Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
WAOM562 Pairing ProcessIf your monitor is not receiving a signal from the camera; the two may not be paired correctly.1. Camera and monitor must be connected to 12 Volt DC power supply. 2. Remove “ pair” button cover from the side of the camera (using a coin or fat head screwdriver). 3. Press and hold the “ pair” button on the back of the monitor for 3 seconds and release. (Monitor will display “ Please press TX pairing button” ) 4. Press and hold the “ pair” button on the side of the camera for 3 seconds and release (you have 60 seconds to press this button.) If done correctly, monitor will display “ Pairing successful” . If pairing is not successful, the monitor will display “ Pairingfailed” . If you receive this message, repeat steps 2 - 4. Installing The Monitor 1. Plug power cable into the back of the monitor. (fig. 1) 2. Attach the suction cup bracket to the rear of the monitor with the supplied screws.. 3. Locate flat section of glass on your windshield 1. POWER: Press to turn the WAOM562 on. 2. SELECT: Press to toggle the active display image Between AV1 and AV 3. BRIGHTNESS - /+ : Press BRIGHTNESS “–“ to d arken the picture. Press BRIGHTNESS “ +” to bri ghten the picture. 4. VOLUME ? /? : Press VOLUME ? to decrease the volume. Press VOLUME ? to increase the volume. (that does not block your vision) and Apply suction cup. Snap the lever into the locked position. 4. Connect the power cord to a 12 Volt DC outlet.5. Align the antenna to its upright position, parallel to the monitor Operation 1. Press the power button on the monitor and turn on your vehicle’ s parking lights. 2. The monitor will display the Voyager logo for 8 seconds and then the camera image should appear. 3. In the top right corner of the mo nitor, you will see the signal strength meter. 4. Adjust the suction cup bracket to provide the best viewing angle. Notice : The changes or modifications not expressly approved by the party responsible for compliance could void the user’ s authority to operate the equipment. Important note:To comply with the FCC RF exposure compliancerequirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’ s authority to operate the device. ! " # $ " % " " # & ' # " $ ( " ) * + ) "% "+ ) "% " "% " ) " % " "% +
SYSGRATION LTD. 10F., No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan (R.O.C.) TEL : 886-2-8221 71 1 1 FAX : 886-2-8221 1775 Date: 201 1/02,10 ~omplian& Certification Services Certification Division 47 173 Benicia Street Fremont, CA 94538, USA To whom it may concern: We, the undersigned, hereby authorize ELECTRONICS TESTING CENTER, TAIWAN, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ELECTRONICS TESTING CENTER, TAIWAN on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C. 853(a). In authorizing ELECTRONICS TESTING CENTER, TAIWAN as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been gibted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g). endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product's compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Manager : Paul Huang 1 OF., No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan (R.O.C.) TEL : 886-2-8221 71 1 1 FAX : 886-2-8221 1775
SYSGRATION LTD. 10F., No.868-3, Zhongzheng Rd., Zhonghe Disi., New Taipei City 235, Taiwan (R.O.C.) TEL : 886-2-8221 71 11 FAX : 886-2-8221 1775 Federal Communications Commission FCC ID: HQXWAOM562 Product Name: 5.8' Wireless monitor Model Name: WAOM562 Trade Name: Voyager Dear Sir: In accordance with 47 C.F.R. Section 0.459, we would like to request confidentiality on some exhibits we submitted for above application for the reason of trade secret. If those exhibits are available for public inspection, any person who once gets the information contained in those exhibits will be able to design and to make the same products very easily. This is a very serious problem and huge loss for us, because we did invest so much on it. Please be not made the Exhibit Types listed below routinely available for public inspection: Block Diagram and Schematics and Operation Description. By: By: Paul Huang (signature) Title : Manager 911 printed) Applicant : SYSGRATION LTD. Address : IOF., No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan (R.O.C.) Tel : : 886-2-8221 71 1 1 Fm: 886-2-8221 1 775 Date : 2011/02/10
ETC Report No. : 11-01-RBF-030-01 FCC ID.: HQXWAOM562 Sheet 1 of 7 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 1. Top View of EUT 2. Bottm View of EUT ETC Report No. : 11-01-RBF-030-01 FCC ID.: HQXWAOM562 Sheet 2 of 7 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 3. Rear View of EUT 4. Side View of EUT ETC Report No. : 11-01-RBF-030-01 FCC ID.: HQXWAOM562 Sheet 3 of 7 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 5. Front View of EUT 6. Bottom View of EUT
MODEL NO.: WAOM562 FCC ID : HQXWAOM562 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IC : XXXXXX-WAOM562 This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. MODEL NO.: WAOM562 FCC ID : HQXWAOM562 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IC : XXXXXX-WAOM562 This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. 43.5 mm 4 2 . 0 m m R1.5
ETC Report No. : 11-01-RBF-030-01 FCC ID.: HQXWAOM562 Sheet 4 of 7 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 7. Internal View of EUT 8. Internal View of EUT ETC Report No. : 11-01-RBF-030-01 FCC ID.: HQXWAOM562 Sheet 5 of 7 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 9. Internal View of EUT ETC Report No. : 11-01-RBF-030-01 FCC ID.: HQXWAOM562 Sheet 6 of 7 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 10. Component View of PCB 11. Solder View of PCB ETC Report No. : 11-01-RBF-030-01 FCC ID.: HQXWAOM562 Sheet 7 of 7 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 12. Component View of PCB 13. Solder View of PCB
