Remote Controller User Guide Introduction Thank you for your purchase of the luetooth Media Remote for iPad. This remote uses Bluetooth technology which provides a seamless connection up to 32 feet (10m) away. This remote is iPad and Mac OS compatible. Its compact size is ideal for portability and travel. Contents • Bluetooth Media Remote • 1 x AAA Energizer® MAX® Batteries • User Guide System Requirements Hardware • iPod • iPhone • iPad • Mac Bluetooth enabled device Operating System • Mac OS X v10.4 or later Installing the Batteries 1 Remove the battery cover located on the bottom of the remote. 2 Insert the supplied battery, making sure that the positive (+) and negative (-) end matches the polarity indicators inside the battery compartment. Establishing the Connection 1. Turn on the remote by sliding the power button to the ON position. 2. Switch ON the Bluetooth function of your iPad. 3. Press the Connect button inside the battery compartment of your Bluetooth Media Remote to enable discovery mode. The low power indicator light will flash blue when the remote is in discovery mode. 4. Once the remote is listed as a found device in the bluetooth menu on the iPad, tap on the name and you will be prompted to enter a pass key as shown. “Bluetooth Media Remote” would 5. Use the number buttons in the battery compartment of your remote to enter the passkey shown on the pop up message, followed by the enter key. 6. Bluetooth Media Remote for iPad is now connected with your iPad and the blue light on the front of the remote will stop flashing. Keys and Functions Buttons Definition (default) Button 1 2 3 4 5 Definition “0-9” buttons “ENTER” buttons ID buttons Volume- Prev-track buttons Button 6 7 8 9 10 Definition Next-track buttons Volume+ Play/Pause buttons s Home-Btn button Power button Bluetooth Connection: Mac 1. Go to the Bluetooth icon located on your desktop or in the system bar and click the icon to begin setup. Select “Turn Bluetooth On” to activate the Bluetooth function on your Mac. 2. Scroll down the list and select “Set up Bluetooth Device...” 3. The Bluetooth Setup Assistant will begin. Please follow the on-screen instructions. 4. Select “Bluetooth Media Remote” and click continue to proceed with setup. Your remote will need to be in “discovery” mode to connect. 5. Press the Connect button on the back of your Bluetooth Media Remote to enable discovery mode. The low power indicator light will flash blue when the remote is in discovery mode. 6. Your computer will begin to search for the remote. Once the remote is found, it will show up in the list. Highlight “Bluetooth Media Remote” and press continue. 7. The remote will now begin pairing. Click continue to proceed. 8. Congratulations. Your Bluetooth Media Remote is setup and ready to use. You can choose to set up another device or click Quit to exit setup. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Sysgration Ltd. 10FL, NO.868-3, Chung Rd, Chung Ho, Taipei, Taiwan, R.O.C. FCC Authorization Letter Number: CF304 Version: V01 Date: 01-02-2010 . We, (the approval holder) Company name Sysgration Ltd. Addresss 10FL, NO.868-3, Chung Rd, Chung Ho, City Taipei, Taiwan, R.O.C. Country declare that the following representative (agent): Name (person) Aven zhou Function Supervisor Company name Compliance Certification Services (Shenzhen) Inc. Addresss No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Bluetooth Remote Control Type or Model(s) APT-N8, APT-N9, 106317, 00095 Tradename or Brand(s) Sysgration (For the models: APT-N8, APT-N9); Hama (For the model : 106317); TUMI (For the model: 00095) We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process (sign and apply) for this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Taipei, Taiwan, R.O.C. October 11, 2011 Paul Huang Manager

Sysgration Ltd. 10FL, NO.868-3, Chung Rd, Chung Ho, Taipei, Taiwan, R.O.C. FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Sysgration Ltd. Addresss 10FL, NO.868-3, Chung Rd, Chung Ho City Taipei, Taiwan, R.O.C. Country request non- di sclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: HQX APT-N9 of the following materials submitted wit h in this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Taipei, Taiwan, R.O.C. October 11, 2011 Paul Huang Manager

Report No: SZ110926B04-RP Page 1 / 6 APT-N8, 106317 Report No: SZ110926B04-RP Page 2 / 6 Report No: SZ110926B04-RP Page 3 / 6 Report No: SZ110926B04-RP Page 4 / 6 APT-N9, 00095 Report No: SZ110926B04-RP Page 5 / 6 Report No: SZ110926B04-RP Page 6 / 6

JASCO(TUMI) Sysgration Model: APT-N9 FCC ID:HQXAPT-N9QDID:B011073 RATING:1.5V---,30mA Model: 00095 FCC ID:HQXAPT-N9QDID:B011073 RATING:1.5V---,30mA

