IMA-T3014TDFM 9000 Series RF Module

T3014 RF Module P/N127502-1 Users Guide DOCUMENT NO: 126553 REVISION: DATE OF ISSUE: DEC. 27, 2012 Technisonic Industries Limited 240 Traders Boulevard, Mississauga, Ontario L4Z 1W7 Tel: (905) 890-2113 Fax: (905) 890-5338 www.til.ca This document contains designs and other information which are the property of Technisonic Industries Ltd. This document may not in whole or in part, be duplicated or disclosed or used for manufacture of the part disclosed herein, without the prior written permission of Technisonic Industries Ltd. T3014 RF MODULE USER GUIDE TiL 126553 -1- INTRODUCTION The T3014 RF module is a Dual Band transceiver assembly that operates in 136-174 MHZ and 380-470 MHz range. The T3014 RF module is a modified Motorola APX 7000 VHF/UHL portable radio. The outer casing, top controls, front display and keypad are removed. The RF chassis is slightly machined but all electronic circuits are unmodified from the original APX 7000 radio. The transceiver is designed to be installed and operated in a Technisonic Multiband Airborne Radio TDFM 9000 platform. All external power and antenna connections are provided by the TDFM 9000 as well as controls are via the front panel and display from the TDFM 9000. The RF module is capable of operating on Analog FM, Wide and Narrow and Project 25 Phase 1 conventional and P25 Trunked Phase 1 and 2 systems. FIGURE 1: Overall view of the T3014 RF Module T3014 RF MODULE USER GUIDE TiL 126553 -2- NOTES ESD CAUTION This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves when handling printed circuit boards. FCC COMPLIANCE INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: For compliance with FCC RF Exposure Requirements the mobile transmitter antenna installation shall comply with the following two conditions: 1. The transmitter antenna gain shall not exceed 3 dBi. 2. The transmitter antenna is required to be located outside of a vehicle and kept at a separation distance of 80 cm or more between the transmitter antenna of this device and persons during operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help T3014 RF MODULE USER GUIDE TiL 126553 -3- TECHNICAL CHARACTERISTICS Specification Characteristic Model Designation: T3014 Physical Dimensions: Approx. (L) 5.77" x (W) 2.1" x (H) 0.95" Operating Temperature Range: -30° C to +60° C Power Requirement: Voltage: Current: 7.5 VDC ± 15% 300 mA minimum / 2.4A maximum Audio Output Power: 500 mW into 600 W FCC ID: IMA-T3014 INDUSTRY CANADA: 120A-T3014 RF Output Power: 1 or 6 Watts (VHF) 1 or 5 Watts (UHF) Frequency Range VHF Band: UHF LO Band: 136 to 174 MHz 380 to 470 MHz No. of channels per band: 2000 pre-programmable channels Transmitter section VHF UHF FM Hum and noise in dB (wideband): Audio Distortion: Frequency Stability in ppm: Modulation Limiting: -48 -45 1% 1.0% ±2.5 ±1.5 Wide band ±5kHz Narrow band ±2.5kHz Receiver section VHF UHF Sensitivity in uV: *Digital 1% BER (12.5kHz) *Digital 5% BER (12.5kHz) **Analog with 12dB SINAD 0.29 0.32 0.21 0.28 0.25 0.25 Selectivity in dB: 25 kHz Channel 12.5 kHz Channel Intermodulation * ** -80 -78 -70 -68 -80 -80 *Measured in digital mode per TIA / EIA IS 102.CAAA under nominal conditions. ** Measured in analog mode per TIA / EIA 603 under nominal conditions. T3014 RF MODULE USER GUIDE TiL 126553 -4- INSTALATION The T3014 module should be installed in the TDFM 9000 in accordance with TIL document 126556 “TDFM-9000 FINAL ASSEMBLY SSP". FCC ID LABELS The T3014 RF module is a modified Motorola APX 7000. Part of the modification requires removal if the original Motorola FCC ID label. After all modifications are done the new Technisonic FCC/IC ID label is applied. FIGURE 2 APX 7000 FCC ID (Left), Right T3014 Module with new FCC ID applied T3014 RF MODULE USER GUIDE TiL 126553 -5- The FCC/Industry Canada label is shown below. It is mounted on the top near the front of the module. FIGURE 3 T3014 FCC/Industry Canada Label Figure 4 FCC/Industry Canada Label placement on the T3014 Module The T3014 is intended to be mounted in the TDFM 9000 chassis and is not visible. Therefore, a second label must be applied to the outside of the TDFM 9000 that contains the following text: “TDFM 9000 Multiband Transceiver. Contains Module: FCC ID IMA-T3014”. In addition, external labeling for Industry Canada shall be applied to the TDFM 9000 to include the following text: “Contains IC: 120A-T3014”. T3014 RF MODULE USER GUIDE TiL 126553 -6- WARNING AND DISCLAIMER Changes or modifications not expressly approved by Technisonic Industries could void the user’s authority to operate the equipment. This manual is designed to provide information about the T3014 RF Module. Every effort has been made to make this …