Rev. No 1.0 FCC Part 15 EMI TEST REPORT of E.U.T. : 5.6" Wireless monitor Model : WAOM562 FCC ID : HQXWAOM562 for APPLICANT : SYSGRATION LTD. ADDRESS : 10FL, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan, R.O.C. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO.34, LIN 5, DINGFU TSUEN, LINKOU SHIANG TAIPEI COUNTY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail : [email protected] Report Number : 11-02-RBF-030-01 ETC Report No. : 11-02-RBF-030-01 FCC ID.: HQXWAOM562 Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : SYSGRATION LTD. 10FL, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan, R.O.C. Manufacture : SYSGRATION LTD. (1) No.26,North Industry Rd., Nan-Kan Idustrial Zone,Nan-Tou City, Nan-Tou County, Taiwan (2) 10FL, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan, R.O.C. Description of Device : a) Type of EUT : 5.6" Wireless monitor b) Trade Name : Voyager c) Model No. : WAOM562 d) Power Supply : DC 12V Regulation Applied : FCC Rules and Regulations Part 15 Subpart C (2009) I HEREBY CERTIFY THAT: The data shown in this report were made in accordance with the procedures given in ANSI C63.4, and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC. ETC Report No. : 11-02-RBF-030-01 FCC ID.: HQXWAOM562 Rev. No 1.0 Date Test Item Received :Feb. 11, 2011 Date Test Campaign Completed :Feb. 22, 2011 Date of Issue :Feb. 24, 2011 Test Engineer : ( Falcon Shi, Engineer ) Check By : ( Charles Wang, Supervisor ) Approve & Authorized : Will Yauo, Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No. : 11-02-RBF-030-01 FCC ID.: HQXWAOM562 Rev. No 1.0 Table of Contents Page 1 GENERAL INFORMATION ....................................................................................................... 1 1.1 Product Description...................................................................................................................... 1 1.2 Test Methodology ........................................................................................................................ 1 1.3 Test Facility.................................................................................................................................. 1 2 PROVISIONS APPLICABLE...................................................................................................... 2 2.1 Definition ..................................................................................................................................... 2 2.2 Requirement for Compliance ....................................................................................................... 3 2.3 Restricted Bands of Operation ..................................................................................................... 5 2.4 Labeling Requirement .................................................................................................................. 6 2.5 User Information .......................................................................................................................... 6 3 SYSTEM TEST CONFIGURATION .......................................................................................... 7 3.1 Justification .................................................................................................................................. 7 3.2 Devices for Tested System ........................................................................................................... 7 4 RADIATED EMISSION MEASUREMENT .............................................................................. 8 4.1 Applicable Standard ..................................................................................................................... 8 4.2 Measurement Procedure ............................................................................................................... 8 4.3 Measuring Instrument ................................................................................................................ 10 4.4 Radiated Emission Data ............................................................................................................. 11 4.5 Field Strength Calculation.......................................................................................................... 16 4.6 Photos of Radiation Measuring Setup........................................................................................ 17 5 CONDUCTED EMISSION MEASUREMENT ........................................................................ 18 5.1 Description ................................................................................................................................. 18 6 ANTENNA REQUIREMENT .................................................................................................... 19 6.1 Standard Applicable ................................................................................................................... 19 6.2 Antenna Construction................................................................................................................. 19 7 HOPPING CHANNEL SEPARATION..................................................................................... 20 7.1 Standard Applicable ................................................................................................................... 20 7.2 Measurement Procedure ............................................................................................................. 20 7.3 Measurement Equipment ........................................................................................................... 21 7.4 Measurement Data ................…
Text truncated - open the document above for the full version.
