ISEIEXLow Power Transmitter

• Observe temperature and humidity restrictions —Refer to the Specifi cations table. • Leave slack in the cable —Leave at least 10 ft. (3 m) of slack in the communication and power cable to allow for adjustments in the location of the Exciter. • No user adjustments to internal circuitry —Tampering may cause component or system failure, or both, and will void the warranty. Important Reference Documents• Hugs Installation Manual (p/n 805I0301)• Hugs System Manual (p/n 805U1601)• Exciter Tester Sheet (p/n 806U6301)Specifi cations Materials Required • Exciter. Includes door contact, L-bracket, adhesive mount, cable ties, and bumpons. • Facility fl oor plan indicating Exciter position and installation orientation, and network wiring path. • 105 Ω network terminator (p/n 805A2401) required to terminate network. Two provided with each Controller (p/n 805A2201) or Laptop Controller (p/n 805A2202). • Mounting hardware, all installations: • 4 Hollow wall anchors, for No. 10 wood screws• 4 No. 10 x 1” stainless steel wood screws • Additional mounting hardware, L-bracket installations: • 4 No. 10 - 3/32” x 3/4” Philips/Pan head screws• 4 Stainless steel hex nuts• 4 No. 10 stainless steel fl at washers • Optional: Passive infrared sensor for open doorways where door contact cannot be used. Refer to Chapter 2 of the Hugs Instal- lation Manual (p/n 805I0301) for important limitations on using PIR sensors. Installation Considerations• Avoid metal —Do not install the Exciter behind or within 2 inches (50 mm) of metal objects, including metal doors. These objects block the detection area of the Exciter. • Use door contacts —Door contacts are required to minimize nuisance alarms. • Confi gure nearby Exciters as slaves —Exciters installed within 30 feet (9 m) of each other must be confi gured as master and slave. Up to four slaves may be connected to one master. Materials Required Specifi cations Installation Considerations Important Reference Documents WarrantyVeriChip’s products are warranted against defects in materials and work-manship and shall perform in accordance with published specifi cations for a period of one year. VeriChip reserves the right to change specifi ca- tions without notice. Limitation of LiabilityThis Product has been designed for use to assist in the prevention of infant abduction and/or mother/infant mismatching.The range, accuracy, function and performance of this Product may vary from the published specifi cations due to many factors, including, without limitation, site impairments from structural effects, metal objects in the vicinity, placement of the receiver and transmitter, interference from other electrical devices, atmospheric effects, installation, and maintenance. There may be other factors, which also affect performance of this Product. VeriChip does not guarantee that this Product will detect 100% of infant abductions and/or mother/infant mismatches. VeriChip does not guar-antee that this Product will not return false reports of infant abductions and/or mother/infant mismatches. Monthly testing and maintenance of this Product, as described in the Product documentation, is essential to verify the system is operating correctly and to ensure that the probability of detecting an alarm and/or locating the transmitter are maximized. The failure to undertake regular testing and maintenance will increase the risk of system failure and failure to detect infant abductions and/or mother/infant mismatches. The failure to undertake regular testing and maintenance will increase the risk of false reports of infant abductions and/or mother/infant mismatches.VeriChip hereby disclaims all warranties, express or implied, arising out of or in connection with any of its Products of the use or performance thereof, including but not limited to, where allowable by law, all other implied warranties or conditions of merchantable quality and fi tness for a particular purpose and those arising by statute or otherwise in law or from a course of dealing or usage of trade.VeriChip’s liability to you or anyone claiming through or on behalf of you with respect to any claim or loss arising out of the use or misuse of VeriChip’s Product, defective products or materials, improper installa-tion or maintenance of VeriChip’s Product or products or the system in which they are incorporated, or alleged to have resulted from an act or omission of VeriChip or any person, negligent or otherwise, shall be limited to:a) the repair or replacement of defective Product or materials supplied by VeriChip during the warranty period as set out in the Product documentation; or, at the option of VeriChip, b) refund of the purchase price of the Product supplied by VeriChip.In no event shall VeriChip be liable for general, specifi c, indirect, con- sequential, incidental, exemplary or punitive damages or any losses or expenses suffered by you or anyone else, whether or not VeriChip, or its employees, offi cers, agents, resellers or installers has been informed of the risk of such loss or expense and whether or not such losses or expenses were foreseeable.StatementsUnited States—Federal Communication Commission (FCC)This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communica-tions. Operation of this equipment in a residential area is likely…

Text truncated - open the document above for the full version.