Text truncated - open the document above for the full version.

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 18 December 2012 SUBJECT: FCC Application for FCC ID: IMA-T3014 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Verification Authorization procedure to the Part 15B - Unintentional Radiator portion of this composite filing. Regards, Steve McIntosh Engineering Manager

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Date: 18 December 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Attestation & Extended Freq. Justification for FCC ID: IMA-T3014 To aid equipment authorization in other countries which accept the United States FCC grant for Certification, Technisonic hereby request that FCC lists the frequencies 136-174 MHz and 380-470 MHz under FCC Rule Parts 80 and 90 on the FCC Grant. This equipment complies with the requirements of the FCC Rules Parts, sections 80.203(b) and 90.203(e) that the operator can’t program and transmit on frequencies other that those programmed by the manufacturer, service or maintenance personnel. As per FCC KDB Guidance # 634817, an alternate to listing exact frequencies, we, Technisonic Industries Ltd., acknowledges that FCC rules will be violated if the device operates on unauthorized frequencies. Regards, Steve McIntosh Engineering Manager

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 20 December 2012 SUBJECT: FCC Application for FCC ID: IMA-T3014 To Whom It May Concern: We, Technisonic Industries Limited, hereby attest to the fact that the transmitter module tested for FCC ID: IMA-T3014 is representative of the unit in the original filing for FCC ID:AZ489FT4886 in regards to the RF conducted emission parameter data. Regards, Steve McIntosh Engineering Manager

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Date: 19 December 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Attestation for Part 90 Operation FCC ID: IMA-T3014 To Whom It May Concern: For part 90 frequency user, 25kHz Channel Spacing operation is disabled in the T3014 RF module by factory firmware in order to comply with FCC mandate for part 90 frequencies. Regards, Steve McIntosh Engineering Manager

December 24, 2012 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 80 and 90 Applicant: Technisonic Industries Limited Product: VHF/UHF LO RF Module Model: T3014 FCC ID: IMA-T3014 Dear Sir/Madam: As appointed agent for Technisonic Industries Limited, we submit the application for FCC certification of the above product. Kindly review all required documents uploaded to your E- Filing Site. Note 1: As declared by the applicant in the attestation letter submitted with this filing, 25kHz channel spacing (16K0F3E) operation of this radio will be permanently disabled for Part 90 use as required by FCC mandate. Note 2: The T3014 module is the same RF radio component used in FCC ID: AZ489FT4886 certification. According to KDB# 996369 D01 Module Certification Guide v01r03 – VII A, the applicant has declared that the conducted tests applied to the FCC ID: AZ489FT4886 certification for only UHF Lo band, accurately represent the test results under this condition. Refer to FCC ID: AZ489FT4886 test report and additional test report provided with this filing, both demonstrate full compliance with applicable FCC rules. Note 3: This application is subject to modular approval; see Applicant’s cover letter requesting for modular approval. If you have any queries, please do not hesitate to contact us. Yours truly, Dharmajit Solanki Dharmajit Solanki Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

Rev. 05/08 Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Date: 18 December 2012 To Whom It May Concern Subject: Authority to Act as an Agent Applicant: Technisonic Industries Limited FCC ID: IMA-T3014 Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application for authorization of above equipment under F.C.C. Rules. The applicant hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. I also certify that the information provided, properly describe the device or system for which authorization is required. Regards Steve McIntosh Engineering Manager

