HQXAXM-913S2.4GHz Full Size Mouse

2.4G Wireless Mouse Users’ Guide Installation 1 . Wireless Mouse with cursor 1 batterie AA Guida per l’utente 1X guida alla garanzia Installation 2（setting up your wireless mouse） 1. lnstalling the battery,if the mouse is on,slide the on/off switch located on the side of mouse to the”off position. 2. lnsert the supplied battery,making sure the positive(+)and negative(-)ends of the battery match the polarity indicators the battery compartment 3. slide the battery cover back into position until it clicks into place 4. turn on the presenter Note: FCC statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on. The user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment.

Sysgration Ltd. 10FL, NO.868-3, Chung Rd, Chung Ho, Taipei, Taiwan, R.O.C. FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Sysgration Ltd. Addresss 10FL, NO.868-3, Chung Rd, Chung Ho City Taipei, Taiwan, R.O.C. Country request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: HQX AX M-913S of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) New Taipei, Taiwan, R.O.C. February 23, 2012 Paul Huang Manager

Report No.: SZ120117B01-RP Page 1/3 Report No.: SZ120117B01-RP Page 2/3 Report No.: SZ120117B01-RP Page 3/3

Report No.: SZ120117B01-RP Page 1/5 Internal Photos of EUT Report No.: SZ120117B01-RP Page 2/5 Report No.: SZ120117B01-RP Page 3/5 Report No.: SZ120117B01-RP Page 4/5 Report No.: SZ120117B01-RP Page 5/5

Report No.: SZ120117B01-RP FCC ID: HQXAXM-913S Page 1/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C for 2.4GHz Full Size Mouse Model: AXM-913S / 68109, 68110, 68111, 68112 Brand: Sysgration / GE Test Report Number: SZ120117B01-RP Issued for: Sysgration Ltd. 10FL, No.868-3, Chung Rd., Zhonghe Dist, New Taipei, 235 Taiwan Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: February 17, 2012 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. Report No.: SZ120117B01-RP FCC ID: HQXAXM-913S Page 2/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ120117B01-RP Initial Issue ALL Ziva Zhang Report No.: SZ120117B01-RP FCC ID: HQXAXM-913S Page 3/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ...........................................................................................4 2 EUT DESCRIPTION.................................................................................................5 3 TEST METHODOLOGY...........................................................................................6 3.1. DESCRIPTION OF TEST MODES.......................................................................................6 4 TEST METHODOLOGY...........................................................................................7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS............................................7 5 INSTRUMENT CALIBRATION ................................................................................8 6 SETUP OF EQUIPMENT UNDER TEST .................................................................8 6.1. DESCRIPTION OF SUPPORT UNITS .................................................................................8 6.2. CONFIGURATION OF SYSTEM UNDER TEST..................................................................8 7 FACILITIES AND ACCREDITATIONS ....................................................................9 7.1. FACILITIES ..........................................................................................................................9 7.2. ACCREDITATIONS ..............................................................................................................9 7.3. MEASUREMENT UNCERTAINTY .......................................................................................9 8 FCC PART 15.249 REQUIREMENTS ...................................................................10 8.1. BAND EDGES MEASUREMENT .......................................................................................10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT ...........................................12 8.3. SPURIOUS EMISSIONS MEASUREMENT .......................................................................19 Report No.: SZ120117B01-RP FCC ID: HQXAXM-913S Page 4/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product 2.4GHz Full Size Mouse Model AXM-913S / 68109, 68110, 68111, 68112 Brand Sysgration / GE Tested January 16~February 16, 2012 Applicant Sysgration Ltd. 10FL, No.868-3, Zhongzheng Rd., Zhonghe Dist, New Taipei, 235 Taiwan Manufacturer Sysgration (Shenzhen) Ltd. Egongling Village, Pinghu Town, Longgang Dist. Shenzhen City. China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No.: SZ120117B01-RP FCC ID: HQXAXM-913S Page 5/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product 2.4GHz Full Size Mouse Model Number AXM-913S / 68109, 68110, 68111, 68112 Trade Name Sysgration / GE Model Discrepancy 1. They are the same except the model names and the brand names. 2. The model AXM-913S is for the brand of sysgration, and the model 68109, 68110, 68111 and 68112 is for the brand o f GE. Serial Number SZ120117B01-RP Power Supply DC 3V supplied by the batteries Frequency Range 2405-2476 MHz Transmit Power Peak: 82.32 dBuV/m (Max.) Average: 57.47 dBuV/m (Max.) Modulation Technique GFSK Number of Channels 64 Channels Antenna Specification PCB Antenna with 2.29 dBi gain(MAX) Temperature Range 0°C ~ +40°C Note: 1. The sample select…

Text truncated - open the document above for the full version.

Report No.: SZ120117B01-RP FCC ID: HQXAXM-913S Page 1/1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST Below 1GHz Above 1GHz