FCC Part 15 Subpart B, March 2005 Test Report: 5W49975.3 Issue 2 Applicant: Instantel Inc. 309 Legget Drive Kanata, Ontario K2K 3A3 Apparatus: International Exciter FCC ID: ISEIEX In Accordance With: FCC Part 15 Subpart C, 15.207 and 15.209 Intentional Radiators Tested By: Nemko Canada Inc. 303 River Road Ottawa, Ontario K1V 1H2 Authorized By: Sim Jagpal, Resource Manager Date: 26 August 2005 Total Number of Pages: 16 Nemko Canada Inc. REPORT SUMMARY Report Number: 5W49975.3 Issue 2 FCC ID: ISEIEX Specification: FCC Part 15 Subpart C Page 2 of 16 Report Summary These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C. Radiated tests were conducted in accordance with ANSI C63.4-2003. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. The assessment summary is as follows: Apparatus Assessed: International Exciter Specification: FCC Part 15 Subpart C, 15.207 and 15.209 Compliance Status: Complies Exclusions: None Non-compliances: None Report Release History: Issue 2 – Reported all field strength measurements in dBuV/m Author: Jason Nixon, Telecom Specialist Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. Nemko Canada Inc. REPORT SUMMARY Report Number: 5W49975.3 Issue 2 FCC ID: ISEIEX Specification: FCC Part 15 Subpart C Page 3 of 16 TABLE OF CONTENTS Report Summary......................................................................................................................................... 2 Section 1 : Equipment Under Test............................................................................................................. 4 1.1 Product Identification .................................................................................................................................4 1.2 Samples Submitted for Assessment............................................................................................................4 1.3 Theory of Operation ...................................................................................................................................4 1.4 Technical Specifications of the EUT ..........................................................................................................4 Section 2 : Test Conditions......................................................................................................................... 5 2.1 Specifications .............................................................................................................................................5 2.2 Deviations From Laboratory Test Procedures ............................................................................................5 2.3 Test Environment .......................................................................................................................................5 2.4 Test Equipment...........................................................................................................................................5 Section 3 : Observations ............................................................................................................................. 6 3.1 Modifications Performed During Assessment ............................................................................................6 3.2 Record Of Technical Judgements ...............................................................................................................6 3.3 EUT Parameters Affecting Compliance .....................................................................................................6 3.4 Test Deleted................................................................................................................................................6 3.5 Additional Observations .............................................................................................................................6 Section 4 : Results Summary ..................................................................................................................... 7 4.1 FCC Part 15 Subpart C : Test Results ........................................................................................................8 Appendix A : Test Results .......................................................................................................................... 9 Clause 15.207(a) Conducted Emissions ................................................................................................................9 Clause 15.209(a) Radiated Emissions, General Limits........................................................................................13 Appendix B : Setup Photographs ............................................................................................................ 15 Appendix C : Block Diagram of Test Setups .......................................................................................... 16 Nemko Canada Inc. SECTION 1 : EQUIPMENT UNDER TEST Report Number: 5W49975.3 Issue 2 FCC ID: ISEIEX Specification: FCC Part 15 Subpart C Page 4 of 16 Section 1 : Equipment Under Test 1.1 Product Identification The Equipment Under Test was identified as follows: International Exciter (M/N: 806A6101) 1.2 S…

Text truncated - open the document above for the full version.

Nemko Canada Inc. APPENDIX B : SETUP PHOTOGRAPHS Report Number: 5W49975.3 Issue 2 FCC ID: ISEIEX Specification: FCC Part 15 Subpart C Page 15 of 16 Appendix B : Setup Photographs Conducted Emissions Setup: Spurious Emissions Setup:
