HQXSY-SHE-M-001BLE Mesh Module

SYSGRATION / Avi-on Confidential & Proprietary 2015-09-03 5 Product Features
CSR 1012 Single Chip solution: B luetooth Specification 4.1 compliant 128KB memory: 64KB RAM and 64KB ROM
RF Features: T ransmitter Power: ≧0 dBm Receiver sensitivity: -85 dBm Typ
External EEPROM memory provides storage for the Bluetooth software parameter and application parameter
Electrical: D C Supply: 1.8V ~3.6V Low current consumption: 16 mA @3V (Peak Current)
Small size: 18mm × 12mm ×2.3mm (L x W x H) SYSGRATION / Avi-on Confidential & Proprietary 2015-09-03 5 2.6 Mechanical Requirements Item Feature Detailed Description 2.6.1 PCB 12 mm * 18 mm * 0.8mm 2.6.2 Weight N/A Top View: SYSGRATION /Avi-on Confidential & Proprietary 2015-09-03 5 Bottom View: SYSGRATION / Avi-on Confidential & Proprietary 2015-09-03 5 2.7 Pin Assignment: SYSGRATION /Avi-on Confidential & Proprietary 2015-09-03 5 Pin Assignment Description: Pins Name Function Description J1 WAKE I Input to wake CSR1012 from hibernate or dormant. Default is pull-down. J2 XTAL_32K_IN Analog in 32.768KHz installed, Disconnect all to this Pin. J3 XTAL_32K_OUT Analog In 32.768KHz installed, Disconnect all to this Pin. J4 I2C_SCL I/O SPI serial flash installed, or I2C clock Input / output. J5 VBATT Power Power input. J6 I2C_SDA I/O SPI serial flash installed, or I2C data Input / output. J7 SPI_PION I Selects SPI debug or Programmable I/O, Pull-High : SPI debug Pull-down: Programmable I/O line, default is. J8 PIO[11] I/O Programmable I/O J9 PIO[10] I/O Programmable I/O J10 PIO[9] I/O Programmable I/O J11 SPI_MISO O SPI data output or Programmable I/O J12 SPI_MOSI I SPI data input or Programmable I/O J13 SPI_CSB I SPI select or Programmable I/O J14 SPI_CLK I/O SPI clock or Programmable I/O J15 PIO[4] I/O Programmable I/O J16 VDD_PADS Power Positive supply for all digital I/O ports J17 PIO[3] I/O Programmable I/O J18 UART0_RX I UART RX or Programmable I/O J19 UART0_TX O UART TX or Programmable I/O J20 AIO[0] I/O Analogue Programmable I/O J21 AIO[1] I/O Analogue Programmable I/O J22 AIO[2] I/O Analogue Programmable I/O J23 GND Ground Ground J24 GND Ground Ground J25 GND Ground Ground J26 GND Ground Ground SYSGRATION / Avi-on Confidential & Proprietary 2015-09-03 5 Recommended of PCB Layout Pads Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: . Reorient or relocate the receiving antenna. . Increase the separation between the equipment and receiver. . Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. . Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). End Product Labeling This transmitter module is authorized only for use in devices where the antenna may be installed such that 0.5 cm may be maintained between the antenna and users. The final end product must be labeled in visible area with the following: “Contains FCC ID: HQXSY-SHE-M-001” ” End Product Manual Information The user manual for end users must include the following information in a prominent location “IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 0.5 cm from all persons and must not be colocated or operating in conjunction with any other antenna or transmitter.” This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or colocation with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for reevaluating the end product (including the transmitter) and obtaining a separate FCC authorization. This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 0.5 cm is maintained between the antenna and users. As long as a condition above is met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).

Sysgration Ltd. 6F-2.,No.1,Sec.1,Tiding Blvd.,Neihu Dist. Taipei City 114 Taiwan Date: 2015-09-09 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Module Approval. To whom may it concern: We have the following attestation to the eight requirements described by FCC public notice DA00-1407 "Part 15 Unlicensed Modular Transmitter Approval". 1. RF shielding. The model SY-SHE-M-001, (FCC ID:HQXSY-SHE-M-001) has its own RF shielding. The shielding is made by metal and completely added to RF part during our manufacturing. It is not easily removed module. Please see exhibition external photos of this module. 2. Excessive data rates or over modulation. The module circuit buffers all modulation and control of the transmitter. The control of the transmitter is via data commands and software instructions contained within the module. The transmitter is tested with the module operated at the maximum power. Data commands are reduced the power of transmitter but do not influence the modulation contents. 3. Power supply regulation. The module has its own power supply regulator to insure compliance with part 15 requirements regardless of the quality or level of external DC supplying the module from the end product. The regulator operates within the 3 Vdc. FCC ID: HQXSY-SHE-M-001 Contact person: Paul Huang E-mail: [email protected] Sysgration Ltd. 6F-2.,No.1,Sec.1,Tiding Blvd.,Neihu Dist. Taipei City 114 Taiwan 4. Antenna and unique coupler requirements to antenna connector. The antenna is an integral type and there is no antenna connector for end product. (1) No modification of antenna will be allowed. (2) The end product must be certified by FCC, if customer will use the other antenna. 5. Stand--alone configuration. The modular transmitter has been performed the testing as a stand alone and then confirmed the compliance. Please refer to the test report number W6M21508-15198-C-1. 6. Label with own FCC ID number and exterior label. The module is labeled with own FCC ID number. Please see exhibition label sample for the FCC ID of this module. The label made by polyester sheet is affixed to the module by a high-strength adhesive. Since the FCC ID number will not be visible when the module is installed inside the end product, there are instructions give to the OEM how to label the end product. Please refer to the “User Manual”. 7. Compliant with any specific rule or operating requirements. The module as manufactured is completely controlled by the onboard processor. There are no influences to the operation of the transmitter the end can induce that will operate the module outside of scope of the regulations. The necessary explanation for user to be complied with this requirement is contained on the manual. 8. RF exposure requirements. To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 0.5 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Sincerely yours, Signature:

Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 2 of 18 EUT Photos With printed antenna Atmel eeprom Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 3 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 4 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 5 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 6 of 18 With printed antenna Fudan eeprom Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 7 of 18

With printed antenna Atmel eeprom Fudan eeprom Without printed antenna Atmel eeprom Fudan eeprom

Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 2 of 18 EUT Photos With printed antenna Atmel eeprom Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 3 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 4 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 5 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 6 of 18 With printed antenna Fudan eeprom Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 7 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 8 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 9 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 10 of 18 Without printed antenna Atmel eeprom Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 11 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 12 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 13 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 14 of 18 Without printed antenna Fudan eeprom Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 15 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 16 of 18 Registration number: W6M21508-15198-FCC FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 17 of 18

Registration number: W6M21508-15198-C-1 FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Page 15 of 29 3.2 RF Exposure Compliance Requirements FCC Rule: 15.247(b)(3) Test exclusion = max. conducted output power + adjusted for tune-up tolerance Test exclusion = -2.30 dBm RESULT: Test standard : FCC KDB Publication 447498 D01 General RF Exposure Guidance v05r02 According to 447498 D01 General RF Exposure Guidance v05r02: SAR evaluation, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. The enclosure of the device provides ≥ 0.5 cm separation from the antenna elements to significant metal parts of the enclosure to minimize potential perturbations. Frequency Band:2402-2480 MHz Maximum Power fed to Antenna: 0.5888 mW Separation distances: Radiator to user: > 5 mm Distance prescribed in user manual: > 5 mm MHz 5 10 15 20 25 mm 2450 10 19 29 38 48 SAR Test Exclusion Threshold (mW) MHz 30 35 40 45 50 mm 2450 57 67 77 86 96 SAR Test Exclusion Threshold (mW) MHz 50 60 70 80 90 100 110120130140150160170 180 190 mm 2450 96 196 296 396496 596 696796896996109611961296 1396 1496 mW

of Applicant: Sysgration Ltd. Address: 6F-2.,No.1,Sec.1,Tiding Blvd.,Neihu Dist. Taipei City 114 Taiwan Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679A-1, IC 5107A-1 A2LA Accredited No.: 2732.01 Report No.: W6M21508-15198-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] FCC PART 15 SUBPART C TEST REPORT for BLE Mesh Module Model No.: SY-SHE-M-001 FCC ID: HQXSY-SHE-M-001 Registration num ber: W6M21508-15198-C-1 FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 29 TABLE OF CONTENTS 1 GENERAL INFORMATION.........................................................................................................................................2 1.1 NOTES......................................................................................................................................................................2 1.2 TESTING LABORATORY.............................................................................................................................................3 1.2.1 Location ..............................................................................................................................................................3 1.2.2 Details of accreditation status ............................................................................................................................3 1.3 DETAILS OF APPROVAL HOLDER...............................................................................................................................3 1.4 APPLICATION DETAILS..............................................................................................................................................4 1.5 GENERAL INFORMATION OF TEST ITEM.....................................................................................................................4 1.6 TEST STANDARDS.....................................................................................................................................................5 2 TECHNICAL TEST........................................................................................................................................................6 2.1 SUMMARY OF TEST RESULTS.....................................................................................................................................6 2.2 TEST ENVIRONMENT.................................................................................................................................................6 2.3 TEST EQUIPMENT LIST..............................................................................................................................................7 2.4 GENERAL TEST PROCEDURE.....................................................................................................................................9 3 TEST RESULTS (ENCLOSURE) ...............................................................................................................................11 3.1 PEAK OUTPUT POWER (TRANSMITTER)...................................................................................................................12 3.2 RF EXPOSURE COMPLIANCE REQUIREMENTS.........................................................................................................15 3.3 TRANSMITTER RADIATED EMISSIONS IN RESTRICTED BANDS................................................................................16 3.4 SPURIOUS EMISSIONS (TX)......................................................................................................................................17 3.5 RADIATED EMISSION ON THE BAND EDGE...............................................................................................................19 3.6 MINIMUM 6 DB BANDWIDTH..................................................................................................................................21 3.7 PEAK POWER SPECTRAL DENSITY..........................................................................................................................24 3.8 RADIATED EMISSION FROM DIGITAL PART..............................................................................................................27 3.9 POWER LINE CONDUCTED EMISSION......................................................................................................................28 APPENDIX.............................................................................................................32 Registration num ber: W6M21508-15198-C-1 FCC ID: HQXSY-SHE-M-001 Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 29 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the Worldwide Testing Services(Taiwan) Co., Ltd. Tester: August 29, 2015Rick Chen DateWTS-Lab. NameSignature Technical responsibility for area o f testing: August …
