HQXAKM-031SWireless 2.4G Keyboard

AKM-031S User’s Guide Thank you for selecting this compact slim wireless keyboard set model: AKM-031S. This keyboard supports Windows and Mac operating systems, and her Plug and Play feature with all hot keys ensures you convenience and joy. Compatibility Windows XP, Windows Vista, Windows 7, Mac 10.3 or later version Requirement: Interface : USB port Contents 1. One keyboard 2. User’s Guide 3. Nano Receiver 4. 2 x AAA batteries for keyboard Installation 1 Connecting receiver to PC (i) Plug the USB receiver into the USB port of your PC. (ii) Under Win 2000 or higher, OS will detect the new RF device automatically. 2 Insert the batteries with correct orientation into the battery compartments of keyboard . 3 This wireless keyboard set provides factory preset connection channels and enables Plug and Play function. Note: 1. This keyboard set does not require to change connection ID as there is no ID button on the nano receiver. 2. When this wireless set encounters radio interference, either keyboard will automatically change to clean channel respectively. Manually changing connection ID is not necessary. This AKB-031S keyboard is 104 keys keyboard structure with hot keys function. AKB-031S Key Designation Hot keys Notes 1). Please do not use the mouse on wed surface. 2). Please do not insert any articles into the mouse and keyboard. 3). Please do not aim the invisible laser light of the mouse at any eyes of living beings under any circumstances, as it might cause danger. 4). Do not press numerous keys on the keyboard at the same time or place any object on it. Trouble Shooting: A. When the keyboard and mouse don’t respond, first check if the receiver is firmly and correctly plug to the USB port of the PC. Reconnect it if required. B. If either of the keyboard or mouse doesn’t respond, check the battery power status, and if batteries are power down replace with new ones. C. Carefully insert the batteries with correct orientation into the battery compartments. D. Beware not to star into the invisible laser light output whenever observing the mouse function. E. When upper methods fail to bring back normal functions, please seek for maintenance support as below: Maintenance Support When the keyboard or mouse encounters failure, please seek maintenance support from customer service hotline. Dismantling of the unit is prohibited. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condition: 1. This device may not cause harmful interference, and; 2. This device must accept any interference received, including interference that may cause undesired operation.

Sysgration Ltd. 10FL, NO.868-3, Chung Rd, Chung Ho, Taipei, Taiwan, R.O.C. FCC Authorization Letter Number: CF304 Version: V01 Date: 01-02-2010 . We, (the approval holder) Company name Sysgration Ltd. Addresss 10FL, NO.868-3, Chung Rd, Chung Ho, City Taipei, Taiwan, R.O.C. Country declare that the following representative (agent): Name (person) Aven zhou Function Supervisor Company name Compliance Certification Services (Shenzhen) Inc. Addresss No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Wireless 2.4G Keyboard Type or Model(s) AKM-031S, CKB-260B, CKB-260W Tradename or Brand(s) Sysgration (For the models: AKM-031S,); Samsung, PLEOMAX (For the model : CKB-260B, CKB-260W); We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) New Taipei, Taiwan, R.O.C. November 22, 2011 Paul Huang Manager

Sysgration Ltd. 10FL, NO.868-3, Chung Rd, Chung Ho, Taipei, Taiwan, R.O.C. FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Sysgration Ltd. Addresss 10FL, NO.868-3, Chung Rd, Chung Ho City Taipei, Taiwan, R.O.C. Country request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: HQX AKM-031S of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) NewTaipei, Taiwan, November 22, 2011 Paul Huang Manager

Report No: SZ111027B02-RP Page 1 / 3 Report No: SZ111027B02-RP Page 2 / 3 Report No: SZ111027B02-RP Page 3 / 3

AKM-031S Metallic Thin-Profile Wireless Keyboard RATING3V---,5mA FCC IDHQXAKM-031S MADE IN CHINA 2953

Report No.: SZ111027B02-RP Page 1 / 4 Internal Photos of EUT Report No.: SZ111027B02-RP Page 2 / 4 Report No.: SZ111027B02-RP Page 3 / 4 Report No.: SZ111027B02-RP Page 4 / 4

Report No: SZ111027B02-RP FCC ID: HQXAKM-031S Page 1 of 26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC TEST REPORT for Wireless 2.4G Keyboard Model: AKM-031S / CKB-260B, CKB-260W Brand: Sysgration / Samsung, PLEOMAX Test Report Number: SZ111027B02-RP Issued for Sysgration Ltd. 10FL, NO.868-3, Chung Rd., Chung Ho, Taipei, Taiwan, R.O.C. Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: November 4, 2011 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. 检 测 CNAS L4818 Report No: SZ111027B02-RP FCC ID: HQXAKM-031S Page 2 of 26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ111027B02-RP Initial Issue ALL Ruby Zhang Report No: SZ111027B02-RP FCC ID: HQXAKM-031S Page 3 of 26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ...........................................................................................4 2 EUT DESCRIPTION.................................................................................................5 3 TEST METHODOLOGY...........................................................................................6 3.1. DESCRIPTION OF TEST MODES.......................................................................................6 4 TEST METHODOLOGY...........................................................................................7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS............................................7 5 INSTRUMENT CALIBRATION ................................................................................8 6 SETUP OF EQUIPMENT UNDER TEST .................................................................8 6.1. DESCRIPTION OF SUPPORT UNITS .................................................................................8 6.2. CONFIGURATION OF SYSTEM UNDER TEST..................................................................8 7 FACILITIES AND ACCREDITATIONS ....................................................................9 7.1. FACILITIES ..........................................................................................................................9 7.2. ACCREDITATIONS ..............................................................................................................9 7.3. MEASUREMENT UNCERTAINTY .......................................................................................9 8 FCC PART 15.249 REQUIREMENTS ...................................................................10 8.1. BAND EDGES MEASUREMENT .......................................................................................10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT ...........................................12 8.3. SPURIOUS EMISSIONS MEASUREMENT .......................................................................19 Report No: SZ111027B02-RP FCC ID: HQXAKM-031S Page 4 of 26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product Wireless 2.4G Keyboard Model AKM-031S / CKB-260B, CKB-260W Brand Sysgration / Samsung, PLEOMAX Tested October 27~ November 4, 2011 Applicant Sysgration Ltd. 10FL, NO.868-3, Chung Rd., Chung Ho, Taipei, Taiwan, R.O.C. Manufacturer Sysgration (Shenzhen) Ltd. Egongling Village, Pinghu Town, Longgang Dist. Shenzhen City. China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No: SZ111027B02-RP FCC ID: HQXAKM-031S Page 5 of 26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product Wireless 2.4G Keyboard Model Number AKM-031S / CKB-260B, CKB-260W Trade Name Sysgration / Samsung, PLEOMAX Model Discrepancy The same product with different model names and trade names for the marketing purpose. Serial Number SZ111027B02-RP Power Supply DC3V supplied by the battery Frequency Range 2405-2476MHz Transmit Power Peak: 84.53 dBuV/m (Max.) Average: 59.91 dBuV/m (Max.) Modulation Technique GFSK Number of Channels 64 Channels Antenna Specification PCB Antenna with 2.02 dBi gain（MAX) Temperature Range 0°C ~ +40°C Note: 1. The sample selected for test was engineering sample that approximated to production product and was provide…
