IIO-0232USB611Wireless USB Adapter

11Mbps Wireless LAN USB Adapter User’s Guide Version 1.0 INFORMATION TO USER Federal Communications Commission Statement This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The antenna used for this transmitter must be installed to provide a separation distance of least 20 centimeters from all persons and must operate in conjunction with other antenna or transmitters. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ˆ Reorient or relocate the receiving antenna. ˆ Increase the separation between the equipment or device. ˆ Connect the equipment to an outlet other than receiver’s. ˆ Consult a dealer or an experienced radio/TV technician for assistance Notice: The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency. Any change or modification not expressly approved by the party responsible could void the user’s authority to operate the device. Regulatory The wireless LAN PC Card must be installed and used in strict accordance with the manufacturer’s instructions. This device complies with the following radio frequency and safety standards. USA - Federal Communications Commission (FCC) This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference that may cause undesired operation. Europe - R&TTE Directive This device complies with the specifications listed below: ⌧ ETS 300-826 General EMC requirements for Radio equipment. ⌧ ETS 300-328 Technical requirements for Radio equipment. ⌧ EN60950 Safety requirements for Radio equipment. EU Countries not intended for use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France (with Frequency channel restrictions). Germany, Greece, Ireland, Italy, Luxembourg, Netherlands, Portugal, Spain, Sweden and United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states Iceland, Liechtenstein, Norway and Switzerland. 1 Table of Contents Chapter 1: Introduction.............................................................................................3 The 11Mbps Wireless LAN USB Adapter............................................................3 Features..............................................................................................................3 Hardware Description..........................................................................................3 Package Contents...............................................................................................4 System Requirements.........................................................................................4 Chapter 2: Network Configuration and Planning......................................................5 Network Topology (Ad-Hoc, Infrastructure mode)...............................................5 Roaming..............................................................................................................7 Chapter 3: Adapter Installation and Configuration - Windows 98/ME/NT/2000........8 Inserting the adapter............................................................................................8 Running the Auto Driver Installation....................................................................8 Chapter 4: Configuration Utility...............................................................................12 Using the configuration utility.............................................................................12 Chapter 5: Installation Procedure Under Windows NT 4.0.....................................19 About Windows NT 4.0......................................................................................19 Installing the Driver............................................................................................19 Configuration / Uninstall....................................................................................20 Chapter 6: Installation Procedure Under WindowsXP............................................21 About Windows XP............................................................................................21 Installing the Driver............................................................................................21 Configuration Under WinXP...............................................................................21 Uninstall Procedure Under WinXP.....................................................................21 Appendix A: Troubleshooting..................................................................................22 Appendix B: Glossary.............................................................................................23 Appendix C: Specifications.....................................................................................25 2 Chapter 1: Introduction The 11Mbps Wireless LAN USB Card The 11Mbps Wireless LAN USB Card now has a new , higher-powered antenna that provides a greater range than ever. The increased sensitivity helps filter out interference and notice to keep your signal clear. Improved error correction in the chipset keeps you operating at higher transmission rates for longer distances. And since you only need USB ports, you’re free to use yo…

Text truncated - open the document above for the full version.

