IMA-T6Analog Multiband RF Module

T6 ANALOG MULTIBAND RF MODULE Installation and Operating Instructions TiL Document No. 22RE638 Revision B OCTOBER 2022 Technisonic Industries Limited 240 Traders Boulevard, Mississauga, Ontario L4Z 1W7 Tel: (905) 890-2113 Fax: (905) 890-5338 www.til.ca Copyright by Technisonic Industries Limited. All rights reserved. CAUTION STATIC SENSITIVE ! This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves when handling printed circuit boards. FCC COMPLIANCE INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: For compliance with FCC RF Exposure Requirements the mobile transmitter antenna installation shall comply with the following two conditions: 1. The transmitter antenna gain shall not exceed 3 dBi. 2. The transmitter antennas shall be located outside of a vehicle and must not be co-located (kept at a separation distance of more than 20 cm from each other when installed). Also, they must be installed in such a way that they always maintain a separation distance of more than 113 cm from any person during operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his/her own expense. WARNING AND DISCLAIMER Changes or modifications not expressly approved by Technisonic Industries could void the user’s authority to operate the equipment. This manual is designed to provide information about the T6 Multiband transceiver module. Every effort has been made to make this manual as complete and accurate as possible. WARRANTY INFORMATION The Model T6 Transceiver Module is under warranty for one year from the date of purchase. Failed units caused by defective parts or workmanship should be returned to: Technisonic Industries Limited 240 Traders Boulevard Mississauga, Ontario L4Z 1W7 Tel: (905) 890-2113 Fax: (905) 890-5338 NOTES TECHNISONIC INDUSTRIES LIMITED T6 Multiband Transceiver Module Operating Instructions TiL 22RE638 Revision A iii SECTION TITLE PAGE 1 GENERAL DESCRIPTION B 1.1 INTRODUCTION ............................................................................................................. 1 1.2 DESCRIPTION ................................................................................................................ 1 2 OPERATING INSTRUCTIONS B 2.1 GENERAL ....................................................................................................................... 2 2.2 FRONT PANEL ............................................................................................................... 2 2.3 POWER SWITCH ............................................................................................................ 2 2.4 KNOB .............................................................................................................................. 2 2.5 SOFT KEYS AND HOME ................................................................................................ 3 2.6 BAND KEY ...................................................................................................................... 3 2.7 MUP(4) AND MDN(7) KEYS (MEMORY UP AND DOWN KEYS) .................................. 3 2.8 BRT(6) AND DIM(9) KEYS .............................................................................................. 3 2.9 DISPLAY ......................................................................................................................... 4 2.10 GENERAL OPERATION ................................................................................................. 4 2.11 FRONT PANEL PROGRAMMING ................................................................................. 4 3 INSTALLATION INSTRUCTIONS B 3.1 GENERAL ....................................................................................................................... 6 3.2 INSTALL INTERFACE BOARD ...................................................................................... 6 3.3 INSTALL MODULE ......................................................................................................... 7 3.4 ALIGNMENT AND TEST ................................................................................................. 7 4 SPECIFICATIONS B 4.1 SPECIFICATIONS .......................................................................................................... 8 TABLE OF CONTENTS TECHNISONIC INDUSTRIES LIMITED T6 Multiband Transceiver Module Operating Instructions TiL 22RE638 Revision A 1 1.1 INTRODUCTION This publication provides operating information for the T6 multiband transceiver module. 1.2 DESCRIPTION The T6 multiband transceiver module is designed to be installed in an airborne multiband radio such as one of the TDFM-9000 series transceivers. The T6 module can operate on the following bands: Band Frequency Range Modulation Usage VHF LO 30 to 50 MHz FM VHF 108 to 118 MHz AM Navigational Beacons Receive only VHF 118 to 138 MHz AM Civilian Aeronautical Communications UHF 225 to 400 MHz AM Military Aeronautical Communications The T6 module has no physical user interface. All control of the module is performed through a serial RS232 interface. The operating instructions in section 2 assume an installation in a Technison…

Text truncated - open the document above for the full version.

