Warning for units equipped with the WLAN radio option: The following section only applies when the PS2 IOOTterminal has FCC ID: I2821224121 on the the serial number label. (This label is on the underside of the terminal.) A Warning: Use of the PS2 7 OOT as a handheld ter mi- nal with FCC ID: I2821224121 meets the FCC require- ments for radio frequency (RF) radiation exposure. To minimize exposure the user should avoid holding the terminal, especially the scanner end, up to hislher head or torso. The terminal with this radio option has been SAR tested. The maximum SAR value measured was 0.78 W/kg averaged over 7 gram. A Warning: Use of the PS2 722 printer with the above PS2 700T terminal docked in the cradle meets the FCC requirements for radio frequency (RF) radiation expo- sure. To minimize exposuR the user should avoid lean- ing over the docked terminal, especially the scanner end. The PS2 722 with this terminal/radio option has been SAR tested. The maximum SAR value was 0.7 7 W/kg av- eraged over 7 gram. UMAN-PS2100 Series - Terminal Section OT-2

August 5, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: ZEBRA TECHNOLOGIES CORPORATION FCC ID: I2821224121 Gentlemen: Attached herewith, on behalf of ZEBRA TECHNOLOGIES CORPORATION is an application for Part 15.247 Certification of the following RF Terminal w/ WLAN PC Card Module: FCC ID: I2821224121 TRADE / MODEL(s): ZEBRA PS2122 EUT TYPE: RF Terminal w/ WLAN PC Card Module Tx / Rx Freq. Range: 2412 —2462 MHz (DSSS) Max. RF Output Power: 0.135W Conducted Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Symbol Technologies Inc.

November 4, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Tim Harrington SUBJECT: Zebra Technologies Corporation FCC ID: I2821224121 731 Confirmation No.: TC803828 Request for Tech. Info.: 10/05/2002 Correspondence Ref. Num.: 5367 Dear Tim: Transmitted herewith, on behalf of Zebra Technologies Corporation, is an amendment provided in response to the request for technical information dated October 5, 2002. 1. Please find attached the revised Users Manual page OT-2. 2. Please find attached the revised Label. If you have any further questions, please do not hesitate to contact us. cc: Zebra Technologies Corporation

April 10, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Tim Harrington SUBJECT: Zebra Technologies Corporation FCC ID: I2821224121 731 Confirmation No.: TC803828 Correspondence Reference No.: 7603 Request for Tech. Info.: 4/03/03 Dear Tim: Transmitted herewith, on behalf of Zebra Technologies Corporation is an amendment provided in response to the request for technical information dated April 03, 2003. 1. The BEDG and end cap antennas were used in this filing. 2. PCTEST has no explanation for the E-field probe PCT25 variation in conversion factors. Probe PCT25 is the only probe calibrated by Aprel/ NCL Lab for PCTEST in the 2.45 GHz band. PCTEST no longer uses this E-field Probe PCT25 for tests. 3. Please find the updated SAR report with test setup photos on report data table pages with amended Figure 14.6 caption, indicating Body SAR. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: Zebra Technologies Corporation

April 10, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Tim Harrington SUBJECT: Zebra Technologies Corporation FCC ID: I2821224121 731 Confirmation No.: TC803828 Correspondence Reference No.: 5366 Request for Tech. Info.: 10/05/02 Dear Tim: Transmitted herewith, on behalf of Zebra Technologies Corporation is an amendment provided in response to the request for technical information dated October 5, 2002. 1. The BEDG and end cap antennas were used in this filing. 2. PCTEST has no explanation for the E-field probe PCT25 variation in conversion factors. Probe PCT25 is the only probe calibrated by Aprel/ NCL Lab for PCTEST in the 2.45 GHz band. PCTEST no longer uses this E-field Probe PCT25 for tests. 3. Please find the updated SAR report with test setup photos on report data table pages with amended Figure 14.6 caption, indicating Body SAR. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: Zebra Technologies Corporation

© 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module

© 2002 PCTEST Lab FCC ID LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) FCC ID: I28PS21224121 Canada I.D. : 3789A-21224121 PS2100T Terminal AC15694-1-4 (Symbol Radio for PS21xx) Approx. Location of S/N Bar Code Protected by U.S. Patent 6,292,595

FCC ID: I2821224121 Canada I.D. : 3789A-21224121 PS2100T Terminal AC15694-1-4 (Symbol Radio for PS21xx) Approx. Location of S/N Bar Code Protected by U.S. Patent 6,292,595

© 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module © 2002 PCTEST Lab ZEBRA FCC ID: I2821224121 RF Terminal with WLAN PC Card Module

