IMA-T3015TDFM 9000 Series RF Module

T3015 RF Module P/N127502-2 Users Guide DOCUMENT NO: 126554 REVISION: DATE OF ISSUE: DEC. 27, 2012 Technisonic Industries Limited 240 Traders Boulevard, Mississauga, Ontario L4Z 1W7 Tel: (905) 890-2113 Fax: (905) 890-5338 www.til.ca This document contains designs and other information which are the property of Technisonic Industries Ltd. This document may not in whole or in part, be duplicated or disclosed or used for manufacture of the part disclosed herein, without the prior written permission of Technisonic Industries Ltd. T3015 RF MODULE USER GUIDE TiL 126554 -1- INTRODUCTION The T3015 RF module is a Dual Band transceiver assembly that operates in 136-174 MHZ and 450-520 MHz range. The T3015 RF module is a modified Motorola APX 7000 VHF/UHHi portable radio. The outer casing, top controls, front display and keypad are removed. The RF chassis is slightly machined but all electronic circuits are unmodified from the original APX 7000 radio. The transceiver is designed to be installed and operated in a Technisonic Multiband Airborne Radio TDFM 9000 platform. All external power and antenna connections are provided by the TDFM 9000 as well as controls are via the front panel and display from the TDFM 9000. The RF module is capable of operating on Analog FM, Wide and Narrow and Project 25 Phase 1 conventional and P25 Trunked Phase 1 and 2 systems. FIGURE 1: Overall view of the T3015 RF Module T3015 RF MODULE USER GUIDE TiL 126554 -2- NOTES ESD CAUTION This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves when handling printed circuit boards. FCC COMPLIANCE INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: For compliance with FCC RF Exposure Requirements the mobile transmitter antenna installation shall comply with the following two conditions: 1. The transmitter antenna gain shall not exceed 3 dBi. 2. The transmitter antenna is required to be located outside of a vehicle and kept at a separation distance of 80 cm or more between the transmitter antenna of this device and persons during operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help T3015 RF MODULE USER GUIDE TiL 126554 -3- TECHNICAL CHARACTERISTICS Specification Characteristic Model Designation: T3015 Physical Dimensions: Approx. (L) 5.77" x (W) 2.1" x (H) 0.95" Operating Temperature Range: -30° C to +60° C Power Requirement: Voltage: Current: 7.5 VDC ± 15% 300 mA minimum / 2.4A maximum Audio Output Power: 500 mW into 600 W FCC ID: IMA-T3015 INDUSTRY CANADA: 120A-T3015 RF Output Power: 1 or 6 Watts (VHF) 1 or 5 Watts (UHF) Frequency Range VHF Band: UHF HI Band: 136 to 174 MHz 450 to 520 MHz No. of channels per band: 2000 pre-programmable channels Transmitter section VHF UHF FM Hum and noise in dB (wideband): Audio Distortion: Frequency Stability in ppm: Modulation Limiting: -48 -45 1% 1.0% ±2.5 ±1.5 Wide band ±5kHz Narrow band ±2.5kHz Receiver section VHF UHF Sensitivity in uV: *Digital 1% BER (12.5kHz) *Digital 5% BER (12.5kHz) **Analog with 12dB SINAD 0.29 0.32 0.21 0.28 0.25 0.25 Selectivity in dB: 25 kHz Channel 12.5 kHz Channel Intermodulation * ** -80 -78 -70 -68 -80 -80 *Measured in digital mode per TIA / EIA IS 102.CAAA under nominal conditions. ** Measured in analog mode per TIA / EIA 603 under nominal conditions. T3015 RF MODULE USER GUIDE TiL 126554 -4- INSTALATION The T3015 module should be installed in the TDFM 9000 in accordance with TIL document 126556 “TDFM-9000 FINAL ASSEMBLY SSP". FCC ID LABELS The T3015 RF module is a modified Motorola APX 7000. Part of the modification requires removal if the original Motorola FCC ID label. After all modifications are done the new Technisonic FCC/IC ID label is applied. FIGURE 2 APX 7000 FCC ID (Left), Right T3015 Module with new FCC ID applied T3015 RF MODULE USER GUIDE TiL 126554 -5- The FCC/Industry Canada label is shown below. It is mounted on the top near the front of the module. FIGURE 3 T3015 FCC/Industry Canada Label Figure 4 FCC/Industry Canada Label placement on the T3015 Module The T3015 is intended to be mounted in the TDFM 9000 chassis and is not visible. Therefore, a second label must be applied to the outside of the TDFM 9000 that contains the following text: “TDFM 9000 Multiband Transceiver. Contains Module: FCC ID IMA-T3015”. In addition, external labeling for Industry Canada shall be applied to the TDFM 9000 to include the following text: “Contains IC: 120A-T3015”. T3015 RF MODULE USER GUIDE TiL 126554 -6- WARNING AND DISCLAIMER Changes or modifications not expressly approved by Technisonic Industries could void the user’s authority to operate the equipment. This manual is designed to provide information about the T3015 RF Module. Every effort has been made to make this…

