ITQ-CMW-300ST300ST Transmitter

300SR/ST - SUPPORT 1 SERIAL NUMBER RECORD 300SR/ST - SUPPORT 1 SERIAL NUMBER RECORD SUPPORT SERIAL NUMBER RECORDRecord the serial numbers and date of purchase of yourDitch Witch Subsite components in the spaces below. ItemDate of purchaseReceiver serial numberTransmitter serial numberAccessory model & serial numberAccessory model & serial number 1129h.eps SUPPORT SERIAL NUMBER RECORDRecord the serial numbers and date of purchase of yourDitch Witch Subsite components in the spaces below. ItemDate of purchaseReceiver serial numberTransmitter serial numberAccessory model & serial numberAccessory model & serial number 1129h.eps FCC ID: ITQ-CMW-300ST 2 300SR/ST - SUPPORT SERVICE PROCEDURE 2 300SR/ST - SUPPORT SERVICE PROCEDURE SERVICE PROCEDURENotify your dealer immediately of any malfunction of Ditch Witch Subsite equipment. Always give model, serial number, and approximate date of purchase. This information should be recorded and placed on file by owner at time of purchase. Give detailed explanation of malfunction.Return damaged parts to dealer for inspection and warranty consideration.Order genuine Ditch Witch Subsite replacement or repair parts from your dealer. Use of another manufacturer’s parts may void warranty. SERVICE PROCEDURENotify your dealer immediately of any malfunction of Ditch Witch Subsite equipment. Always give model, serial number, and approximate date of purchase. This information should be recorded and placed on file by owner at time of purchase. Give detailed explanation of malfunction.Return damaged parts to dealer for inspection and warranty consideration.Order genuine Ditch Witch Subsite replacement or repair parts from your dealer. Use of another manufacturer’s parts may void warranty. 300SR/ST - FOREWORD 3 300SR/ST - FOREWORD 3 FOREWORD This manual is an important part of your equipment. It provides safety information and operation instructions to help you use and maintain your Ditch Witch Subsite Electronics equipment. Read this manual before using your equipment. Keep it with the equipment at all times for future reference. If you sell your equipment, be sure to give this manual to the new owner.If you need a replacement copy, contact your Ditch Witch Subsite Electronics dealer. If you need assistance in locating a dealer, visit our website at www.ditchwitch.com or write to the following address: The Charles Machine Works, Inc.Attn: Subsite ElectronicsPO Box 66Perry, OK 73077-0066USA The descriptions and specifications in this manual are subject to change. The Charles Machine Works, Inc. reserves the right to improve equipment. Some product improvements may have taken place after this manual was published.Thank you for buying and using Ditch Witch Subsite Electronics equipment. FOREWORD This manual is an important part of your equipment. It provides safety information and operation instructions to help you use and maintain your Ditch Witch Subsite Electronics equipment. Read this manual before using your equipment. Keep it with the equipment at all times for future reference. If you sell your equipment, be sure to give this manual to the new owner.If you need a replacement copy, contact your Ditch Witch Subsite Electronics dealer. If you need assistance in locating a dealer, visit our website at www.ditchwitch.com or write to the following address: The Charles Machine Works, Inc.Attn: Subsite ElectronicsPO Box 66Perry, OK 73077-0066USA The descriptions and specifications in this manual are subject to change. The Charles Machine Works, Inc. reserves the right to improve equipment. Some product improvements may have taken place after this manual was published.Thank you for buying and using Ditch Witch Subsite Electronics equipment. 4 300SR/ST - FOREWORD 4 300SR/ST - FOREWORD Operator’s Manual 300SR/ST Issue No.1.0/OP - 4/02 Part Number 054 - 081 Copyright 2002 by The Charles Machine Works, Inc., Perry, Oklahoma , Ditch Witch, AutoCrowd, Modularmatic, Jet Trac, Roto Witch, Subsite, Fluid Miser, Sidekick, Perma-Soil, Super Witch, Super Witch II, and Pierce Airrow are registered trademarks of The Charles Machine Works, Inc.CMW, Power Pipe, The Underground, and The Underground Authority Worldwide are pending trademarks of The Charles Machine Works, Inc.U.S. Patent No. 5,065,098; 4,881,083. Other U.S. and foreign patents pending. Operator’s Manual 300SR/ST Issue No.1.0/OP - 4/02 Part Number 054 - 081 Copyright 2002 by The Charles Machine Works, Inc., Perry, Oklahoma , Ditch Witch, AutoCrowd, Modularmatic, Jet Trac, Roto Witch, Subsite, Fluid Miser, Sidekick, Perma-Soil, Super Witch, Super Witch II, and Pierce Airrow are registered trademarks of The Charles Machine Works, Inc.CMW, Power Pipe, The Underground, and The Underground Authority Worldwide are pending trademarks of The Charles Machine Works, Inc.U.S. Patent No. 5,065,098; 4,881,083. Other U.S. and foreign patents pending. 300SR/ST - CONTENTS 5 300SR/ST - CONTENTS 5 CONTENTS SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Serial Number Record . . . . . . . . . . . . . . . . . . . . . . . . . 1Service Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 FOREWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3RECEIVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7Single Key Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 82nd Function Controls . . . . . . . . . . . . . . . . . . . . . . . . 10Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 TRANSMITTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . 18Setup . . . . . . . . . . . …

Text truncated - open the document above for the full version.

