HQXAXM-913P2.4G Wireless mouse

2.4G Wireless Mouse and Receiver Users’ Guide Installation 1. Plug the receiver into a USB port on your computer. 2. Insert battery into the mouse. 3. This mouse provides factory default ID and so the link will be set up after a while. 4. Click the mouse key and her response will be read on the monitor. Trouble Shooting 1. No connection between the mouse and the receiver. Re-insert the receiver. Try to insert receiver to another USB port on your computer. 2. No any response on the mouse. Take out the battery from the mouse and reinstall it with correct orientation. Try a new battery if necessary. Note: FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of FCC RF Rules. Operation is subject to the following two conditions: 1) This device may not cause interference and 2) This device must accept any interference, including interference that may cause undesired operation of the device. Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment.

Neutron Engineering Inc. Project No.: 1003C031 Page 2 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 2 of 8 1003C031 1003C031

42.3 24.1 30.8 AXM-913P Changeable Color Clip Mouse FOR HOME OR OFFICE USEFOR HOME OR OFFICE USE RATING: 3V- - -, 20mA FCC ID：HQXAXM-913P 10.18 4.36 R07-M AXM-913P Changeable Color Clip Mouse FOR HOME OR OFFICE USEFOR HOME OR OFFICE USE RATING: 3V- - -, 20mA FCC ID：HQXAXM-913P R07-M 42.3 24.1 30.8 99905 Changeable Color Clip Mouse Rev.S1 FOR HOME OR OFFICE USEFOR HOME OR OFFICE USE WK MM XXWK MM XX RATING: 3V- - -, 20mA FCC ID：HQXAXM-913P 99905 Changeable Color Clip Mouse Rev.S1 FOR HOME OR OFFICE USEFOR HOME OR OFFICE USE WK MM XXWK MM XX RATING: 3V- - -, 20mA FCC ID：HQXAXM-913P 10.18 4.36 99905 99905

Neutron Engineering Inc. Project No.: 1003C031 Page 3 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 3 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 4 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 4 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 5 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 5 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 6 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 6 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 7 of 8 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 8 of 8 1003C031 1003C031 Neutron Engineering Inc. Project No.: 1003C031 Page 8 of 8 1003C031 1003C031

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1003C031 Page 2 of 63 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1003C031 Page 3 of 63 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 错误！未定义书签。 2.2 MEASUREMENT UNCERTAINTY 错误！未定义书签。 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 21 4.2.4 DEVIATION FROM TEST STANDARD 21 4.2.5 TEST SETUP 错误！未定义书签。 4.2.6 EUT OPERATING CONDITIONS 错误！未定义书签。 4.2.7 TEST RESULTS (BETWEEN30 – 1000 MHZ) 23 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 25 4.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 37 5 . NUMBER OF HOPPING CHANNEL 41 5.1 APPLIED PROCEDURES / LIMIT 41 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 41 5.1.2 TEST PROCEDURE 41 5.1.3 DEVIATION FROM STANDARD 41 5.1.4 TEST SETUP 41 5.1.5 EUT OPERATION CONDITIONS 41 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1003C031 Page 4 of 63 Table of Contents Page 5.1.6 TEST RESULTS 42 6 . AVERAGE TIME OF OCCUPANCY 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.1.1 MEASUREMENT INSTRUMENTS LIST 43 6.1.2. TEST PROCEDURES 43 6.1.3. TEST SETUP LAYOUT 43 6.1.4. TEST DEVIATION 43 6.1.5. EUT OPERATION DURING TEST 43 6.1.6. RESULTS OF OCCUPIED BANDWIDTH AND SPREAD-SPECTRUM BANDWIDTH 44 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 46 7.1 APPLIED PROCEDURES / LIMIT 46 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 46 7.1.2 TEST PROCEDURE 46 7.1.3 DEVIATION FROM STANDARD 46 7.1.4 TEST SETUP 46 7.1.5 EUT OPERATION CONDITIONS 46 7.1.6 TEST RESULTS 47 8 . BANDWIDTH TEST 49 8.1 APPLIED PROCEDURES / LIMIT 49 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 49 8.1.2 TEST PROCEDURE 49 8.1.3 DEVIATION FROM STANDARD 49 8.1.4 TEST SETUP 49 8.1.5 EUT OPERATION CONDITIONS 49 8.1.6 TEST RESULTS 50 9 . PEAK OUTPUT POWER TEST 52 9.1 APPLIED PROCEDURES / LIMIT 52 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 52 9.1.2 TEST PROCEDURE 52 9.1.3 DEVIATION FROM STANDARD 52 9.1.4 TEST SETUP 52 9.1.5 EUT OPERATION CONDITIONS 52 9.1.6 TEST RESULTS 53 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 55 10.1 APPLIED PROCEDURES / LIMIT 55 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 55 10.1.2 TEST PROCEDURE 55 10.1.3 DEVIATION FROM STANDARD 55 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1003C031 Page 5 of 63 Table of Contents Page 10.1.4 TEST SETUP 56 10.1.5 EUT OPERATION CONDITIONS 56 10.1.6 TEST RESULTS 57 11 . RF EXPOSURE TEST 59 11.1 APPLIED PROCEDURES / LIMIT 59 11.1.1 MEASUREMENT INSTRUMENTS LIST 59 11.1.2 MPE CALCULATION METHOD 60 11.1.3 DEVIATION FROM STANDARD 61 11.1.4 TEST SETUP 61 11.1.5 EUT OPERATION CONDITIONS 61 11.1.6 TEST RESULTS 62 12 . EUT TEST PHOTO 63 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1003C031 Page 6 of 63 1. CERTIFICATION Equipment : 2.4G Wireless mouse Brand Name : Sysgration Model Name : AXM-913P A p p l i c a n t : Sysgration Ltd.. Factory : Sysgration(Shenzhen) Ltd. Address : Egongling Village, Pinghu Town, Longgang Dist, Shenzhen City, China T e s t I t e m : ENGINEERING SAMPLE Date of Test: Mar. 31, 2010 ~ Apr. 19, 2010 Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1003C031) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1003C031 Page 7 of 63 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A Note(1) 15.247 (c) Antenna conducted Spurious EmissionPASS 15.247 (a)(1) Hopping Channel …