Text truncated - open the document above for the full version.

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Date: 18 December 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: IMA-T3015 To Whom It May Concern: This equipment meets the requirements of the FCC rules, Part 90.203(e). To aid equipment authorization in other countries which accept the United States FCC grant for Certification, Technisonic is requesting that the FCC lists the frequencies 136-174 MHz and 380-470 MHz under FCC Rule Parts 80 and 90 on the FCC Grant. This equipment meets the requirements of the FCC Rules, Parts 80.203(b) as applicable. Programming of this products transmit frequencies can be performed ONLY by the manufacturer or by service or by maintenance personnel. As per FCC KDB Guidance # 634817, an alternate to listing exact frequencies, we, Technisonic Industries Limited, acknowledges that FCC rules will be violated if the device operates on unauthorized frequencies. Regards, Steve McIntosh Engineering Manager

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 20 December 2012 SUBJECT: FCC Application for FCC ID: IMA-T3015 To Whom It May Concern: We, Technisonic Industries Limited, hereby attest to the fact that the transmitter module tested for FCC ID: IMA-T3015 is representative of the unit in the original filing for FCC ID:AZ489FT4893 in regards to the RF conducted emission parameter data. Regards, Steve McIntosh Engineering Manager

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 18 December 2012 SUBJECT: FCC Application for FCC ID: IMA-T3015 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Verification Authorization procedure to the Part 15B - Unintentional Radiator portion of this composite filing. Regards, Steve McIntosh Engineering Manager

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Date: 19 December 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: IMA-T3015: Part 90 Operation To Whom It May Concern: Technisonic Industries LTD. herby declares that 25 KHz operation is disabled in the T3015 RF module for Part 90 operation. For part 90 frequency user, 25KHz mode is disabled in the radio by factory firmware in order to comply with FCC mandate for part 90 frequencies. Regards, Steve McIntosh Engineering Manager

December 24, 2012 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 80 and 90 Applicant: Technisonic Industries Limited Product: VHF/UHF HI RF MODULE Model: T3015 FCC ID: IMA-T3015 Dear Sir/Madam: As appointed agent for Technisonic Industries Limited, we submit the application for FCC certification of the above product. Kindly review all required documents uploaded to your E- Filing Site. The T3015 module is the same radio component used in FCC ID: AZ4 89FT4893 certification. According to 996369 D01 Module Certification Guide v01r03 – VII A, the Applicant has declared that the conducted tests applied to the FCC ID: AZ4 89FT4893 certification, accurately represent the test results under the new conditions. For conducted tests, refer to FCC ID: AZ4 89FT4893 test report, the additional test report provided in the filing will demonstrate full compliance under the new conditions. NOTE: This application is subject to modular approval; see Applicant’s cover letter requesting for modular approval. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

Rev. 05/08 Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Date: 18 December 2012 To Whom It May Concern Subject: Authority to Act as an Agent Applicant: Technisonic Industries Limited FCC ID: IMA-T3015 Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application for authorization of above equipment under F.C.C. Rules. The applicant hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. I also certify that the information provided, properly describe the device or system for which authorization is required. Regards Steve McIntosh Engineering Manager