Date: September 21, 2022 To Whom It May Concern Subject: Authority to Act as an Agent Applicant: Steve McIntosh FCC ID: IMA-T6 Dear Sir/Madam: I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application for authorization of above equipment under F.C.C. Rules. The applicant hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. I also certify that the information provided, properly describe the device or system for which authorization is required. Regards Steve McIntosh

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: September 21, 2022 SUBJECT: FCC Application for FCC ID: IMA-T6 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Supplier’s Declaration of Conformity Authorization procedure pursuant to Part 15, Subpart B - Unintentional Radiators, portion of this composite filing. Regards, Steve McIntosh

Federal Communications Commission Authorization and Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 September 21, 2022 Ref: 8.33 kHz Channel Spacing for FCC ID: IMA-T6 To Whom It May Concern, Technisonic Industries Limited is aware that 8.33 kHz Channel Spacing will get a grant of Certification, but that there is no U.S. (United States) Rule making for 8.33 kHz operations and this operation will not be exercised within the U.S. as per the FAA. Regards, Steve McIntosh Engineering Manager email: [email protected]

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 19 October 2022 SUBJECT: UHF AM (225 to 400MHz) for FCC ID: IMA-T6 To Whom It May Concern: This equipment operates on UHF AM (225 to 400MHz). This band is for military use and not for FCC approval scope. Regards, Steve McIntosh Engineering Manager

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 19 October 2022 SUBJECT: FCC Application for FCC ID: IMA-T6 To Whom It May Concern: This equipment meets the requirements of the FCC Rules, Parts 90.203(e) The operator cannot program and transmit on frequencies other than those programmed by the manufacturer, service or maintenance personnel. As per FCC KDB Guidance # 634817, an alternate to listing exact frequencies, we, Technisonic Industries Limited, acknowledges that FCC rules will be violated if the device operates on unauthorized frequencies. Regards, Steve McIntosh Engineering Manager

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 19 October 2022 SUBJECT: Manufacturer’s Declaration for compliance with FCC KDB Guidance 996369 D01 FOR Licensed Modular Transmitter Approval similar to Sec 15.212 FCC ID: IMA-T6 To Whom It May Concern: The applicant hereby confirms that the following requirements per FCC KDB# 996369 for a Licensed Modular Transmitter are met for this Modular Approval certification: Modular Approval Checklist: Modular approval requirement Yes No 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly; The modular transmitter has its own shielding. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with requirements under conditions of excessive data rates or over-modulation. The modular transmitter provides limiting and data buffering on the inputs to prevent over modulation. 3. The module must contain power supply regulation on the module. The modular transmitter has its own power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). Not applicable for licensed module 5. The module must demonstrate compliance in a stand-alone configuration. The modular transmitter was tested in a standalone configuration. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. The modular transmitter is labeled with FCC identification number. The label can not be seen when installed in the main unit. A label will be placed on the outside of the unit that states: ‘Contains FCC ID: IMA-T6’ 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization A copy of the instructions are provided with the application. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093. Maximum Permissible Exposure (MPE) evaluation was conducted, specific instructions for users and installers are provided that ensures that the public is not exposed to radio frequency energy levels in excess of the commission’s guidelines. Dated: 19 October 2022 Steve McIntosh Title: Engineering Manager On behalf of: Technisonic Industries Limited Phone No: (905) 890-2113 x205 Fax No: (905) 890-5338 Email: [email protected]

Date: September 21, 2022 To Whom It May Concern Subject: Confidentiality Letter Applicant: Steve McIntosh FCC ID: IMA-T6 Dear Sir/Madam: The applicant would like to request the following documents submitted with this application for certification be withheld from public disclosure as per Section 0.457 & 0.459 of FCC Rules. 1. Operational Description 2. Block Diagram 3. Schematic(s) 4. Parts List 5. Tuning info The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Regards Steve McIntosh