Rev. 05/08 Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Date: 18 December 2012 To Whom It May Concern Subject: Confidentiality Letter Applicant: Technisonic Industries Limited FCC ID: IMA-T3014 Dear Sir/Madam: The applicant would like to request the following documents submitted with this application for certification be withheld from public disclosure as per Section 0.457 & 0.459 of FCC Rules. 1. Operational Description 2. Block Diagram 3. Schematics 4. Parts List 5. Tuning Info The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Regards Steve McIntosh Engineering Manager

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Subject: Manufacturer’s Declaration for compliance with FCC KDB Guidance 996369 D01 FOR Licensed Modular Transmitter Approval similar to Sec 15.212 FCC ID: IMA-T3014 Dear Sir/Madam: The applicant hereby confirms that the following requirements per FCC KDB# 996369 for a Licensed Modular Transmitter are met for this Modular Approval certification: Modular Approval Checklist: Modular approval requirement Yes No 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly; The modular transmitter has its own shielding. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with requirements under conditions of excessive data rates or over-modulation. The modular transmitter provides limiting and data buffering on the inputs to prevent over modulation. 3. The module must contain power supply regulation on the module. The modular transmitter has its own power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). Not applicable for licensed module 5. The module must demonstrate compliance in a stand-alone configuration. The modular transmitter was tested in a standalone configuration. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. The modular transmitter is labeled with FCC identification number. The label can not be seen when installed in the main unit. A label will be placed on the outside of the unit that states: ‘Contains FCC ID: IMA-T3014’ 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization A copy of the instructions are provided with the application. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093. Maximum Permissible Exposure (MPE) evaluation was conducted, specific instructions for users and installers are provided that ensures that the public is not exposed to radio frequency energy levels in excess of the commission’s guidelines. Dated: 18 December 2012 By: Steve McIntosh (Signature) (Print Name) Title: Engineering Manager On behalf of : Technisonic Industries Limited Phone No.: (905) 890-2113 x205 Fax No.: (905) 890-5338 Email : [email protected]

FCC Parts 2, 80 and 90 Page 85 VHF/UHF LO RF Module, Model: T3014 FCC ID: IMA-T3014 ULTRATECH GROUP OF LABS File #: TIL-090F80-90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 December 24, 2012 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.8. EXPOSURE OF HUMANS TO RF FIELD [[§§ 1.1310 & 2.1091] The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation. FCC 47 CFR § 1.1310: 5.8.1. Method of Measurements See RSS-102 & FCC 47 CFR §§ 1.1310, 2.1091 In order to demonstrate compliance with MPE requirements, the following information is typically needed: (1) Calculation that estimates the minimum separation distance (20 cm or more) between an antenna and persons required to satisfy power density limits defined for free space. (2) Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement (3) Any caution statements and/or warning labels that are necessary in order to comply with the exposure limits (4) Any other RF exposure related issues that may affect MPE compliance FCC Parts 2, 80 and 90 Page 86 VHF/UHF LO RF Module, Model: T3014 FCC ID: IMA-T3014 ULTRATECH GROUP OF LABS File #: TIL-090F80-90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 December 24, 2012 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) Calculation Method of RF Safety Distance : 22 44r EIRP r GP S ⋅⋅ = ⋅⋅ ⋅ = ππ Where: P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm 5.8.2. RF Evaluation Evaluation of RF Exposure Compliance Requirements RF Exposure Requirements Compliance with FCC Rules *Minimum calculated separation distance between antenna and persons required: 74.5 cm Manufacturer’ instruction for separation distance of 80 cm between antenna and persons required: See the user’s manual for information. Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement Antenna installation and device operating instructions shall be provided to installers to maintain and ensure compliance with RF exposure requirements. Caution statements and/or warning labels that are necessary in order to comply with the exposure limits Refer to User’s Manual for RF Exposure Information. Any other RF exposure related issues that may affect MPE compliance None. *The minimum separation distance between the antenna and bodies of users are calculated using the following formula: RF EXPOSURE DISTANCE LIMITS S EIRP S GP r ⋅⋅ = ⋅⋅ ⋅ = ππ44 S = 0.2 mW/cm 2 (General Population/Uncontrolled Exposure) EIRP = 38.43 dBm + 3dBi Antenna Gain = 41.43 dBm = 10 41.43/10 mW = 13900 mW (Worst Case) (Minimum Safe Distance, r) = cm S EIRP 5.74 )2.0(4 13900 4 ≈ ⋅⋅ = ⋅⋅ ππ T3014 RF MODULE USER GUIDE TiL 126553 -2- NOTES ESD CAUTION This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves when handling printed circuit boards. FCC COMPLIANCE INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: For compliance with FCC RF Exposure Requirements the mobile transmitter antenna installation shall comply with the following two conditions: 1. The transmitter antenna gain shall not exceed 3 dBi. 2. The transmitter antenna is required to be located outside of a vehicle and kept at a separation distance of 80 cm or more between the transmitter antenna of this device and persons during operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help