Rev. 05/08 Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Date: 18 December 2012 To Whom It May Concern Subject: Confidentiality Letter Applicant: Technisonic Industries Limited FCC ID: IMA-T3015 Dear Sir/Madam: The applicant would like to request the following documents submitted with this application for certification be withheld from public disclosure as per Section 0.457 & 0.459 of FCC Rules. 1. Operational Description 2. Block Diagram 3. Schematics 4. Parts List 5. Tuning Info The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Regards Steve McIntosh Engineering Manager

Technisonic Industries Limited 240 Traders Blvd., Mississauga, Ontario L4Z 1W7 Tel.: (905) 890-2113 Fax: (905) 890-5338 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Subject: Manufacturer’s Declaration for compliance with FCC KDB Guidance 996369 D01 FOR Licensed Modular Transmitter Approval similar to Sec 15.212 FCC ID: IMA-T3015 Dear Sir/Madam: The applicant hereby confirms that the following requirements per FCC KDB# 996369 for a Licensed Modular Transmitter are met for this Modular Approval certification: Modular Approval Checklist: Modular approval requirement Yes No 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly; The modular transmitter has its own shielding. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with requirements under conditions of excessive data rates or over-modulation. The modular transmitter provides limiting and data buffering on the inputs to prevent over modulation. 3. The module must contain power supply regulation on the module. The modular transmitter has its own power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). Not applicable for licensed module 5. The module must demonstrate compliance in a stand-alone configuration. The modular transmitter was tested in a standalone configuration. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. The modular transmitter is labeled with FCC identification number. The label can not be seen when installed in the main unit. A label will be placed on the outside of the unit that states: ‘Contains FCC ID: IMA-T3015’ 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization A copy of the instructions are provided with the application. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093. Maximum Permissible Exposure (MPE) evaluation was conducted, specific instructions for users and installers are provided that ensures that the public is not exposed to radio frequency energy levels in excess of the commission’s guidelines. Dated: 18 December 2012 By: Steve McIntosh (Signature) (Print Name) Title: Engineering Manager On behalf of : Technisonic Industries Limited Phone No.: (905) 890-2113 x205 Fax No.: (905) 890-5338 Email : [email protected]

FCC Parts 2, 80 and 90 Page 14 VHF/UHF HI RF MODULE, Model: T3015 FCC ID: IMA-T3015 ULTRATECH GROUP OF LABS File #: TIL-091F80-90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 December 24, 2012 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.4. EXPOSURE OF HUMANS TO RF FIELD [[§§ 1.1310 & 2.1091] The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation. FCC 47 CFR § 1.1310: 5.4.1. Method of Measurements See RSS-102 & FCC 47 CFR §§ 1.1310, 2.1091 In order to demonstrate compliance with MPE requirements, the following information is typically needed: (1) Calculation that estimates the minimum separation distance (20 cm or more) between an antenna and persons required to satisfy power density limits defined for free space. (2) Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement (3) Any caution statements and/or warning labels that are necessary in order to comply with the exposure limits (4) Any other RF exposure related issues that may affect MPE compliance FCC Parts 2, 80 and 90 Page 15 VHF/UHF HI RF MODULE, Model: T3015 FCC ID: IMA-T3015 ULTRATECH GROUP OF LABS File #: TIL-091F80-90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 December 24, 2012 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) Calculation Method of RF Safety Distance : 22 44r EIRP r GP S       Where: P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm 5.4.2. RF Evaluation Evaluation of RF Exposure Compliance Requirements RF Exposure Requirements Compliance with FCC Rules *Minimum calculated separation distance between antenna and persons required: 72 cm Manufacturer’ instruction for separation distance between antenna and persons required: See the user’s manual for information. Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement Antenna installation and device operating instructions shall be provided to installers to maintain and ensure compliance with RF exposure requirements. Caution statements and/or warning labels that are necessary in order to comply with the exposure limits Refer to User’s Manual for RF Exposure Information. Any other RF exposure related issues that may affect MPE compliance None. *The minimum separation distance between the antenna and bodies of users are calculated using the following formula: RF EXPOSURE DISTANCE LIMITS S EIRP S GP r      44 S = 0.2 mW/cm 2 EIRP = 41.14 dBm = 10 41.14/10 mW = 13002 mW (Worst Case) (Minimum Safe Distance, r) = cm S EIRP 9.71 )2.0(4 13002 4     

