HOLCL906900MHz Cordless Telephone System

CL906 User Manual 900 MHz CL906.book Page 1 Friday, January 18, 2002 2:25 PM Copyright © 2002 Cidco Communications Corporation. All Rights Reserved. Part No. 105550-01 Rev. ANo part of this publication may be reproduced, copied, transcribed, stored in a retrieval system, or translated into any language in any form, by any means without the prior written permission of Cidco Communications Corporation. CL906.book Page 2 Friday, January 18, 2002 2:25 PM TABLE OF CONTENTS i TABLE OF CONTENTS
SAFETY INSTRUCTIONS & WARRANTY 1 Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Telephone Wiring and Jack Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 FCC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
INTRODUCTION 6 Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
INSTALLING THE CL906 7 Checking the Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
FEATURES AND CONTROLS 11 Controls and Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Personalizing Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
USING THE CL906 15 Answering Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Dialing Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Pre-Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Paging and Finding the Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Using Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 CL906.book Page i Friday, January 18, 2002 2:25 PM ii TABLE OF CONTENTS Using Temporary Tone Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Adjusting The Handset Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Reading The Call Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Finding Clear Reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Going Out of Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Using Network Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Using Caller ID and Call Waiting ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Switching Between Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Using The Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Reading Display Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
TROUBLESHOOTING 23 Problem/Solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 CL906.book Page ii Friday, January 18, 2002 2:25 PM CL906 - 900MHz Cordless SAFETY INSTRUCTIONS & WARRANTY 1 SAFETY INSTRUCTION S & WARRANTY S AFETY S YMBOLS WARNING: This symbol is intended to alert you to the presence of uninsulated dangerous voltage within the product's enclosure that might be of sufficient magnitude to constitute a risk of electric shock. Do not open the product's case. CAUTION: This symbol is intended to inform you that important operating and maintenance instructions are included in the literature accompanying this product. NEED TO KNOW: This symbol is intended to highlight important information. S AFETY I NSTRUCTIONS CAUTION To reduce the risk of fire or injury to persons, read and follow these instructions:
Read and understand all instructions.
Follow all warnings and instructions marked on the unit and in the User Manual(s).
Use only the battery type recommended in this manual.
Unplug this telephone from the wall outlet before cleaning. Do not use liquid or aerosol cleaners, just use a damp cloth for cleaning.
Do not place this telephone on an unstable cart, stand, or table. It could fall, causing serious damage or impede operation.
Never place this telephone near or over a radiator or heat register.
Only operate this telephone using the type of power source listed on the marking label. If you are not sure of the power supply of your home, consult your dealer or local power company.
Do not overload wall outlets and extension cords as this can result in the risk of fire or electrical shock.
Never push objects of any kind into this telephone as they can touch dangerous voltage points or short out parts that could result in a risk of fire or electrical shock.
Take the phone to a qualified technician when it requires repair work or service.
To reduce the risk of electrical shock, do not disassemble the telephone. Opening or removing covers can expose you to dangerous voltages or other risks. Incorrect re-assembly can cause electrical shock during subsequent use. S - SAVE THESE INSTRUCTIONS - CL906.book Page 1 Friday, January 18, 2002 2:25 PM CL906 - …

Text truncated - open the document above for the full version.

CL -906 BLOCK DIAGRAM Base Block Diagram Base Block Diagram Power Supply Input 9Vdc MCU 32KB ROM, 2KB RAM Called ID Type & RTC Counter Clock Resource : 3.579545MHz EEPROM RF Section Line Interface Called_ID Interface Base Audio Handset Block Diagram Handset Block Diagram EEPROM RF Section LCD Panel -Drive HTN 3 Line Dot Matrix MCU 32KB ROM 2KB RAM Called ID RTC Counter LCD Control Clock Resource: 4.194304 MHz Handset Audio

PROPOSED FCC ID LABEL AND LOCATION CIDCO COMMUNICATIONS INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone FCC ID: HOLCL906 FCC ID LABEL