TÜV MANAGEMENT SERVICEPhone: (651) 631 2487 TÜV PRODUCT SERVICE INC.Fax: (651) 638 0285 1775 Old Highway 8 NW, Suite 104email [email protected] New Brighton MN 55112-1891http:://www.tuvglobal.com Divisions of TÜV America Inc., a subsidiary of TÜV Süddeutschland and TÜV Nord Group TÜV PRODUCT SERVICE INC 19333 WILD MOUNTAIN ROAD TAYLORS FALLS, MINNESOTA 55084-1786 ENGINEERING STATEMENT For Certification of Subsite Electronics ( a sub-division of Charles Machine Works) Standard Pipe and Cable Locator System Model No(s): 300ST Transmitter FCC ID ITQ-CMW-300ST FRN: 0006-8824-50 I am an Electromagnetic Compatibility Engineer for TÜV PRODUCT SERVICE INC, Taylors Falls, Minnesota. My education and experience are a matter of record with the Federal Communications Commission. TÜV PRODUCT SERVICE INC has been authorized by Randy Richardson, Manager of Product Design of Subsite Electronics, to make Certification measurements and act as the authorized representative in the preparation of applications for registration of equipment. TÜV PRODUCT SERVICE INC is on file with the FCC under Paragraph 2.948 of the FCC Rules. Test data required by the TCB for Certification is included in this report. It is submitted that the above equipment meets the FCC Part 15, Subpart C (Section 15.213) requirements and Certification is hereby requested. Joel T. Schneider Chief Engineer Minnesota Wild River Lab TÜV Product Service [email protected] Dated: 12 June 2002

300 ST Block Diagram 4.0MHz Oscillator Frequency Synthesizer Pre amplifier and Gain control Power amplifier Power Supply Microprocessor Broadcast Antenna Direct Connect Output LCD DisplayKeypad Interface Battery Measurement and power output measurement FCC ID: ITQ-CMW-300ST

FCC ID: ITQ-CMW-300ST

FCC ID: ITQ-CMW-300ST

FCC ID: ITQ-CMW-300STPage 1 of 6 FCC ID: ITQ-CMW-300STPage 2 of 6 FCC ID: ITQ-CMW-300STPage 3 of 6 FCC ID: ITQ-CMW-300STPage 4 of 6 FCC ID: ITQ-CMW-300STPage 5 of 6 FCC ID: ITQ-CMW-300STPage 6 of 6

FCC ID: ITQ-CMW-300STPage 1 of 1 Label Placement

FCC ID: ITQ-CMW-300STPage 1 of 9 FCC ID: ITQ-CMW-300STPage 2 of 9 FCC ID: ITQ-CMW-300STPage 3 of 9

FCC ID: ITQ-CMW-300STPage 4 of 9 FCC ID: ITQ-CMW-300STPage 5 of 9 FCC ID: ITQ-CMW-300STPage 6 of 9

FCC ID: ITQ-CMW-300STPage 7 of 9 FCC ID: ITQ-CMW-300STPage 8 of 9 FCC ID: ITQ-CMW-300STPage 9 of 9

FCC ID: ITQ-CMW-300ST

TCB BABT Product Service 4855 Patrick Henry Drive, Building 6 Santa Clara CA 95054 Declaration of Compliance to RF Exposure Limits for Humans The 300ST Transmitter complies with the RF exposure limits for humans as called out in 2.1091 (mobile >20 cm) or 2.1093 (portable <20 cm). The 300ST Transmitter is used to locate underground cables. It is exempt from RF Evaluation based on its operating frequency of 29.4 kHz, and output power of 115 microwatts based on TP = (FS x D) 2 / 30 x 1.64, (2511 uV/m x 30) 2 / 30 x 1.64. This would be less than the 1.5 watt requirement for a mobile device and the 200 mW requirement for a portable device operating at 29.4 kHz. Joel T. Schneider Chief Engineer Minnesota Wild River Lab TÜV Product Service [email protected] Dated: 12 June 2002 FCC ID: ITQ-CMW-300ST