December 24, 2012 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 80 and 90 Applicant: Technisonic Industries Limited Product: VHF/UHF HI RF MODULE Model: T3015 FCC ID: IMA-T3015 Dear Sir/Madam: As appointed agent for Technisonic Industries Limited, we submit the application for FCC certification of the above product. Kindly review all required documents uploaded to your E- Filing Site. The T3015 module is the same radio component used in FCC ID: AZ4 89FT4893 certification. According to 996369 D01 Module Certification Guide v01r03 – VII A, the Applicant has declared that the conducted tests applied to the FCC ID: AZ4 89FT4893 certification, accurately represent the test results under the new conditions. For conducted tests, refer to FCC ID: AZ4 89FT4893 test report, the additional test report provided in the filing will demonstrate full compliance under the new conditions. NOTE: This application is subject to modular approval; see Applicant’s cover letter requesting for modular approval. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 FCC 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 6 SHEET 1 OF 38 EXHIBIT 6 INDEX OF SUBMITTED MEASURED DATA This exhibit contains the measured data for this equipment as follows: EXHIBIT 6A – RF Power Output (Table) EXHIBIT 6B – Audio Frequency Response 6B-1 –485.025 MHz, 12.5 kHz Channel Spacing 6B-2 –155.025 MHz, 12.5 kHz Channel Spacing 6B-3 –485.025 MHz, 25 kHz Channel Spacing 6B-4 –155.025 MHz, 25 kHz Channel Spacing EXHIBIT 6C – Audio Low Pass Filter Response 6C-1 –485.025 MHz, 12.5 kHz Channel Spacing 6C-2 –155.025 MHz, 12.5 kHz Channel Spacing 6C-3 –485.025 MHz, 25 kHz Channel Spacing 6C-4 –155.025 MHz, 25 kHz Channel Spacing EXHIBIT 6D – Modulation Limiting 6D-1 –485.025 MHz, 12.5 kHz Channel Spacing 6D-2 –155.025 MHz, 12.5 kHz Channel Spacing 6D-3 –485.025 MHz, 25 kHz Channel Spacing 6D-4 –155.025 MHz, 25 kHz Channel Spacing EXHIBIT 6E – Occupied Bandwidth 6E-1 –485.075 MHz, 12.5 kHz Channel Spacing (Analog Voice) 6E-2 –153.0125 MHz, 12.5 kHz Channel Spacing (Analog Voice) 6E-3 –485.075 MHz, 25 kHz Channel Spacing (Analog Voice) 6E-4 –153.0125 MHz, 25 kHz Channel Spacing (Analog Voice) 6E-5 –485.075 MHz, 12.5 kHz Channel Spacing (Digital Data) 6E-6 –153.0125 MHz, 12.5 kHz Channel Spacing (Digital Data) 6E-7 –485.075 MHz, 12.5 kHz Channel Spacing (Digital Voice) 6E-8 –153.0125 MHz, 12.5 kHz Channel Spacing (Digital Voice) 6E-9 –485.075 MHz, 12.5 kHz Channel Spacing (Digital TDMA) 6E-10 –153.0125 MHz, 12.5 kHz Channel Spacing (Digital TDMA) 6E-11 –485.075 MHz, (Digital Voice with Encryption) 6E-12 –153.0125 MHz,(Digital Voice with Encryption) EXHIBIT 6F – Radiated Spurious Emissions 6F-1 - High Power 450.075, 485.075 MHz, 25 kHz Channel Spacing 6F-2 - High Power 519.975 MHz, 25 kHz Channel Spacing 6F-3 - High Power 136.0125, 153.0125 MHz, 25 kHz Channel Spacing 6F-4 - High Power 173.9875 MHz, 25 kHz Channel Spacing EXHIBIT 6G – Frequency Stability 6G-1 – 425.025 MHz vs. Supply Voltage 6G-2 –156.675 MHz vs. Supply Voltage 6G-3 – 425.0125 MHz vs. Temperature 6G-4 – 156.675 MHz vs. Temperature EXHIBIT 6H – Conducted Spurious Emissions Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 6 SHEET 2 OF 38 6F-1 - High Power 450.075 MHz, 25 kHz Channel Spacing 6F-2 - High Power 485.075 MHz, 25 kHz Channel Spacing 6F-3 - High Power 519.975 MHz, 25 kHz Channel Spacing 6F-4 - High Power 136.0125 MHz, 25 kHz Channel Spacing 6F-5 - High Power 153.0125 MHz, 25 kHz Channel Spacing 6F-6 - High Power 173.9875 MHz, 25 kHz Channel Spacing EXHIBIT 6I – Power Line Conducted Interference 