VHF/UHF LO RF Module Model No.: T3014 FCC ID: IMA-T3014 Applicant: Technisonic Industries Limited 240 Traders Blvd. E. Mississauga, Ontario Canada L4Z 1W7 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Part 2, Parts 80 and 90 UltraTech's File No.: TIL-090F80-90 This Test report is Issued under the Authority of Tri M. Luu Vice President of Engineering UltraTech Group of Labs Date: December 24, 2012 Report Prepared by: Dharmajit Solanki Issued Date: December 24, 2012 Tested by: Mr. Hung Trinh Test Dates: December 18 - 24, 2012  The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected.  This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] FCC Korea KCC-RRL 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R CA2049 FCC Parts 2, 80 and 90 Contents i VHF/UHF LO RF Module, Model: T3014 FCC ID: IMA-T3014 ULTRATECH GROUP OF LABS File #: TIL-090F80-90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 December 24, 2012 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ......................................................................................................................................... 1 1.1. SCOPE......................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S)................................................................................................................... 1 1.3. NORMATIVE REFERENCES ................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .............................................................................................................. 2 2.1. CLIENT INFORMATION .......................................................................................................................................... 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION............................................................................................. 2 2.3. EUT’S TECHNICAL SPECIFICATIONS.................................................................................................................. 3 2.4. LIST OF EUT’S PORTS........................................................................................................................................... 4 2.5. ANCILLARY EQUIPMENT ...................................................................................................................................... 4 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 5 3.1. CLIMATE TEST CONDITIONS................................................................................................................................ 5 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS ............................................. 5 EXHIBIT 4. SUMMARY OF TEST RESULTS ............................................................................................................... 6 4.1. LOCATION OF TESTS .............................................................................................................................................. 6 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS.............................................................. 6 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ....................................... 6 4.4. DEVIATION OF STANDARD TEST PROCEDURES ............................................................................................. 6 EXHIBIT 5. TEST DATA................................................................................................................................................... 7 5.1. RF POWER OUTPUT [§§ 2.1046, 80.215 & 90.205] ................................................................................................ 7 5.2. AUDIO FREQUENCY RESPONSE [§ 2.1047(A), 80.213(E) & 90.242(B)(8)]........................................................ 9 5.3. MODULATION LIMITING [§ 2.1047 (B), 74.463, 80.213 & 90.210] ................................................................... 14 5.4. OCCUPIED BANDWIDTH & EMISSION MASK [§ 2.1049, 80.205, 80.211, 90.209 & 90.210] ......................... 19 5.5. TRANSMITTER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS [§2.1051, 2.1057, 80.211(F) & 90.210] .................................................................................................................................................. 66 5.6. TRANSMITTER SPURIOUS/HARMONIC RADIATED EMISSIONS [§§ 2.1053, 80.211 & 90.210]................. 79 5.7. FREQUECNY STABILITY [§§ 2.1055, 80.209 & 90.213] ..................................................................................... 82 5.8. EXPOSURE OF HUMANS TO RF FIELD [[§§ 1.1310 & 2.1091] ......................................................................... 85 5.9. POWER LINE CONDUCTED EMISSIONS [§ 15.107(A)]..................................................................................... 87 EXHIBIT 6. TEST EQUIPMENT LIST ......................................................................................................................... 92 EXHIBIT 7. MEASUREMENT UNCERTAINTY.........................................................................................................93 7.1. LINE CONDUCTED EMISSION MEA…

Text truncated - open the document above for the full version.

