HHOYC006750Mbps Intelligent Dual Band Gigabit Wireless Router

w ww.jcgcom.com 750Mbps Intelligent Dual Band Gigabit WirelessRouter User Manual Version: V1.0 Date: 2013.02.01 Copyright : Copyright © 2013 Shenzhen Yichen Technology Development Co., Ltd. All rights reserved. JCG is a registered trademark of Shenzhen Yichen Technology Development Co., Ltd. Without the express written permission from Shenzhen Yichen Technology Development Co., Ltd., no organization or individual is allowed to imitate, duplicate, copy, translate or use for other purposes. All other trademarks or registered trademarks in this document are owned by their holders and protected by the relevant laws. The product specifications and information mentioned in this manual are for reference only, and no further notice will be provided for possible content update. For more detailed product information, please visit our offi cial website: http://www.jcgcom.com. w ww.jcgcom.com J HR-N936R 1 .Power LED Off: powered off On: powered on 2.2.4G/5G wireless status LED Off: wireless radio off On: wireless radio on 3.WPS Off: WPS idle or disabled On: WPS connected successfully Blinking:WPS in progress or fi rmware upgrading 4.USB status LED Off: USB port unconnected On: USB port connected 5.LED Sensor Touch with a fi nger to switch on/off the status LED w ww.jcgcom.com 6 .RST/WPS button When the router is working, press this button for 1 second to set encryption; press this button for more than 5 seconds to restore to factory settings. 7.WLAN (wireless) button Switch on/off the wireless network. Press this button for one second to switch on/off the 2.4G wireless network; press this button for more than 5 seconds to switch on/off the 5G wireless network. 8.QoS button Shortly press on this button to limit the host’s maximum traffic. When the QoS is in IP address limited traffic mode, limit the host to use the 1/10 of the maximum network bandwidth; when the QoS is in priority mode, limit the host to the lowest priority; when the IP connection limit is enabled, the maximum connection sessions of this host is limited to 10; shortly press this button once to switch the current limited host; press this button for more than 5 seconds to release the bandwidth limitation on the host. 9.digital display Digital number of online hosts 10.USB 2.0 Connect to USB device, such as USB hard disk, USB thumb driver or USB printer 11.WAN (Internet) port WAN port 12.LAN 1-4 network interface LAN port 13.Power jack (DC IN) Connect to power adapter FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the followingmeasures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only.

Date:2013-03-20 FCC ID: HHOYC006 Subject: Ad Hoc Mode Function Declaration To Whom it may concern, We, declare that the EUT (Model Name: JHR-N936R) doesn’t have Ad Hoc function on “non-US frequencies” and/or “on DFS frequencies”. In non-associated mode, that software and associated drivers will not initiate any transmission on DFS frequencies. This includes transmissions for beacon ad-hoc peer-to-peer modes. Regards, Yours sincerely, Signatory Signature Name: Yong Zhou Title: Manager Tel: +86-0755-33019922 Fax: +86-0755-86238830

Shenzhen Yichen Technoloy Development Co.,LTD Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2013-3-21 SUBJECT: FCC Application for ( FCCID: HHOYC006) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Client’s name / title : Yong Zhou / Manager Contact information / address : 5F, No.1, Honghualing 2nd Industrial Zone, Xili Town, Nanshan District, Shenzhen,China

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Shenzhen Yichen Technoloy Development Co.,LTD 2013-3-20 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Shenzhen Yichen Technoloy Development Co.,LTD.hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (750Mbps Intelligent Dual Band Gigabit Wireless Router,Model: JHR-N936R, FCC ID: HHOYC006) We affirm that between SIEMIC and Shenzhen Yichen Technoloy Development Co.,LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title : Yong Zhou / Manager Contact information / address : 5F, No.1, Honghualing 2nd Industrial Zone, Xili Town, Nanshan District, Shenzhen,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenzhen Yichen Technoloy Development Co., Ltd. 2013-3-20 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: HHOYC006 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Yong Zhou / Manager Contact information / address : 5F, No.1, Honghualing 2nd Industrial Zone, Xili Town, Nanshan District, Shenzhen,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