Report No: SZ110926B04-RP Page 1 / 5 Internal Photos of EUT APT-N8, 106317 APT-N9, 00095 Report No: SZ110926B04-RP Page 2 / 5 Report No: SZ110926B04-RP Page 3 / 5 Report No: SZ110926B04-RP Page 4 / 5 Report No: SZ110926B04-RP Page 5 / 5

1 1 2 2 3 3 4 4 DD CC BB AA Title NumberRevisionSize A4 Date:2011/5/12Sheet of File:E:\WINDOWS\..\RM01-B-v01.schDrawn By: P0_0 28 P0_1 40 P0_2 36 P0_3 39 P0_4 31 P0_5 30 P0_6 33 P0_7 32 P1_0 44 P1_1 45 P1_2 6 P1_3 9 P1_4 5 P1_5 26 P1_6 19 P1_7 17 P2_0 8 P2_1 7 P2_2 20 P2_3 25 P2_4 22 P2_5 37 P2_6 42 P2_7 41 GND 47 GND 18 GND 2 GND 1 P3_0 29 P3_1 24 P3_2 11 P3_3 12 P3_4 15 P3_5 16 P4_0 14 P4_1 10 P4_2 43 P4_3 4 P4_4 3 P4_5 46 RESET 38 UP_RX 35 UP_TX 34 VBATT 21 3PV0_1 13 3PV0 27 1P8V_1 23 U1 BPM20422 ROW_00 ROW_01 ROW_02 ROW_03 ROW_04 ROW_05 ROW_06 ROW_07 COL_00 COL_01 COL_02 COL_03 COL_04 COL_05 COL_06 COL_07 COL_08 COL_09 COL_10 COL_11 COL_12 COL_13 COL_14 COL_15 D1 Pairing LED R6330R C2 2.2uF VCC3V VCC2.7V UP_TX UP_RX RESET E_ZB E_ZA GPIO_2 VBAT GPIO_1 GPIO_0 COL_16 COL_17 COL_18 COL_19 VCC3V 1 2 3 4 J1 CON4 UP_TX UP_RX C1 4.7uF R2 10K VCC3V 1 2 3 S1 CON3 VBAT BT1 D3 D-4148 123 Vout=2.7V GND Vi 3 Vo 2 GND 1 U3 IC-CE8301 L1100uH C6 0.1uF + C3 68uF C5 0.1uF + C4 100uF VCC2.7V Vi C Vo E GND B U2 2.7V Reset IC R310R C7 0.1uF RESET SW1home_btn SW3Prey_Track SW5NEXT_Track SW2VOL- SW4Play/pause SW6VOL+ COL_00 COL_01 COL_02 COL_03 COL_04 COL_05 VBAT R40R R5NC VCC3V ROW_00ROW_00 SW7Enter SW8key_0 SW9key_1 COL_00 COL_01 COL_02 ROW_01 SW10Key_2 SW11key_3 SW12key_4 COL_03 COL_05 COL_04 ROW_01 SW13Key_5 SW14key_6 SW15key_7 COL_00 COL_02 COL_01 ROW_02 SW16Key_8 SW17key_9 SW18Pair key COL_03 COL_05 COL_04 ROW_02 RM01-B Reference design R7330R D2 Pairing LED 55 44 33 22 11 D D C C B B A A 1P5VC 1P5VA 1P5VA 1P5VA 1P5VREG1 1P5VC 1P8V_1 TitleSize Document Number Rev Date: Sheet of V1 Thursday, May 27, 2010 BCM92042MDX-B88--- RF 34 TitleSize Document Number Rev Date: Sheet of V1 Thursday, May 27, 2010 BCM92042MDX-B88--- RF 34 TitleSize Document Number Rev Date: Sheet of V1 Thursday, May 27, 2010 BCM92042MDX-B88--- RF 34 Broadcom Proprietary & Confidential Note: Antenna matching network.Replace LC1=2.7pF formodule only antennamatching. Note:"Pi" harmonic filterfor 2nd and 3rdharmonic +/- 0.1pF +/- 0.1pF Note:Place ground viaas close to pinF1 as possible Note:Place C40 as closeto pin D1 aspossible note: for 10pF crystal thematching caps values are--C29=12pF and C28=15pF C33 0_01uF C33 0_01uF L5120@100MHz 0402L5120@100MHz 0402 C31 4_7uF C31 4_7uF C84_7uFC84_7uF R12 150K R12 150K LC2TBDLC2TBD C34 0_01uF C34 0_01uF Y224MHz_12pFY224MHz_12pF 1 3 24 C403_9pFC403_9pF C37470pFC37470pF C164_7uFC164_7uF C50TBDC50TBD LC12_7pFLC12_7pF TP2DONUT140_80TP2DONUT140_80 1 C74_7uFC74_7uF L6 120@100MHz 0402 L6 120@100MHz 0402 C36 1_2pF C36 1_2pF LC3TBDLC3TBD C2918pFC2918pF C32 0_01uF C32 0_01uF U5B BCM2042_88 PIN_1 U5B BCM2042_88 PIN_1 RFION E1 VDDRF B1 VDDPLL G2 RES G4 VDDR3V A3 VCTRIFP H2 XTAL_IN J3 XTAL_OUT J2 GND F1 VDDTF C1 RFIOP D1 VDDXO J1 VDDVCO G1 GND E2 GND D2 GND C2 GND B2 VDDLO F2 VDDIFP H1 VREG2 A1 VREG1 A2 TST1 F3 GND G3 GND H3 C35 0_01uF C35 0_01uF C2820pFC2820pF L4BEAD0603L4BEAD0603 LC55_6pFLC55_6pF A2 INV_F_ANTENNA_3 A2 INV_F_ANTENNA_3 1 2