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT TEST REPORT FOR 900 MHz ANALOG PHONE – BASE UNIT FCC ID: HOLCL906 MODEL NO: CL906 REPORT NO: 02U1137-1 ISSUE DATE: JUNE 11, 2002 Prepared for CIDCO COMMUNICATIONS CORPORATION 105 COCHRANE CIRCLE MORGAN HILL, CA 95035 U.S.A. Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, U.S.A. TEL: (408) 463-0885 FAX: (408) 463-0888 TABLE OF CONTENTS PAGE NO 1. VERIFICATION OF COMPLIANCE.....................................................................3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT)....................................4 3. TEST LOCATION.....................................................................................................4 4. EQUIPMENT MODIFICATIONS...........................................................................4 5. TEST EQUIPMENT LIST........................................................................................5 6. TEST RESULT SUMMARY....................................................................................5 6. TEST RESULT SUMMARY....................................................................................6 RADIATED EMISSIONS......................................................................................................6 Test Requirement: 15.249(A)(B)(C).............................................................................6 RADIATED EMISSIONS......................................................................................................9 RADIATED EMISSIONS....................................................................................................10 Test Requirement: 15.209..........................................................................................10 AC LINE CONDUCTED EMISSIONS..................................................................................14 Test Requirement: 15.207.........................................................................................14 PROJECT NO: 02U1137-1B DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (BASE UNIT) Page 3 of 20 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: CIDCO COMMUNICATIONS CORPORATION 105 COCHRANE CIRCLE MORGAN HILL, CA 95035 U.S.A. CONTACT PERSON: RON ANGLIKOWSKI TELEPHONE NUMBER: (408) 782 - 8200 EUT DESCRIPTION: 900 MHz ANALOG PHONE – BASE UNIT MODEL NAME: CL906 DATE TESTED: 6/4/2002, 6/5/2002 LIMITS APPLY TO: FCC PART 15 SECTION 15.249 TECHNICAL LIMITS TEST RESULT Radiated Emission of Fundamental Frequency No non-compliance found Radiated Emission of Harmonic Frequencies No non-compliance found Radiated Emission Outside the Band No non-compliance found LIMITS APPLY TO: FCC PART 15 SECTION 15.209 Radiated Emission Digital Device No non-compliance found LIMITS APPLY TO: FCC PART 15 SECTION 15.207 AC Line Conducted Emission No non-compliance found The above equipment was tested by Compliance Certification Services Inc. for compliance with the requirements set forth in CFR 47 PART 15 SUBPART C. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. _____________________________ ___________________________ Tested by: Approved & Reviewed by: Frank Ibrahim / EMC Engineer Thu Chan / EMC Senior Engineer Compliance Certification Services Compliance Certification Services Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. PROJECT NO: 02U1137-1B DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (BASE UNIT) Page 4 of 20 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) This is a Wireless Battery Pack. CHASSIS TYPE PLASTIC Frequency Range 902.8 – 904.8 MHz Number of Channels 40 Type of Emission CONTINUOUS Antenna Requirement PERMANENTLY ATTACHED Antenna Gain 0 dbi No of External Connectors and Types RJ11 Connector, and Power Jack for the charger Power requirement 9VDC 300 mA AC/DC adapter 3. TEST LOCATION All emissions tests were performed at: Compliance Certification Services 561F Monterey Road Morgan Hill, CA 95037 CCS has site descriptions on file with the FCC for 10 and 3 meter site configurations. CCS is a NVLAP accredited facility. 4. EQUIPMENT MODIFICATIONS To achieve compliance Levels, the following change(s) were made during compliance testing: No changes were required in order to achieve compliance to class B levels. PROJECT NO: 02U1137-1B DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (BASE UNIT) Page 5 of 20 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be no…

