HOLE2722.4GHz DSS Cordless Telephone

User Manual 2.4 GHz DSS 106520-01 Rev 2 E272 TABLE OF CONTENTS i TABLE OF CONTENTS ■ INTRODUCTION iii E272 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii■ SAFETY INSTRUCTIONS iv Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv Telephone Wiring and Jack Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi■ INSTALLING THE E272 1 Check the Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Choose a Location for the Base Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Plug in the Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Install the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Desktop / Wall Mount Wedge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Install the Telephone Line Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Attach the Belt Clip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Attach Headset (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4■ FEATURES AND CONTROLS 5 Handset Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Personalizing your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9■ USING THE E272 15 Answering Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Pre-Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Last Number Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 ii TABLE OF CONTENTS Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Temporary Tone Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Timing Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Locating a Lost Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Low Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Using Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Using Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Using Network Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Using the Intercom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Using Message Screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Clearing the Voicemail Light. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Using Transfer to Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Using Call Waiting ID (CWID) Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Caller ID Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Directory Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Reading Display Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26■ TROUBLESHOOTING 27 Problem / Solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27■ FCC AND WARRANTY 31 FCC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 E272 - 2.4GHz Cordless INTRODUCTION iii INTRODUCTIONE272 F EATURES ■ 2.4GHz Digital Spread Spectrum ■ Voice Announce Caller ID ■ Caller ID/Call Waiting ID ■ Call Waiting ID Options ■ Internal DSL Filter ■ Speakerphone in handset and base ■ Intercom ■ Works in the event of a power failure (when spare battery is installed and charged) ■ New Voicemail Message Indicator ■ 50 Caller ID Records ■ 50 Directory Records ■ Dedicated Keys on the Base: Hold, Mute, Speaker, Voicemail, Page/Find, Flash and Redial ■ Backlit display and keypad on handset ■ Adjustable Ringer on both handset and base ■ Adjustable Volume Control for handset, handset speakerphone, base and base speakerphone ■ Hearing-aid Compatible ■ English and Spanish ■ Headset Jack ■ Call timer ■ Single key redialing The E272 is a digital 2.4GHz cordless phone that incorporates your telephone company’s calling features, such as Caller ID, Voicemail and Call Waiting ID, to provide a powerful, full function cordless telephone. The E272 also has an exciting new feature - Voice Announce. The Voice Announce feature allows you to hear the caller’s number or a short message you previously recorded announcing the cal ler before you answer your phone. E272 - 2.4GHz Cordlessiv SAFETY INSTRUCTIONS S - SAVE THESE INSTRUCTIONS - SAFETY INSTRUCTION S S AFETY S YMBOLS WARNING:This symbol is intended to alert you to the presence of uninsulated dangerous voltage within the product's enclosure that might be of sufficient m…

Text truncated - open the document above for the full version.

From: Helen Zhao Sent: Thursday, June 26, 2003 2:29 PM To: Steve Cheng; Mike Kuo Cc: Anne Liang; Claire Hoque Subject: RE: CIDCO Communications Corporation, FCC ID:HOLE272, AN03T2932 Hello Mike and Steve, Since Claire is busy today, I help on this. Re Q1: In the proposed FCC ID label format and location, the FCC ID label is proposed to be placed on the base unit. When the Cordless Phone system is applied for system approval, the FCC ID label is required to be placed on the hand set as well. In addition, the proposed FCC ID label does not contain information required under section 15.214( c ) of FCC rules. Please provide revised FCC ID label format and proposed FCC ID label location. Please see revised FCC ID label. Re Q2: The max. measured hand set conducted output power is 35.6mW which is above SAR low threshold power requirement. SAR evaluation is required if there is no considering of source-based average. If the handset and base are utilizing source-based averaging, please provide duty cycle plots to state the max. duty cycle factor and provide technical description to justify the source- based averaging. As mentioned in revised Theory of Operation, the device is using DTMF(Dual Tone Multi-Frequency) modulation with a 50%/50% duty cycle. Re Q3: MPE estimate is included in the test report to address RF exposure compliance for base and handset unit. The base unit is considered as mobile device per section 2.1091 of FCC rules. However, the handset is considered as portable device per section 2.1093 of FCC rules and using MPE estimate to justify RF exposure for portable device is not applicable. Please remove relate information for handset in the MPE estimate. Please see Page 21 of FCC Report - Part 1 of 3. Re Q4: In the theory of operation, there is no information provided to address 15.214(d) requirements. Please refer to Q2 - Revised Theory of Operation. Re Q5: In the internal photos, it looks like only handset portion of internal photos were provided. If internal photos of base unit is included in internal photos, please indicate which photos are for handset and which photos are for base unit. Please see revised Internal Photos. Re Q6: Page 31 of user manual, RF exposure warning statement does not indicate 20cm separation distance is required for base unit. Please provide revised user manual to address this issue. Please see revised user manual. Re Q7: The FCC report file size is over the max, allowed file size of 4MB. Please reduce the file size and provided the test report again. Please see FCC Report-Part 1 of 3, FCC Report-Part 2 of 3, and FCC Report-Part 3 of 3. Best Regards Helen

PROPOSED FCC ID LABEL AND LOCATION CIDCO COMMUNICATIONS CORPORATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone FCC ID: HOLE272 FCC ID LABEL LOCATION

BASE UNIT Page 76 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. BACK BACK Page 77 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. BACK BACK Page 78 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. BACK BACK HANDSET Page 80 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Page 81 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Page 82 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Page 83 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Page 84 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Page 85 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Page 86 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document.

FCC CFR47 PART 15 CERTIFICATION TEST REPORT FOR 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE MODEL: E272 FCC ID: HOLE272 REPORT NUMBER: 03U1988-1 ISSUE DATE: JUNE 07, 2003 Prepared for CIDCO COMMUNICATIONS CORPORATION 105 COCHRANE CIRCLE MORGAN HILL, CA 95037 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 2 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.................................................................................................3 2. EUT DESCRIPTION.........................................................................................................................4 3. TEST METHODOLOGY..................................................................................................................5 4. FACILITIES AND ACCREDITATION..........................................................................................5 4.1. FACILITIES AND EQUIPMENT.................................................................................................5 4.2. TABLE OF ACCREDITATIONS AND LISTINGS........................................................................6 5. CALIBRATION AND UNCERTAINTY.........................................................................................7 5.1. MEASURING INSTRUMENT CALIBRATION............................................................................7 5.2. MEASUREMENT UNCERTAINTY..............................................................................................7 5.3. TEST AND MEASUREMENT EQUIPMENT...............................................................................8 6. SETUP OF EQUIPMENT UNDER TEST.......................................................................................9 7. APPLICABLE LIMITS AND TEST RESULTS...........................................................................11 7.1. 6 dB BANDWIDTH.....................................................................................................................11 7.2. OUTPUT POWER......................................................................................................................18 7.3. MAXIMUM PERMISSIBLE EXPOSURE...................................................................................20 7.4. PEAK POWER SPECTRAL DENSITY.......................................................................................22 7.5. CONDUCTED SPURIOUS EMISSIONS...................................................................................29 7.6. RADIATED EMISSIONS............................................................................................................48 7.7. POWERLINE CONDUCTED EMISSIONS................................................................................64 7.8. SETUP PHOTOS........................................................................................................................67 REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 3 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: CIDCO COMMUNICATION CORPORATION 105 COCHRANE CIRCLE MORGAN HILL, CA 95037 USA EUT DESCRIPTION: 2.4GHZ SPREAD SPECTRUM CORDLESS TELEPHONE MODEM NAME: E272 DATE TESTED: MAY 14, 2003 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART C NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Approved & Released For CCS By: Tested By: MIKE HECKROTTE VIEN TRAN CHIEF ENGINEER EMC TECHNICIAN COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 4 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. EUT DESCRIPTION The E272 is a 2.4GHz cordless phone that incorporates your telephone company’s calling features, such as calling ID. Voice Mail, and call Waiting ID, to provide a powerful full function caller ID cordless telephone. Listed below are some key features; • Handset Jack • Speakerphone • Call timer • New message Indicator • Single key redialing • Stores up to 50 caller ID recordings • En…

Text truncated - open the document above for the full version.

REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 31 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. LOW CH SPURIOUS REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 32 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. LOW CHANNEL SPURIOUS REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 33 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. SPURIOUS EMISSIONS, MID CHANNEL – BASE UNIT MID CH REFERENCE REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 34 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. MID CH SPURIOUS REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 35 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. MID CHANNEL SPURIOUS REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 36 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. SPURIOUS EMISSIONS, HIGH CHANNEL – BASE UNIT HIGH CH BANDEDGE REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 37 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. HIGH CH SPURIOUS REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 38 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. HIGH CHANNEL SPURIOUS REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 39 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. SPURIOUS EMISSIONS, LOW – HANDSET UNIT LOW CH BANDEDGE REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 40 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. LOW CH SPURIOUS REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 41 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. LOW CHANNEL SPURIOUS REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 42 of 8…

Text truncated - open the document above for the full version.

REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 61 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. HARMONICS AND SPURIOUS EMISSIONS – LOW, MID, HIGH CHANNEL – HANDSET UNIT REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 62 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. SPURIOUS EMISSIONS 30 TO 1000 MHz (WORST-CASE CONFIGURATION) – BASE UNIT 03U1988-1 03U988-1 SITE C 05/16/039:59 AM VIEN TRAN CLIFFORD TECHNOLOGIES 2.4 GHz SPREAD SPECTRUM CORDLESS PHONE / E272 EUT / LAPTOP _ BASE UNIT FCC CLASS B Tx at Middle channel 05/16/03 Freq.ReadingAFCloss Pre-ampLevelLimitMarginPolAzHeightMark (MHz)(dBuV)(dB)(dB)(dB)(dBuV/m)FCC_B(dB)(H/V)(Deg)(Meter)(P/Q/A) 124.8056.0011.531.8726.9842.4243.50-1.083mH0.001.00P 547.7249.4018.004.2927.6744.0246.00-1.983mV0.001.00P 240.0056.3011.412.6526.4743.8946.00-2.113mH0.001.00P 259.1354.7012.132.7626.4243.1746.00-2.833mH0.001.00P 230.4053.1011.232.6026.5040.4246.00-5.583mH0.001.00P 278.7150.5013.272.8826.4140.2446.00-5.763mV0.001.00P 6 Worst Data << Main Sheet Company: EUT Description: Test Configuration : Type of Test: Mode of Operation: FCC, VCCI, CISPR, CE, AUSTEL, NZ UL, CSA, TUV, BSMI, DHHS, NVLAP 561F MONTEREY ROAD, SAN JOSE, CA 95037-9001 PHONE: (408) 463-0885 FAX: (408) 463-0888 Project #: Report #: Date& Time: Test Engr: REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 63 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. SPURIOUS EMISSIONS 30 TO 1000 MHz (WORST-CASE CONFIGURATION) – HANDSET UNIT 03U1988-1 03U988-1 SITE C VIEN TRAN CLIFFORD TECHNOLOGIES 2.4 GHz SPREAD SPECTRUM CORDLESS PHONE / E272 EUT / HANDSET FCC CLASS B Tx at Mid Channel 05/16/03 Freq.ReadingAFCloss Pre-ampLevelLimitMarginPolAzHeightMark (MHz)(dBuV)(dB)(dB)(dB)(dBuV/m)FCC_B(dB)(H/V)(Deg)(Meter)(P/Q/A) 374.3350.0415.153.4226.9341.6746.00-4.333mH0.001.00P 479.7546.8017.213.9427.4740.4846.00-5.523mV0.001.00P 479.7545.9017.213.9427.4739.5846.00-6.423mH0.001.00P 144.1345.7015.582.0126.9036.4043.50-7.103mV0.001.00P 192.3046.0014.222.4226.6236.0243.50-7.483mH0.001.00P 124.0046.6011.401.8626.9832.8843.50-10.623mV0.001.00P 6 Worst Data << Main Sheet Company: EUT Description: Test Configuration : Type of Test: Mode of Operation: FCC, VCCI, CISPR, CE, AUSTEL, NZ UL, CSA, TUV, BSMI, DHHS, NVLAP 561F MONTEREY ROAD, SAN JOSE, CA 95037-9001 PHONE: (408) 463-0885 FAX: (408) 463-0888 Project #: Report #: Date& Time: Test Engr: REPORT NO: 03U1988-1 DATE: JUNE 07, 2003 EUT: 2.4GHz SPREAD SPECTRUM CORDLESS TELEPHONE FCC ID: HOLE272: Page 64 of 86 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 7.7 POWERLINE CONDUCTED EMISSIONS LIMIT §15.207 (a) Except as shown in paragraphs (b) and (c) of this section, for an intentional radiator that is designed to be connected to the public utility (AC) power line, the radio frequency voltage that is conducted back onto the AC power line on any frequency or frequencies within the band 150 kHz to 30 MHz shall not exceed the limits in the following table, as measured using a 50 μH/50 ohms line impedance stabilization network (LISN). Compliance with the provisions of this paragraph shall be based on the measurement of the radio frequency voltage between each power line and ground at the power terminal. The lower limit applies at the boundary between the frequency ranges. TEST PROCEDURE The EUT is placed on a non-conducting table 40 cm from …