Technisonic Industries Ltd. 240 Traders Blvd. Mississauga, Ontario L4Z 1W7 Sept 21, 2022 Jae Shin Spectrum Planning and International Group Federal Aviation Administration This letter has been prepared by Technisonic Industries Ltd. to notify the FAA of a certification application (87.147 Authorization of Equipment) for our new T6 MultiBand Transceiver Module. Equipment Description The T6 Transceiver will be a module in our existing TDFM-9100, TDFM-9200 and TDFM-9300 as well as future Airborne Radios. The Current TDFM-9x00 radios are meeting environment requirements of DO160C also is STC approved for rotorcraft and fixed wing aircraft. We are not seeking TSO approval for the T6 transceiver. The T6 will be used for non-primary communication for the National Guard, Police, Border Protection, and other United States and Canadian government agencies. The T6 Transceiver is a MultiBand RF module covering 4 bands in the 30 to 400MHz range. • Low Band FM (30 to 50MHz) • VOR Voice AM (107 to 117.9MHz) - RX Only • VHF AM (118 to 138MHz) • UHF AM (225 to 400MHz) This letter will only cover the VHF AM band. FCC Identification number IMA-T6 Manufacture and Model number Manufacture Number – 193073 Module Number - T6 Rated Power Output Nominal RF carrier power is 4W, Modulation depth will not Exceed 95% and Occupied bandwidth will comply with applicable FCC rules part 87. Frequencies Range The Transceiver will operate from 117.975 to 136.975MHz for 25kHz Ch Spacing and 117.975 to 136.992MHz for 8.33kHz Ch Spacing. Method of tuning Synthesizer Channeling capability 25 kHz and 8.33 kHz *Note – 8.33KHz channels will be locked out for US Frequency stability 1 ppm Emission Bandwidth 6 kHz Emission Type Emission Designator - 6K00A3E 25 kHz Ch Spacing and 5K6A3E 8.33 kHz Ch Spacing Class of Emission – A3E Antenna Characteristics The antenna will be a quarter wave ground plane antenna. Receiver Characteristics The receiver is Dual Conversion with first IF 45 MHz and second IF 1.92 MHz. The nominal sensitivity will be 12dB SINAD at 2uV. No special protection will be required. Desensitization (2.2.11 DO-186) Transceiver meets the standard for desensitization specified in section 2.2.11 of RTCA DO-186 on both 25KHz and 8.33KHz channel spacing. Emission Plots 118MHz – See Figure 1 and 2 128MHz – See Figure 3 and 4 136.975MHz – See Figure 5 and 6 Harmonic Levels in GNSS Band (2.3.7 DO-186) TX Frequency (MHz) Harmonic Harmonic Frequency (MHz) See Figure 130.625 12 1567.500 7 131.275 12 1575.300 8 134.150 12 1609.800 9 120.925 13 1572.025 10 121.175 13 1575.275 11 123.825 13 1609.725 12 Ref 40 dBmAtt 35 dB * * Offset 30.7 dB 1 PK VIEW A LVL 3DB RBW 100 kHz VBW 1 MHz SWT 25 ms Start30 MHzStop250 MHz22 MHz/ EXT -60 -50 -40 -30 -20 -10 0 10 20 30 40 1 Marker 1 [T1 ] 36.11 dBm 117.788461538 MHz LIMIT-13 Date: 21.JUL.2022 11:05:55 Figure 1 Ref 10 dBmAtt 5 dB * * Offset 30.7 dB 1 PK VIEW A LVL 3DB RBW 100 kHz VBW 1 MHz SWT 175 ms Start250 MHzStop2 GHz175 MHz/ EXT -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -26.25 dBm 353.766025641 MHz 2 Marker 2 [T1 ] -46.30 dBm 1.063301282 GHz LIMIT-13 Date: 21.JUL.2022 11:07:34 Figure 2 R e f 4 0 d B m A t t 3 5 d B * * O f f s e t 3 0 . 