HQXAKM-022SWireless Keyboard

Sysgration Ltd.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Sep 06, 2012
Application Purpose: Original Equipment
Date of Application: Sep 06, 2012
Equipment Note: Wireless Keyboard
Frequency Range: 2405.00000000 - 2476.00000000
Company: Sysgration Ltd.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

��  ��  ��  �� …

Text truncated - open the document above for the full version.

Cover Letter(s)

Sysgration Ltd. 10FL No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 235 Taiw an FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Sysgration Ltd. Addresss 10FL No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 235 Taiwan City Taiwan Country FF request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: HQX AKM-022S of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Taiw an September 5, 2012 Paul Huang Manager

Cover Letter(s)

Sysgration Ltd. 10FL No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 235 Taiw an FCC Authorization Letter Number: CF304 Version: V01 Date: 26-06-2012 . We, (the approval holder) Company name Sysgration Ltd. Addresss 10FL No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 235 Taiwan City Taiwan Country declare that the following representative (agent): Name (person) Aven zhou Function Supervisor Company name Compliance Certification Services (Shenzhen) Inc. Addresss No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Wirless Keyboard Type or Model(s) K20G / 98614, 98615 Tradename or Brand(s) Sysgration / GE We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Taiw an September 5, 2012 Paul Huang Manager

External Photos

Report No.: C120821Z08-RP1 Page 1/3 Report No.: C120821Z08-RP1 Page 2/3 . Report No.: C120821Z08-RP1 Page 3/3 .

ID Label/Location Info

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

Report No.: C120821Z08-RP1 Page 1/3 Report No.: C120821Z08-RP1 Page 2/4 . Report No.: C120821Z08-RP1 Page 3/4 . Report No.: C120821Z08-RP1 Page 4/4 .

Test Report

Report No: C120821Z08-RP1 FCC ID: HQXAKM-022S Page 1/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C for Wireless Keyboard Model: K20G / 98614, 98615 Brand: Sysgration / GE Test Report Number: C120821Z08-RP1 Issued for Sysgration Ltd. 10FL No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 235 Taiwan Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: August 31, 2012 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. Report No: C120821Z08-RP1 FCC ID: HQXAKM-022S Page 2/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 C120821Z08-RP Initial Issue ALL Ruby Zhang Report No: C120821Z08-RP1 FCC ID: HQXAKM-022S Page 3/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ...........................................................................................4 2 EUT DESCRIPTION.................................................................................................5 3 TEST METHODOLOGY...........................................................................................6 3.1. DESCRIPTION OF TEST MODES.......................................................................................6 4 TEST METHODOLOGY...........................................................................................7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS............................................7 5 INSTRUMENT CALIBRATION ................................................................................8 6 SETUP OF EQUIPMENT UNDER TEST .................................................................8 6.1. DESCRIPTION OF SUPPORT UNITS .................................................................................8 6.2. CONFIGURATION OF SYSTEM UNDER TEST..................................................................8 7 FACILITIES AND ACCREDITATIONS ....................................................................9 7.1. FACILITIES ..........................................................................................................................9 7.2. ACCREDITATIONS ..............................................................................................................9 7.3. MEASUREMENT UNCERTAINTY .......................................................................................9 8 FCC PART 15.249 REQUIREMENTS ...................................................................10 8.1. BAND EDGES MEASUREMENT .......................................................................................10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT ...........................................12 8.3. SPURIOUS EMISSIONS MEASUREMENT .......................................................................19 Report No: C120821Z08-RP1 FCC ID: HQXAKM-022S Page 4/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product Wireless Keyboard Model K20G / 98614, 98615 Brand Sysgration / GE Tested August 21~31, 2012 Applicant Sysgration Ltd. 10FL No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 235 Taiwan Manufacturer Sysgration (Shenzhen) Ltd. Egongling Village, Pinghu Town, Longgang Dist. Shenzhen City. China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No: C120821Z08-RP1 FCC ID: HQXAKM-022S Page 5/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product Wireless Keyboard Model Number K20G / 98614, 98615 Trade Name Sysgration / GE Model Discrepancy All models are identical to each other, except the brand name and the model name are different. 1. The brand name of the model K20G is Sysgration; 2. The brand name of the model 98614, 98615 is GE. Identify Number C120821Z08-RP1 Power Supply DC3V supplied by the battery Frequency Range 2405-2476 MHz Transmit Power Peak: 82.57dBuV/m (Max.) Average: 71.16dBuV/m (Max.) Modulation Technique GFSK Number of Channels 64 Channels Antenna Specification PCB Antenna with 2.0dBi gain(MAX) Temperature Range 0°C ~ +40°C Note: 1. The sample selected for test was engineering sample that approximated to production p…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: C120821Z08-RP1 FCC ID: HQXAKM-022S Page 1/1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST Below 1GHz Above 1GHz
