SUPERDISK USB DRIVE UNIT LKM-RMB33 INSTRUCTION MANUAL Please read through these instructions before operating the unit. Interface : USB iii TABLE OF CONTENTS IMPORTANT SAFETY NOTICE 1. PRECAUTIONS WHEN OPERATING ................................................................... A-2 1.1 PRECAUTIONS WHEN TRANSPORTING ...................................................... A-2 1.2 INSTALLATION LOCATION ............................................................................ A-2 1.3 PRECAUTIONS FOR USE .............................................................................. A-2 1.4 PRECAUTIONS FOR OPERATION ................................................................ A-2 1.5 PRECAUTIONS WHEN HANDLING DISKS .................................................... A-2 2. PARTS AND FUNCTIONS .................................................................................... A-3 2.1 FRONT VIEW ................................................................................................... A-3 2.2 REAR VIEW ..................................................................................................... A-4 3. CONNECTIONS ..................................................................................................... A-5 3.1 CONNECTING VIEW ....................................................................................... A-5 4. GUIDE TO OPERATION....................................................................................... A-6 4.1 INSTALLATIONS ............................................................................................. A-6 5. GENERAL DESCRIPTION .................................................................................... A-7 5.1 SUMMARY OF FEATURES ............................................................................. A-7 5.2 SYSTEM SET UP ............................................................................................ A-7 5.3 POWER SAVING ............................................................................................. A-7 6. SPECIFICATION SUMMARY ................................................................................ A-8 6.1 PERFORMANCE ............................................................................................. A-8 6.2 ERROR RATES ............................................................................................... A-8 6.3 GENERAL PERFORMANCE ........................................................................... A-8 6.4 ENVIRONMENTAL CONDITIONS ................................................................... A-8 6.5 PICK UP LASER .............................................................................................. A-8 7. BEFORE REQUESTING SERVICE ....................................................................... A-9 7.1 TROUBLESHOOTING ..................................................................................... A-9 APPENDIX ............................................................................................................... A-10 SUPERDISK USB DRIVE UNIT LKM-RMB33 INSTRUCTION MANUAL Please read through these instructions before operating the unit. Interface : USB BUSY iv IMPORTANT SAFETY NOTICE NOTICE (1) You may not reproduce or transcribe any part of this publication without permission. (2) We reserve the right to revise this document at any time without notice. (3) If you have any questions about contents of this document, contact your sales representative. SAFETY NOTICE (1) To prevent fire or electric shock, do not expose this drive unit to rain or moisture. (2) To avoid electric shock or damage to the eyes due to laser beam, do not attempt to disassemble the cabinet. FEDERAL COMMUNICATIONS COMMISSION (FCC) RADIO FREQUENCY INTERFERENCE STATEMENT Class B Computing Device NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and , if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - - Reorient or relocate the receiving antenna. - - Increase the separation between the equipment and receiver. - - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - - Consult the dealer or an experienced radio/TV technician for help. FCC WARNING : Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION : Use shielded connecting cables in order to meet FCC emission limits and also to prevent interference to nearby radio and television reception. For USA This equipment is certified to conform to EN60950, EN60825. The drive system with AC Adapter and Interface cable must be certified to conform to the relevant regulations. v LASER SAFETY INFORMATION Class 1 LASER Product This equipment is certified to comply with DHHS Rule 21 CFR Chapter 1, Subchapter J in effect as of date of manufacture. Elsewhere, the drive is certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 and CENELEC EN60825 for Class 1 laser products. Class 1 laser products are not considered to be hazardous. To ensure continued product safety, the following precautions should be heeded. Caution : (1) The use of controls or adjustments or procedures other than those specified herein may result in hazardous radiation e…

Text truncated - open the document above for the full version.