7 d B 1 P K V I E W A L V L 3 D B R B W 1 0 0 k H z V B W 1 M H z S W T 2 5 m s S t a r t 3 0 M H z S t o p 2 5 0 M H z 2 2 M H z / E X T - 6 0 - 5 0 - 4 0 - 3 0 - 2 0 - 1 0 0 1 0 2 0 3 0 4 0 1 M a r k e r 1 [ T 1 ] 3 6 . 0 9 d B m 1 2 8 . 0 1 2 8 2 0 5 1 3 M H z L I M I T - 1 3 Date: 21.JUL.2022 11:08:41 Figure 3 Ref 10 dBmAtt 5 dB * * Offset 30.7 dB 1 PK VIEW A LVL 3DB RBW 100 kHz VBW 1 MHz SWT 175 ms Start250 MHzStop2 GHz175 MHz/ EXT -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -19.93 dBm 255.608974359 MHz 2 Marker 2 [T1 ] -27.85 dBm 381.810897436 MHz LIMIT-13 Date: 21.JUL.2022 11:09:26 Figure 4 R e f 4 0 d B m A t t 3 5 d B * * O f f s e t 3 0 . 7 d B 1 P K V I E W A L V L 3 D B R B W 1 0 0 k H z V B W 1 M H z S W T 2 5 m s S t a r t 3 0 M H z S t o p 2 5 0 M H z 2 2 M H z / E X T - 6 0 - 5 0 - 4 0 - 3 0 - 2 0 - 1 0 0 1 0 2 0 3 0 4 0 1 M a r k e r 1 [ T 1 ] 3 6 . 1 3 d B m 1 3 7 . 8 8 4 6 1 5 3 8 5 M H z L I M I T - 1 3 Date: 21.JUL.2022 11:11:50 Figure 5 Ref 10 dBmAtt 5 dB * * Offset 30.7 dB 1 PK VIEW A LVL 3DB RBW 100 kHz VBW 1 MHz SWT 175 ms Start250 MHzStop2 GHz175 MHz/ EXT -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -20.81 dBm 275.240384615 MHz 2 Marker 2 [T1 ] -28.98 dBm 412.660256410 MHz 3 Marker 3 [T1 ] -45.07 dBm 1.932692308 GHz LIMIT-13 Date: 21.JUL.2022 11:12:32 Figure 6 Ref-40 dBmAtt 5 dB * * Offset-20 dB 1 PK VIEW A LVL 3DB RBW 1 MHz VBW 3 MHz SWT 2.5 ms Center1.5675 GHzSpan10 MHz1 MHz/ EXT -140 -130 -120 -110 -100 -90 -80 -70 -60 -50 -40 1 Marker 1 [T1 ] -93.92 dBm 1.569695513 GHz Date: 21.JUL.2022 10:12:15 Figure 7 Ref-40 dBmAtt 5 dB * * Offset-20 dB 1 PK VIEW A LVL 3DB RBW 1 MHz VBW 3 MHz SWT 2.5 ms Center1.5753 GHzSpan10 MHz1 MHz/ EXT -140 -130 -120 -110 -100 -90 -80 -70 -60 -50 -40 1 Marker 1 [T1 ] -94.07 dBm 1.575957051 GHz Date: 21.JUL.2022 10:17:18 Figure 8 R e f - 4 0 d B m A t t 5 d B * * O f f s e t - 2 0 d B 1 P K V I E W A L V L 3 D B R B W 1 M H z V B W 3 M H z S W T 2 . 5 m s C e n t e r 1 . 6 0 9 8 G H z S p a n 1 0 M H z 1 M H z / E X T - 1 4 0 - 1 3 0 - 1 2 0 - 1 1 0 - 1 0 0 - 9 0 - 8 0 - 7 0 - 6 0 - 5 0 - 4 0 1 M a r k e r 1 [ T 1 ] - 9 4 . 2 1 d B m 1 . 6 0 5 2 8 0 7 6 9 G H z Date: 21.JUL.2022 10:19:41 Figure 9 Ref-40 dBmAtt 5 dB * * Offset-20 dB 1 PK VIEW A LVL 3DB RBW 1 MHz VBW 3 MHz SWT 2.5 ms Center1.572025 GHzSpan10 MHz1 MHz/ EXT -140 -130 -120 -110 -100 -90 -80 -70 -60 -50 -40 1 Marker 1 [T1 ] -94.28 dBm 1.568948077 GHz Date: 21.JUL.2022 10:22:34 Figure 10 R e f - 4 0 d B m A t t 5 d B * * O f f s e t - 2 0 d B 1 P K V I E W A L V L 3 D B R B W 1 M H z V B W 3 M H z S W T 2 . 5 m s C e n t e r 1 . 5 7 5 2 7 5 G H z S p a n 1 0 M H z 1 M H z / E X T - 1 4 0 - 1 3 0 - 1 2 0 - 1 1 0 - 1 0 0 - 9 0 - 8 0 - 7 0 - 6 0 - 5 0 - 4 0 1 M a r k e r 1 [ T 1 ] - 9 3 . 6 0 d B m 1 . 5 …

Text truncated - open the document above for the full version.

800 Independence Ave., S. W. Washington, D. C. 20591 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Dear Mr. Corey Cahill: The Federal Aviation Administration, Spectrum Engineering Services Group received the Technisonic Industries Ltd. notification letter of its filing with the Federal Communications Commission (FCC). The application is for certification of the T6 Transceiver with FCC ID: IMA-T6. We have completed the review process of the information submitted by Technisonic Industries Ltd. and concluded that we have no objection to the FCC granting certification for this equipment. If you require any additional information, please contact Mr. Jae Shin, Electronics Engineer, Spectrum Planning and International Group, at (202) 267-7365 or via e-mail [email protected]. Sincerely, Michael Weiler Group Manager Spectrum Engineering Services

Ultr Gro FCC T Accreditat APEC CA A SL2- Kore 3000 Oak Can Tel.: Fax.: Website: w Email: vic@ raTech oup of Labs TCB & ISED CB tions: C TEL CA0001 1309 A0001/2049 AT-1945 -IN-E-1119R ea KCC-RRA CA0001 0 Bristol Circle, kville, Ontario, nada L6H 6G4 (905) 829-1570 (905) 829-8050 www.ultratech-labs.com @ultratech-labs.com O U 30 O L6 S D As ce E- N If Yo Sa Sa A h m October 28, 20 ltratech Eng 000 Bristol Ci Oakville, Ontar 6H 6G4 ubject: ear Sir/Mada s appointed a ertification of -Filing web si OTE: This ap reques you have any ours truly, Santhosh Fernand anthosh Fern uthorized Age 022 ineering Lab rcle rio Equipment Non-Broad 30-50 MHz Operating Applicant: Product: Model: FCC ID: m: agent for Tech the above pro te. pplication is s sting for modu y queries, ple dez nandez ent bs, Inc. t Authorizati dcast Radio T and 7 (Subp in the Frequ Technis Analog T6 IMA-T6 hnisonic Indu oduct. Please subject to mod ular approval. ease do not he on under FC Transceivers part D) - Non- ency Band 1 sonic Industr Multiband R stries Limited e review all re dular approva . esitate to con CC 47 CFR, P s Operating i -broadcast A 117.975 - 138 ries Limited RF Module d, we submit t equired docum al; see Applic ntact us. Parts 2, 90 (S in the Freque Aviation Rad 8 MHz. the applicatio ments uploade ant’s cover le ubpart I) - ency Band io Services n for ed to your etter 8

Test Jig Housing the Module Module photo

Label and locationn

Model: T6 FCC ID: IMA‐T6 MPE 1.1. RF EXPOSURE REQUIRMENTS [§§ 1.1310 & 2.1091] [RSS Gen Sec 5.6 & RSS-102] The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio‐frequency (RF) radiation. FCC 47 CFR § 1.1310: 1.1.1. Method of Measurements Refer to Sections 1.1310, 2.1091 In order to demonstrate compliance with MPE requirements (see Section 2.1091), the following information is typically needed: (1) Calculation that estimates the minimum separation distance (20 cm or more) between an antenna and persons required to satisfy power density limits defined for free space. (2) Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement (3) Any caution statements and/or warning labels that are necessary in order to comply with the exposure limits (4) Any other RF exposure related issues that may affect MPE compliance Model: T6 FCC ID: IMA‐T6 MPE RSS Gen Sec 5.6 & RSS‐102] Table 4: RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m 2 ) Reference Period (minutes) 0.003-10 21 83 90 - Instantaneous* 0.1-10 - 0.73/ ƒ - 6** 1.1-10 87/ ƒ 0.5 - - 6** 10-20 27.46 0.0728 2 6 20-48 58.07/ ƒ 0.25 0.1540/ ƒ 0.25 8.944/ ƒ 0.5 6 48-300 22.06 0.05852 1.291 6 300-6000 3.142 ƒ 0.3417 0.008335 ƒ 0.3417 0.02619ƒ 0.6834 6 6000-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ ƒ 1.2 Note: ƒ is frequency in MHz. *Based on nerve stimulation (NS). ** Based on specific absorption rate (SAR). Note 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. Note 2: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Model: T6 FCC ID: IMA‐T6 MPE Calculation Method of RF Safety Distance: 22 44r EIRP r GP S       Where: P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm 1.1.2. RF Evaluation Bands 30‐50 MHz is 10W and 117.975‐137 MHz is 4.5W, below represent worst case distance for RF Exposure Maximum RF Power conducted, P conducted [W]: 10.23 Maximum Antenna Gain, G[dBi]: 3 Maximum EIRP, P EIRP [W]: 20.42 MPE Environment FCC Power Density limit , S (mW/m 2 ) FCC Minimum Distance (Cm) Distance In user’s manual (Cm) Power Density at user’s manual distance, S (mW/m 2 ) General Population/Uncontrolled Exposure 0.2 91 113 0.127 MPE Environment ISED Power Density limit , S (mW/m 2 ) ISED Minimum Distance (Cm) Distance In user’s manual (Cm) Power Density at user’s manual distance, S (mW/m 2 ) General Population/Uncontrolled Exposure 0.1291 113 113 0.127 Model: T6 FCC ID: IMA‐T6 MPE

