 8.04 6.368 CH06 2437 8.79 7.12 5.53 4.12 11.05 7.89 6.152 CH11 2462 8.33 7.06 5.53 4.05 10.75 7.86 6.109 TX 802.11n/40M Mode CH03 2422 10.54 9.42 6.84 5.08 13.03 9.06 8.054 CH06 2437 10.63 9.27 6.62 5.63 13.01 9.16 8.241 CH09 2452 10.87 9.64 6.48 5.38 13.31 8.98 7.907 RF EXPOSURE TEST FCC ID: HHOJYL-AC120 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID:HHOJYL-AC120 WIFI 5G Maximum output power. Antenna port Total Power Frequency (PK) (dBm) (AV) (dBm) (PK) (AV) Maxim um output power (AV) Te s t Channe (MHz) ANT A ANT BmW ANT B dBm dBm mW TX 802.11a Mode CH149 5745 9.76 8.73 4.52 3.46 12.29 7.03 5.047 CH157 5785 9.83 8.35 4.75 3.75 12.16 7.29 5.358 CH165 5825 9.35 8.76 4.57 3.73 12.08 7.18 5.224 TX 802.11 n20M Mode CH149 5745 9.67 8.64 4.32 3.23 12.20 6.82 4.808 CH157 5785 9.84 8.47 4.44 3.08 12.22 6.82 4.808 CH165 5825 9.63 8.36 4.28 3.56 12.05 6.95 4.955 TX 802.11 n40M Mode CH151 5755 9.76 8.86 4.07 3.63 12.34 6.87 4.864 CH159 5795 9.38 8.67 4.24 3.87 12.05 7.07 5.093 Remark: The best case gain of the antenna is 1.0dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.26 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] FCC ID:HHOJYL-AC120 WIFI:2.4G Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [√f(GHz)] Result 802.11B CH01 8.185 5 2.412 2.54 CH06 8.570 5 2.437 2.68 CH11 8.204 5 2.462 2.57 802.11G CH01 6.714 5 2.412 2.09 CH06 6.839 5 2.437 2.14 CH11 6.324 5 2.462 1.98 802.11N(20) CH01 6.368 5 2.412 1.98 CH06 6.152 5 2.437 1.92 CH11 6.109 5 2.462 1.92 802.11N(40) CH03 8.054 5 2.422 2.51 CH06 8.241 5 2.437 2.57 CH09 7.907 5 2.452 2.48 . WIFI: 5G Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [√f(GHz)] Result TX 802.11a Mode CH149 5.047 5 2.412 2.42 CH157 5.358 5 2.437 2.58 CH165 5.224 5 2.462 2.52 TX 802.11 n20M Mode CH149 4.808 5 2.412 2.31 CH157 4.808 5 2.437 2.31 CH165 4.955 5 2.462 2.39 TX 802.11 n40M Mode CH151 4.864 5 2.412 2.33 CH159 5.093 5 2.437 2.45 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: no Simultaneously SAR is required

FCC RADIO TEST REPORT FCC ID:HHOJYL-AC120 Product： Dual Band Wireless USB Adapter Trade Name： Model Name： JYL-AC120 Serial Model： N/A Report No.： NTEK-2013NT1219821F Prepared for Shenzhen Yichen Technoloy Development Co.,LTD 5F,NO.1, Honghualing 2nd industrial Zone, Xili Town,Nanshan District,Shenzhen, China. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 94 Report No.: NTEK-2013NT1219821F TEST RESULT CERTIFICATION Applicant’s name........ Shenzhen Yichen Technoloy Development Co.,LTD Address ........................ 5F,NO.1, Honghualing 2nd industrial Zone, Xili Town,Nanshan District, Shenzhen, China Manufacture's Name... Shenzhen Yichen Technoloy Development Co.,LTD Address ........................ 5F,NO.1, Honghualing 2nd industrial Zone, Xili Town,Nanshan District, Shenzhen, China Product description Product name .................Dual Band Wireless USB Adapter Model and/or type reference ..................... JYL-AC120 Serial Model .................... N/A Standards.................... FCC Part15.247 Test procedure ................ ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test...................................... Date (s) of performance of tests ....... 19 Dec. 2013 ~25 Feb. 2014 Date of Issue..................................... 07 Dec. 2013 Test Result......................................... Pass Testing Engineer : (Polo Cha) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 94 Report No.: NTEK-2013NT1219821F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 10 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 12 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3 . EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.1.2 TEST PROCEDURE 15 3.1.3 DEVIATION FROM TEST STANDARD 15 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 15 3.1.6 TEST RESULTS 16 3.2 RADIATED EMISSION MEASUREMENT 18 3.2.1 RADIATED EMISSION LIMITS 18 3.2.2 TEST PROCEDURE 19 3.2.3 DEVIATION FROM TEST STANDARD 19 3.2.4 TEST SETUP 20 3.2.5 EUT OPERATING CONDITIONS 21 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 22 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 23 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 27 4 . POWER SPECTRAL DENSITY TEST 50 4.1 APPLIED PROCEDURES / LIMIT 50 4.1.1 TEST PROCEDURE 50 4.1.2 DEVIATION FROM STANDARD 50 4.1.3 TEST SETUP 50 4.1.4 EUT OPERATION CONDITIONS 50 4.1.5 TEST RESULTS 51 5 . BANDWIDTH TEST 65 5.1 APPLIED PROCEDURES / LIMIT 65 5.1.1 TEST PROCEDURE 65 Page 4 of 94 Report No.: NTEK-2013NT1219821F Table of Contents Page 5.1.2 EUT OPERATION CONDITIONS 65 5.1.3 TEST RESULTS 66 6 . PEAK OUTPUT POWER TEST 80 6.1 APPLIED PROCEDURES / LIMIT 80 6.1.1 TEST PROCEDURE 80 6.1.2 DEVIATION FROM STANDARD 80 6.1.3 TEST SETUP 80 6.1.4 EUT OPERATION CONDITIONS 80 6.1.5 TEST RESULTS 81 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 83 7.1 DEVIATION FROM STANDARD 83 7.2 TEST SETUP 83 7.3 EUT OPERATION CONDITIONS 83 7.4 TEST RESULTS 84 8 . ANTENNA REQUIREMENT 92 8.1 STANDARD REQUIREMENT 92 8.2 EUT ANTENNA 92 9 . EUT TEST PHOTO 93 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 94 Report No.: NTEK-2013NT1219821F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 94 Report No.: NTEK-2013NT1219821F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 94 Report No.: NTEK-2013NT1219821F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Dual Band Wireless USB Adapter Trade Name Model Name JYL-AC120 Product Description The EUT is a Dual Band Wireless USB Adapter Operation Frequency: 802.11b/g/n(20MHz):2412~2462 MHz 802.11n(40MHz):2422~2452 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz):150/144.44/130/117/ 115.56/104/86.67/78/52/6.5Mbps 802.11n(40MHz):300/270/240/180/150 /120/108/90/54 Mbps Number Of Channel 802.11b/g/n20MHz:11CH 802.11n40MHz:7CH Max.Output Power(Conducted): 13.31 dBm Operation Frequency: 5725 MHz ~ 5850 MHz Modulation Type: OFDM (BPSK / QPSK / 16QAM / 64QAM) Max.Output Power(Conducted): 12.34dBm Antenna Designation: Please see Note 3.…

Text truncated - open the document above for the full version.

Page 94 of 95 Report No.: NTEK-2013NT1219821F 9. EUT TEST PHOTO Radiated Measurement Photos Page 95 of 95 Report No.: NTEK-2013NT1219821F Conducted Measurement Photos
