January 19, 2007 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 To Whom It May Concern: In reference to the application for FCC ID#: I28RFID-402931 (13.56 MHz RFID encoder radio module), this device is being submitted for Limited MODULAR TRANSMITTER APPROVAL based on the guidelines in FCC Publication DA 00-1407. This transmitter does not meet all 8 criterions listed in DA 00-1407. Where there is a non-conformance, an explanation is provided that allows for a Limited Modular Approval. Note that I28RFID-402931 is a radio module that will be used exclusively within products made by Zebra Technologies Corporation. 1) The RF portion of the module is not shielded. Shielding is provided by the host devices. 2) The ASIC (MFRC400) provides buffering on all digital lines. Overdriving one or more of the digital inputs will have no affect on the transmitter output. 3) The RFID 402931 accepts a regulated 5 VDC, which is provided by the host devices, to the RFID 402931 module. Further, since the module will only be used in Zebra products, Zebra has full control of the power supply to the RFID 402931 module and will assure a 5 VDC supply. 4) I28RFID-402931 module has an integrated antenna. The antenna consists of traces on the PCB. It is not removable. 5) I28RFID-402931 was tested in the host devices. 6) I28RFID-402931 will carry a label containing its FCC ID number. Additionally “Contains FCC ID: I28RFID- 402931 ” will appear on the external label of the product the radio is mounted it. All products containing this module will have this statement clearly visible. Examples of both the internal and external labels have been provided as part of the application. 7) I28RFID-402931 will only be used with Zebra Technologies products; this includes printers built by Zebra that are branded for other companies. Thus Zebra will maintain full control over the use of the module and can guarantee that all conditions for use will be met in any product that the module is installed in. 8) The products that I28RFID-402931 will be used in will be at least 20 cm away from any body part. Sincerely, Gus Medina Compliance Engineer Zebra Technologies Corporation

January 19, 2007 FCC Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21045-0429 To Whom It May Concern: In reference to the application I28RFID-402931, the following information is to be held confidential pursuant of 47 CFR Part 0, 0.457 and section 552(b)(4) of the Freedom of Information Act, because the information provided contains trade secrets and propriety information. If made public, the information may be used to the disadvantage of the applicant in the market place. • Schematics • Technical product descriptions. • Block Diagrams Sincerely, Guzvaldo Medina Compliance Engineer

FCC ID: I28RFID-402931 D.L.S. ELECTRONIC SYSTEMS, INC. 1250 Peterson Drive Wheeling, Illinois 60090 September 6, 2007 FCC Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21045-0429 Gentlemen: We are submitting for Zebra Technologies Corporation, Inc., an RFID 402931 Transmitter, Model Number: 402931, with an FCC ID: I28RFID-402931 for Certification. The RFID 402931 is being co-located tested with another transmitter, ZM4e with FCC ID: I28RFID-M4E-01. The P330i and P430i Zebra printers were tested with both transmitters simultaneously transmitting. The 402931 is a 13.56 MHz transmitter and the ZM4e is a 902 MHz to 928 MHz transmitter. This unit has been tested and complies to Part 15, Subpart C. If there are any questions in regard to this application, please call D.L.S. Electronic Systems, Inc. at (847) 537 6400. Enclosed you will find a copy of our test report with the information and results of tests that is required under Part 15, Section 15.225. Thank you for your assistance in this matter. Sincerely, Arnom C. Rowe EMC-001375-NE DLS/cp