FCC ID: HQXWAOM562 RF Exposure Evaluation of E.U.T. : 5.6" Wireless monitor FCC ID. : HQXWAOM562 MODEL : WAOM562 for APPLICANT : SYSGRATION LTD. ADDRESS : 10FL, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan, R.O.C. Prepared by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5. DINGFU TSUEN, LINKOU SHIANG TAIPEI COUNTY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 11-02-RBF-030-MPE FCC ID: HQXWAOM562 Product Information: Type of EUT: 5.6" Wireless monitor FCC ID: HQXWAOM562 Manufacturer: SYSGRATION LTD. Model: WAOM562 Description: 5.6" Wireless monitor Maximum conducted output power (measured): 15.21 dBm or 33.189mW The following table lists the provided authorized antennas: Antenna Gain Model Antenna Type (dBi) Numeric HD-0006-12-1R Omni 1 1.25 Below is an example of the RF Exposure Statement: IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. No change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. FCC ID: HQXWAOM562 Relative Requirement for Compliance According to section 1.1310 of FCC 47 CFR Part 1, limits for maximum permissible exposure (MPE) are as following: TABLE 1 – LIMITS FOR MAXIMUN PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 .................. 6141.63*(100) 6 3-30 ..................... 1842/f4.89/f *(900/f 2 ) 6 30-300 .................. 61.40.1631.0 6 300-1500 ............... ...................... ......................f/300 6 1500-100,000 ......... ...................... ......................5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 ............... 6141.63*(100) 30 1.34-30 ............... 824/f2.19/f*(180/f2) 30 30-300 .................. 27.50.0730.2 30 300-1500 ............... ...................... ......................f/1500 30 1500-100,000 ......... ...................... ......................1.0 30 f = frequency in MHz * = Plane-wave equivalent power density NOTE 1 TO TABLE 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational / controlled limits apply provided he or she is made aware of the potential for exposure. NOTE 2 TO TABLE 1: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC ID: HQXWAOM562 RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0 mW/cm 2 uncontrolled exposure limit. The formula shown in OET Bulletin 65 is used in the calculation. Equation from page 19 of OET Bulletin 65, Edition 97-01 is: S= PG / 4πR 2 where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) hence R= (PG / 4πS) 1/2 For our device P = 33.189mW G = 1.58 R = 20 cm S = (33.189 * 1.58) / (4*π*20 2 ) = 0.008 mW/cm 2 < 1.0 mW/cm 2 For complying the FCC limits for general population/uncontrolled exposure, the power density limit is 1.0 mW/cm 2 . The calculation result of the power density at a distance of 20 cm of our device is less than the limit. This means that according to OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of 47 CFR Part 15.247 (b)(5).
ETC Report No. : 11-01-RBF-030-01 FCC ID.: HQXWAOM562 Sheet 17 of 57 Sheets Rev. No 2.1 4.6 Photos of Radiation Measuring Setup
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 33.00 mW |