PRODUCT SERVICE TEST RESULT SUMMARY FCC PART 15 SUBPART C Section 15.213 MANUFACTURER'S NAMESubsite Electronics NAME OF EQUIPMENTCable Locating Transmitter MODEL NUMBER 300ST MANUFACTURER'S ADDRESS1950 West Fir Street Perry OK 73077 TEST REPORT NUMBERNC200679 TEST DATE19 February 2002 According to testing performed at TÜV Product Service Inc, the above-mentioned unit is in compliance with the electromagnetic compatibility requirements defined in FCC Part 15. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. TÜV Product Service Inc, as an independent testing laboratory, declares that the equipment tested as specified above conforms to the requirements of FCC Part 15. Date:25 March 2002 Location:Taylors Falls MNR. M. JohnsonT. K. Swanson USATest TechnicianTechnical Writer Not Transferable FCC ID: ITQ-CMW-300ST File No. NC200679, Page 1 of 12 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE EMC EMISSION - T E S T R E P O R T Test Report File No.: NC200679 Date of issue: 25 March 2002 Model / Serial No.: 300ST Product Type: Cable Locating Transmitter Applicant: Subsite Electronics Manufacturer: Subsite Electronics License holder: Subsite Electronics Address: 1950 West Fir Street : Perry OK 73077 Test Result: nn Positiveoo Negative Test Project Number: Reference(s) NC200679 Total pages including Appendices26 TÜV Product Service Inc is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO/IEC Guide 25 and EN 45001. TÜV Product Service Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV Product Service Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV Product Service Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV Product Service Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI File No. NC200679, Page 2 of 12 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE D I R E C T O R Y - EMISSIONS Page(s) A)Documentation Test report1 - 10 Directory2 Test Regulations3 Deviation from standard / Summary10 Test-setups (Photos)11 - 12 Test-setup (drawing)Appendix A B)Test data Conducted emissions10/150 kHz - 30 MHz5, 9 Radiated emissions10 kHz - 30 MHz5, 9 Radiated emissions30 MHz - 1000 MHz6, 9 Interference power30 MHz - 300 MHz6, 9 Equivalent Radiated emissions1 GHz - 18 GHz7, 9 C)Appendix A Test Data Sheets and Test Setup Drawing(s) A2 – A4 D)Appendix B Constructional Data Form B2 – B8 Product Information Form(s) N/A E)Appendix C Measurement ProtocolC1 - C2 File No. NC200679, Page 3 of 12 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: -------------------------------------------------------------------------------- o - EN 50081-1 / 1991 o - EN 55011 / 1991o - Group 1o - Group 2 o - Class Ao - Class B o - EN 55013 / 1990 o - EN 55014 / 1987o - Household appliances and similar o - Portable tools o - Semiconductor devices o - EN 55014 / A2:1990 o - EN 55014 / 1993o - Household appliances and similar o - Portable tools o - Semiconductor devices o - EN 55015 / 1987 o - EN 55015 / A1:1990 o - EN 55015 / 1993 o - EN 55022 / 1987o - Class Ao - Class B o - EN 55022 / 1994o - Class Ao - Class B o - BS o - VCCIo - Class Ao - Class B n - FCC Part 15 Subpart C Section 15.213 o - FCC Part 15 Subpart C Section 15.207 - Conducted o - FCC Part 15 Subpart Bo - Class Ao - Class B o - CISPR 11 (1990) o - Group 1o - Group 2 o - Class Ao - Class B o - CISPR 22 (1993) o - Class Ao - Class B File No. NC200679, Page 4 of 12 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE Environmental conditions in the lab: Actual Temperature: 15 °C Relative Humidity: 46 % Atmospheric pressure: 98.6 kPa Power supply system: 9 VDC Sign Explanations: o - not applicable n - applicable File No. NC200679, Page 5 of 12 TÜV PRODUCT SERVICE INC19035 Wild Mountain RoadTaylors Falls MN 55084-1758Tel: 651 638 0297Fax: 651 638 0298Rev.No 1.0 PRODUCT SERVICE Emissions Test Conditions: CONDUCTED EMISSIONS (15.207) The CONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: n - Test not applicable o - Wild River Lab Large Test Site (Open Area Test Site) o - Wild River Lab Small Test Site (Open Area Test Site) o - Oakwood Lab (Open Area Test Site) o - Wild River Lab Screen Room o - New Brighton Lab Shielded Room Emissions Test Conditions: RADIATED EMISSIONS (15.213 - 10 kHz to 30 MHz) The RADIATED EMISSIONS (MAGNETIC FIELD) measurements were performed at the following test location: o - Test not applicable o - Wild River Lab Large Test Site (Open Area Test Site) n - Wild River Lab Small Test Site (Open Area Test Site) – NSA measurements made 7-01, due 7-02. o - Oakwood Lab (Open Ar…

Text truncated - open the document above for the full version.

TEST SETUP FOR EMISSIONS TESTING WILD RIVER LAB Small Test Site (STS) EUT 180 27090 0 60 Hz 50 Hz Turntable is 1.2 meters in diameter Enlarged View of Shelter (4 meters square) STS Building Shelter 3 meter antenna 10 meter antenna 30 meter antenna Turntable Control Cable Ground Screen (34 meters long x 12 meters wide) 8 meters FCC ID: ITQ-CMW-300ST Radiated Emissions (Magnetic Field) Test Setup Radiated Emissions (Magnetic Field) Test Setup Radiated Emissions (Electric Field) Test Setup Radiated Emissions (Electric Field) Test Setup