Encryption On the Encryption screen, show in Fig 4-5, you can set the level of security with which you will be using the WLAN PC Card. Under the drop-down box, you can choose to have WEP encryption Disabled, 64-Bit, or 128- Bit Wired Equivalent Privacy (WEP) is an encryption scheme use to protect wireless data communi- cation. If you decide to use encryption, you can choose any of the available WEP keys (1 to 4). You also have option to select the WEP mode (Mandatory/optional). If you select “Mandatory”, then not only WEP will be used, but also any other station needs to use WEP encryption in order to establish a communication with your station. This requirement is in line with the IEEE 802.11b standard. If, on the other hand, you choose “Option”, then your station can communication with every other station regardless if they use WEP or not. The Disabled setting prevents the sharing of data with other computers on the WEP network. When Enable encryption for the WEP Key entry, enter the hexa- decimal number (the letters “A” through “F” and the numbers “0” through “9”) set by the other wireless WEP settings; these settings must be identical to the WEP encryption on all points in your wireless network in order to network to your WLAN PC Card. The security keys are four 10 digit key for the 64-Bit WEP setting and four 26 digit key for the 128-Bit WEP setting. Fig 4-5 15 NOTE: The WEP Key Entry must match the Key on all other devices on the wireless network or this device will be unable to transmit or receive data. 33 33 3 Advanced The Advanced screen (Fig 4-6) allows you to set Fragmentation Threshold, the RTS/CTS Threshold, and the Preamble Type. The Fragmentation Threshold Value indicates how much of the network resources is devoted to recovering packet errors. The value should remain at its default setting of 2,432. If you experience high packet error rates, you can decrease this value but it will likely decrease overall network performance. Only minor modifications of this value are recom- mended. Fig 4-6 For Authentication Type, you may choose between Open System or Shared Key. Shared Key is when both the sender and recipient share a secret key. Both units this key for an extended length of time, sometimes indefinitely. Any eavesdropper that discovers the key may decipher all packets unit the key is changed. Open System the default setting, is when the sender and the recipient do not share a secret key. Each party generates its own key-pair and asks the receiver to accept the (usually randomly) generated key. Once accepted, this key is use for short time only: then a new key is generated and agrees upon. 16 The About screen (Fig 4-7) shown the release information for the Driver Version, Firmware Version, Application Version, and MAC Address. User the “Exit” button in order to exit the application. About Fig 4-7 17 The RTS Threshold Value should remain at its default setting of 2,432. A preamble is a signal used to synchronize the transmission timing between two or more systems. A series of transmission pulses is sent before the data to indicate that “someone is about transmit data.” this ensures that systems receive the information correctly when the data transmission stars. The Preamble Type should be set to Short (if the network environment is “noisy”) or Long (if the environment is “clear”) Click Submit to complete the configuration. 18 How to Uninstall the configuration & Monitor Utility In order to uninstall the Configuration & Monitor Utility from Windows 95/98/ME, you can RUN Setup utility again then you will see Fig 4-7 then step by step remove all installed components. It is recommended to stop the WLAN adapter and “Exit” the application prior to staring the uninstallation procedure. Fig 4-8 Chapter 5: Installation Procedure Under Windows NT 4.0 (Only For PCMCIA) About Windows NT 4.0 Use the procedures described in this section to install and configure the WLAN adapter under MS Windows NT 4.0. Although Windows NT 4.0 are similar in appearance wit Windows 95/98/ME, and Windows 2000, they have different philosophy when installing a new hardware. Throughout this section it is assumed that you have basic working knowledge of Windows NT 4.0 and how to install new network cards on them. However, in this paragraph, some specific features of Windows NT 4.0 are briefly explained. Unlike Windows 95/98/ME, and Windows 2000. Windows NT 4.0 do not support the “Plug & Play” and “Hot Swapping” features. In Windows NT 4.0 you need to inform the operating system about the existence of the new card in order to star installing the driver. Also, if you want to swap cards, you need to restart the PC in order to recognize the card. Another difference between Windows 95/98/ME and Windows NT 4.0 is how these operating systems handle the “User Profiles” feature. Windows 2000 handle “User Profiles” in the same way as Windows NT 4.0. In Windows 95/98/ME, the “User Profiles” are use only in order to customize the appearance of the desktop between the different users. However, in Windows NT 4.0, “User Profiles” play the role of accounts and are associated with certain privileges on the machine. Therefore, we have different “User Profiles” (and privileges) for simple users, power users, and administrators. The privilege settings for each user are set in the “User Manager” program of Windows NT 4.0. Installing the Driver NOTE: In order to be able to install the WLAN adapter on to your PC running under Windows NT 4.0, you will need to log on as “Administrator”. Also to have at least NT Service Pack 4 installed. 33 33 3 First of all, in order to obtain the necessary privileges for the driver installation, you need to log on as Administrator to Windows NT 4.0. Since Windows NT 4.0 do not support “Plug & Play”, you must enable the detection of PC cards by the operating system by following the following procedure: 1. Click Start XSettingsXControl Panel. 2. Double click the “Devices” icon. 3. Select “PCMCIA” from …

