HQXAPT-N52.4G Wireless Presenter

Wireless Presenter Users’ guide Installation 1. Plug the receiver into a USB port of your computer. 2. Insert battery into wireless presenter 3. Click the presenter key to get connected with the receiver. Trouble Shooting 1. Check receiver connection; try to inserting receiver to another USB port on your computer. 2. No Connection between the wireless presenter and the Receiver. Re-insert the Receiver. take out the battery from the wireless presenter and reinstall it. Note: FCC statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on. The user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment. Power Supply DC 3V supplied by the battery Frequency Range 2412-2472MHz Modulation Technique GFSK Number of Channels 5 Channels

Sysgration Ltd. Federal Communications Commission Authorization and Evaluation Division FCC ID : HQXAPT-N5 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description 4. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Narnflitle: Paul Huang / ~arh~er Applicant: S ysgration Ltd ADDRESS: lOFL No. 868-3, Zhongzheng Rd.,Zhonghe Dist., New Taipei City, 235 TaiwanJ2.O.C. TEL: 886-2-8221-71 11 ext:215 FAX: 886-2-8221-1775 Email: paulhuang @ sysgration.com

Sysgration Ltd. March 21,2011 FCC ID : HQXAPT-N5 Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Compliance Certification Services Inc. Address: no lo-1, Mingkeda Logistics Park, No. 18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China Name: Aven Zhou Job Title: Supervisor Email: aven.zhou @ ccsrf.com I am therefore responsible for the contents of the application. Brand Name and Model Name of the specified radio equipment: Sysgration , Acer / AFT-N5,APOl B FCC ID: HQXAPT-N5 Product Name: 2.4G Wireless Presenter U Name~Title: Paul Huang / Manager Applicant: Sysgration Ltd A ADDRESS: lOFL No. 868-3, Zhongzheng Rd.,Zhonghe Dist., New Taipei City, 235 Taiwan,R.O.C. TEL: 886-2-8221-71 1 1 ext:215 FAX: 886-2-8221-1775 Email: paulhuang @ sysgration.com

Report No.: SZ110129B02 Page 1 / 3 TX Report No.: SZ110129B02 Page 2 / 3 Report No.: SZ110129B02 Page 3 / 3

Model: APT-N5 FCC ID: HQXAPT-N5 RATING3V- - -,20mA CLASS 2 LASER PRODUCT MADE IN CHINA LC.OTH0A.008106000015300 Model: AP01B FCC ID:HQXAPT-N5 CLASS 2 LASER PRODUCT RATING: 3V- - -, 20mA

Report No: SZ110129B02 Page 1 / 2 Report No: SZ110129B02 Page 2 / 2

Report No.: SZ110129B02-RP FCC ID : HQXAPT-N5 Page 1 / 26 FCC TEST REPORT for 2.4G Wireless Presenter Model: APT-N5/AP01B Brand: Sysgration/Acer Test Report Number: SZ110129B02-RP Issued for Sysgration Ltd. 10FL.,NO.868-3,Zhongzheng Rd., Zhonghe Dist, New Taipei City, 235 Taiwan,R.O.C Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: February 21, 2011 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. 检 测 CNAS L4818 Report No.: SZ110129B02-RP FCC ID : HQXAPT-N5 Page 2 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ110129B02-RP Initial Issue ALL Vincent Yao Report No.: SZ110129B02-RP FCC ID : HQXAPT-N5 Page 3 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION........................................................................................... 4 2 EUT DESCRIPTION................................................................................................ 5 3 TEST METHODOLOGY .......................................................................................... 6 3.1. DESCRIPTION OF TEST MODES ...................................................................................... 6 4 TEST METHODOLOGY .......................................................................................... 7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................... 7 5 INSTRUMENT CALIBRATION ............................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ................................................................ 8 6.1. DESCRIPTION OF SUPPORT UNITS................................................................................. 8 6.2. CONFIGURATION OF SYSTEM UNDER TEST ................................................................. 8 7 FACILITIES AND ACCREDITATIONS ................................................................... 9 7.1. FACILITIES .......................................................................................................................... 9 7.2. ACCREDITATIONS ............................................................................................................. 9 7.3. MEASUREMENT UNCERTAINTY....................................................................................... 9 8 FCC PART 15.249 REQUIREMENTS................................................................... 10 8.1. BAND EDGES MEASUREMENT....................................................................................... 10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT........................................... 16 8.3. SPURIOUS EMISSIONS MEASUREMENT....................................................................... 19 Report No.: SZ110129B02-RP FCC ID : HQXAPT-N5 Page 4 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product: 2.4G Wireless Presenter Model: APT-N5/AP01B Brand: Sysgration/Acer Tested: February 9~18,2011 Applicant: Sysgration Ltd. 10FL.,NO.868-3,Zhongzheng Rd., Zhonghe Dist, New Taipei City, 235 Taiwan,R.O.C Manufacturer: Sysgration(Shenzhen) Ltd. Egongling Village, Pinghu Town, Longgang Dist. Shenzhen City.China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Vincent Yao Manager Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No.: SZ110129B02-RP FCC ID : HQXAPT-N5 Page 5 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product 2.4G Wireless Presenter Trade Name APT-N5/AP01B Model Number Sysgration/Acer Model Discrepancy All models are identical to each other except for market designation for marketing purpose. Serial Number SZ110129B02-RP Power Supply DC 3V supplied by the battery Received Date February 18, 2011 Frequency Range 2412-2472MHz Transmit Power Peak:72.03dBuV/m (Max.) Average:23.50 dBuV/m (Max.) Modulation Technique GFSK Number of Channels 5 Channels Antenna Specification PCB Antenna with 2.12dBi gain（MAX) Temperature Range 0°C ~ +45°C Note: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: HQXAPT-N5 filing to comply with Section 15.207, 15.209 and 15.249 of the FCC Part 15, Subpart C Rul…

Text truncated - open the document above for the full version.

Report No.: SZ110129B02 Page 1 / 1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
