HQXAKM-020Metallic Thin-Profile Wireless Keyboard

2.4G Wireless KB Users’ Guide Installation 1. Plug the receiver into a USB port on your computer. 2. Insert battery into the keybroad. 3. This keybroad. provides factory default ID and so the link will be set up after a while. 4. Click the keybroad.key and her response will be read on the monitor. Trouble Shooting 1. No connection between the keybroad.. and the receiver. Re-insert the receiver. Try to insert receiver to another USB port on your computer. 2. No any response on the mouse. Take out the battery from the keybroad..and reinstall it with correct orientation. Try a new battery if necessary. Note: FCC statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on. The user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). FCC Compliance This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment.

Neutron Engineering Inc. Project No.: 1002C113 Page 2 of 19 AKM-020(104KEY) 1002C113 1002C113 Neutron Engineering Inc. Project No.: 1002C113 Page 2 of 19 AKM-020(104KEY) 1002C113 1002C113 Neutron Engineering Inc. Project No.: 1002C113 Page 11 of 19 AKM-020(105KEY) 1002C113 1002C113 Neutron Engineering Inc. Project No.: 1002C113 Page 11 of 19 AKM-020(105KEY) 1002C113 1002C113

AKM-020 Metallic Thin-Profile Wireless Keyboard RATING: 3V - - -, 15mA WK XX XX WK XX XX This device complies with Part 15 of the FCC Rules FCC ID:HQXAKM-020 ID ConnectID Connect 0560 AKM-020 Metallic Thin-Profile Wireless Keyboard RATING: 3V - - -, 15mA WK XX XX WK XX XX This device complies with Part 15 of the FCC Rules FCC ID:HQXAKM-020 ID ConnectID Connect 0560 ID ConnectID Connect 98134 Metallic Thin-Profile Wireless Keyboard Rev.S1 RATING: 3V - - -, 15mA WK XX XX WK XX XX This device complies with Part 15 of the FCC Rules FCC ID:HQXAKM-020 0560 ID ConnectID Connect 98134 Metallic Thin-Profile Wireless Keyboard Rev.S1 RATING: 3V - - -, 15mA WK XX XX WK XX XX This device complies with Part 15 of the FCC Rules FCC ID:HQXAKM-020 0560

Neutron Engineering Inc. AKM-020(104KEY) IC-A7105(Package) 1002C113 Neutron Engineering Inc. 1002C113 Project No.: 1002C113 Page 4 of 19 1002C113 Neutron Engineering Inc. 1002 C 113 Project No.: 1002C113 Page 5 of 19 1002C113 Neutron Engineering Inc. 1002C113 Project No.: 1002C113 Page 8 of 19 1002C113 AKM-020(104KEY) IC-A7105(Dice) Neutron Engineering Inc. 1002C113 AKM-020(105KEY) IC-A7105(Package) Neutron Engineering Inc. 1002C113 AKM-020(105KEY) IC-A7105(Dice) Project No.: 1002C113 Page 13 of 19 1002C113

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 2 of 48 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutronshall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 3 of 48 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 MEASUREMENT INSTRUMENTS LIST 17 4.2.3 TEST PROCEDURE 19 4.2.4 DEVIATION FROM TEST STANDARD 19 4.2.5 TEST SETUP 20 4.2.6 EUT OPERATING CONDITIONS 21 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHz) 22 4.2.8 TEST RESULTS (ABOVE 1000 MHz) 24 4.2.9 SUMMARY OF TEST RESULTS OF FUNDAMENTAL FREQUENCIES (2400 – 2483.5MHz) 36 4.2.10 TEST RESULTS (Restricted Bands Requirements) 37 5 . BANDWIDTH TEST 41 5.1 MEASUREMENT INSTRUMENTS LIST 41 5.2 TEST PROCEDURE 41 5.3 DEVIATION FROM STANDARD 41 5.4 TEST SETUP 41 5.5 EUT OPERATION CONDITIONS 41 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 4 of 48 Table of Contents Page 5.6 TEST RESULTS 42 6 . ANTENNA CONDUCTED SPURIOUS EMISSION 44 6.1 APPLIED PROCEDURES / LIMIT 44 6.1.1 MEASUREMENT INSTRUMENTS LIST 44 6.1.2 TEST PROCEDURE 44 6.1.3 DEVIATION FROM STANDARD 44 6.1.4 TEST SETUP 44 6.1.5 EUT OPERATION CONDITIONS 45 6.1.6 TEST RESULTS 46 7 . EUT TEST PHOTO 48 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 5 of 48 1. CERTIFICATION E q u i p m e n t : Metallic Thin-Profile Wireless Keyboard Trade Name : Sysgration Model Name. : AKM-020 A p p l i c a n t : Sysgration Ltd. F a c t o r y : Sysgration (shenzhen) Ltd. A d d r e s s : Egongling Village, Pinghu Town, Longgang Dist, Shenzhen city, China Date of Test : Feb. 24, 2010 ~ Mar. 08, 2010 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.249)/ ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1002C113) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Test result included in this report is only for the Keyboard part of the product. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 6 of 48 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark 15.207 Conducted Emission - N/A 15.209 Radiated emission PASS 15.249 Radiated Spurious Emission PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) The EUT used new battery. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 7 of 48 2.1 TEST FACILITY The test facilities used to collect the test data in this report is CB03 at the location of No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China.523792 Neutron's test firm number is 319330 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE C01 ANSI150 KHz ~ 30MHz 1.94 B. Radiated Measurement : Test Site Method Measurement Frequency Range Ant. H / V U，(dB) NOTE CB03 ANSI30MHz ~ 200MHz V 3.82 30MHz ~ 200MHz H 3.60 200MHz ~ 1,000MHz V 3.86 200MHz ~ 1,000MHz H 3.94 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 8 of 48 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT Equipment Metallic Thin-Profile Wireless Keyboard Trade Name Sysgration Model Name. AKM-020 OEM Brand/Model Name GE/98134 Model Difference They are same product, but different customers use different brands and models. Product Description The EUT is a Metallic Thin-Profile Wireless Keyboard. Product Type Low Power Communication Device Operation Frequenc…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 48 of 48 7. EUT TEST PHOTO Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1002C113 Page 48 of 48 7. EUT TEST PHOTO Radiated Measurement Photos