6I-1- Radio Off Line/Neutral 6I-2- Radio On Line/Neutral 450.075MHz 6I-3- Radio On Line/Neutral 485.075MHz 6I-4- Radio On Line/Neutral 519.975MHz 6I-5- Radio On Line/Neutral 136.0125MHz 6I-6- Radio On Line/Neutral 153.0125MHz 6I-7- Radio On Line/Neutral 173.9875MHz EXHIBIT 6J – Transient Frequency Behavior 6J-1 – 485.075 MHz, 12.5 kHz Channel Spacing – Transmitter On 6J-2 – 485.075 MHz, 12.5 kHz Channel Spacing – Transmitter Off 6J-3 – 153.0125 MHz, 12.5 kHz Channel Spacing – Transmitter On 6J-4 – 153.0125 MHz, 12.5 kHz Channel Spacing – Transmitter Off 6J-5 – 485.075 MHz, 25 kHz Channel Spacing – Transmitter On 6J-6 – 485.075 MHz, 25 kHz Channel Spacing – Transmitter Off 6J-7 – 153.0125 MHz, 25 kHz Channel Spacing – Transmitter On 6J-8 – 153.0125 MHz, 25 kHz Channel Spacing – Transmitter Off Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 6 SHEET 3 OF 38 EXHIBIT 6A RF Conducted Power Output Data -- Pursuant 47 CFR 2.1046(a), 2.1033(c)(6), 2.1033(c)(7) and 2.1033(c)(8) Frequency = 485.025 MHz: Output RF power 1.0 Watts DC Voltage 7.50 Volts DC Current 1.42 Amps Output RF power 3.00 Watts DC Voltage 7.50 Volts DC Current 1.75 Amps Output RF power 5.6 Watts DC Voltage 7.50 Volts DC Current 2.03 Amps Frequency = 154.225 MHz: Output RF power 1.0 Watts DC Voltage 7.50 Volts DC Current 1.04 Amps Output RF power 3.00 Watts DC Voltage 7.50 Volts DC Current 1.47 Amps Output RF power 6.6 Watts DC Voltage 7.50 Volts DC Current 2.12 Amps Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 6 SHEET 4 OF 38 EXHIBIT 6B Transmit Audio Response - Pursuant 47 CFR 2.1047 and 2.1033(c) (13) Audio Frequency Response (Freq: 485.025MHz, ChSp: 12.5kHz) T X A UDIO FREQUENC Y RESPONSE 12. 5 k Hz -40 -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100.01000.010000.0 Audio Frequency in Hz Modulation Level in dB Exhibit 6B-1 Audio Frequency Response (Freq: 155.025MHz, ChSp: 12.5kHz) T X A UDIO FREQUENC Y RESPONSE 12.5 k Hz -40 -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100.01000.010000.0 Audio Frequency in Hz Modulation Level in dB Exhibit 6B-2 Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 6 SHEET 5 OF 38 Audio Frequency Response (Freq: 485.025MHz, ChSp: 25kHz) T X A UDIO FREQUENC Y RESPONSE 25 k Hz -40 -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100.01000.010000.0 Audio Frequency in Hz Modulation Level in dB Exhibit 6B-3 Audio Frequency Response (Freq: 155.025MHz, ChSp: 25kHz) T X A UDIO FREQUENC Y RESPONSE 12. 5 k Hz -40 -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100.01000.010000.0 Audio Frequency in Hz Modulation L evel in dB Exhibit 6B-4 Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 6 SHEET 6 OF 38 EXHIBIT 6C Audio Low Pass Filter Response- Pursuant 47 CFR 2.1047 and 2.1033(c)(13) Transmit Low Pass Filter Frequency Response (Freq: 485.025MHz, ChSp: 12.5kHz) Tx Audio Low Pass Filter Response 12.5 kHz -100 -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 100010000100000 Audio Frequency in Hz dB Exhibit 6C-1 Transmit Low Pass Filter Frequency Response (Freq: 155.025MHz, ChSp: 12.5kHz) Tx Audio Low Pass Filter Response 12.5 kHz -100 -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 100010000100000 Audio Frequency in Hz dB Exhibit 6C-2 Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 6 SHEET 7 OF 38 Transmit Low Pass Filter Frequency Response (Freq: 485.025MHz, ChSp: 25kHz) Tx Audio Low Pass Filter Response 25 kHz -100 -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1000.0010000.00100000.00 Audio Frequency in Hz dB Exhibit 6C-3 Transmit Low Pass Filter Frequency Response (F…

