Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 1 of 55 FCC/IC Radio Test Report FCC ID: HQXAA-SM5PWPB IC: 2831A-AASM5PWPB This report concerns (check one): Original Grant Class II Change Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Jul. 24, 2012 Date of Test: Jul. 24, 2012 ~ Aug. 01, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Issued Date : Aug. 02, 2012 Project No. : 1207C229 Equipment : 2.4GHz Wireless Mouse Model Name : AA-SM5PWPB Applicant : Sysgration Ltd. Address : 10FL.,No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan (R.O.C.) Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 2 of 55 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 3 of 55 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 MEASUREMENT INSTRUMENTS LIST 17 4.2.3 TEST PROCEDURE 18 4.2.4 DEVIATION FROM TEST STANDARD 18 4.2.5 TEST SETUP 19 4.2.6 EUT OPERATING CONDITIONS 20 4.2.7 TEST RESULTS (BELOW 30MHz) 21 4.2.8 TEST RESULTS (BETWEEN 30 – 1000 MHz) 22 4.2.9 TEST RESULTS (ABOVE 1000 MHz) 30 5 . BANDWIDTH TEST 44 5.1 MEASUREMENT INSTRUMENTS LIST 44 5.2 TEST PROCEDURE 44 5.3 DEVIATION FROM STANDARD 44 5.4 TEST SETUP 44 5.5 EUT OPERATION CONDITIONS 44 5.6 TEST RESULTS 45 6 . ANTENNA CONDUCTED SPURIOUS EMISSION 47 6.1 APPLIED PROCEDURES / LIMIT 47 Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 4 of 55 Table of Contents Page 6.1.1 MEASUREMENT INSTRUMENTS LIST 47 6.1.2 TEST PROCEDURE 47 6.1.3 DEVIATION FROM STANDARD 47 6.1.4 TEST SETUP 47 6.1.5 EUT OPERATION CONDITIONS 47 6.1.6 TEST RESULTS 48 7 . EUT TEST PHOTO 53 Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 5 of 55 1. CERTIFICATION Equipment : 2.4GHz Wireless Mouse Brand Name : SAMSUNG Model Name : AA-SM5PWPB Applicant : Sysgration Ltd. Factory : Sysgration(Shenzhen) Ltd. Address : Egongling Village, Pinghu Town, Longgang Dist. Shenzhen City. China Date of Test : Jul. 24, 2012 ~ Aug. 01, 2012 Test Sample : Engineering Sample Standards : FCC Part15, Subpart C(15.249)/ ANSI C63.4 : 2009; Canada RSS-210:2010 ; Canada RSS-Gen:2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FICP-1-1207C229) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 6 of 55 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Canada RSS-Gen:2010 StandardSection FCC RSS-210/ RSS-Gen Test Item Judgment Remark 15.207 RSS-Gen 7.2.2 Conducted Emission - N/A 15.209 RSS-210 2.7 Radiated Emission PASS 15.249 RSS-210 A2.9(a) Radiated Spurious Emission PASS NOTE: (1)”N/A” denotes test is not applicable in this test report. Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 7 of 55 2.1 TEST FACILITY The test facilities used to collect the test data in this report is DG-C01/DG-CB03 at the location of No.3,Jinshagang 1st Road, ShiXia, Dalang Town,Dong Guan, China.523792 Neutron's test firm number for FCC 319330 Neutron's test firm number for IC 4428B-1 2.2 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: The reported uncertainty of measurement y ± U,where expended uncertainty U is based on a standard uncertainty multiplied by a coverage fac…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 53 of 55 7. EUT TEST PHOTO Radiated Measurement Photos 9K-30MHz Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 54 of 55 Radiated Measurement Photos 30M~1000MHz Neutron Engineering Inc. Report No.: NEI-FICP-1-1207C229 Page 55 of 55 Radiated Measurement Photos Above 1000MHz