Photo 9 Photo 10 Photo 11 Photo 12 Photo 13

FCC ID: HHOYC006 RF EXPOSURE Applied procedures / limit These devices are not exempted from compliance does not exceed the Commission’s RF exposure guidelines.Unless a device operates at substantially low power levels,with a low gain antenna(s),supporting information is generally needed to establish the various potential operating configurations and exposure conditions of a transmitter and its antenna(s) in order to determine compliance with the RF exposure guidelines. In order to demonstrate compliance with MPE requirement(see Section 2.1091),the following information is typically needed: Calculation that estimates the minimum separation distance(20 cm or more)between an antenna and persons required to satisfy power density limits defined for free space. Antenna installation and device operating instructions for installers(professional/unskilled users),and the parties responsible for ensuring compliance with the RF exposure requirement Any caution statements and/or warming labels that are necessary in order to comply with the exposure limits Any other RF exposure related issues that may affect MPE compliance. FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency(RF) radiation as specified in 1.1307(b). (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density FCC ID: HHOYC006 MPE CALCULATION METHOD Calculation Method of RF Safety Distance: P :power input to the antenna in Mw EIRP :Equivalent(effective) isotropic radiated power. S :power density mW/ cm 2 G ;numeric gain of antenna relative to isotropic radiator R :distance to centre of radiation in cm FCC radio frequency exposure limits may be exceeded at distances closer than r cm from the antenna of this device EIRP=10 ( Antenna Gain+Peak Output Power/10) Note: 1. s=1.0 mW /cm 2 for limits for General Population/Uncontrolled Exposures. 2. The time averaged power over 30 minutes will be equaled Output Power. 3. The Power Density at a distance of 20cm calculated from the formula is far below the limit of 1MW/ cm 2 FCC ID: HHOYC006 TEST RESULTS 2.4GHz: 802.11b Mode Te s t Channe Frequency Output Power/AOutput Power/B Total Output Power LIMIT (MHz) dBm dBm dBm dBm CH01 2412 16.22 13.10 17.94 29 CH06 2437 15.67 11.70 17.13 29 CH11 2462 14.65 10.53 16.07 29 802.11g Mode CH01 2412 12.03 10.98 14.55 29 CH06 2437 11.47 9.45 13.59 29 CH11 2462 10.66 8.43 12.70 29 802.11n(20) Mode CH01 2412 11.46 10.48 14.01 29 CH06 2437 10.92 8.96 13.06 29 CH11 2462 9.33 8.28 11.85 29 802.11n(40) Mode CH03 2422 11.66 9.61 13.77 29 CH06 2437 11.17 9.13 13.28 29 CH09 2452 10.77 9.11 13.03 29 Frequency (MHz) Max. output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 2412~2462 17.94 62.23 5.01(7dBi) 0.062 1 Pass FCC ID: HHOYC006 5.8GHz: 802.11a Mode Te s t Channe Frequency Output Power/C Output Power/D Output Power/E Total Output Power LIMIT (MHz) dBm dBm dBm dBm dBm CH149 5745 MHz 18.28 9.53 10.67 18.63 26.23 CH157 5785 MHz 17.68 9.42 10.98 19.48 26.23 CH165 5825 MHz 16.82 9.33 10.87 19.01 26.23 802.11n(20) Mode CH149 5745 MHz 18.33 9.32 10.78 19.47 26.23 CH157 5785 MHz 17.51 9.21 10.76 18.84 26.23 CH165 5825 MHz 17.04 9.22 10.76 18.50 26.23 802.11n(40) Mode CH151 5755 MHz 17.20 9.45 10.54 18.61 26.23 CH159 5795 MHz 16.07 9.52 10.43 17.81 26.23 Frequency (MHz) Max. output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 5745-5825 19.48 88.71 9.48(9.77dBi) 0.167 1 Pass FCC ID: HHOYC006 5.2GHz 802.11a Mode Te s t Channe Frequency Output Power/C Output Power/D Output Power/E Total Output Power LIMIT (MHz) dBm dBm dBm dBm dBm 36 5180 9.34 7.43 7.67 13.004 13.23 40 5200 9.59 7.21 7.98 13.147 13.23 46 5240 9.02 7.14 7.87 12.851 13.23 802.11n(20) Mode 36 5180 9.51 7.54 7.78 13.140 13.23 40 5200 9.70 7.42 7.76 13.186 13.23 46 5240 9.30 7.31 7.76 12.981 13.23 NOTE: 1. For 2.4GHz mode, antenna A B are transmitting, antenna C D E were closed, two antennas simultaneously transmit. And the data is recorded for radiated emission and band edge. For 5GHz mode,antenna C D E are transmitting, antenna A B were closed Three antennas simultaneously transmit. And the data is recorded for radiated emission and band edge. 2.(For mobile or fixed location transmitters, the maximum power density is 1.0mW/cm2 even if the calculation indicates that the power density would be larger) This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Frequency (MHz) Max. output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 5180-5240 13.19 20.84 9.48(9.77dBi) 0.0393 1 Pass