ANTENNA BOARD TOP ANTENNA BOARD BOTTOM

ANTENNA BOARD TOP

P330i PRINTER LABEL LOCATION EXTERNAL

P330i PRINTER P330i PRINTER P330i PRINTER P430i PRINTER P430i PRINTER P430i PRINTER P430i PRINTER

P330i PRINTER P430i PRINTER

1250 Peterson Dr., Wheeling, IL 60090 Company: Zebra Technologies Corporation Model Tested: 402931 Report Number: 12921 FCC Rules and Regulations / Intentional Radiators Operational in the Band 13.553-13.567 MHz Part 15, Subpart C, Section 15.225 THE FOLLOWING ''MEETS'' THE ABOVE TEST SPECIFICATION Formal Name: RFID 402931 Kind of Equipment: RFID Encoder Test Configuration: Limited Modular Approval - Tested in P330i & P430i (Tested at 120 vac, 60 Hz) Model Number(s): 402931 Model(s) Tested: 402931 Serial Number(s): NA Date of Tests: January 18, 19 & 22 & September 24, 2007 Test Conducted For: Zebra Technologies Corporation 333 Corporate Woods Parkway Vernon Hills, Illinois 60061 NOTICE: “This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government”. Please see the "Additional Description of Equipment Under Test" page listed inside of this report. © Copyright 1983- 2006 D.L.S. Electronic Systems, Inc COPYRIGHT NOTICE This report or any portion their of, may not be reproduced or modified in any form without the expressed written consent of D.L.S. Electronic Systems, Inc. Page -1 of 68- 1250 Peterson Dr., Wheeling, IL 60090 Company: Zebra Technologies Corporation Model Tested: 402931 Report Number: 12921 SIGNATURE PAGE Report By: Arnom C. Rowe Test Engineer EMC-001375-NE Reviewed By: William Stumpf OATS Manager Approved By: Brian Mattson General Manager Company Official: Zebra Technologies Corporation Page -2 of 68- 1250 Peterson Dr., Wheeling, IL 60090 Company: Zebra Technologies Corporation Model Tested: 402931 Report Number: 12921 TABLE OF CONTENTS i. Cover Page ...........................................................................................................................................1 ii. Signature Page .....................................................................................................................................2 iii. Table of Contents .............................................................................................................................3 iv. NVLAP Certificate of Accreditation ...............................................................................................5 1.0 Summary of Test Report ..................................................................................................................6 2.0 Introduction......................................................................................................................................6 3.0 Object ...............................................................................................................................................6 4.0 Test Set-Up ......................................................................................................................................7 5.0 Test Equipment ................................................................................................................................7 6.0 Ambient Measurements ...................................................................................................................8 7.0 Description of Test Sample..............................................................................................................9 8.0 Additional Description of Test Sample..........................................................................................10 9.0 Photo Information and Test Set-Up ...............................................................................................11 10.0 Radiated Photos Taken During Testing .........................................................................................12 10.0 Conducted Photos Taken During Testing ......................................................................................16 11.0 Results of Tests ..............................................................................................................................20 12.0 Conclusion .....................................................................................................................................20 Page -3 of 68- 1250 Peterson Dr., Wheeling, IL 60090 Company: Zebra Technologies Corporation Model Tested: 402931 Report Number: 12921 TABLE OF CONTENTS TABLE 1 – EQUIPMENT LIST ...............................................................................................................21 Appendix A – Electric Field Radiated Emissions Test..............................................................................22 1.0 Conducted Emission Measurements ..............................................................................................23 1.0 P330i Card Printer AC Conducted Data and Charts taken during testing .....................................24 1.0 P430i Card Printer AC Conducted Data and Charts taken during testing .....................................29 2.0 Restricted Bands, Bandwidth and Band Edge Compliance ...........................................................34 2.0 P330 Printer Graphs showing the Bandwidth and Band Edge Compliance ..................................35 2.0 P430 Printer Graphs showing the Bandwidth and Band Edge Compliance ..................................38 3.0 Field Strength of Fundamental and Spurious Emission Measurements ........................................41 3.0 P330i Printer Radiated Data and Graphs taken for Fundamental Emission Measurements..........42 3.0 P430i Printer Radiated Data and Graphs taken for Fundamental Emission Measurements..........46 3.0 P330i Radiated Data and Graphs taken for Restricted Band and Spurious Emissions..................50 3.0 P430i Radiated Data and Graphs taken for Restricted Band and Spurious Emissions..................57 4.0 Frequency Stability (Temperature and Voltage)............................................................................64 Page -4 of 68- 1250 Peterson Dr., Wheeling, IL 60090 Company: Zebra Technologies Corporation Model Tested: 402931 Report Number: 12921…