Text truncated - open the document above for the full version.

Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 7 SHEET 1 OF 6 Measurement Procedure & Test Equipment Used Except where otherwise stated, all measurements are made following the Electronic Industries Association (EIA) Minimum Standard for Portable/Personal Land Mobile Communications FM or PM Equipment 25-1000 MHz-(EIA/TIA-603). This exhibit presents a brief summary of how the measurements were made, the required limits, and the test equipment used. The following procedures are presented with this application. 1. Test Equipment List x 2. RF Power Output Data x 3. Audio Frequency Response x 4. Audio Low Pass Filter Response x 5. Modulation Limiting x 6. Occupied Bandwidth x 7. Radiated Spurious Emissions x 8. Conducted Spurious Emissions x 9. Power Line Conducted Emissions x 10. Frequency Stability (Volt/Temp) x 11. Transient Frequency Behavior x Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 7 SHEET 2 OF 6 Test Equipment List Pursuant To FCC Rules 2.947 (d) 1) Computer: DELL Latitude D600 Notebook, Window 2000. 2) Spectrum Analyzer: Agilent E4445A, 3 Hz – 13.2 GHz 3) Spectrum Analyzer: HP 8560E, 30 Hz - 2.9 GHz. 4) Dynamic Signal Analyzer: HP35665A 5) RF Signal Generator: E4420BB, 250 kHz – 2 GHz RF Signal Generator. 6) Modulation Analyzer. HP 8901B. 7) Audio Analyzer .HP 8903B. 8) Power Meter. HP437B. Sensor 80401A 9) Oscilloscope. Phillips PM3382. 10) Multimeter: Hewlett Packard 34401A. 11) DC Power Supply: Hewlett Packard 6623A 12) Directional Coupler: Hewlett Packard 778D, Dual Directional Coupler. 13) Temperature Chamber: VOTSCH, VT4010. 14) 30 dB attenuator: MCE/Weinschel, model 33-30-34 15) HP35665A Dynamic Signal Analyzer 16) High Pass Filter, Mini-Circuit NHP 300 & 25W 17) MCE/Weinschel 1429-4, 50 ohms terminating load RF Power Output Pursuant to FCC Rules 2.1046 (a) Method of Measurement The RF power output is measured with the transmitter adjusted in accordance with the tune-up procedure outlined in Exhibit 10 to give the value of voltage and current as specified in Exhibit 12 as required by 2.1033(c) (8). A 50-ohm RF attenuator of proper power rating was used as a load for making these measurements. The power measurements are made using an Agilent series E4419B RF power meter and 30 dB attenuator. Audio Frequency Response Pursuant FCC Rules 2.1047 (a) Method of Measurement Operate the transmitter under standard test conditions and monitor the output with a frequency deviation meter or calibrated test receiver. With 1000 Hz sine wave audio input applied through a dummy microphone circuit, adjust the audio input to give 20% of full rated system deviation. Maintaining a constant input voltage, vary the input frequency from 300 to 3000 Hz, and observe the deviation. Minimum Standard The audio frequency response shall not vary more than +1 or -3 dB from 300 to 3000 Hz from a true 6 dB per octave pre-emphasis characteristic as referenced to 1000 Hz level, with the exception of a permissible 6 dB/octave roll off below 500 Hz. Equivalent to TIA/EIA 603 Section 5.2.6.2 mask. Applicant: Motorola Inc. FCC ID: AZ489FT4893 EXHIBIT 7 SHEET 3 OF 6 Audio Low Pass Filter Response Pursuant FCC …

Text truncated - open the document above for the full version.