AMP HEAD HEAD MR ENCODER LINEAR MOTOR SPDL MOTOR R/W FPC Block LASER DRIVER R/W OPT COMBO R/W COMBO MOTOR DRIVE LPF MOTOR DRIVER OPT FPC Block ENCODE DECODE ECC, EDC SEQUENCER IDE/BUF CONTROL Flash EEPROM Mask ROM RAM CPU ADC SERVO PROCESSING SYSTEM CLOCK : 32MHz CLOCK : 6.4MHz CPU/ASIC IDE BUS USB SLIM Ver3 BLOCK DIAGRAM DRIVER 1K EEPROM LDHU + AMP EJECT MOTOR ASIC USB - ATAPI CONVERTER ATAPI CHIP IC CPU CPU ROM RAM USB CONTROL 256K SRAM BUFFER SUPER DISK DRIIVE BLOCK USB INTERFACE BLOCK LKM-RMB33 USB BUS IC3 IC1 IC14 IC301 IC401 IC201 : SIGNAL LINE : CLOCK LINE CLOCK : 24MHz CLOCK : 24MHz MKE CONFIDENTIAL

MATSUSHITA-KOTOBUKI ELECTRONICS INDUSTRIES LTD. MATSUYAMA DIVISION 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan PHONE +81 89 966 2111 FAX +81 89 966 2123 Date : May 19, 1999 Federal Communications Commission Office of Engineering and Technology Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern : We, the undersigned, hereby authorize Akzo Kashima Limited to act on our behalf in all matters relating to applications for the equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by Akzo Kashima Limited on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefit, pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C.853(a). This authorization expires one year from the current date. Sincerely, Matsushita-Kotobuki Electronics Industries, Ltd. Matsuyama Division K. Matsugi Engineer Legal Affairs Sec.

MATSUSHITA-KOTOBUKI ELECTRONICS INDUSTRIES LTD. MATSUYAMA DIVISION 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan PHONE +81 89 966 2111 FAX +81 89 966 2123 Page 1 of 18 pages TEST REPORT REPORT NUMBER: MKM99F-001 APPLICANT: Matsushita-Kotobuki Electronics Industries, Ltd. MODEL NUMBER:LKM-RMB33 FCC ID:IUO9TB078LSS Regulation:FCC Part15B Class B Conducted Emission Test Radiated Emission Test Matsushita-Kotobuki Electronics Ind., Ltd. Matsuyama Division 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan Tel.: +81 89 966 2111 Fax.: +81 89 966 5733 Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 2 of 18 pages TABLE OF CONTENTS Page SECTION1.TEST CERTIFICATION3 SECTION2.EQUIPMENT UNDER TEST5 SECTION3.SUPPORT EQUIPMENT USED6 SECTION4.CABLE(S) USED 7 SECTION5.CONSTRUCTION OF EQUIPMENT 8 SECTION6.OPERATING CONDITIONS9 SECTION7.TEST PROCEDURE(S)10 SECTION8.EVALUATION OF TEST RESULTS11 SECTION9.PHOTOGRAPHS OF TEST SET-UP15 SECTION10.INSTRUMENTS USED FOR TEST17 SECTION11.PRECISION18 SECTION12.VALIDITY OF TEST REPORT18 Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 3 of 18 pages SECTION 1. TEST CERTIFICATION APPLICANT INFORMATION Company: Matsushita-Kotobuki Electronics Industries, Ltd. Address: 8-1, Furujin-machi, Takamatsu-city, Kagawa-ken, 760-0025 Japan GRANTEE INFORMATION Company: Matsushita-Kotobuki Electronics Industries, Ltd. Division / Section: Matsuyama Division Legal Affairs Sec. Address: 2131-1 Minamikata, Kawauchi-cho, Onsen-gun, Ehime-ken, 791-0395 Japan Telephone number: +81 89 966 2111 Fax number: +81 89 966 5733 Contact person: Kenji Matsugi DESCRIPTION OF TEST ITEM Kind of equipment: Super Disk Drive Trademark: Matsushita-Kotobuki FCC ID:IUO9TB078LSS Model number: LKM-RMB33 Serial number: BA950600M00001 Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 4 of 18 pages TEST PERFORMED FCC File No.: 31040/SIT Test started: May 6, 1999 Test completed: May 6, 1999 Purpose of test: FCC Docket 87-389 Regulation: FCC Part 15B Class B Unintentional Radiators Test setup: ANSI C63.4 -1992 Report file number: MKM99F-001 Report issue date: May 17, 1999 Test engineer: Shinji Yamauchi Report approved by: Shigeru Suzuki [ Manager ] This equipment complies with above standard or regulation under the test condition or test configuration shown on this test report. Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 5 of 18 pages SECTION 2. EQUIPMENT UNDER TEST The equipment under test (EUT) consists of the following equipment. Indication in the following left side column corresponds to section 5. SymbolItemModel No. Serial No. FCC IDManufacturer A)Super DiskLKM-RMB33BA950600M00001IUO9TB078LSSMatsushita-Kotobuki DriveElectronics Ind., Ltd. Power ratings of EUT : +5V DC, 1.2A 2.1 Port(s) / Connector(s) : USB Connector(4pin), DC IN Connector(2pin) 2.2 Oscillator(s) / Crystal(s) : OscillatorOperatingBoard nameRemarks Frequency 24.0MHz24.0MHzI/F PCBCPU, M37640 6.4 MHz32.0MHzMain PCBASIC, UPD90F49 Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 6 of 18 pages SECTION 3. SUPPORT EQUIPMENT USED The EUT has been supported by the following equipment during these tests. Indication in the following left side column corresponds to section 5. SymbolItemModel No.Serial No.FCC IDManufacturer B)Host ComputerThink Pad 60097-9244VDeclaration of IBM Type 2645Conformity C)Printer3630A3040A00351BSD8533630AHEWLETT PACKARD Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 7 of 18 pages SECTION 4. CABLE(S) USED The following cable(s) was used for testing. Indication number in the following left side column corresponds to section 5. NumberNameLengthShieldFromTo 1)USB Interface cable1.1 mYesSuper Disk DriveHost Computer Plastic connector 2)DC Power cable2.0 mNoneSuper Disk DriveAC Adapter Plastic connector 3)Parallel I/F cable1.5 mYesHost ComputerPrinter Metal connector 4)Power cord for Printer2.0 mNonePrinterAC Adapter 5)Power cord for Printer2.0 mNoneAC AdapterPower Source 6)Power cord for1.8 mNoneHost ComputerAC Adapter Host Computer 7)Power cord for1.0 mNoneAC AdapterPower Source Host Computer None : All cables are not attached ferrite core. Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 8 of 18 pages SECTION 5. CONSTRUCTION OF EQUIPMENT The construction of EUT during testing is as follows. System configuration : EUT 3 2 1 6 4 A) C) Printer Super Disk B) Host Computer Drive 16V DC 3.36A AC Adapter 20V AC 60Hz AC Adapter 7 5 5V DC 1.2A AC Adapter 120V AC 120V AC120V AC 60Hz 60Hz60Hz Symbol or numbers assigned to equipment or cables on this diagram are corresponded to the symbols or numbers assigned to equipment or cables on tables in Sections 2 to 4. Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 9 of 18 pages SECTION 6. OPERATING CONDITIONS The EUT has been operated under the following conditions during the tests. 6.1 Operating condition The tests have been carried out under Write/Read mode. 6.2 Operation flow[ Write/Read mode ] Performed following operations continuously. 1. The Computer sends write command to EUT. 2. The Computer sends ‘H’ characters data to EUT. 3. The EUT writes ‘H’ characters’ data. 4. The EUT sends the status and message to Computer. 5. The Display displays ‘H’ characters’ data. 6. The Printer prints ‘H’ characters’ data. 7. The Computer sends read command to EUT. 8. The EUT reads the data and sends it to Computer. 9. The EUT sends the status and message to Computer. 10. The Display displays ‘H’ characters’ data. 11. The Printer prints ‘H’ characters’ data. Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 10 of 18 pages SECTION 7. TEST PROCEDURE(S) Tests have been carried out with the test procedure(s) drawn up by our laboratory which is in accordance with the following test procedure(s). Test itemTest procedure usedScanned Frequency Range Conducted Emission ANSI C63.4-19920.45 - 30 MHz Radiated EmissionANSI C63.4-199230 - 1000 MHz Report No. MKM99F-001 FCC ID : IUO9TB078LSS Page 11 of 18 pages SECTION 8. EVALUATION OF TEST RESULTS 8.1 Conducted Emission Test…