SAR Data Report 02080517 Start : 5-Aug-02 03:39:30 pm End : 5-Aug-02 03:47:45 pm Code Version : 4.08 Robot Version: 4.08 Product Data: Type : ZEBRA Model Number : PS2122 Serial Number : 1 Frequency : 2412 MHz Transmit Pwr : 0.135 W Antenna Type : BEDG Antenna Posn. : Internal Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 53.570 Tissue Conductivity : 1.960 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT25 Probe Type : E Fld Triangle Frequency : 2450 MHz Tissue Type : Muscle Calibrated Dielectric : 49.200 Calibrated Conductivity : 1.950 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 16.500 Probe Sensitivity : 0.753 0.726 0.683 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: DSSS MODE Low Channel BODY (BACK) CF=1; Amb. Temp= 22.2 'C; Liq. Temp=22.1 'C Area Scan - Max Peak SAR Value at x=5.0 y=71.0 = 0.04 W/kg Zoom Scan - Max Peak SAR Value at x=13.0 y=81.0 z=0.0 = 0.15 W/kg Max 1g SAR at x=14.0 y=81.0 z=0.0 = 0.04 W/kg Max 10g SAR at x=10.0 y=73.0 z=0.0 = 0.02 W/kg 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:13.0 y:81.0 1g SAR Values 0.01212 0.01137 0.01061 0.00985 0.00909 0.00834 0.00758 0.00682 0.00606 0.00531 0.00455 SAR Data Report 02080514 Start : 5-Aug-02 02:55:20 pm End : 5-Aug-02 03:03:36 pm Code Version : 4.08 Robot Version: 4.08 Product Data: Type : ZEBRA Model Number : PS2122 Serial Number : 1 Frequency : 2412 MHz Transmit Pwr : 0.135 W Antenna Type : BEDG Antenna Posn. : Internal Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 53.570 Tissue Conductivity : 1.960 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT25 Probe Type : E Fld Triangle Frequency : 2450 MHz Tissue Type : Muscle Calibrated Dielectric : 49.200 Calibrated Conductivity : 1.950 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 16.500 Probe Sensitivity : 0.753 0.726 0.683 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: DSSS MODE Low Channel BODY (SCREEN) CF=1; Amb. Temp= 22.2 'C; Liq. Temp=22.1 'C Area Scan - Max Peak SAR Value at x=-2.0 y=66.0 = 0.17 W/kg Zoom Scan - Max Peak SAR Value at x=-11.0 y=66.0 z=0.0 = 0.34 W/kg Max 1g SAR at x=-7.0 y=67.0 z=0.0 = 0.18 W/kg Max 10g SAR at x=-2.0 y=66.0 z=0.0 = 0.10 W/kg 0.0 0.1 0.2 0.3 0.4 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-11.0 y:66.0 1g SAR Values 0.1770 0.1694 0.1617 0.1540 0.1463 0.1386 0.1309 0.1232 0.1155 0.1078 0.1001 SAR Data Report 02080502 Start : 5-Aug-02 11:12:41 am End : 5-Aug-02 11:20:11 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : ZEBRA Model Number : PS2122 Serial Number : 3 Frequency : 2412 MHz Transmit Pwr : 0.135 W Antenna Type : End Cap Antenna Posn. : Internal Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 53.570 Tissue Conductivity : 1.960 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT25 Probe Type : E Fld Triangle Frequency : 2450 MHz Tissue Type : Muscle Calibrated Dielectric : 49.200 Calibrated Conductivity : 1.950 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 16.500 Probe Sensitivity : 0.753 0.726 0.683 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: DSSS MODE - Low Channel BODY (BACK) CF=1; Amb. Temp= 22.2 'C; Liq. Temp=22.1 'C Area Scan - Max Peak SAR Value at x=30.0 y=-19.0 = 0.01 W/kg Zoom Scan - Max Peak SAR Value at x=37.0 y=-9.0 z=0.0 = 0.09 W/kg Max 1g SAR at x=35.0 y=-9.0 z=0.0 = 0.02 W/kg Max 10g SAR at x=33.0 y=-14.0 z=0.0 = 0.01 W/kg -0.01 0.00 0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09 0.10 SAR (mW/g) 102030 Z Distance (mm) SAR - Z Axis at Hotspot x:37.0 y:-9.0 1g SAR Values 0.00786 0.00718 0.00649 0.00580 0.00512 0.00443 0.00375 0.00306 0.00237 0.00169 0.00100 SAR Data Report 02080506 Start : 5-Aug-02 12:43:15 pm End : 5-Aug-02 12:50:49 pm Code Version : 4.08 Robot Version: 4.08 Product Data: Type : ZEBRA Model Number : PS2122 Serial Number : 3 Frequency : 2412 MHz Transmit Pwr : 0.135 W Antenna Type : End Cap Antenna Posn. : Internal Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 53.570 Tissue Conductivity : 1.960 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT25 Probe Type : E Fld Triangle Frequency : 2450 MHz Tissue Type : Muscle Calibrated Dielectric : 49.200 Calibrated Conductivity : 1.950 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 16.500 Probe Sensitivity : 0.753 0.726 0.683 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: DSSS MODE - Low Channel BODY (SCREEN) CF=1; Amb. Temp= 22.2 'C; Liq. Temp=22.1 'C Area Scan - Max Peak SAR Value at x=-5.0 y=59.0 = 0.06 W/kg Zoom Scan - Max Peak SAR Value at x=-11.0 y=58.0 z=0.0 = 0.20 W/kg Max 1g SAR at x=-8.0 y=59.0 z=0.0 = 0.08 W/kg Max 10g SAR at x=-8.0 y=58.0 z=0.0 = 0.03 W/kg 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 0.18 0.20 0.22 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-11.0 y:58.0 1g SAR Values 0.0780 0.0721 0.0662 0.0603 0.0544 0.0485 0.0426 0.0367 0.0308 0.0249 0.0190 SAR Data Report 02080509 Start : 5-Aug-02 02:05:21 pm End : 5-Aug-02 02:13:04 pm Code Version : 4.08 Robot Version: 4.08 Product Data: Type : ZEBRA Model Number : PS2122 Serial Number : 1 Frequency : 2412 MHz Transmit Pwr : 0.135 W Antenna Type : BEDG Antenna Posn. : Internal Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 53.570 Tissue Conductivity : 1.960 Tissue Density : 1.000 Robot Name : CRS Probe Data: P…