FCC RADIO TEST REPORT FCC ID: HHOYC006 Product： 750Mbps Intelligent Dual Band Gigabit Wireless Router Trade Name： Model Name： JHR-N936R Serial Model： N/A Report No.： NTEK- 2013NT0225205F2 Prepared for Shenzhen Yichen Technoloy Development Co.,LTD 5F，NO.1，Honghualing 2nd industrial Zone, Xili Town,Nanshan District,Shenzhen,Guangdong,People’s Republic Of China Longgang District, Shenzhen, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 69 Report No.: NTEK- 2013NT0225205F2 TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Yichen Technoloy Development Co.,LTD Address ................................. : 5F，NO.1，Honghualing 2nd industrial Zone, Xili Town,Nanshan District,Shenzhen,Guangdong,People’s Republic Of China Longgang District, Shenzhen, China Manufacture's Name ............ : Shenzhen Yichen Technoloy Development Co.,LTD Address ................................. : 5F，NO.1，Honghualing 2nd industrial Zone, Xili Town,Nanshan District,Shenzhen,Guangdong,People’s Republic Of China Longgang District, Shenzhen, China Product description Product name ........................... : 750Mbps Intelligent Dual Band Gigabit Wireless Router Model and/or type reference : JHR-N936R Serial Model .............................. : N/A Standards ............................. : FCC Part15.407 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 01 Apr. 2013 ~10 Apr. 2013 Date of Issue ........................................... : 10 Apr. 2013 Test Result ............................................... : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 69 Report No.: NTEK- 2013NT0225205F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 10 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 12 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3 . EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.1.2 TEST PROCEDURE 15 3.1.3 DEVIATION FROM TEST STANDARD 15 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 15 3.1.6 TEST RESULTS 16 3.2 RADIATED EMISSION MEASUREMENT 18 3.2.1 RADIATED EMISSION LIMITS 18 3.2.2 TEST PROCEDURE 19 3.2.3 DEVIATION FROM TEST STANDARD 19 3.2.4 TEST SETUP 20 3.2.5 EUT OPERATING CONDITIONS 21 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 22 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 23 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 25 4 . POWER SPECTRAL DENSITY TEST 41 4.1 APPLIED PROCEDURES / LIMIT 41 4.1.1 TEST PROCEDURE 41 4.1.2 DEVIATION FROM STANDARD 41 4.1.3 TEST SETUP 41 4.1.4 EUT OPERATION CONDITIONS 41 4.1.5 TEST RESULTS 42 5 . 26 BANDWIDTH TEST 46 5.1 APPLIED PROCEDURES / LIMIT 46 5.1.1 TEST PROCEDURE 46 Page 4 of 69 Report No.: NTEK- 2013NT0225205F2 Table of Contents Page 5.1.2 DEVIATION FROM STANDARD 46 5.1.3 TEST SETUP 46 5.1.4 EUT OPERATION CONDITIONS 46 5.1.5 TEST RESULTS 47 6 . MAXIMUM CONDUCTED OUTPUT POWER 51 6.1 APPLIED PROCEDURES / LIMIT 51 6.1.1 TEST PROCEDURE 51 6.1.2 DEVIATION FROM STANDARD 51 6.1.3 TEST SETUP 51 6.1.4 EUT OPERATION CONDITIONS 52 6.1.5 TEST RESULTS 53 7 . PEAK EXCURSION RATIO MEASUREMENT 58 7.1 STANDARD REQUIREMENT 58 7.2 MEASURING INSTRUMENTS 58 7.3 TEST PROCEDURES 58 7.3 TEST SETUP 58 8 . FREQUENCY STABILITY MEASUREMENT 64 8.1 LIMIT OF FREQUENCY STABILITY 64 8.2 MEASURING INSTRUMENTS 64 8.3 TEST PROCEDURES 64 8.4 TEST SETUP 64 9 . AUTOMATICALLY DISCONTINUE TRANSMISSION 66 9.1 LIMIT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 66 9.2 TEST RESULT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 66 10 . ANTENNA REQUIREMENT 67 10.1 STANDARD REQUIREMENT 67 10.2 EUT ANTENNA 67 11 . EUT TEST PHOTO 68 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 69 Report No.: NTEK- 2013NT0225205F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.407) , Subpart E IC RSS-210 Issued 8 Standard Section Test Item Judgment Remark 15.207& Gen 7.2.4 Conducted Emission PASS 15.403(i)& A9.2 26dB Bandwidth PASS 15.407(a) &A9.2 Maximum Conducted Output Power PASS 15.407(b)& A9.3 Peak Excursion Ratio PASS 15.407(b) &A9.3 Radiated Spurious Emission PASS 15.407(a) &A9.2 Power Spectral Density PASS 15.407(g)& A9.5 Frequency Stability PASS 15.407(c)& A9.5 Automatically Discontinue Transmission PASS 15.203& A9.2 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 69 Report No.: NTEK- 2013NT0225205F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68…