Applicant: Motorola Inc. FCC ID: AZ489FT4886 EXHIBIT 6 SHEET 1 OF 32 EXHIBIT 6 INDEX OF SUBMITTED MEASURED DATA This exhibit contains the measured data for this equipment as follows: EXHIBIT 6A – RF Power Output (Table) EXHIBIT 6B – Audio Frequency Response 6B-1 –425.025 MHz, 12.5 kHz Channel Spacing 6B-2 –155.025 MHz, 12.5 kHz Channel Spacing 6B-3 –425.025 MHz, 25 kHz Channel Spacing 6B-4 –155.025 MHz, 25 kHz Channel Spacing EXHIBIT 6C – Audio Low Pass Filter Response 6C-1 –425.025 MHz, 12.5 kHz Channel Spacing 6C-2 –155.025 MHz, 12.5 kHz Channel Spacing 6C-3 –425.025 MHz, 25 kHz Channel Spacing 6C-4 –155.025 MHz, 25 kHz Channel Spacing EXHIBIT 6D – Modulation Limiting 6D-1 –425.025 MHz, 12.5 kHz Channel Spacing 6D-2 –155.025 MHz, 12.5 kHz Channel Spacing 6D-3 –425.025 MHz, 25 kHz Channel Spacing 6D-4 –155.025 MHz, 25 kHz Channel Spacing EXHIBIT 6E – Occupied Bandwidth 6E-1 –425.025 MHz, 12.5 kHz Channel Spacing (Analog Voice) 6E-2 –156.675 MHz, 12.5 kHz Channel Spacing (Analog Voice) 6E-3 –425.025 MHz, 25 kHz Channel Spacing (Analog Voice) 6E-4 –156.675 MHz, 25 kHz Channel Spacing (Analog Voice) 6E-5 –425.025 MHz, 12.5 kHz Channel Spacing (Digital Data) 6E-6 –156.675 MHz, 12.5 kHz Channel Spacing (Digital Data) 6E-7 –425.025 MHz, 12.5 kHz Channel Spacing (Digital Voice) 6E-8 –156.675 MHz, 12.5 kHz Channel Spacing (Digital Voice) 6E-9 –425.025 MHz, 12.5 kHz Channel Spacing (Digital TDMA) 6E-10 –156.675 MHz, 12.5 kHz Channel Spacing (Digital TDMA) 6E-11 –425.025 MHz, (Digital Voice with Encryption) 6E-12 –156.675 MHz,(Digital Voice with Encryption) EXHIBIT 6F – Radiated Spurious Emissions 6F-1 - High Power 380.075 MHz, 25 kHz Channel Spacing 6F-2 - High Power 424.975 MHz, 25 kHz Channel Spacing 6F-3 - High Power 469.975 MHz, 25 kHz Channel Spacing 6F-4 - High Power 136.0125 MHz, 25 kHz Channel Spacing 6F-5 - High Power 153.0125 MHz, 25 kHz Channel Spacing 6F-6 - High Power 173.9875 MHz, 25 kHz Channel Spacing EXHIBIT 6G – Frequency Stability 6G-1 – 425.025 MHz vs. Supply Voltage 6G-2 –156.675 MHz vs. Supply Voltage 6G-3 – 425.0125 MHz vs. Temperature 6G-4 – 156.675 MHz vs. Temperature Applicant: Motorola Inc. FCC ID: AZ489FT4886 EXHIBIT 6 SHEET 2 OF 32 EXHIBIT 6H – Conducted Spurious Emissions 6F-1 - High Power 380.075 MHz, 25 kHz Channel Spacing 6F-2 - High Power 424.975 MHz, 25 kHz Channel Spacing 6F-3 - High Power 469.975 MHz, 25 kHz Channel Spacing 6F-4 - High Power 136.0125 MHz, 25 kHz Channel Spacing 6F-5 - High Power 153.0125 MHz, 25 kHz Channel Spacing 6F…

Text truncated - open the document above for the full version.