This T Tri M. Vice P UltraT Date: S Repor Issue d  The res  This re  This te #0685 Test report is I Luu President of E ech Group of September 2 rt Prepared by d Date: Septe sults in this Test eport must not be st report shall no Web 5 APE TEL#CA A Te Federal C 47 C U Issued under Engineering f Labs 9, 2022 y: Santhosh F ember 29, 202 Report apply on e used by the clie ot be reproduced 300 bsite: www.ultratech EC A0001 13 Analog Mul M FCC IC A echnisonic 240 Tr Mississ Cana Tested in Communic FR, Parts 2 ISED RS UltraTech's F the Authority Fernandez 22 nly to the sample ent to claim produ d, except in full, w Ult 00 Bristol Circle, O Tel.: (905) 829-1 5 h-labs.com, Email: 309 CA ltiband RF Model:T6 C ID:IMA-T6 C:120A-T6 Applicant: c Industries raders Blvd sauga, Onta ada L4Z 1W Accordance cations Com 2 and 90 (S SS-119, Iss File No.: 22TI y of Teste Test (s) tested, and th uct endorsement without a written traTech akville, Ontario, C a 570 Fax.: (905 vic@ultratech-labs A0001/2049 Module s Limited . E. ario W7 e With mmission Subpart I) ue 12 IL129-F90 ed by: Nimish Dates: Augu he sample tested t by any agency approval from U l h anada, L6H 6G4 5) 829-8050 s.com, Email: tri@u AT-1945 (FCC) & a Desai and A st 17- Sep 21 d is randomly sel of the US Gover ltraTech ultratech-labs.com 5 S Angus Au 1, 2022 lected. rnment. Ko K R SL2-IN-E- 1119R CA orea CC- RRA A000 1 FCC Parts 2 & 90, Subpart I, RSS-119 Contents i Model: T6 FCC ID: IMA-T6 ULTRATECH GROUP OF LABS File #: 22TIL129-F90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 September29, 2022 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ......................................................................................................................................... 1 1.1. SCOPE ......................................................................................................................................................................... 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................... 1 1.3. NORMATIVE REFERENCES ................................................................................................................................... 1 1.4. ........................................................................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT .............................................................................................................. 2 2.1. CLIENT INFORMATION .......................................................................................................................................... 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION .............................................................................................. 2 2.3. EUT’S TECHNICAL SPECIFICATIONS .................................................................................................................. 3 2.4. LIST OF EUT’S PORTS ............................................................................................................................................. 3 2.5. ANCILLARY EQUIPMENT .............................................................................................................................................. 3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ............................... 4 3.1. CLIMATE TEST CONDITIONS ................................................................................................................................ 4 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS .............................................. 4 EXHIBIT 4. SUMMARY OF TEST RESULTS ............................................................................................................... 5 4.1. LOCATION OF TESTS .............................................................................................................................................. 5 4.2. APPLICABILITY & SUMMARY OF EMISSION TEST RESULTS ......................................................................... 5 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ......................................... 6 4.4. DEVIATION OF STANDARD TEST PROCEDURES .............................................................................................. 6 EXHIBIT 5. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS ............................... 7 5.1. TEST PROCEDURES ................................................................................................................................................. 7 5.2. MEASUREMENT UNCERTAINTIES ................................................…

Text truncated - open the document above for the full version.