Text truncated - open the document above for the full version.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT TEST REPORT FOR 900 MHz ANALOG PHONE - HANDSET FCC ID: HOLCL906 MODEL NO: CL906 REPORT NO: 02U1137-1 ISSUE DATE: JUNE 11, 2002 Prepared for CIDCO COMMUNICATIONS CORPORATION. 105 COCHRANE CIRCLE MORGAN HILL, CA 95035 U.S.A. Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037 U.S.A. TEL: (408) 463-0885 FAX: (408) 463-0888 TABLE OF CONTENTS PAGE NO 1. VERIFICATION OF COMPLIANCE.....................................................................3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT)....................................4 3. TEST LOCATION.....................................................................................................4 4. EQUIPMENT MODIFICATIONS...........................................................................4 5. TEST EQUIPMENT LIST........................................................................................5 6. TEST RESULT SUMMARY....................................................................................5 6. TEST RESULT SUMMARY....................................................................................6 RADIATED EMISSIONS......................................................................................................6 Test Requirement: 15.249(A)(B)(C).............................................................................6 RADIATED EMISSIONS....................................................................................................10 Test Requirement: 15.209..........................................................................................10 AC LINE CONDUCTED EMISSIONS..................................................................................13 Test Requirement: 15.207.........................................................................................13 PROJECT NO: 02U1137-1H DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (HANDSET) Page 3 of 13 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: CIDCO COMMUNICATIONS CORPORATION 105 COCHRANE CIRCLE MORGAN HILL, CA 95035 U.S.A. CONTACT PERSON: RON ANGLIKOWSKI TELEPHONE NUMBER: (408) 782 - 8200 EUT DESCRIPTION: 900 MH ANALOG PHONE - HANDSET MODEL NAME: CL906 DATE TESTED: 6/4/2002, 6/5/2002 LIMITS APPLY TO: FCC PART 15 SECTION 15.249 TECHNICAL LIMITS TEST RESULT Radiated Emission of Fundamental Frequency No non-compliance found Radiated Emission of Harmonic Frequencies No non-compliance found Radiated Emission Outside the Band No non-compliance found LIMITS APPLY TO: FCC PART 15 SECTION 15.209 Radiated Emission Digital Device No non-compliance found LIMITS APPLY TO: FCC PART 15 SECTION 15.207 AC Line Conducted Emission Not Applicable The above equipment was tested by Compliance Certification Services Inc. for compliance with the requirements set forth in CFR 47 PART 15 SUBPART C. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. ____________________________ ___________________________ Tested by: Approved & Reviewed by: Frank Ibrahim / EMC Engineer Thu Chan / EMC Senior Engineer Compliance Certification Services Compliance Certification Services Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. PROJECT NO: 02U1137-1H DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (HANDSET) Page 4 of 13 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) This is a Wireless Battery Pack. CHASSIS TYPE PLASTIC Frequency Range 925.3 – 927.3 MHz Number of Channels 40 Type of Emission CONTINUOUS Antenna Requirement PERMANENTLY ATTACHED Antenna Gain 0 dbi No of External Connectors and Types NONE Power requirement 3.6 VDC 600mAh Battery 3. TEST LOCATION All emissions tests were performed at: Compliance Certification Services 561F Monterey Road Morgan Hill, CA 95037 CCS has site descriptions on file with the FCC for 10 and 3 meter site configurations. CCS is a NVLAP accredited facility. 4. EQUIPMENT MODIFICATIONS To achieve compliance Levels, the following change(s) were made during compliance testing: No changes were required in order to achieve compliance to class B levels. PROJECT NO: 02U1137-1H DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (HANDSET) Page 5 of 13 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 5. TEST EQUIPMENT LIST TEST EQUIPMENTS LIST Name of EquipmentManufacturerModel No.Serial No.Due Date Spectrum AnalyzerHP 0.1K - 1.5GHz8568B2732…

Text truncated - open the document above for the full version.

PROJECT NO: 02U1137-1B DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (BASE UNIT) Page 7 of 20 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Setup Photo & Test Results: PROJECT NO: 02U1137-1B DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (BASE UNIT) Page 15 of 20 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Test Setup Photos & Results:

PROJECT NO: 02U1137-1H DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (HANDSET) Page 7 of 13 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Setup Photo & Test Results: PROJECT NO: 02U1137-1H DATE: JUNE 11, 2002 FCC ID: HOLCL906 EUT: 900 MHz ANALOG PHONE (HANDSET) Page 11 of 13 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO:CCSUP4031B 561F MONTEREY ROAD, MORGAN HILL, CA 95037 TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Test Setup Photos & Results:
