HQX-D-GP0010SRGamepad PS2 RF

Crystal RF Game Pad PS2 User’s Manual Welcome to choose RF Game Pad PS2, please you familiarize thoroughly this manual before starting to operate it. FCC Regulatory Statement: This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Features : 1. Fully compatible with PlayStation®2, PlayStation® , and PS one™ and any title of racing games. 2. With three different color LEDs to indicating difference motor vibrate indication. 3. Two modes: Digital and Analog mode for experiencing different fun in games. 4. synthetic soft rubber-covered gives you more comfortable. 5. the most distance is 30m in open side. Installation: 1. Turn off your console. 2. Put the PS2 game disc into the PS2 console. 3. Connect the TV and PS2 console. 4. connect RF receiver and console. 5. put two batteries into pad and slid the “om/off” switch into “On” position. 6. Start your gaming and have fun. * When connect successul, all the vibration LEDs will turn on (Green). If the Crystal RF GamePad functions: 1. Mode indications: Crystal RF gamepad has 2 different operation modes. which are indicated by the colored LED on the pad. Digital mode: Red LED power off. It is the default mode at start-up. Analog mode: Red LED power on. By pressing the mode button, while Green LED turns on, indicating that it is switched into Analog mode. Pressing the mode button for the second times will go back to the Digital mode, indicated by a Mode LED on. 2. Automatic Centering: Auto centering can detect the joystick center point when the console is powered on. Instead of scrolling through complex settings in the game “OPTION” menu. 3. Crystal casing with interacting lighting features Green color growing body supports by 4pcs green LEDs. - 3-color growing center logo. - Grows with green color when the big vibration motor is stop. - Grows with yellow color when the big vibration motor runs with half speed. - Grows with red color when the big vibration motor runs with full speed. z With slip free rubber pads on the grips. z Built-in fans on two vibration motors z 2 high quality Mini sticks with up to 1M life cycles. 3. Slow function To use this function will win more times to thinking when you in gaming. Press “Slow” button one time, the screen will appears pause by continuous. Press the “Slow” button again, out of this mode. 4. “Turbo” function in shooting gaming When you in shooting gaming, you can press “Turbo” to performing running fire to have more fun. Press “Turbo” and press the button ()you like to setting simultaneously. Then the button () have running fire function. Note: , , ○, X, L1, R1, L2, R2 buttons can be settled by Turbo function. 5. Low voltage indication: When the low battery indicator comes on, Mode LED will flash ceaselessly. Please replace your batteries as soon as possible. In this condition, there will no vibration in gaming. 6. Control motor vibrate On/Off: If you want to stop the motors off, please press “Select” + “O” simultaneously, the motor vibrate will be off. Press the buttons again, motors vibrate will be On. Note: when under vibration Off mode, Logo LED will not change color any more. 7. Force connect function: When there are two or more than two RF controllers gaming meanwhile, you can thru force connect function to choose your favorite RF controller. Press “Select” + simultaneously, Mode LED will lighting, then press “FC” button in receiver, it will be application within 15 seconds. 9. Sleeping function: Case 1: The RF controller will automatically go to sleep after approximately 10 minutes of not using any buttons. In this case, Mode LED will turn off. Case 2: after connection ok, then RF receiver power off, and the pad still power on, Mode LED will flash for 30minutes, RF controller will get into sleeping mode. Case 3: when RF pad power on but RF receiver power off, Mode LED will flash for 15minutes, RF controller will get into sleeping mode. Note: when wheel get into sleeping mode, all LEDs will turn off. 10. Wake up To power again after RF controller sleep, press any or L3, R3 or Start button. Note: If RF pad cannot searching any signal from RF receiver in 30minutes, RF controller will get into sleeping mode again.

Sysgration Ltd. _ 10/F, N.868-3, Chung Cheng Rd., Chung Ho, Taipei, Taiwan Date: 2005/10/08 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Shenzhen office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS SZ, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS SZ on our behalf shall have the same effect as acts of our own. In authorizing CCS SZ as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours,

Sysgration Ltd. ____ _ 10/F, N.868-3, Chung Cheng Rd., Chung Ho, Taipei, Taiwan Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: HQX-D-GP0010SR To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID: HQX-D-GP0010SR LABEL LOCATION Label location

Compliance Certification Services (Shenzhen) Inc. Report No.:SZ051027B02-RP FCC ID: HQX-D-GP0010SR Date of Issue: November11, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 26 Rev. 00 FCC 47 CFR PART 15 Subpart C TEST REPORT For GAMEPAD PS2 RF Model: GP0010SR Trade Name: N/A Issued to SYSGRATION(SHEN ZHEN) CO., LTD. EGONGLING, PINGHU TOWN, LONGGANG DISTRICT, SHENZHEN CITY, GUANGDONG PROVINCE, CHINA Issued by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 6, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No.:SZ051027B02-RP FCC ID: HQX-D-GP0010SR Date of Issue: November11, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION...................................................................................................................5 3.2 EUT EXERCISE...............................................................................................................................5 3.3 GENERAL TEST PROCEDURES........................................................................................................5 3.4 MODIFICATION.............................................................................................................................5 3.5 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS....................................................6 3.6 DESCRIPTION OF TEST MODES......................................................................................................6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES....................................................................................................................................8 5.2 EQUIPMENT...................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING.............................................................................8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT....................................................................................................9 6.2 SUPPORT EQUIPMENT ............................................................................................................9 7. FCC PART 15.249 REQUIREMENTS...................................................................................... 10 7.1 BAND EDGES MEASUREMENT ...........................................................................................10 7.2 SPURIOUS EMISSION ............................................................................................................16 7.3 POWERLINE CONDUCTED EMISSIONS..........................................................................................25 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ....................................................................... 26 Compliance Certification Services (Shenzhen) Inc. Report No.:SZ051027B02-RP FCC ID: HQX-D-GP0010SR Date of Issue: November11, 2005 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: SYSGRATION(SHEN ZHEN) CO., LTD. EGONGLING, PINGHU TOWN, LONGGANG DISTRICT, SHENZHEN CITY, GUANGDONG PROVINCE, CHINA Equipment Under Test: GAMEPAD PS2 RF Tr a d e N a m e : N/A Model: GP0010SR Date of Test: October 27-November 10, 2005 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services (Shenzhen) Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Te s t e d B y : Terry.Yang / Engineer Reviewed By: Clinton. Kao / EMC Manager Eric. Wong/ Assistant manager COMPLIANCE CERTIFICATION COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. SERVICES (SHENZHEN) INC. Compliance Certification Services (Shenzhen) Inc. Report No.:SZ051027B02-RP FCC ID: HQX-D-GP0010SR Date of Issue: November11, 2005 Page 4 Rev. 00 2. EUT DESCRIPTION Product GAMEPAD PS2 RF Trade Name N/A Model Number GP0010SR Model Discrepancy N/A Power Supply Powered by AA batteries (2pcs) Frequency Range 2402 ~ 2480 MHz Modulation Technique FHSS Number of Channels 32 Channels Antenna Specification Multilayer Ceramic Antenna Gain: 0 dBi (max) Remark: This submittal(s) (test report) is intended for FCC ID:HQX-D-GP0010SR filing to comply with Section 15.207, 15.209, 15.249 (FCC Part 15, Subpart C Rules.) Compliance Certification Services (Shenzhen) Inc. Report No.:SZ051027B02-RP FCC ID: HQX-D-GP0010SR Date of Issue: November11, 2005 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in…

Text truncated - open the document above for the full version.

Compliance Certification Services (Shenzhen) Inc. Report No.: SZ051027B02-RP FCC ID: HQX-D-GP0010SR Date of Issue: November11, 2005 Page 26 Rev. 00 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP Radiated Emission Set up Photos