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 10, 2002 RE: FCC ID: IIO-0232USB611 Attention: Vivi Wang I have a few comments on this Application. 1 This device is subject two authorizations. The FCC ID number applies to the transmitter portion 15.247. You have elected to DoC the computer peripheral Class B portion. However, you have not provided an appropriate label for this purpose. Please note that in order to DoC a product the appropriate DoC FCC logo must appear on the label. Consequently, the label for this device must contain both the FCC ID number and an FCC DoC logo. Please provide a revised FCC label. 2 Please note that the FCC has routinely asked for pdf files that do not contain Asian fonts. If the FCC audits this application their Acrobat reader will not be able to read the following files: Block Diagram. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5

Page 6 Page 7 Page 8

FCC ID: IIO-0232USB611 ADT No.910814R07 Operational Description The transmitter of the EUT is powered by host equipment from USB port. The antenna is Chip Antenna, and there is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: IIO-0232USB611 ADT No.: 910814R07 FCC TEST REPORT REPORT NO.: RF910814R07 MODEL NO.: WLUSB611 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:CNet Technology, Inc. ADDRESS:No. 15, Park Avenue II, Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: IIO-0232USB611 ADT No.: 910814R07 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: IIO-0232USB611 ADT No.: 910814R07 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: IIO-0232USB611 ADT No.: 910814R07 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1dBi or 1.26 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241232.661.81 6243731.481.78 11246228.841.70 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: IIO-0232USB611 Report No.: RF910814R07 1 Issued: Aug. 26, 2002 FCC TEST REPORT REPORT NO.: RF910814R07 MODEL NO.: WLUSB611 RECEIVED: Aug. 14, 2002 TESTED: Aug. 15 ~ Aug. 19, 2002 APPLICANT:CNet Technology, Inc. ADDRESS:No. 15, Park Avenue II, Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: IIO-0232USB611 Report No.: RF910814R07 2 Issued: Aug. 26, 2002 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................................... 9 4.1.2TEST INSTRUMENTS ...........................................................................................................9 4.1.3TEST PROCEDURES .......................................................................................................... 10 4.1.4DEVIATION FROM TEST STANDARD ................................................................................ 10 4.1.5TEST SETUP ....................................................................................................................... 11 4.1.6EUT OPERATING CONDITIONS......................................................................................... 12 4.1.7TEST RESULTS ................................................................................................................... 13 4.2RADIATED EMISSION MEASUREMENT................................................... 19 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 19 4.2.2TEST INSTRUMENTS ......................................................................................................... 20 4.2.3TEST PROCEDURES .......................................................................................................... 21 4.2.4DEVIATION FROM TEST STANDARD ................................................................................ 21 4.2.5TEST SETUP ....................................................................................................................... 22 4.2.6EUT OPERATING CONDITIONS......................................................................................... 22 4.2.7TEST RESULTS ................................................................................................................... 23 4.36dB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 27 4.3.2TEST INSTRUMENTS ......................................................................................................... 27 4.3.3TEST PROCEDURE ............................................................................................................28 4.3.4DEVIATION FROM TEST STANDARD ................................................................................ 28 4.3.5TEST SETUP ....................................................................................................................... 28 4.3.6EUT OPERATING CONDITIONS......................................................................................... 28 4.3.7TEST RESULTS ................................................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER.......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 33 4.4.2INSTRUMENTS.................................................................................................................... 33 4.4.3TEST PROCEDURES .......................................................................................................... 34 4.4.4DEVIATION FROM TEST STANDARD ................................................................................ 34 4.4.5TEST SETUP ....................................................................................................................... 34 4.4.6EUT OPERATING CONDITIONS......................................................................................... 34 4.4.7TEST RESULTS ................................................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ........................................... 36 4.5.2TEST INSTRUMENTS ......................................................................................................... 36 FCC ID: IIO-0232USB611 Report No.: RF910814R07 3 Issued: Aug. 26, 2002 4.5.3TEST PROCEDURE ....................................…

Text truncated - open the document above for the full version.

FCC ID: IIO-0232USB611 Report No.: RF910814R07 47 Issued: Aug. 26, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: IIO-0232USB611 Report No.: RF910814R07 48 Issued: Aug. 26, 2002 RADIATED EMISSION TEST