Report No: SZ110926B04-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. FCC ID: HQXAPT-N9 Page 1 of 42 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C TEST REPORT For Bluetooth Remote Control Model: APT-N8, APT-N9, 106317, 00095 Brand: Sysgration (For the models: APT-N8, APT-N9); Hama (For the model : 106317); TUMI (For the model: 00095) Test Report Number: SZ110926B04-RP Prepared for Sysgration Ltd. 10FL, NO.868-3, Chung Rd, Chung Ho, Taipei, Taiwan, R.O.C. Prepared by Compliance Certification Services (Shenzhen) Inc. No.10-1 Mingkeda Logistics park, No.18 Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: October 8, 2011 检 测 CNAS L4818 Report No: SZ110926B04-RP FCC ID: HQXAPT-N9 Page 2 of 42 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ110926B04-RP Initial Issue ALL Ruby Zhang Report No: SZ110926B04-RP FCC ID: HQXAPT-N9 Page 3 of 42 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.............................................................................................. 4 2. EUT DESCRIPTION..................................................................................................................... 5 3. TEST METHODOLOGY.............................................................................................................. 6 3.1 DESCRIPTION OF TEST MODES ............................................................................................. 6 4. FACILITIES AND ACCREDITATIONS..................................................................................... 7 4.1 FACILITIES................................................................................................................................. 7 4.2 ACCREDITATIONS ................................................................................................................... 7 4.3 MEASUREMENT UNCERTAINTY........................................................................................... 7 5. SETUP OF EQUIPMENT UNDER TEST.................................................................................. 8 5.1 SETUP CONFIGURATION OF EUT........................................................................................... 8 5.2 SUPPORT EQUIPMENT ........................................................................................................... 8 6. FCC PART 15.247 REQUIREMENTS....................................................................................... 9 6.1 20DB BANDWIDTH ................................................................................................................... 9 6.2 PEAK POWER ...........................................................................................................................12 6.3 PEAK POWER SPECTRAL DENSITY .................................................................................... 14 6.4 BAND EDGES MEASUREMENT ............................................................................................ 15 6.5 FREQUENCY SEPARATION .................................................................................................. 21 6.6 NUMBER OF HOPPING FREQUENCY .................................................................................. 23 6.7 TIME OF OCCUPANCY (DWELL TIME) ............................................................................... 25 6.8 SPURIOUS EMISSIONS ........................................................................................................... 29 6.9 POWER LINE CONDUCTED EMISSIONS ............................................................................. 41 Report No: SZ110926B04-RP FCC ID: HQXAPT-N9 Page 4 of 42 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST RESULT CERTIFICATION Product: Bluetooth Remote Control Model: APT-N8, APT-N9, 106317, 00095 Brand: Sysgration (For the models: APT-N8, APT-N9); Hama (For the model : 106317); TUMI (For the model: 00095) Tested: June 13~July 5, 2011 Applicant: Sysgration Ltd. 10FL, NO.868-3, Chung Rd, Chung Ho, Taipei, Taiwan, R.O.C. Manufacturer: Sysgration (Shenzhen) Ltd. Egongling Village, Pinghu Town, Longgang Dist. Shenzhen City. China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No: SZ110926B04-RP FCC ID: HQXAPT-N9 Page 5 of 42 This report shall not be reproduced except in full, without the written approval of Compliance Certificati…
